QWV-BTGPRSBT-GPRS-S

BT-GPRS-S Installation Guide – Preliminary Wireless Data Modem Rev A | Feb 2003, © BlueTree Wireless Data, Inc. Page 1 of 15 BT-GPRS-S Installation Guide Preliminary Table of Contents Introduction....................................................................2 Standard Package Contents...............................................2 Safety and Hazards..........................................................2 Limitation of Liability........................................................2 Patents..........................................................................2 Copyright.......................................................................2 Trademarks....................................................................2 Product Overview.............................................................2 Data Connection..............................................................3 LED Status Indicators.......................................................3 Antenna Selection and Installation......................................4 Power Connection............................................................5 Product Activation............................................................6 Step – 1: Powering-up the modem..................................6 Step – 2: Activating the cellular unit on the network...........6 Step – 3: Programming the phone number........................6 Step – 4: Testing the modem.........................................6 Product Operation............................................................6 Mobile Terminated Call..................................................6 Mobile Originated Call:..................................................6 GSM circuit-switched data or GPRS packet-switched data....6 SMS Mobile Originated/Terminated..................................6 SIM Card Installation........................................................7 Product Configuration – AT Commands................................8 Installing the Modem Driver (WinXP)...................................9 Creating a Dialup Networking Session (WinXP)....................10 Customer Support..........................................................13 Warranty......................................................................13 Technical Specifications..................................................14 Regulatory Information...................................................15 BT-GPRS-S Installation Guide – Preliminary Wireless Data Modem Rev A | Feb 2003, © BlueTree Wireless Data, Inc. Page 2 of 15 Introduction The BT-GPRS-S is a fully integrated GSM modem, which adds wireless GPRS functionality to remote and mobile applications. Standard Package Contents The BT-GPRS-S package includes the following components: • BT-GPRS-S cellular modem • Power harness – 10 feet – with 3A inline fuse • CD-ROM that contains this manual and the BlueVue2.0 software Additional accessories are available from BlueTree Wireless. These include: • Serial Cables • Approved Cellular Antennas • AC/DC power adapter 120Vac to 12Vdc Safety and Hazards Do not operate the BlueTree Wireless Data BT-GPRS modem in areas near medical equipment, where blasting is in progress, where explosive atmospheres may be present, or near any equipment that may be susceptible to any form of radio interference. Limitation of Liability While every effort has been made to achieve technical accuracy, information in this document is subject to change without notice and does not represent a commitment on the part of BlueTree Wireless Data, Inc., or any of its subsidies, affiliates, agents, licensors, or resellers. There are no warranties, express or implied, with respect to the content of this document. Patents Portions of this product are covered by some or all of the following patents: US 6,278,442 6,271,605 6,219,694 6,075,470 6,073,318 D445,428 D416,256 Copyright © 2003 BlueTree Wireless Data, Inc. All rights reserved. Trademarks All brand or product names, logos, trademarks, etc. mentioned in this guide are owned by their respective companies. BT-GPRS-S and BlueTree are trademarks of BlueTree Wireless Data, Inc. Product Overview The BT-GPRS-S is a rugged GSM/GPRS wireless data modem incorporating Research In Motion’s 1902G radio module. The modem is intended for use with a host platform such as a computer or remote terminal data unit. The modem exchanges data between the host platforms using an RS232 serial connection. BT-GPRS-S Installation Guide – Preliminary Wireless Data Modem Rev A | Feb 2003, © BlueTree Wireless Data, Inc. Page 3 of 15 Data Connection The BT-GPRS-S is configured as DCE (Data Communications Equipment) and uses the standard RS232 9-pin designations. Two RS232 serial ports are available, each with a DB9 female connector: MAIN – Port 1: connects to a data terminal such as a computer, RTU, etc. AUX – Port 2: intended for field diagnostics and future consideration. Both Port 1 and Port 2 support speeds from 9600 bps up to 115.2 kbps. RS-232 voltage levels Table 1 RS-232 Serial Port Pin Designation Pin Name Description Port 1 Port 2 1 DCD Data Carrier Detect Out X 2 RXD Receive Data Out Out 3 TXD Transmit Data In In 4 DTR Data Terminal Ready In X 5 GND Ground Common X 6 DSR Data Set Ready Out X 7 RTS Request To Send In In 8 CTS Clear To Send Out Out 9 RI Ring Indicator Out X How to install the data cable To install the serial data cable between the modem and your computer, connect the male DB9 end of the cable to the BT- GPRS-S and tighten the screws. The other end of the cable connects to the communications port of the computer. The maximum length of a standard RS232 cable is 25 feet. If longer cable runs are required a special low loss cable can be used. LED Status Indicators Table 2 The LED Indicators LED Color Scheme Corresponding state DTR Red Data Terminal Ready detected TX Red Transmitting data RX Red Receiving data COV Red Coverage indicator (GPRS or GSM) Off No power Red Flashing 2Hz Channel scannin…

