QV7-GC88752-38JETPOD REVOLT

GUANGDONG SYMA MODEL AIRCRAFT INDUSTRIAL CO., LTD

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Sep 14, 2020
Application Purpose: Original Equipment
Date of Application: Sep 14, 2020
Equipment Note: JETPOD REVOLT
Frequency Range: 2409.00000000 - 2475.00000000
Company: GUANGDONG SYMA MODEL AIRCRAFT INDUSTRIAL CO., LTD
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

RED RF frequency band: 2409-2475MHz Transmitter power: 6.247dBm (Max.) Sold to EU country Product name: [JET POD] Model number: [TF1002] Brand name: SYMA Contact person: Ivan Tel:+86-0754-86381701 Hereby, [GUANGDONG SYMA MODEL AIRCRAFT INDUSTRIAL CO., LTD], declares that this [JET POD ] is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. The full test of the EU declaration of conformity is available at the following internet address: www.symatoys.com SIMPLIFIED EU DECLARATION OF CONFORMITY

Cover Letter(s)

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 6.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (obsolete) 4.0 5.0 Sep-16-2014 Updated company name & logo (current) 5.0 6.0 Jun-27-2018 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 6.0 GUANGDONG SYMA MODEL AIRCRAFT INDUSTRIAL CO., LTD 2020.8.31 To: BVCPS, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, _____ GUANGDONG SYMA MODEL AIRCRAFT INDUSTRIAL CO., LTD ____ hereby authorize Bureau Veritas Consumer Product Services, Inc. to act as a Certification Body for certifying for the following project(s): FCC ID: QV7-GC88752-38 Product Description: JETPOD REVOLT Model: TF1002，S5H,S107H, X21W, X22W, X22SW, X23W,X5SW Sincerely, Client’s signature Client’s name:Ivan Chen Title : Sale Director Contact information / address : NO.2 West Xingye Road, Laimei Industrial Area Chenghai, Shantou, Guangdong, China.

Cover Letter(s)

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 6.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (obsolete) 4.0 5.0 Nov-19-2015 Updated company logo (current) 5.0 6.0 Jun-26-2019 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 6.0 GUANGDONG SYMA MODEL AIRCRAFT INDUSTRIAL CO., LTD 2020.9.1 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: QV7-GC88752-38 Pursuant to sections 0.457 and 0.459 of CFR 47, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application as: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name:Ivan Chen Title : Sale Director Contact information / address : NO.2 West Xingye Road, Laimei Industrial Area Chenghai, Shantou, Guangdong, China.

Cover Letter(s)

GUANGDONG SYMA MODEL AIRCRAFT INDUSTRIAL CO., LTD Declaration of Identical Product Hereby, Name of manufacturer: GUANGDONG SYMA MODEL AIRCRAFT INDUSTRIAL CO., LTD Address: NO.2 West Xingye Road Laimei Industrial Area Chenghai Shantou Guangdong China City: Shantou Country: china declares that: Product description: JETPOD REVOLT Type designation(s): S5H,S107H, X21W, X22W, X22SW, X23W,X5SW Trademark: SYMA Family name is technically identical to: Product description: JETPOD REVOLT Type designation: TF1002 Trademark: SYMA Certificate number (if applicable) They are identical with the test model TF1002 except the color of the appearance and model name for trading purpose. Date: 2020.8.31 City: Shantou Name: Ivan chen Signature

External Photos

ID Label/Location Info

Label and Location Model：TF1002 FCC ID：QV7-GC88752-38 Label size :80mm*80mm The label stamped to the equipment by permanent adhesive This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
