Page 1 SonicWALL Internet Security Appliance Regulatory Statement and Safety Instructions Models APL04-016, APL04-017,1RK05-015, 1RK07-025, and 1RK08-026 are FCC Class A devices (for office use only), and the following statement is applicable to these models*: FCC Part 15 Class A Notice NOTE: This equipment was tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy. And if not installed and used in accordance with the instruction manual, the device may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user is required to correct the interference at his own expense. Complies with EN 55022 Class A and CISPR22 Class A. *Refer to the label on the bottom of the unit for device information including Class A or Class B FCC information. Caution: Modifying this equipment or using this equipment for purposes not shown in this manual without the written consent of SonicWALL, Inc. could void the user’s authority to operate this equipment. Regulatory Model/TypeProduct Name APL11-027SOHO TZW (North America) APL11-031SOHO TZW (International) APL10-01FTELE3 SP (Class B) APL04-01ETELE3 TZ and PRO 100 (Class B) APL11-024TELE3 TZX (Class B) APL04-022TELE3 (Class B) and SOHO3 (Class B) APL04-016PRO 100 (Class A) APL04-017TELE3 (Class A) and SOHO3 (Class A) 1RK05-015PRO 200 and PRO 300 1RK07-025PRO 230 1RK08-026PRO 330 232-000330-03.fm Page 1 Thursday, April 3, 2003 10:31 AM Page 2 BMSI Statement VCCI Statement Canadian Radio Frequency Emissions Statement This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à toutes la norme NMB-003 du Canada. CISPR 22 (En 55022) Class A Warning: This is a class A product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. Declaration of Conformity Application of council DirectiveDirective 89/336/EEC (EMC) and 72/23/EEC (LVD) Standards to which conformity is declaredEN 55022 (1998) Class A EN 55024 (1998) EN 61000-3-2 (1995) + A1, A2, A14 EN 61000-3-3 (1994) EN 60950 (1992) + A1, A2, A4, A11 National Deviations: AT, AU, BE, CH, CN, CZ, DE, DK, FI, FR, GB, GR, HU, IE, IL, IN, IT, JP, KR, NL, NO, PL, SE, SG, SI 232-000330-03.fm Page 2 Thursday, April 3, 2003 10:31 AM Page 3 Class B Information Models APL11-027, APL11-031, APL04-01E, APL10-01F, APL04-022, and APL11-024 are Class B devices (for home and office use), and the following statement is applicable to these models*: FCC Part 15 Class B Notice NOTE:This equipment was tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. And, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If the equipment doescause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference using one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and the receiver. •Connect the equipment into an outlet on a circuit different from the receiver connection. •Consult SonicWALL for assistance. Complies with EN55022 Class B and CISPR22 Class B. *Refer to the label on the bottom of the unit for device information including Class A or Class B FCC information. Canadian Radio Frequency Emissions Statement This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à toutes la norme NMB-003 du Canada. Declaration of Conformity Application of council DirectiveDirective 89/336/EEC (EMC) and 72/23/EEC (LVD) Standards to which conformity is declaredEN 55022 (1998) Class B EN 55024 (1998) EN 61000-3-2 (1995) + A1, A2, A14 EN 61000-3-3 (1994) EN 60950 (1992) + A1, A2, A4, A11 National Deviations: AT, AU, BE, CH, CN, CZ, DE, DK, FI, FR, GB, GR, HU, IE, IL, IN, IT, JP, KR, NL, NO, PL, SE, SG, SI 232-000330-03.fm Page 3 Thursday, April 3, 2003 10:31 AM Page 4 VCCI Statement FCC part 68 Telecom Information (Model APL10-01F) Repair Information - According to the FCC, only the modem vendor for the SonicWALL modem is allowed to service the modem. Contact SonicWALL Technical Support for any repairs including the modem. The FCC has established rules which permits this device to be directly connected to the telephone network. If this device is malfunctioning, it may also cause harm to the telephone network. This device should be disconnected until the source of the problem is determined and the repair is made. If this is not done, the telephone company may temporarily disconnect service. The telephone company may make changes in its technical operations and procedures. If such changes affect the compatability or use of this device, the telephone company is required to give adequate notice of the changes. If the telephone company requests information on the equipment connected to their lines, inform them of the following: •Telephone number of the line connected to the device. •The Ringer Equivalence Number (REN) located on the bottom of the device. •The device uses an RJ11-type jack. •The FCC Registration Number located on the bottom of the device. FCC RF Radiation Exposure Statement (Model APL11-027 and Model A…

Text truncated - open the document above for the full version.

