QW7020527 MHZ WIRELESS R/C TOY-TX

I MINI RADIO CONTROL HELICOPTER ,,,.,,I ,sy&mRML4-y -Z~JZ i I I - * Only one 'Decal set contain in each box, please see box for set indication. J b I KEY FEATURES INCLUDED PARTS 3 Digital Speed Control > 2 sets M Maln Rotors > Digital Proportlonab tontrol $ I PC of Tall Rotor 3 90 mah long lasting Battery > Fasting Charging Function * Crush Resistance > With Lights > Easy Triming Function I IMPORTANT NOTES 4.Check the content llst and all parts, 2.Study the instruction manual carefully before use. J.Ensure all required batteries are ready. 4.Follow the Instructions prSnted in manual when using the qulck charger. 5.This product is intended for 8 years old and over. (A~UI~ supervision is required if user is below 8 years old). 6.Do not fly wer or near people, power pylon, buildings, highways, train, rails, vehicles, trees, lake, and airport. FCC NOTE: THE ANTENNA PROVIDED IS A UNIQUE ANTENNA. BY INSTALLATION OF 'UNAUTHORIZED lz ANTENNA TO THIS EQUIPMENT. SUCH UNAUTHORIZED INSTALLATION COULD VOID THE USERIS AUMOR~TY TO OPERATE THE EQUIPMENT. THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO ORTV INTERFERENCE CAUSED - BY UNAUTHORIZED MODlFlCATlONS TOTHIS EQUIPMENT. SUCH MODIFICATIONS COULD YOIDTHE USERiS AUTHORfTY TO OPERATETHE EQUIPMENT. 1 I BATTERY WA'RN-~~G Keep packaging as it contalns important Information. CAUTION: To prevent battery leakage: Be Never sure mix to old insert and batteries new batteries correctly (replace and always all batteries follow at the the product same time). and battery manufacturers Instructions. Never mix Alkaline, standard (Carbon Zinc) or rechargeable (Nickel-Cadmium) batteries. Only batteries of the same or equivalent type as recommended are to be used. Do not use RECHARGEABLE batteries, unless specified. Non-rechargeable batteries are not to be recharged. Rechargeable batteries are to be removed from the product before being charged (if removable). Rechargeable batteries are only to be charged under adult supervision (if removable). Always remove exhausted or dead batteries from the product. Remove batteries from product before extended storage. The supply terminals are not to be short- circuited. Batteries are to be inserted with correct polarity. Batteries may explode or leak if misused. ATTENTION: Battery I Batteries should be installed by adult only. I SPECIAL CAUTIONS FOR LlaPOLY RECHARGEABLE BATTERY: Keep the battery away from water, heat or fire. Charge the banery by the provlded charging plug and transmitter only. Never put any objects into the helicopter charging plug. I PROPER PLACE FOR OPERATION Choose a place free from obstacles. For best performance, it is recommended to operate the helicopter indoor without air-flow caused by electric fan or air-conditioner. Strong light may interfere with the transmitting and receiving system. I 7 WARNING When the helicopter continues to spinning in any one direction, first try to make adjustment by following the "TRIMMING INSTRUCTION", If the situation remains unchanged, then please check the Tail Rotor, and make change if necessary (follow the "TAIL 'PROPELLER REPLACEMENT") Do not operate the helicopter; when any of the rotors is stuck under any circumstances. Forcing any rotor to turn when stuck could damage mechanism of the helicopter. Keep the helicopter within 5 meters126 feet from yourself as it is the maximum control range of your Sky Copter. Remember to witch off the power of the transmitter and helicopter when not in use. 3 t 1 2

