QVHDBWIFIBLE05802.11 abgn + BLE 5.0 module

1 / 25 □ Normal □ Internal Use  Confidential □ Restricted Confidential DBWIFIBLE05 User Manual Project Name: DBWIFIBLE05 Author: Wistron NeWeb Corporation Revision: 0.2 Revision Date: 2022/06/13 2 / 25 □ Normal □ Internal Use  Confidential □ Restricted Confidential DBWIFIBLE05 User Manual Revision History REV Author Summary Changes Date 0.1 Jim Chuang SGA(ES1) Draft Product Spec 2021/12/08 0.2 Jim Chuang SGB(ES2) Draft Product Spec 2022/06/13 3 / 25 □ Normal □ Internal Use  Confidential □ Restricted Confidential DBWIFIBLE05 User Manual © Wistron NeWeb Corporation THIS DOCUMENT AND THE INFORMATION CONTAINED HEREIN IS PROPRIETARY AND IS THE EXCLUSIVE PROPERTY OF WNC AND SHALL NOT BE DISTRIBUTED, REPRODUCED, OR DISCLOSED IN WHOLE OR IN PART WITHOUT PRIOR WRITTEN PERMISSION FROM WNC. LIMITATION OF LIABILITY THIS DOCUMENT AND THE INFORMATION CONTAINED HEREIN IS PURELY FOR DESIGN REFERENCE AND SUBJECT TO REVISION BY WNC AT ANY TIME. NOTHING IN THIS DOCUMENT SHALL BE CONSTRUED AS GRANTING ANY WARRANTY OR RIGHT TO USE THE MATERIAL CONTAINED HEREIN WITHOUT WNC’S PRIOR EXPRESS WRITTEN CONSENT. WNC SHALL NOT BE LIABLE FOR ANY USE, APPLICATION OR DEVELOPMENT DERIVED FROM THE MATERIAL WITHOUT SUCH PRIOR EXPRESS WRITTEN CONSENT. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Country Code selection feature to be disabled for products marketed to the US/CANADA 4 / 25 □ Normal □ Internal Use  Confidential □ Restricted Confidential DBWIFIBLE05 User Manual Integration instructions for host product manufacturers Applicable FCC rules to module FCC Part 15.247 Summarize the specific operational use conditions The module is must be installed in mobile device. This device is intended only for OEM integrators under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and 2) The transmitter module may not be co-located with any other transmitter or antenna 3) For all products market in US, OEM has to limit the operation channels in CH1 to CH11 for 2.4G band by supplied firmware programming tool. OEM shall not supply any tool or info to the end-user regarding to Regulatory Domain change. As long as 3 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed. IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warning as show in this manual. Limited module procedures Not applicable Trace antenna designs Not applicable RF exposure considerations 20 cm separation distance and co-located issue shall be met as mentioned in “Summarize the specific operational use conditions”. Product manufacturer shall provide below text in end-product manual “This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.” Antennas Brand name Model name Antenna type Antenna gain Antenna connector Dyson ANT2_1370X950 PIFA 2400~2483.5MHz: 2.12dBi 5150~5250MHz: 2.59dBi 5250~5350MHz: 2.62dBi 5470~5725MHz: 2.79dBi 5725~5850MHz: 3.44dBi No Changing the antenna type, gain, including the trace design while installing the host may requires to be recertified via FCC class change procedure 5 / 25 □ Normal □ Internal Use  Confidential □ Restricted Confidential DBWIFIBLE05 User Manual Label…

Text truncated - open the document above for the full version.

