1 Metre-Pro Technologies Mobile Radio Unit (MRU) User’s Guide 2 Overview This document covers the MRU series of radio transceivers designed and manufactured by Metre-Pro Technologies, Inc. It is intended to guide the user through the proper setup and operation of the MRU. Failure to strictly adhere to this guide may cause improper operation and/or damage to the unit, and this could result in voiding of all warranties. Authority to Operate Equipment This equipment complies with Part 15 of the FCC Rules. Any changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. Product Description The MRU is a radio transceiver specifically designed for automated meter reading applications, providing a low cost and high reliability solution. It establishes a wireless link to the ER series of radio transceivers located at the meters. The primary purpose of the MRU is to collect data from ER series radio transceivers. Contact your account manager or distributor regarding the ER series radio transceivers. Performance The performance of the MRU and any other radio frequency device is subject to many factors. Some of these factors are: interference from other radio frequency sources, soil and soil moisture, buildings, proximity to surrounding objects, and weather. The MRU is designed for optimum performance, however, the above factors may enhance or degrade performance. Consult Metre-Pro Technologies if performance issues occur. Enhancements and Design Changes Metre-Pro Technologies is continually improving and enhancing its products and services. We reserve the right to make product, service, and specification changes without notice. Repairs and Service This product is not field repairable. In the event of a failure, contact your account manager or distributor for assistance in returning the product and getting replacements. Metre-Pro liability is limited solely to the replacement of the device and excludes labor and other costs. The purchase of this product implies an agreement to all restrictions, guides, and terms contained within this document. 3 Training Metre-Pro offers an instructor-led training program for those involved in the use, sales, installation, or marketing of the full line of Metre-Pro products and services. Contact your account manager or distributor for more details. MRU Installation 1. Place the magnetically-mounted MRU antenna unit in a central location atop the vehicle. Route the cable from the antenna unit into the cabin of the vehicle, being careful not to crush or crimp the cable. Failure to comply with this may cause improper operation and/or damage to the unit. WARNING: This antenna device must be installed in a location that is not accessible to the general public. Install the device so that it is more than 20 cm from unsuspecting personnel. Failure to install this device as described will result in a failure to comply with FCC rules for radio frequency exposure and is discouraged. NOTE: The MRU is designed to be used only with the MRU antenna unit. The MRU will not function if an attempt is made to connect a different type of antenna unit. 2. Screw the connector at the end of the antenna cable into the MRU transceiver unit. The MRU will not operate if the antenna cable is left unconnected. 3. Plug the power cord into a 12 volt cigarette lighter socket. Turn the cigarette lighter adapter power switch on (if equipped). 4. Connect the laptop computer’s serial cable to the MRU’s serial port. 5. Turn the MRU power switch on.

KempMeek_label.doc September 16, 2003 Metre Pro Confidential Proprietary Page 1 of 1 FCC ID Label Information for FCC Type Acceptance on TruckRadio by Kemp-Meek Manufacturing (Metre Pro Technologies Inc.) The FCC ID label will be located on the bottom of the interrogator housing and is designed to last the lifetime of the product. 1.50” 2.75” QYOTRUCKRADIO

