Fuzhou Smart Digital Science & Technology Co., Ltd. No.8 Building, Honshan science & Technology Zone, Gulou District, Fuzhou, Fujian, China Date:2012-12-04 FCC ID: QWK755RW-TBD753B Subject: Ad Hoc Mode Function Declaration To Whom it may concern, This device is acting as slave and operating in the 2.4 GHz (2412 – 2462 MHz) band. Ad Hoc function is supported but not able to operate on non-US frequencies. Please contact the one signed below or the authorized agent for this filing. Thank you. Regards, Yours sincerely, Signatory Signature Name: Lin Lei Title: sales Tel: +86-755-86672202858

Date:2012-12-06 FCC ID: QWK755RW-TBD753B Subject: Attestation Letter “Declaration of Conformity” Dear Sirs, Our products with the above FCC ID are defined as composite device. The transmitter is authorized under the “Certification” procedure. The device is also defined as “PC Periphery” acc to §15.101 Equipment authorization of unintentional radiators, where we hereby declare, that we apply and follow the “Declaration of Conformity” procedure. If you have any questions, please feel free to contact me at the address shown below. Regards, Yours sincerely, Signatory Signature Name: Lin Lei Title: sales Tel: +86-755-86672202858

PUTIAN HANJIANG BAILI ELECTRONIC PLASTIC COMPANY LIMITED Tel:0755-86672202 Fax:0755-86655045 Authorization Letter We, (the approval holder) Company name PUTIAN HANJIANG BAILI ELECTRONIC PLASTIC COMPANY LIMITED Addresss NO.689, NONGSHAN ROAD, SHITING TOWN, HANJIANG DISTRICT, City PUTIAN CITY,FUJIAN, Country CHINA declare that the following representative (agent): Name (person) Bovey.yang Company name NTEK Testing Technology Co., Ltd. Addresss 1/F, Building E, Fenda Science Park Sanwei Community, Xixiang Street, Baoan District City Shenzhen Country China to act on our behalf on all matters concerning the application and documents submitted to Timco TEST-LAB for product certification below Product Description Tablet Type or Model(s) TBD753B Tradename or Brand(s) ZEKI Attestation: City and Country: Date:Name: (this must be a person) Function:Signature: (or official company stamp) FUJIAN 2012/12/11 Lin Lei sales

PUTIAN HANJIANG BAILI ELECTRONIC PLASTIC COMPANY LIMITED Tel:0755-86672202 Fax:0755-86655045 FCC Confidentiality Request To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name PUTIAN HANJIANG BAILI ELECTRONIC PLASTIC COMPANY LIMITED Addresss NO.689, NONGSHAN ROAD, SHITING TOWN, HANJIANG DISTRICT, City PUTIAN CITY,FUJIAN Country CHINA request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: QWK 755RW-TBD753B of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) x Operational Description x Block Diagrams x Schematics Diagrams x Turn up produrce Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function:Signature: (or official company stamp) FUJIAN 2012/12/11 Lin Lei sales

PUTIAN HANJIANG BAILI ELECTRONIC PLASTIC COMPANY LIMITED Tel:0755-86672202 Fax:0755-86655045 PUTIAN HANJIANG BAILI ELECTRONIC PLASTIC COMPANY LIMITED Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2012-12-1 3 SUBJECT: FCC App lication for ( FCCID: QWK755RW-TBD753B) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Regards, Signatory Signature Date:2012-12-1 3 Nam e: Lin Lei Title: sales Tel: +86-755-86672202858

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8

TBD753B壳料丝印2012-11-10ODM70-TBD753B-1110-01 120*194 mm 华方国际（中国）发展有限公司 HUAFUN INT.(CHINA)DVPT.CO.LTD TBD753B 备注：面壳黑色TP，丝印颜色为白色， 中框塑胶材质，喷黑色油过七分哑UV， 底壳塑胶材质，喷油白色，过全亮UV，字符丝印颜色PT 430C。 120mm 194mm 13mm FCC ID:QWK755RW-TBD753B

Photo 9 Photo 10 Photo 11 Photo 12 Photo 13 Photo 14 Photo 15 Photo 16 Photo 17 Photo 18

RF EXPOSURE EVALUATION METHOD For RF exposure report, the power limit is 60/f(in GHz) mW， Tx frequency range: 2412~2462MHz For limit 60/f is equal: 60/2.412=24.87mW 60/2.437=24.62 mW 60/2.462=24.37mW Maximum measured transmitter power. EIRP=conducted power + antenna Gain 802.11B frequency range MAX Conducted Power (dBm) Max Antenna Gain (dBi) EIRP (dBm) EIRP (mW) limit(mW) 2412 11.69 1.0 12.43 17.49 24.87 2437 11.66 1.0 11.43 13.89 24.62 2462 11.33 1.0 11.89 15.45 24.37 802.11G frequency range MAX Conducted Power (dBm) Max Antenna Gain (dBi) EIRP (dBm) EIRP (mW) limit(mW) 2412 9.62 1.0 9.97 9.93 24.87 2437 9.84 1.0 9.46 8.83 24.62 2462 9.49 1.0 9.14 8.20 24.37 802.11N frequency range MAX Conducted Power (dBm) Max Antenna Gain (dBi) EIRP (dBm) EIRP (mW) limit(mW) 2412 9.76 1.0 9.87 9.71 24.87 2437 9.54 1.0 9.78 9.51 24.62 2462 9.62 1.0 9.31 8.53 24.37 To Tune Up information max possible output power (PK) ：11±1dbm MAX possible Conducted Power (dBm) Max Antenna Gain (dBi) EIRP (dBm) EIRP (mW) limit(mW) 12 1.0 13 19.95 24.37 Conclusion: No SAR is required.

