1 / 30  M750‐767RUsermanual  Announcement Our company is dedicated to improve product quality and providing up-to-date software. Please note that the manual might be changed without prior notice. 2 / 30   1、Basic operations  1.1 Unlock the home screen  Slide to unlock and enter the home screen（ Figure 1.1）               Tap the padlock icon and move it rightward to overlap with the unlocked icon.(Fig 1.2/Fig 1.3) Figure1.1 Figure 1.2 3 / 30 1.2 Home Screen  Once unlocked, the home screen appears, there are five pages to be shown, swipe your finger left and right to switch among the pages. In every page there are screens with 3D effects.(Fig 1.4) 1.3 Main buttons  1.3.1 Main function buttons Return —Tap this button to return to a higher directory. Home—Tap this button to return to the home screen Background programs —Tap to view the programs running in the background Volume- - Tap this to decrease volume Volume+ -- Tap this to increase volume Menu button —This button usually appears on lower left and sometimes on lower right. The exact location depends upon the programs but works to the same effect. Likewise, if the program does not include a menu it will definitely not appear on the screen.  Notification tray—On the upper left of the screen, tap to pop up the application list. Search button: On the upper left of the home screen, tap to bring out Google search box. Input method —this will appear automatically whenever input is required, tap to show all the installed input method and choose the one you prefer.  Figure 1.3 Fig 1.4 4 / 30 1.3.2 Notification bar From right to left: Battery indicator(display battery charged level, while charging, a lightening symbol will appear), 3G symbol, WIFI symbol(while connecting via WIFI), time indicator and other notifying symbols(hide or unhide depending on the programs you run). Tap the notification area, a hidden menu will pop up (Fig 1.5) Tap time digits will bring out the setup shortcut(Fig 1.6): : Tap away to close the pop-up menu.     Fig 1.6 Fig 1.5 5 / 30 1.4 Application and widget screen 1.4.1 Enter application screen Tap Application to enter the application list. The application list displays all the applications installed in this MID. Tap any app icon to start the program. Let ’s say you want to open the files in the local disk, tap “ES file browser” to enter. To play video clips or view photos, tap Gallery(Fig 1.7). When the number of app icons exceed a single screen , the rest will be displayed on the next screen, swipe your finger leftward to switch to the next screen. 1.4.2 Enter widget screen In application screen, tap or swipe your finger to enter the widget screen. Long press on any widget can create shortcut on the desktop, and tap any shortcut to enter the corresponding application(Fig 1.8). Fig 1.7 Fig 1.8 6 / 30 1.5 Create and manage shortcuts  1.5.1 Create app shortcut  In application and widget screen, long press an icon and hold it till the desktop screen appears, and drag to anywhere on the desktop screen and drop it(Fig 1.9). 1.5.2 Create app shortcut  It is easy to create new folders, simply tap and drag the icon to overlap with another icon to form a folder (Fig 1.10)                  Fig 1.9 Fig 1.10 7 / 30 To open the folder, simply tap the folder to expand and show all the app icons(Fig 1.11)                        Tap the place shown “Unnamed folder” to bring out the keyboard, then you can rename it(Fig 1.12) Long press to move the icons (Fig 1.13) Fig 1.11 Fig 1.12 Fig 1.13 8 / 30 1.6 Delete app shortcut on the screen Longpresstheiconthatyouwanttodelete,anXsymbolwillappearonthetopof screen(Fig 1.14)                          Drag the said icon above the X symbol until the icon turns red and release it (Fig 1.15). 1.7 Change wallpaper Fig 1.14 Fig 1.15 9 / 30 There are at least two ways to set the wallpaper 1、A long press on the screen to bring up the menu(Fig 1.16) Tap Wallpaper to choose the wallpaper from the wallpapers list. Tap live wallpaper to choose the live wallpaper from the live wallpapers list. Tap gallery to choose the image from the gallery list. 2. Enter setup—Display—Choose Wallpaper (Fig 1.17) Fig 1.16 Fig 1.17 10 / 30    1.8 Connecting to PC  Using the USB cable to connect this MID to a PC. You can copy files like music, video clips, ebooks, apps etc. Once connected to the PC, the following interface will appear. (Fig 1.18)           Tap the lower right button “Open USB storage device”, you can see two disks, usually the first disk is the local disk, the second is the removable disk, you must insert TF card to open it. When connected to a PC, only the home screen is displayed. Tap USB icon, and tap Developer ’s options to enables USB debugging. Android robot will appear in this case. (Fig 1.19) Fig 1.18 Fig 1.19 11 / 30 Tap Notification bar to pop up the following panel (Fig 1.20), then tap "USB connected" option.  Tap to enter the ES file browser, you can see the files copied from the PC Besides, When TF card is inserted or external USB stick is connected to this tablet via USB hosts, you also view files via “ES File Browser” 2、Settings   The Settings is quite similar to Settings in cell phone or is equivalent to the control panel in Windows system. You can customize the settings according to your personal preference. Tap the notification bar on the lower right of the home screen or the settings icon on the application list to enter the Settings screen.(Fig 2.1) 2.1 Wireless & network Fig 1.20 Fig 2.1 12 / 30 2.1.1 Wi-Fi 1. Turn WIFI on or off: Drag the Wi-Fi switch leftward or rightward to switch on or off the WIFI. While WIFI is on, the WIFI hotspots will be shown (Fig 2.2). Please note that Wi-Fi hot spot, also named SSID(you can also set it up in the router, it is not recommended to work in Chinese interface), the descriptions under the SSID shows encr…