Text truncated - open the document above for the full version.

THIS DOCUMENT IS PROPRIETARY AND CONFIDENTIAL - BLUETREE WIRELESS DATA INC. 2405 46 TH Avenue, Lachine Quebec, Canada postal code H8T 3C9 Date : 18th of February 2003 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. Subject: Request for withholding from public disclosure the schematic diagrams and system block diagrams pursuant to an application for certification. Applicant:Bluetree Wireless Data Inc. Product:BlueTree GSM/GPRS Standard modem Model:BT-GPRS-S FCC ID:QWV-BTGPRS Dear Sir/Madam, We, Bluetree Wireless Data Inc., would like to request that the schematic diagrams, system block diagrams and Parts List, submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This request is made under the provisions of Section 0.457(d) of the Commission's Rules, and Section 552(b)(4) of the Freedom of Information Act. These sections authorize as a withholding from public inspection materials which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. If you have any queries, please do not hesitate to contact us by our TOLL FREE numbers: OUR TELEPHONE NO.:514-422-9110 x455 Yours truly, Ziad Nader.

Research In Motion Limited 295 Phillip Street Waterloo, Ontario Canada N2L 3W8 Tel: +1 519 888 7465, Fax: +1 519 888 6906 E-mail: [email protected] Our Ref: 04566-CERT-COVER-CONFID March 3, 2003 Federal Communications Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Rd. Columbia, Md. 21046 FCC ID: L6AR6420GN Subject: Letter requesting of documentation for GPRS OEM Radio Module RIM 1902G, Model R6420GN, FCC ID L6AR6420GN in support of the application for Certification of Bluetree Wireless Data Inc, FCC ID QWV-BTGPRS Pursuant to 47 CFR Chapter 1 Section 0.459, Research In Motion Limited (RIM) requests that the following identified detailed technical information regarding the GPRS OEM Radio Module Model R6420GN, FCC ID L6AR6420GN be held confidential by the FCC’s designated TCB TIMCO and as such be withheld from public inspection. Pursuant to 47 CFR Chapter 1 Sections 0.457(d) and 0.457(d)(2)(i) the exhibits contain details of trade secrets and technical data that is customarily guarded from competitors and not released to the public by RIM. RIM has taken necessary measures to have limited access to confidential documents only to RIM internal employees on a need-to-know basis, and have signed confidentiality agreements with employees. If the disclosure of such information is made public, it will cause serious competitive harm to RIM. In the past, none of the requested confidential Exhibits have been disclosed to third parties by RIM. The following Exhibits with specific sections described, submitted with the Form 731 attachments should be held confidential: Exhibit Operation Description 47 CFR 2.1033(c)(1)-(8) Technical Description of Equipment Exhibit Parts List/Tune Up Info 47 CFR 2.1033(c)(9) Description of operational, test, and device tune-up modes and methods. Detailed technical procedure and operator’s manual for device tune-up -“GSM Calibration” 47 CFR 2.1033(c)(10) Description of frequency stabilizing circuitry Description of circuits for suppression of spurious radiation Description of circuits for modulation limiting Description of circuits for power limiting 47 CFR 2.1033(c)(13) Description of digital modulation format and generation methods and circuits Detailed diagrams of modulation format and generation methods and circuits 47 CFR 2.1033 (b)(4) System, functional, detailed technical RF, power/interface, and audio circuit description Exhibit Block Diagram 47 CFR 2.1033 (b)(5) 04566-CERT-BLOCK-“ RIM 1902G & 1902GS SYSTEM BLOCK” and -“AUDIO BLOCK” – Detailed technical radio and audio block diagrams Exhibit Schematics 47 CFR 2.1033 (c) (10) - “GPRS OEM DB NA (850/1900) ” SCH-04566-002 Rev C - Complete technical schematic circuit diagrams Yours truly, Masud S. Attayi, P.Eng. Senior Engineer, Compliance & Certification Research In Motion Limited Tel: +1 519 888–7465 x2442 Fax:+1 519 888-6906 Email: [email protected]