www.dyson.com Dyson Technology Limited REG. IN ENGLAND NO. 01959090 REG. OFFICE: TETBURY HILL, MALMESBURY, WILTSHIRE, SN16 0RP Date: 05-23-2023 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Ref: Attestation Statements Part 2.911(d)(5)(i) and Part 2.911(d)(5)(ii) Filing Re. KDB 986446 D01 FCC ID: QVHDBWIFIBLE05 Dear Sir or Madam, Dyson Technology Ltd (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. If you have any questions, please contact us. Sincerely, Contact name: Mike Partridge Company name: Dyson Technology Ltd Address: Tetbury Hill, Malmesbury, SN16 0RP E-mail: [email protected] Tel: +(44)1666 836097

www.dyson.com REGISTERED IN ENGLAND NO. 01959090 1/1REGISTERED OFFICE ADDRESS: TETBURY HILL, MALMESBURY, WILTSHIRE, SN16 0RP To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 05-23-2023 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: QVHDBWIFIBLE Dyson Technology Limited, the applicant certifies that, as of the date of the filing of the application, Andrew Wingerter is our designated U.S. agent for service of process for the above referenced FCC ID. Dyson Technology Limited accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Dyson Inc accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: Dyson Inc 1330 W Fulton St 5 th Floor, Chicago IL 60137 Contact Person: Andrew Wingerter 312-846-7792 Email: [email protected] Sincerely, Dyson Inc Dyson Technology Limited Andrew Wingerter Michael Partridge

www.dyson.com Dyson Technology Limited REG. IN ENGLAND NO. 01959090 REG. OFFICE: TETBURY HILL, MALMESBURY, WILTSHIRE, SN16 0RP Date: 2022/9/13 Federal Communications Commission 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Product Certification Representative Authorization Letter FCC ID: QVHDBWIFIBLE05 Product name: 802.11 abgn + BLE 5.0 module To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization of model DBWIFIBLE05 to the FCC Rules and Regulations. International Certification Corp. Address : No.3-1, Lane 6, Wen San 3rd St. Kwei Shan Dist., TaoYuan City 333, Taiwan (R.O.C.) Name : Gary Chang Job Title : Manager e-mail : [email protected] Webs We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 862. Applicant : Dyson Technology Ltd Address : Tetbury Hill Malmesbury Wiltshire SN16 0RP United Kingdom Signature : _________________________________ Name and Job Title. : Mike Partridge, Associate Principal Radio Approvals Engineer E-mail : [email protected] Tel. : 0044-(0)1666-836097

www.dyson.com Dyson Technology Limited REG. IN ENGLAND NO. 01959090 REG. OFFICE: TETBURY HILL, MALMESBURY, WILTSHIRE, SN16 0RP Confidentiality Request Letter Date: 2022/9/20 Federal Communications Commission Authorization and Evaluation Division FCC ID：QVHDBWIFIBLE05 Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: 1. Block Diagram 2. Circuit Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Applicant’s company name : Dyson Technology Ltd Applicant’s company address : Tetbury Hill Malmesbury Wiltshire SN16 0RP United Kingdom Signature : Job Title and Dept. : Mike Partridge Associate Principal Radio Approvals Engineer E-mail : [email protected] Tel. : 0044-(0)1666-836097

www.dyson.com Dyson Technology Limited REG. IN ENGLAND NO. 01959090 REG. OFFICE: TETBURY HILL, MALMESBURY, WILTSHIRE, SN16 0RP Date: September 13, 2022 Subject: Ad Hoc Mode Function Declaration FCC ID: QVHDBWIFIBLE05 IC: 7986A-DBWIFIBLE05 To Whom it may concern, We, Dyson Technology Ltd declare that the device does not support any non-US channels, country code selection and Channel 12 and 13 in 2.4 GHz band in all the operational mode(s). Also, the client software and associated drivers will not initiate any transmission on DFS frequencies without initiation by a master and the device without support DFS detection capability. This includes restriction on transmissions for beacons and support for ad-hoc peer-to-peer modes. Regards, Applicant : Dyson Technology Ltd Address : Tetbury Hill Malmesbury Wiltshire SN16 0RP United Kingdom Signature : _________________________________ Name and Job Title. : Mike Partridge Associate Principal Radio Approvals Engineer E-mail [email protected] Tel. 0044-(0)1666-836097