FCC RADIO TEST REPORT FCC ID:QWK755RW-TBD753B Product： Tablet Trade Name： ZEKI Model Name： TBD753B Serial Model： N/A Report No.： NTEK- 2012NT1126387F Prepared for PUTIAN HANJIANG BAILI ELECTRONIC PLASTIC COMPANY LIMITED NO.689, NONGSHAN ROAD, SHITING TOWN, HANJIANG DISTRICT, PUTIAN CITY, FUJIAN, CHINA Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 72 Report No.: NTEK-2012NT1126387F TEST RESULT CERTIFICATION Applicant’s name ................. : PUTIAN HANJIANG BAILI ELECTRONIC PLASTIC COMPANY LIMITED Address ................................. : NO.689, NONGSHAN ROAD, SHITING TOWN, HANJIANG DISTRICT, PUTIAN CITY, FUJIAN, CHINA Manufacture's Name ............ : PUTIAN HANJIANG BAILI ELECTRONIC PLASTIC (XIE GANG) COMPANY LIMITED Address ................................. : YAO SHAN INDUSTRY AREA, YAO SHAN XIE GANG TOWN, DONG GUAN CITY, GUANG DONG, CHINA Product description Product name ........................... : Tablet Model and/or type reference : TBD753B Serial Model .............................. : N/A Standards ............................. : FCC Part15.247 Test procedure ..............................ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 26 Nov. 2012 ~02 Dec. 2012 Date of Issue ........................................... : 03 Dec. 2012 Test Result ............................................... : Pass Testing Engineer : (Apple Huang) Technical Manager : (Tom Zhang) Authorized Signatory : (Bovey Yang) Page 3 of 72 Report No.: NTEK-2012NT1126387F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 24 4 . POWER SPECTRAL DENSITY TEST 54 4.1 APPLIED PROCEDURES / LIMIT 54 4.1.1 TEST PROCEDURE 54 4.1.2 DEVIATION FROM STANDARD 54 4.1.3 TEST SETUP 54 4.1.4 EUT OPERATION CONDITIONS 54 4.1.5 TEST RESULTS 55 5 . BANDWIDTH TEST 61 5.1 APPLIED PROCEDURES / LIMIT 61 5.1.1 TEST PROCEDURE 61 Page 4 of 72 Report No.: NTEK-2012NT1126387F Table of Contents Page 5.1.2 DEVIATION FROM STANDARD 61 5.1.3 TEST SETUP 61 5.1.4 EUT OPERATION CONDITIONS 61 5.1.5 TEST RESULTS 62 6 . PEAK OUTPUT POWER TEST 68 6.1 APPLIED PROCEDURES / LIMIT 68 6.1.1 TEST PROCEDURE 68 6.1.2 DEVIATION FROM STANDARD 68 6.1.3 TEST SETUP 68 6.1.4 EUT OPERATION CONDITIONS 68 6.1.5 TEST RESULTS 69 7 . ANTENNA REQUIREMENT 70 7.1 STANDARD REQUIREMENT 70 7.2 EUT ANTENNA 70 8 . EUT TEST PHOTO 71 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 72 Report No.: NTEK-2012NT1126387F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 72 Report No.: NTEK-2012NT1126387F 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 72 Report No.: NTEK-2012NT1126387F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Tablet Trade Name ZEKI Model Name TBD753B Serial Model N/A Model Difference N/A Product Description The EUT is a Tablet Operation Frequency: 802.11b/g/n:2412~2462 MHz Modulation Type: CCK/OFDM/DBPSK/DAPSK Bit Rate of Transmitter 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6 Mbps 802.11n:150/144.44/130/117/115.56 /104/86.67/78/52/6.5 Mbps Number Of Channel 802.11b/g/n: 11CH Antenna Designation: Please see Note 3. Output Power(Conducted): 802.11b: 11.69 dBm (Max.) 802.11g: 9.84 dBm (Max.) 802.11n: 9.76 dBm (Max.) Antenna Gain (dBi) 1.0dbi Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT techni…

Text truncated - open the document above for the full version.

Page 71 of 72 Report No.: NTEK-2012NT1126387F 8. EUT TEST PHOTO Radiated Measurement Photos Page 72 of 72 Report No.: NTEK-2012NT1126387F Conducted Measurement Photos