Annex 2 - External PhotographsPhoto # 1 BT-GPRS-S Modem, Model BT-GPRS-SFCC ID: QWV-BTGPRS Annex 2 - External PhotographsPhoto # 2 BT-GPRS-S Modem, Model BT-GPRS-SFCC ID: QWV-BTGPRS

FCC ID Label Location

Annex 3 - Internal PhotographsPhoto # 1 BT-GPRS-S Modem, Model BT-GPRS-SFCC ID: QWV-BTGPRS Annex 3 - Internal PhotographsPhoto # 2 BT-GPRS-S Modem, Model BT-GPRS-SFCC ID: QWV-BTGPRS Annex 3 - Internal PhotographsPhoto # 3 BT-GPRS-S Modem, Model BT-GPRS-SFCC ID: QWV-BTGPRS Annex 3 - Internal PhotographsPhoto # 4 BT-GPRS-S Modem, Model BT-GPRS-SFCC ID: QWV-BTGPRS Annex 3 - Internal PhotographsPhoto # 5 BT-GPRS-S Modem, Model BT-GPRS-SFCC ID: QWV-BTGPRS Annex 3 - Internal PhotographsPhoto # 6 BT-GPRS-S Modem, Model BT-GPRS-SFCC ID: QWV-BTGPRS

BT-GPRS-S Modem Model No.: BT-GPRS-S FCC ID: QWV-BTGPRS Applicant:Blue Tree Wireless Data Inc. 2405, 46th Avenue Ville Lachine, Quebec Canada, H8T 3C9 Tested in Accordance With Federal Communications Commission (FCC) CFR 47, Parts 2, 22 (Subpart H) and 24 (Subpart E) Radio Services in 824 - 849 MHz (Cellular) and 1850 - 1910 MHz (PCS) UltraTech's File No.: BLT-003FCC22-24 This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: Feb. 13, 2003 Report Prepared by: Tri Luu, P.Eng.Tested by: Hung Trinh, RFI Technician Issued Date: Feb. 13, 2003Test Dates: Feb. 10-11, 2003 The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected], Email: [email protected] 2 31040/SITC-137646390-2049200093-000-034 FCC PARTS 2 & 24 - Radio Services in 824 - 849 MHz (Cellular) and 1850 - 1910 MHz (PCS)Contents i BT-GPRS-S Modem, Model BT-GPRS-SFCC ID: QWV-BTGPRS ULTRATECH GROUP OF LABSFile #: BLT-003FCC22-24 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4Feb. 13, 2003 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected], Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1.SUBMITTAL CHECK LIST...........................................................................................................................................1 EXHIBIT 2.INTRODUCTION...............................................................................................................................................................2 2.1.SCOPE..............................................................................................................................................................................................2 2.2.NORMATIVE REFERENCES....................................................................................................................................................2 EXHIBIT 3.PERFORMANCE ASSESSMENT.................................................................................................................................3 3.1.CLIENT INFORMATION...............................................................................................................................................................3 3.2.EQUIPMENT UNDER TEST (EUT) INFORMATION..................................................................................................................3 3.3.EUT’S TECHNICAL SPECIFICATIONS................................................................................................................................4 3.4.LIST OF EUT’S PORTS....................................................................................................................................................................4 3.5.ANCILLARY EQUIPMENT................................................................................................................................................................5 3.6.DRAWING OF TEST SETUP...............................................................................................................................................................6 EXHIBIT 4.EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS........................................7 4.1.CLIMATE TEST CONDITIONS...........................................................................................................................................................7 4.2.OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TEST SIGNALS................................................................................7 EXHIBIT 5.SUMMARY OF TEST RESULTS.................................................................................................................................8 5.1.LOCATION OF TESTS................................................................................................................................................................8 5.2.APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS....................................................................................8 EXHIBIT 6.MEASUREMENTS, EXAMINATIONS & TEST DATA FOR EMC EMISSIONS.....................................10 6.1.TEST PROCEDURES.......................................................................................................................................................................10 6.2.MEASUREMENT UNCERTAINTIES.................................................................................................................................................10 6.3.MEASUREMENT EQUIPMENT USED:.............................................................................................................................................10 6.4.ESSENTIAL/PRIMARY FUNCTIONS AS DECLARED BY THE MANUACTURER:.............................................10 6.5.RF POWER OUTPUT AND EIRP @ FCC §2.1046, 22.913 & 24.232...............................................................................11 6.5.1.Limits.....................................................................................................................................................................................11 6.5.2.Method of Measurements...................................................................................................................................................11 6.5.3.Test Equipment List............................................................................................................................................................11 6…