www.dyson.com Dyson Technology Limited REG. IN ENGLAND NO. 01959090 REG. OFFICE: TETBURY HILL, MALMESBURY, WILTSHIRE, SN16 0RP Date : September 13, 2022 UNII Declaration Letter Frequency Plan & Channel Scan Type We have declared below featured for FCC equipment authorization, Device FCC ID: QVHDBWIFIBLE05 (1) DFS Device -- Client with Radar detection capability , Client without radar detection capability (2) Active / Passive Scanning , Ad hoc mode access point capability Frequency Band (MHz) Active Scanning (the device can transmit a probe (beacon)) Passive Scanning (where the device is can listen only with no probes) Ad Hoc Mode capability Access point capability 5150 – 5250 Yes , No Yes , No Yes , No Yes , No 5250 – 5350 Yes , No Yes , No Yes , No Yes , No 5470 – 5725 Yes , No Yes , No Yes , No Yes , No 5725 – 5850 Yes , No Yes , No Yes , No Yes , No (3) Country code selection ability - Yes, No If no, pls explain how was implemented: (4) Meet 15.202 requirement - Yes , No , pls check below : A client device is defined as a device operating in a mode in which the transmissions of the device are under control of the master. A device in client mode is not able to initiate a network. (5) For client devices that have software configuration control to operate in different modes (active scanning in some and passive scanning in others) in different bands (devices with multiple equipment classes or those that operate on non- DFS frequencies) or modular devices which configure the modes of operations through software, the application must provide software and operations description on how the software and / or hardware is implemented to ensure that proper operations modes can not be modified by end user or an installer. Apply , No Apply , (If apply, pls help to provide explanation on how it was implement (By hardware or software , and how software was controlled) On DFS channels, the WLAN driver on the device operates under the control of an AP at all times, except when in ad-hoc mode, on US non-DFS channels. As described in the answer to question (2), the device passively scans DFS frequencies until a master device is detected. The control of this functionality is not accessible to anyone under any conditions. Furthermore, the firmware is locked by proprietary password and cannot be changed or modified by end user. Applicant : Dyson Technology Ltd Address : Tetbury Hill Malmesbury Wiltshire SN16 0RP United Kingdom Signature : Name and Job Title. : Mike Partridge, Associate Principal Radio Approvals Engineer E-mail : [email protected] Tel. : 0044-(0)1666-836097

RF_734_05 FCC Modular Approval Request Page 1 of 3 28-12-2022 Modular Approval Request FCC (KDB 996369 D01 & Part 15.212) FCC ID: QVHDBWIFIBLE05 Items to be covered by Single modular transmitters. Answer from applicant 1. The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly. The modular has a shielding Case. Please refer to EUT Photo. 2. The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal. Modulation/buffering for data inputs is embedded within the MT7931AN Mediatek chip set 3. The module must contain power supply regulation on the module Power supply regulation is embedded within the MT7931AN Mediatek chip set 4. The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per §§ 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b). Antenna is permanently attached. And no external amplifier will be used with this modular 5. The module must demonstrate compliance in a stand-alone configuration. This modular is tested under stand-alone configuration. Please refer to Test setup photo. 6. The module must be labelled with its permanently affixed FCC ID label, or use an electronic display (see KDB Publication 784748). The modular transmitter is labelled with its own FCC ID number. Please refer to label sample and label location. 7. The module must comply with all specific rules applicable to the transmitter, including all the conditions provided in the integration instructions by the grantee. The module complies with this requirement. Please refer to user manual. 8. The module must comply with RF exposure requirements. The device complies with this requirement. Please refer to RF exposure report. Items to be covered by Split modular transmitters. Answer from applicant 1. The modular transmitter must comply with all requirements of a single modular transmitter except for items (1) & (5) of the above single modular approval requirements. N/A 2. Only the radio front end must be shielded. The physical crystal and tuning capacitors may be located external to the shielded radio elements. The interface between the split sections of the modular system must be digital with a minimum signalling amplitude of 150 mV peak-to-peak. N/A 3. Control information and other data may be exchanged between the transmitter control elements and radio front end. N/A 4. The sections of a split modular transmitter must be tested installed in a host device(s) similar to that which is representative of the platform(s) intended for use. N/A 5. Manufacturers must ensure that only transmitter control elements and radio front end components that have been approved together are capable of N/A RF_734_05 FCC Modular Approval Request Page 2 of 3 28-12-2022 operating together. The transmitter module must not operate unless it has verified that the installed transmitter control elements and radio front end have been authorized together. Manufacturers may use means including, but not limited to, coding in hardware and electronic signatures in software to meet these requirements, and must describe the methods in their application for equipment authorization. Note: A limited modular approval (LMA) may be granted for single or split modular transmitters that comply partially with the requirements above. Name and surname of applicant (or authorized representative): Mike Partridge Date: _24 May 2023________ Signature: Revision Record Sheet: Revision Section number Page number Date Remark(s) issued by 5 1 28-12-2022 History sheet added WJJ Issued/modified by : Willem Jan Jong Function : Team Lead Revision : 5 Date : 28-12-2022 Verified by : Axel Gase Function : Quality Manager Date : 28-12-2022 Released by : Axel Gase Function : Manager Quality Assurance Date of release: : 28-12-2022