Page 24 SonicWALL Internet Security Appliance Administrator’s Guide 3 Configuring Wireless on the SOHO TZW The SOHO TZW uses a wireless protocol called IEEE 802.11b, commonly known as Wi-Fi, and sends data via radio transmissions. Wi-Fi transmission speed is usually faster than broadband connection speed, but it is slower than Ethernet. The SonicWALL SOHO TZW combines three networking components to offer a fully secure wireless firewall: an 802.11b Access Point, a secure wireless gateway, and a stateful firewall with flexible NAT and VPN termination and initiation capabilities. With this combination, the SOHO TZW offers the flexibility of wireless without compromising network security. Typically, the SOHO TZW is the access point for your wireless LAN and serves as the central access point for computers on your LAN. In addition, it shares a single broadband connection with the computers on your network. Since the SOHO TZW also provides firewall protection, intruders from the Internet cannot access the computers or files on your network. This is especially important for an “always-on” connection such as a cable modem or T1 line that is shared by computers on a network. However, wireless LANs are vulnerable to “eavesdropping” by other wireless networks which means you should establish a wireless security policy for your wireless LAN. Wired Equivalent Privacy, WEP, should not be used as your only security policy. On the SOHO TZW, wireless clients connect to the Access Point layer of the firewall. Instead of bridging the connection directly to the wired network, wireless traffic is first passed to the Secure Wireless Gateway layer where the client is required to be authenticated via User Level Authentication. Access to Wireless Guest Services (WGS) and Access Control Lists (ACL) are managed by the SOHO TZW. It is also at this layer that the SOHO TZW has the capability of enforcing WiFiSec, and IPSec-based VPN overlay for wireless networking. As wireless network traffic sucessfully passes through these layers, it is then passed to the VPN-NAT-Stateful firewall layer where WiFiSec termination, address translation, and access rules are applied. If all of the security criteria is met, then wireless network traffic can then pass via one of the following Distribution Systems (DS): •LAN •WAN •Wireless Client on the WLAN •VPN tunnel Configuring Wireless on the SOHO TZW Page 25 Considerations for Using Wireless Connections •Mobility - if the majority of your network is laptop computers, wireless is more portable than wired connections. •Convenience - wireless networks do not require cabling of individual computers or opening computer cases to install network cards. •Speed - if network speed is important to you, you may want to consider using Ethernet connections rather than wireless connections. •Range and Coverage - if your network environment contains numerous physical barriers or interference factors, wireless networking may not be suitable for your network. •Security - wireless networks have inherent security issues due to the unrestrictive nature of the wireless transmissions. However, the SOHO TZW is a firewall and has NAT capabilities which provides security, and you can use WEP to secure data transmissions. Recommendations for Optimal Wireless Performance •Place the SOHO TZW near the center of your intended network. This can also reduce the possibility of eavesdropping by neighboring wireless networks. •Minimize the number of walls or ceilings between the SOHO TZW and the receiving points such as PCs or laptops. •Try to place the TZW in a direct line with other wireless components. Best performance is achieved when wireless components are in direct line of sight with each other. •Building construction can make a difference on wireless performance. Avoid placing the TZX near walls, fireplaces, or other large solid objects. Placing the TZW near metal objects such as computer cases, monitors, and appliances can affect performance of the unit. •Metal framing, UV window film, concrete or masonry walls, and metallic paint can reduce signal strength if the TZW is installed near these types of materials. •Installing the TZW in a high place can help avoid obstacles and improve performance for upper stories of a building. •Neighboring wireless networks and devices can affect signal strength, speed, and range of the SOHO TZW. Also, devices such as cordless phones, radios, microwave ovens, and televisions may cause interference on the TZW. Adjusting the SOHO TZW Antennas The antennas on the SOHO TZW can be adjusted for the best radio reception. Begin with the antennas pointing straight up, and then adjust as necessary. Note that certain areas, such as the area directly below the SOHO TZW, get relatively poor reception. Pointing the antenna directly at another wireless device does not improve reception. Do not place the antennas next to metal doors or walls as this can cause interference. Page 26 SonicWALL Internet Security Appliance Administrator’s Guide Wireless Guest Services (WGS) With your SOHO TZW, you can provide wireless guest services to wireless-equipped users who are not part of your corporate network, for example, a consultant or a sales person. You can offer authenticated wireless users access to the Internet through your SOHO TZW while preventing them from accessing your corporate LAN, or allowing them access to specific resources on the LAN and unencrypted access to the Internet. When WGS is active, wireless clients can authenticate and associate with the Access Layer of the SonicWALL. When a Web browser is launched, the wireless user is prompted to provide a user name and password to gain access to WGS. The browser is redirected to the HTTP (unencrypted) management address of the SOHO TZW, but the user name and password is not transmitted. Instead, a secure hash is transmitted rendering the information useless to anyone “eavesdropping” on the network. After authentication, WGS is tracked an…

Text truncated - open the document above for the full version.