Text truncated - open the document above for the full version.

This report shall NOT be reproduced except in full without the written consent of Research In Motion Limited. Copyright 2002, Research In Motion Limited EMI Test Report Research In Motion Limited REPORT NO.: RIM-0204-04 PRODUCT Model No: PRD-4230-001 & PRD-4230-002 Type Name: RIM 1902G and 1902GS FCC ID: L6AR6420GN Approved by: _______________ Paul G. Cardinal, Ph.D. Manager, Compliance and Certification Date: 9 May, 2002 Page 1 of 8 RESEARCH IN MOTION Report No. RIM-0204-04 Test Date: April 23 to 30, 2002 This report shall NOT be reproduced except in full without the written consent of Research In Motion Limited. Copyright 2002, Research In Motion Limited Table of Contents A) Scope ------------------------------------------------------------------------------------------------ Pg. 2 B) Product Identification -------------------------------- -------------------------------------------- Pg. 2 C) Support Equipment Used for Testing of the EUT ----------------------------------------- Pg. 3 D) Test Voltage ---------------------------------------------------------------------------------------- Pg. 3 E) Test Results Chart -------------------------------------------------------------------------------- Pg. 4 F) Modifications to EUT ----------------------------------------------------------------------------- Pg. 4 G) Summary of Results ------------------------------------------------------------------------------ Pg. 4 H) Compliance Test Equipment Used ----------------------------------------- ------------------ Pg. 7 I) Declaration ------------------------------------------------------------------------------------------ Pg. 8 Appendix 1 Conducted Emissions Test Data/Plots Appendix 2 Conducted RF Output Power Test Data Appendix 3 Frequency Stability Test Data Appendix 4 Radiated Emissions Test Data Page 2 of 8 RESEARCH IN MOTION Report No. RIM-0204-04 Test Date: April 23 to 30, 2002 This report shall NOT be reproduced except in full without the written consent of Research In Motion Limited. Copyright 2002, Research In Motion Limited A) Scope This report details the results of compliance tests which were performed in accordance with the requirements of: FCC CFR 47 Part 22, Subpart H, Cellular Radiotelephone Services FCC CFR 47 Part 24, Subpart E, Broadband PCS Industry Canada, RSS-128 Issue 2, Rev 1, Nov. 6/99, 800 MHz Dual-Mode TDMA Cellular Telephones Industry Canada, RSS-133 Issue 2, Rev. 1 Nov. 6/99, 2.0 GHz Personal Communications Services B) Product Identification The equipment under test (EUT) was tested at the Research In Motion Limited (RIM) EMI test facility, located at: 305 Phillip Street Waterloo, Ontario Canada, N2L 3W8 The testing began on April 23, 2002 and completed on April 30, 2002. The sample equipment under test (EUT) were: 1. GPRS OEM Radio Modem kit, model number PRD-4230-001 The kit includes the following items: a. GPRS OEM Radio Modem, type RIM 1902G, model number R6420GN, IMEI 001020000070260, FCC ID L6AR6420GN (has 6 pin ZIF