Project No.: EP253002 Page No. : 1 of 5 Photographs of EUT Project No.: EP253002 Page No. : 2 of 5 Project No.: EP253002 Page No. : 3 of 5

ANEW RELEASE EDWARD SU WNC CONFIDENTIAL 4L.DHSAD.002 A 2 SANDY CHEN SANDY CHEN EDWARD SU 01/03/19 01/03/19 01/03/19 01/03/19 1/1 1 OF 1 REEL DIRECTION 26.5 17.5 C2 //Model: DBWIFIBLE05 FCC ID : QVHDBWIFIBLE05 IC : 7986A-DBWIFIBLE05 MACID : XXXXXXXXXXX1 BLEID : XXXXXXXXXXX2 CMIIT : XXXXXXXXXX CCAXXXXXXXXXX 5.0GH (W52,W53): Indoor Use Only DYSON TECHNOLOGY LIMITED R-C-dtl-DBWIFIBLE05 MM/YY 제조 년월일 NOTE: 1. MATERIAL: ART PAPER , T=0.072 2. ADHESIVE: , 0.020±0.003 3. COLOR: a. (WHITE) 4. TEMPERATURE RESISTANT=-5~60 5. ROLLED/ 3.0±0.3, 1.5±0.3 mm WHITE LABEL,26.5X17.5,C2,ART PAPER,DHSA-DS1 020-XXXXXX FCC ID: QVHDBWIFIBLE05 IC: 7986A-DBWIFIBLE05