Page 1 of 4 © 2003 SonicWALL, Inc. SonicWALL is a registered trademark of SonicWALL, Inc. Other product and company names mentioned herein may be trademarks and/or registered trademarks of their respective companies. P/N 232-000373-00 Rev A 04/03 Release Notes for the SOHO TZW Internet Security Appliance Prepared by SonicWALL, Inc. 04/25/03 SonicOS 1.0 is now available only on the SOHO TZW Internet Security appliance. This release note provides technical information on the initial release of this product. • Some firmware updates include updates for the wireless radio card. This information is provided when the firmware update is released. Firmware updates that include updates for the Wireless radio card can cause the Test, WLAN, WiFiSec, and Wireless LEDs to remain lit while the firmware is uploading to the appliance. Do not power the unit off during the update as this permanently damages your wireless radio card. After the firmware upload is complete, the SOHO TZW automatically restarts and completes the firmware update. • If you begin a management session using the WLAN interface and interrupt the session by opening another management session on the LAN, you can interrupt active WLAN to LAN sessions at the TCP layer. • If you experience multiple failures while attempting to establish a PPPoE connection, it may be necessary to reboot the SOHO TZW to restore PPPoE functionality. • Wireless Guests and Users are not unique accounts. If the same user name and password is created for a wireless guest and a user, the Wireless Guest account is referenced. • Changing the HTTP management port on a SOHO TZW providing Wireless Guest Services requires a reboot to ensure that wireless guest Web browsers are redirected to the correct URL (specifying the new port) for authentication. • To create simultaneous Global VPN Client connections through the SOHO TZW to a remote point and the WLAN, with or without WiFiSec enforcement, you must first create the connection through the SOHO TZW to the remote termination point on the Internet, and then to the WLAN port. • Attempting to create a VPN policy that enables Perfect Forward Secrecy and Forward Packets to Remote VPNs can cause unfounded proposal-based Phase 2 failures. • If WiFiSec is enforced on the WLAN, the only broadcast traffic allowed on the WLAN is NetBIOS, DHCP, and ARP. All other broadcast traffic is dropped by design. • If the WLAN radio fails, the SOHO TZW watchdog automatically reboots in an attempt to recover from the failure. If the WLAN LED blinks following the automatic recovery process, this indicates that the WLAN radio requires a full reset. Please power off the SOHO TZW; wait a few seconds, then power on to completely reset the WLAN radio. Release Notes for the SOHO TZW Internet Security Appliance Page 2 of 4 © 2003 SonicWALL, Inc. SonicWALL is a registered trademark of SonicWALL, Inc. Other product and company names mentioned herein may be trademarks and/or registered trademarks of their respective companies. P/N 232-000373-00 Rev A 04/03 • XAUTH support for SecureID’s New PIN Mode, Next PIN Mode, and Next Token Mode is excluded from this release. • Changing the VPN keying method, for example, IKE to Manual Mode or Manual Mode to IKE, can inadvertently change the subnet mask of the defined remote destination network. • Some wireless cards, notably Netgear and Linksys 54G cards, have demonstrated compatibility issues when connecting to other manufacturer’s devices. Compatibility issues are further complicated by the use of WEP, or by increasing the beaconing interval beyond its default value. It is strongly recommended that you upgrade to the latest firmware and device drivers available from your wireless client card’s manufacturer, particularly if you are using Netgear or Linksys 54G equipment. • By default, the TZW does not handle WLAN based WiFiSec tunneled packets larger than 1,518 bytes (packets requiring fragmentation). If you are running a large packet protocol (such as Kerberos or certain UDP applications), you must create a specific access rule for that protocol, and enable fragmentation on that rule. • Extremely heavy WiFiSec WLAN traffic loads could result in spurious IPSec Replay Attack log messages. • Changing the WAN interface mode, for example, from NAT Enabled to NAT with DHCP Client while using DHCP services on the TZW can cause the current DHCP lease table to be flushed. • Attempting a configuration requiring wireless clients to connect to the TZW with a WiFiSec connection, and the TZW then attempts to route all traffic through a VPN connection to a hub termination point can result in failed phase 2 negotiations between the hub and the TZW. • Although validation and error-checking is implemented on all management entry fields, it is strongly recommended that user names, service names, comments, etc. not contain any non-alphanumeric characters such as apostrophes or backslashes. • Internet Explorer 5.2.2 running on a Mac exhibits numerous page rendering problems. When using a Mac for management, an alternative browser (e.g. Safari, iCab, Opera, Mozilla) is recommended. Microsoft Windows XP and the SOHO TZW If you are running Microsoft Windows XP as your computer’s operating system, Windows XP, by default, manages your wireless PC card settings. If you want to use the Microsoft wireless management tools rather than your card vendor’s management tools, please note the following information: • Your wireless PC card drivers must be compatible with Microsoft’s Wireless Zero Configuration service. • You can access the wireless card settings by clicking on the wireless card icon in the system tray, or by right-clicking on the My Network Places icon on the desktop and double-clicking on the wireless card icon. When the initial configuration screen appears it lists all of the wireless networks available. Click Advanced on the lower left side of this screen. Release Notes for the SOHO TZW Internet Security Appliance Page 3 of 4 …