FPC connector for off- board SIM). b. AC Adapter, Globtek, model number SA-052AU-1, part number WR91A2400CCP, with an output voltage of 5volt dc. c. GPRS OEM Interface and Test Board, PCB-04020-002 Rev. A d. Broadcast Antenna, Andrew, Eclipse II, magnet mount e. Ribbon cable, Parlex Corp., part number 3999 f. Ribbon cable, part number WIR-02214-001 g. RF cable, MMCX male to SMA female, part number WIR-01908-001 h. DB-9 to DB-9 straight through serial cable i. Audio headset, model number HDW-03458-001 Page 3 of 8 RESEARCH IN MOTION Report No. RIM-0204-04 Test Date: April 23 to 30, 2002 This report shall NOT be reproduced except in full without the written consent of Research In Motion Limited. Copyright 2002, Research In Motion Limited 2. GPRS OEM Radio Modem kit, model number PRD-4230-002 The kit includes the following items: a. GPRS OEM Radio Modem, type RIM 1902GS, model number R6420GN, IMEI 001020000070270, FCC ID L6AR6420GN (on-board SIM connector). b. AC Adapter, Globtek, model number SA-052AU-1, part number WR91A2400CCP, with an output voltage of 5volt dc. c. GPRS OEM Interface and Test Board, PCB-04020-002 Rev. A d. Broadcast Antenna, Andrew, Eclipse II, magnet mount e. Ribbon cable, part number WIR-02214-001 f. RF cable, MMCX male to SMA female, part number WIR-01908-001 g. DB-9 to DB-9 straight through serial cable h. Audio headset, model number HDW-03458-001 C) Support Equipment Used for the Testing of the EUT 1) Communication Tester, Rohde & Schwarz, model CMU200, serial number 837493/073 2) PC, Dell, model number MMP, serial number 6SPS20B 3) Monitor, KDS, model number KD-1460, serial number 4530019652 4) Printer, H/P, model number C5884A, serial number US8251W0VQ 5) DC Power Supply, H/P, model 6632B, serial number US37472179 D) Test Voltage The ac input voltage to the ac Adapter, Globtek, model number SA-052AU-1 was 120 volts, 60 Hz. The ac adapter provided 5.0 volts dc to the GPRS OEM Radio Modem kit. This configuration was per RIM’s specifications Page 4 of 8 RESEARCH IN MOTION Report No. RIM-0204-04 Test Date: April 23 to 30, 2002 This report shall NOT be reproduced except in full without the written consent of Research In Motion Limited. Copyright 2002, Research In Motion Limited E) Test Results Chart SPECIFICATION Test Type MEETS REQUIREMENTS Performed By FCC CFR 47 Part 22, Subpart H IC RSS-128 Radiated Spurious/harmonic Emissions, ERP Yes Masud Attayi FCC CFR 47 Part 22, Subpart H IC RSS-128 Conducted Emissions, Occupied Bandwidth, Frequency Stability Yes Jonathan Doll Maurice Battler FCC CFR 47 Part 24, Subpart E IC RSS-133 Radiated Spurious/harmonic Emissions, EIRP Yes Masud Attayi FCC CFR 47 Part 24, Subpart E IC RSS-133 Conducted Emissions, Occupied Bandwidth, Frequency Stability Yes Jonathan Doll Maurice Battler F) Modifications to EUT No modifications were required to the EUT. G) Summary of Results 1) The EUT passed the Occupied Bandwidth and Spurious Emissions requirements in the GSM850 band as per 22.917. The channels m…

Text truncated - open the document above for the full version.