Project No.: EP253002 Page No. : 4 of 5 Project No.: EP253002 Page No. : 5 of 5

Report No.: FA253002 Page : 1 of 6 Report Version: Rev. 01 FCC RF Exposure Exemption Report FCC ID : QVHDBWIFIBLE05 Equipment : 802.11 abgn + BLE 5.0 module Model No. : DBWIFIBLE05 Brand Name : Dyson Applicant : Dyson Technology Ltd Address : Tetbury Hill Malmesbury Wiltshire SN16 0RP United Kingdom Standard : 47 CFR FCC Part 2.1091 Received Date : May 30, 2022 Tested Date : Jun. 08 ~ Jun. 15, 2022 We, International Certification Corporation, would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It shall not be reproduced except in full without the written approval of our laboratory. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FA253002 Page : 2 of 6 Report Version: Rev. 01 Table of Contents 1 RF EXPOSURE TEST EXEMPTIONS ................................................................................................... 4 1.1 1-mW TEST EXEMPTION ..................................................................................................................... 4 1.2 SAR-BASED EXEMPTION .................................................................................................................... 4 1.3 MPE-BASED EXEMPTION .................................................................................................................... 4 1.4 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE ................................... 5 1.5 MEASUREMENT UNCERTAINTY ......................................................................................................... 5 1.6 EXEMPTION CALCULATION ................................................................................................................ 5 2 TEST LABORATORY INFORMATION ................................................................................................. 6 Report No.: FA253002 Page : 3 of 6 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FA253002 Rev. 01 Initial issue May. 05, 2023 Report No.: FA253002 Page : 4 of 6 Report Version: Rev. 01 1 RF Exposure Test Exemptions 1.1 1-mW TEST EXEMPTION Available maximum time-averaged power is no more than 1 mW. 1.2 SAR-BASED EXEMPTION This exemption is applicable to the frequency range between 300 MHz and 6 GHz, with test separation distances between 0.5 cm and 40 cm, and for all RF sources in fixed, mobile, and portable device exposure conditions. The maximum time-averaged power or effective radiated power (ERP), whichever is greater, ≤ Pth Pth (mW) = ERP 20cm (d/20) x d≤20cm Pth (mW) = ERP 20cm 20 cm < d ≤40cm Where = - log 10 Pth (mW) = ERP 20cm (mW) = 2040f 0.3GHz ≤ f < 1.5 GHz Pth (mW) = ERP 20cm (mW) = 3060 1.5GHz ≤ f < 6 GHz Frequency (MHz) Power Thresholds mW dBm 663 1353 31.31 699 1426 31.54 704 1436 31.57 777 1585 32.00 824 1681 32.26 902 1840 32.65 1500 ~ 6000 3060 34.86 1.3 MPE-BASED EXEMPTION For a much wider frequency range, from 300 kHz to 100 GHz, applicable for separation distances greater or equal to λ/2π, where λ is the free-space operating wavelength in meters. Radio Source Frequency Minimum Distance Threshold ERP F L MHz F H MHz λ L / 2π λ H / 2π W 0.3 - 1.34 159 m - 35.6 m 1920 R 2 1.34 - 30 35.6 m - 1.6 m 3450 R 2 /f 2 30 - 300 1.6 m - 159 mm 3.83 R 2 300 - 1500 159 mm - 31.8 mm 0.0128 R 2 f 1500 - 100000 31.8 mm - 0.5 mm 19.2 R 2 Note: R is the antenna-person separation distance. Report No.: FA253002 Page : 5 of 6 Report Version: Rev. 01 1.4 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE None 1.5 MEASUREMENT UNCERTAINTY The measurement uncertainties given below are based on a 95% confidence level (based on a coverage factor (k=2)). Parameters Uncertainty Conducted power ±0.808 dB Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. 1.6 EXEMPTION CALCULATION Frequency Range (MHz) Maximum Conducted Power (dBm) Rated Power (dBm) Antenna Gain (dBi) EIRP (dBm) ERP (dBm) SAR-Based Exemption Thresholds (dBm) Pass/ Fail 2412~2462 22.47 22.5 2.12 24.62 22.47 34.86 Pass 5180~5240 20.81 21 2.59 23.59 21.44 34.86 Pass 5745~5825 19.75 20 2.62 22.62 20.47 34.86 Pass 5260~5320 21.24 21.5 2.79 24.29 22.14 34.86 Pass 5500~5720 19.02 19.5 3.44 22.94 20.79 34.86 Pass 2402~2480 9.85 10 2.12 12.12 9.97 34.86 Pass Note: Minimum separation distance = 20 cm. Report No.: FA253002 Page : 6 of 6 Report Version: Rev. 01 2 Test laboratory information Established in 2012, ICC provides foremost EMC & RF Testing and advisory consultation services by our skilled engineers and technicians. Our services employ a wide variety of advanced edge test equipment and one of the widest certification extents in the business. International Certification Corporation (EMC and Wireless Communication Laboratory), it is our definitive objective is to institute long term, trust-based associations with our clients. The expectation we set up with our clients is based on outstanding service, practical expertise and devotion to a certified value structure. Our passion is to grant our clients with best EMC / RF services by oriented knowledgeable and accommodating staff. Our Test sites are located at Linkou District and Kwei Shan District. Location map can be found on our website http://www.icertifi.com.tw. Linkou Kwei Shan Kwei Shan Site II Tel: 886-2-2601-1640 Tel: 886-3-271-8666 Tel: 886-3-271-8640 No.30-2, Ding Fwu Tsuen, Lin Kou District, New Taipei City, Taiwan (R.O.C.) No.3-1, Lane 6, Wen San 3rd St., Kwei Shan Dist., Tao Yuan City 33381, Taiwan (R.O.C.) No.2-1, Lane 6, Wen San 3rd St., Kwei Shan Dist., Tao Yua…