Text truncated - open the document above for the full version.

Date:2013-4-15 FCC ID: QWKM750-767R Subject: Ad Hoc Mode Function Declaration To Whom it may concern, This device is acting as slave and operating in the 2.4 GHz (2412 – 2462 MHz) band. Ad Hoc function is supported but not able to operate on non-US frequencies. Please contact the one signed below or the authorized agent for this filing. Thank you. Regards, Yours sincerely, Signatory Signature Name: Lin Lei Title: sales Tel: +86-755-86672202858

PUTIAN HANJIANG BAILI ELECTRONIC PLASTIC COMPANY LIMITED Tel:0755-86672202 Fax:0755-86655045 PUTIAN HANJIANG BAILI ELECTRONIC PLASTIC COMPANY LIMITED Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: SUBJECT: FCC Application for ( FCCID: QWKM750-767R) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Regards, Signatory Signature Date:2013-4-15 Name: Lin Lei Title: sales Tel: +86-755-86672202858

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 PUTIAN HANJIANG BAILI ELECTRONIC PLASTIC COMPANY LIMITED 2013-4-16 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _____ _ PUTIAN HANJIANG BAILI ELECTRONIC PLASTIC COMPANY LIMITED____hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): ( Tablet,Model: M750-767R, FCC ID:QWKM750-767R) We affirm that between SIEMIC and ___ PUTIAN HANJIANG BAILI ELECTRONIC PLASTIC COMPANY LIMITED ___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Client’s name / title : Lin Lei / sales Contact information / address : No.689 Nongshan Road, Shiting, Hanjiang, District, Putian, China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 PUTIAN HANJIANG BAILI ELECTRONIC PLASTIC COMPANY LIMITED 2013-4-15 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: QWKM750-767R We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name / title : Lin Lei / sales Contact information / address : No.689 Nongshan Road, Shiting, Hanjiang, District, Putian, China

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

4.6*3.5cm label

Photo 9 Photo 10 Photo 11 Photo 12 Photo 13 Photo 14 Photo 15 Photo 16 Photo 17 Photo 18

FCC ID:QWKM750-767R RF EXPOSURE EVALUATION METHOD SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. Maximum measured transmitter power. Maximum Peak Conducted Output Power (dBm) Maximum Conducted Output Power(AV) (dBm) Maximum Conducted Output Power (mW) 12.14 9.52 8.95 11.98 9.42 8.75 11.84 9.22 8.36 Referto44749825D01GeneralRFExposureGuidancev05AppendixA, youseethatfor Maximum Conducted Output Power8.95mW(<10mW),sonoSAR is required.