&7;IFF UWWHVFK6DW'HF

FCC PART 15.227 TEST REPORT LOW POWER UNLICENSED TRANSMITTER Applicant HOBBYENGINE MODEL INDUSTRIAL LTD. Address ROOM 619, 6/F., PENINSULA CENTRE, 67 MODY ROAD, TSIMSHATSUI EAST KOWLOON HONG KONG FCC ID QW70205 Product Description 27 MHZ WIRELESS R/C TOY-TX Date Sample Received 1/7/2008 Date Tested 1/8/2008 Tested By NAM NGUYEN Approved By MARIO DE ARANZETA Timco Report No. 42UT8TestReport.doc Test Results Pass Fail THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW STATE ROAD 45 NEWBERRY, FL 32669 USA PH: 888.472.2424 OR 352.472.5500 FAX: 352.472.2030 EMAIL: [email protected] HTTP: //WWW.TIMCOENGR.COM Certificate # 0955-01 APPLICANT: HOBBYENGINE MODEL INDUSTRIAL LTD. FCC ID: QW70205 REPORT: X:\H\HOBBYENGINE_QW7\42UT8\42UT8TestReport.doc Page 2 of 10 mdea 09.20.2007 TABLE OF CONTENTS GENERAL REMARKS ....................................................................................................3 REPORT SUMMARY ......................................................................................................4 TEST ENVIRONMENT....................................................................................................4 TEST SETUP .................................................................................................................4 DUT SPECIFICATION ....................................................................................................5 TEST EQUIPMENT LIST ................................................................................................6 TEST PROCEDURES .....................................................................................................7 RADIATION INTERFERENCE .........................................................................................8 OCCUPIED BANDWIDTH...............................................................................................9 RADIATED EMISSIONS TEST SET UP PHOTO ............................................................10 APPLICANT: HOBBYENGINE MODEL INDUSTRIAL LTD. FCC ID: QW70205 REPORT: X:\H\HOBBYENGINE_QW7\42UT8\42UT8TestReport.doc Page 3 of 10 mdea 09.20.2007 GENERAL REMARKS The attached report shall not be reproduced except in full without the written permission of Timco Engineering Inc. The test results only relate to the item tested. Summary The device under test does: fulfill the general approval requirements as identified in this test report not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025 requirements. Testing Certificate # 0955-01 I attest that the necessary measurements were made, under my supervision, at: Timco Engineering Inc. 849 NW State Road 45 Newberry, Fl 32669 Authorized Signatory Name: Mario de Aranzeta C.E.T. Compliance Engineer/ Lab. Supervisor Date: 01/08/2008 APPLICANT: HOBBYENGINE MODEL INDUSTRIAL LTD. FCC ID: QW70205 REPORT: X:\H\HOBBYENGINE_QW7\42UT8\42UT8TestReport.doc Page 4 of 10 mdea 09.20.2007 REPORT SUMMARY Applicable Rule(s) FCC Pt 15.227, ANSI C63.4: 2003 TEST ENVIRONMENT Test Facility The test sites are located at 849 NW State Road 45 Newberry, FL 32669 USA. Test Condition: Temperature: 26ºC Relative humidity: 50% TEST SETUP Test Exercise (e.g software description, test signal, etc.): The DUT was placed in continuous transmit mode of operation. Deviation from the standard(s) No deviation from the standard(s) Modification to the DUT: No modification was made to the DUT. Supporting Peripheral Equipment Not applicable. The device is a stand-alone remote control radio. APPLICANT: HOBBYENGINE MODEL INDUSTRIAL LTD. FCC ID: QW70205 REPORT: X:\H\HOBBYENGINE_QW7\42UT8\42UT8TestReport.doc Page 5 of 10 mdea 09.20.2007 DUT SPECIFICATION Applicant HOBBYENGINE MODEL INDUSTRIAL LTD. Description 27 MHZ WIRELESS R/C TOY-TX FCC ID QW70205 Frequency Range 27.145 MHz 110–120Vac/50– 60Hz DC Power DUT Power Source Battery Operated Exclusively Test Item Prototype Pre-Production Production Type of Equipment Fixed Mobile Portable APPLICANT: HOBBYENGINE MODEL INDUSTRIAL LTD. FCC ID: QW70205 REPORT: X:\H\HOBBYENGINE_QW7\42UT8\42UT8TestReport.doc Page 6 of 10 mdea 09.20.2007 TEST EQUIPMENT LIST Device Manufacturer Model Serial Number Cal/Char Date Due Date 3/10-Meter OATS TEI N/A N/A Listed 3/20/07 3/19/10 3-Meter OATS TEI N/A N/A Listed 1/11/06 1/10/09 3-Meter Semi- Anechoic Chamber Panashield N/A N/A Listed 5/11/07 5/10/10 Antenna: Biconnical Eaton 94455-1 1096 CAL 10/11/06 10/11/08 Antenna: Biconnical Electro- Metrics BIA-25 1171 CAL 7/18/07 7/18/09 Analyzer Blue Tower Quasi-Peak Adapter HP 85650A 2811A01279 CAL 5/17/07 5/17/09 Analyzer Blue Tower RF Preselector HP 85685A 2926A00983 CAL 5/17/07 5/17/09 Analyzer Blue Tower Spectrum Analyzer HP 8568B 2928A04729 2848A18049 CAL 5/17/07 5/17/09 LISN Electro- Metrics ANS-25/2 2604 CAL 10/5/06 10/5/08 LISN Electro- Metrics EM-7820 2682 CAL 7/23/07 7/23/09 Antenna: Log- Periodic Eaton 96005 1243 CAL 12/14/07 12/14/09 APPLICANT: HOBBYENGINE MODEL INDUSTRIAL LTD. FCC ID: QW70205 REPORT: X:\H\HOBBYENGINE_QW7\42UT8\42UT8TestReport.doc Page 7 of 10 mdea 09.20.2007 TEST PROCEDURES Radiated Spurious Emissions: The test procedure used was ANSI C63.4-2003 using a spectrum analyzer with a preselector. The bandwidth of the spectrum analyzer was 100 kHz with an appropriate sweep speed. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The resolution bandwidth was 100 kHz and the video bandwidth was always greater than the RBW. Occupied Bandwidth: A small sample of the transmitter output was fed into the spectrum analyzer and…