Text truncated - open the document above for the full version.

Request FCC ID QWU-027 3 April 2003 By why of this letter Sonicwall, Inc. request to have model APL11-027 Certified per 47CFR Part 2 Subpart J to 47CFR Part 15 Subpart C 15.247. This device uses digital modulation technique. Sincerely RICK LINFORD Regulatory Compliance Engineer T: 408.962.8798 F: 408.745.9300 [email protected]

To: Mike Nicolay [email protected] FCC Equipment Authorization Brunch From: Dieter Griep [email protected]/05/2003 FCC ID: QWU-027 QWU-031 Many thanks for your kind assistance. The grants for the above mentioned FCC-ID’s should be changed now, as requested. We hope these procedures are complete now.

ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH Registrationnumber U0M20303-4887-E-16 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR.38c, D-15526 REICHENWALDE B. BERLIN page 1 External Photos ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH Registrationnumber U0M20303-4887-E-16 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR.38c, D-15526 REICHENWALDE B. BERLIN page 2 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH Registrationnumber U0M20303-4887-E-16 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR.38c, D-15526 REICHENWALDE B. BERLIN page 3 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH Registrationnumber U0M20303-4887-E-16 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR.38c, D-15526 REICHENWALDE B. BERLIN page 4 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH Registrationnumber U0M20303-4887-E-16 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR.38c, D-15526 REICHENWALDE B. BERLIN page 5

The below information should be printed on a blank label per the specified Product. Page two of this documents shows were this information should be printed. Page two also show printed information that is printed the same for each product. See table for correct text Serial Number: Assembly: nnn-nnnnnnn-nn REV. XX SONICWALL CONFIDENTIAL Silver Label TZW, 3.36”x2.81” Model / Type: AAAAA-XXX Input: xx V xx A Made in USA Sonicwall TZW APL11-027 (47CFR 15.247) FCC ID: QWU-027

ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH Registrationnumber U0M20303-4887-E-16 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR.38c, D-15526 REICHENWALDE B. BERLIN Page 1 Internal Photos ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH Registrationnumber U0M20303-4887-E-16 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR.38c, D-15526 REICHENWALDE B. BERLIN Page 2 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH Registrationnumber U0M20303-4887-E-16 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR.38c, D-15526 REICHENWALDE B. BERLIN Page 3 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH Registrationnumber U0M20303-4887-E-16 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR.38c, D-15526 REICHENWALDE B. BERLIN Page 4 FCC ID : LNQ-802MIP ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH Registrationnumber U0M20303-4887-E-16 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR.38c, D-15526 REICHENWALDE B. BERLIN Page 5 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH Registrationnumber U0M20303-4887-E-16 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR.38c, D-15526 REICHENWALDE B. BERLIN Page 6 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH Registrationnumber U0M20303-4887-E-16 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR.38c, D-15526 REICHENWALDE B. BERLIN Page 7

Registrationnumber : U0M20303-4887-E-16 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR.38c, D-15526 REICHENWALDE B. BERLIN Page 1 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH MPE Prediction FCC Rule: 15.247(b)(5) Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this Chapter. LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Average Time (minutes) (A)Limits For Occupational / Control Exposures 30-300 61.4 0.163 1.0 6 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 30-300 27.5 0.073 0.2 30 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S= -------------- where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna PG 4 p R² Registrationnumber : U0M20303-4887-E-16 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR.38c, D-15526 REICHENWALDE B. BERLIN Page 2 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH Maximum peak output power at antenna input terminal: 23.52 (dBm) Maximum peak output power at antenna input terminal: 224.8 (mW) Antenna gain(maximal): 5 (dBi) Prediction distance: 10 (cm) Prediction frequency: 2412 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1.0 (mW/cm²) Power density at prediction frequency: 0.894451 (mW/cm²) Maximum allowable antenna gain: 5.59 (dBi) The manual instruct the user to install and operate the device in a minimum distance of 20 cm between antenna and the users body.

ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH COMPETENT BODY DAR-REGISTRATION NUMBER: BPT-ZE-026/96-00 ACCREDITED TESTING LABORATORY DAR-REGISTRATION NUMBER: TTI-P-G 126/96-30 ACCREDITED BY: BUNDESAMT FÜR POST UND TELEKOMMUNIKATION (BAPT) TEST - REPORT FCC 15.247 Test report no.: U0M20303-4887-E-16 ELECTRONIC TECHNOLOGY SYSTEMS STORKOWER STR.38c D-15526 REICHENWALDE B. BERLIN DR. GENZ GMBH PHONE +49-33631-888-00 FAX +49-33631-888.66 Registrationnumber : U0M20303-4887-E-16 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR.38c, D-15526 REICHENWALDE B. BERLIN page 1 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH Table of Contents 1.0 SUMMARY OF TESTS....................................................................................................................................................2 2.0 GENERAL DESCRIPTION............................................................................................................................................3 2.1. PRODUCT DESCRIPTION....................................................................................................................................................3 2.2. RELATED SUBMITTAL(S) GRANTS..................................................................................................................................4 2.3. TEST METHODOLOGY.......................................................................................................................................................5 2.4. TEST FACILITY...................................................................................................................................................................5 3.0 SYSTEM TEST CONFIGURATION...........................................................................................................................6 3.1. SUPPORT EQUIPMENT AND DESCRIPTION.......................................................................................................................6 3.2. BLOCK DIAGRAM OF TEST SETUP...................................................................................................................................6 3.3. JUSTIFICATION...................................................................................................................................................................6 3.4. SOFTWARE EXERCISE PROGRAM.....................................................................................................................................7 3.5. MODE OF OPERATION DURING TEST..............................................................................................................................7 3.6. MODIFICATIONS.................................................................................................................................................................7 3.7. ADDITIONS, DEVIATIONS AND EXCLUSIONS FROM STANDARDS...............................................................................7 3.8. TESTEN ENVIRONMENT.....................................................................................................................................................7 3.9. TEST EQUIPMENT UTILIZED..............................................................................................................................................8 4.0 MEASUREMENT RESULTS.......................................................................................................................................10 4.1. DSSS SYSTEMS...............................................................................................................................................................10 4.1.1. Maximum Peak Output Power............................................................................................................................10 4.1.2. Minimum 6 dB Bandwidth...................................................................................................................................11 4.1.3. Maximum Power Density.....................................................................................................................................11 4.1.4. Out of Band Radiated Emissions........................................................................................................................13 4.1.5. Transmitter Radiated Emissions in Restricted Bands......................................................................................14 4.1.6. Radiated Emissions from Receiver Section of Transceiver...........................................................................16 ANNEX A DIAGRAMS MINIMUM 6 DB BANDWIDTH..................................................................................................1 ANNEX B DIAGRAMS MAXIMUM POWER DENSITY..................................................................................................1 ANNEX C DIAGRAMS RADIATED EMISSIONS TRANSCEIVER.............................................................................1 Registrationnumber : U0M20303-4887-E-16 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR.38c, D-15526 REICHENWALDE B. BERLIN page 2 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1.0 Summary of Tests Model: 802.11b VPN Accesspoint Model No.: APL11-027 FCC ID: QWU-027 TEST REFERENCE RESULTS Max. Output power 15.247(b) pass 6 dB Bandwidth 15.247(a)(2) pass Max. Power Density 15.247(d) pass Out of Band Antenna Conducted Emission 15.247(c) pass Out of Band Radiated Emission 15.247(c) pass Radiated Emission in Restricted Bands 15.35(b)(c) pass AC Conducted Emission 15.207 EMT Test report M30304A1 Radiated Emission from Digital Part 15.109 N/A Radiated Emission from Receiver L.O. 15.109 N/A Antenna Requirement 15.203 Provided by applicant Test Engineer: _________________ Date:_____________ EMC Site Manager: _________________ Date:_____________ Registrationnumber : U0M20303-4887-E-16 ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH STORKOWER STR.38c, D-15526 REICHENWALDE B. BERLIN page 3 ELECTRONIC…