FCC RADIO TEST REPORT FCC ID:QWKM750-767R Product： Tablet Trade Name： Polaroid Model Name： M750-767R Serial Model： N/A Report No.： NTEK-2013NT0312302F Prepared for PUTIAN HANJIANG BAILI ELECTRONIC PLASTIC COMPANY LIMITED No.689 Nongshan Road, Shiting, Hanjiang, District, Putian, China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 86 Report No.: NTEK-2013NT0312302F TEST RESULT CERTIFICATION Applicant’s name ................. : PUTIAN HANJIANG BAILI ELECTRONIC PLASTIC COMPANY LIMITED Address ................................. : No.689 Nongshan Road, Shiting, Hanjiang, District, Putian, China Manufacture's Name ............ : PUTIAN HANJIANG BAILI ELECTRONIC PLASTIC COMPANY LIMITED Address ................................. : No.689 Nongshan Road, Shiting, Hanjiang, District, Putian, China Product description Product name ........................... : Tablet Model and/or type reference : M750-767R Serial Model .............................. : N/A Standards ............................. : FCC Part15.247 Test procedure ..............................ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 12 Mar. 2013 ~15 Apr. 2013 Date of Issue ........................................... : 15 Apr. 2013 Test Result ............................................... : Pass Testing Engineer : (Apple Huang) Technical Manager : (Tom Zhang) Authorized Signatory : (Bovey Yang) Page 3 of 86 Report No.: NTEK-2013NT0312302F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 24 4 . POWER SPECTRAL DENSITY TEST 64 4.1 APPLIED PROCEDURES / LIMIT 64 4.1.1 TEST PROCEDURE 64 4.1.2 DEVIATION FROM STANDARD 64 4.1.3 TEST SETUP 64 4.1.4 EUT OPERATION CONDITIONS 64 4.1.5 TEST RESULTS 65 5 . BANDWIDTH TEST 73 5.1 APPLIED PROCEDURES / LIMIT 73 5.1.1 TEST PROCEDURE 73 Page 4 of 86 Report No.: NTEK-2013NT0312302F Table of Contents Page 5.1.2 DEVIATION FROM STANDARD 73 5.1.3 TEST SETUP 73 5.1.4 EUT OPERATION CONDITIONS 73 5.1.5 TEST RESULTS 74 6 . PEAK OUTPUT POWER TEST 82 6.1 APPLIED PROCEDURES / LIMIT 82 6.1.1 TEST PROCEDURE 82 6.1.2 DEVIATION FROM STANDARD 82 6.1.3 TEST SETUP 82 6.1.4 EUT OPERATION CONDITIONS 82 6.1.5 TEST RESULTS 83 7 . ANTENNA REQUIREMENT 84 7.1 STANDARD REQUIREMENT 84 7.2 EUT ANTENNA 84 8 . EUT TEST PHOTO 85 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 86 Report No.: NTEK-2013NT0312302F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 86 Report No.: NTEK-2013NT0312302F 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 86 Report No.: NTEK-2013NT0312302F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Tablet Trade Name Polaroid Model Name M750-767R Serial Model N/A Model Difference N/A Product Description The EUT is a Tablet Operation Frequency: 802.11b/g/n20MHz:2412~2462 MHz 802.11n40MHz:2422~2452 Modulation Type: CCK/OFDM/DBPSK/DAPSK Bit Rate of Transmitter 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6 Mbps 802.11n(20MHz/40MHz):150/144.4 4/130/117/115.56/104/86.67/78/52/6 .5 Mbps Number Of Channel 802.11b/g/n20MHz:11CH 802.11n40MHz:7CH Antenna Designation: Please see Note 3. Output Power(Conducted): 802.11b: 12.14 dBm (Max.) 802.11g: 10.72 dBm (Max.) 802.11n(20M) : 9.78dBm (Max.) 802.11n(40M) : 9.76 dBm (Max.) Antenna Gain (dBi) 1.0dbi Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an IT…