Truck Radio PCB Top Truck Radio PCB Bottom MHA PCB Top MHA PCB Bottom

Nemko Test Report: 2L0389RUS1 Applicant: Kemp-Meek Mfg. 101 Park Central Mineola, TX 75773 Equipment Under Test: TruckRadio (E.U.T.) In Accordance With: FCC Part 15, Subpart C, 15.247 Frequency Hopping Transmitters Tested By: Nemko Dallas Inc. 802 N. Kealy Lewisville, Texas 75057-3136 Authorized By: Tom Tidwell, Frontline Manager Date: 10/01/03 Total Number of Pages: 37 Nemko Dallas FCC PART 15, SUBPART C FREQUENCY HOPPING SPREAD SPECTRUM TRANSMITTER EQUIPMENT: Truck Radio PROJECT NO.: 2L0389RUS1 Page 2 of 37 Table of Contents Section 1. Summary of Test Results ......................................................... 3 Section 2. Equipment Under Test (E.U.T.) ................................................ 5 Section 3. Channel Separation .................................................................. 7 Section 4. Pseudorandom Hopping Algorithm........................................... 9 Section 5. Time of Occupancy................................................................. 12 Section 6. Occupied Bandwidth............................................................... 14 Section 7. Peak Power Output ................................................................ 18 Section 8. Spurious Emissions (Radiated)............................................ 20 Section 9. Test Equipment List ............................................................ 24 ANNEX A - TEST DETAILS ....................................................................... 25 ANNEX B - TEST DIAGRAMS ................................................................... 35 Nemko Dallas FCC PART 15, SUBPART C FREQUENCY HOPPING SPREAD SPECTRUM TRANSMITTER EQUIPMENT: Truck Radio PROJECT NO.: 2L0389RUS1 Page 3 of 37 Section 1. Summary of Test Results Manufacturer: Kemp-Meek Mfg Model No.: TruckRadio Serial No.: None General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 15, Subpart C, Paragraph 15.247 for Frequency Hopping Spread Spectrum devices. Radiated tests were conducted is accordance with ANSI C63.4-1992. Radiated emissions are made on an open area test site. A description of the test facility is on file with the FCC. New Submission Production Unit Class II Permissive Change Pre-Production Unit Family Listing THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. NONE NVLAP LAB CODE: 100426-0 Nemko Dallas Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Dallas Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko Dallas FCC PART 15, SUBPART C FREQUENCY HOPPING SPREAD SPECTRUM TRANSMITTER EQUIPMENT: Truck Radio PROJECT NO.: 2L0389RUS1 Page 4 of 37 Summary Of Test Data NAME OF TEST PARA. NO. SPEC. RESULT Powerline Conducted Emissions 15.207(a) 48 dBμV N/A (1) Channel Separation 15.247(a)(1) Greater of 25 kHz or 20 dB Bandwidth Complies Pseudorandom Hopping Algorithm 15.247(a)(1) Complies Time of Occupancy 15.247(a)(1)(ii ) ≤ 0.4 sec in 30 sec Complies 20 dB Occupied Bandwidth 15.247(a)(1) ≤ 1 MHz Complies Peak Power Output 15.247(b) 1 Watt Complies Spurious Emissions (Antenna Conducted) 15.247(c) -20 dBc N/A (2) Spurious Emissions (Radiated) 15.247(c) Table 15.209(a) Complies Footnotes: (1) The device is battery powered. (2) The device has an integral antenna. Nemko Dallas FCC PART 15, SUBPART C FREQUENCY HOPPING SPREAD SPECTRUM TRANSMITTER EQUIPMENT: Truck Radio PROJECT NO.: 2L0389RUS1 Page 5 of 37 Section 2. Equipment Under Test (E.U.T.) General Equipment Information Frequency Band: Transmitt: 922.8 – 927.9 MHz Receive: 902.1 – 907.8 MHz Number of Channels: 50 Channel Spacing: 100 kHz User Frequency Adjustment: Software controlled Supply Voltage 12 Vdc battery Nemko Dallas FCC PART 15, SUBPART C FREQUENCY HOPPING SPREAD SPECTRUM TRANSMITTER EQUIPMENT: Truck Radio PROJECT NO.: 2L0389RUS1 Page 6 of 37 Description of EUT Wireless meter interrogation device. System Diagram Nemko Dallas FCC PART 15, SUBPART C FREQUENCY HOPPING SPREAD SPECTRUM TRANSMITTER EQUIPMENT: Truck Radio PROJECT NO.: 2L0389RUS1 Page 7 of 37 Section 3. Channel Separation NAME OF TEST: Channel Separation PARA. NO.: 15.247(a)(1) TESTED BY: Eldon Berry DATE: 02Sep03 Test Results: Complies. Measurement Data: See 20 dB BW plot Measured 20 dB bandwidth: 57.5 kHz Channel Separation: 100 kHz Nemko Dallas FCC PART 15, SUBPART C FREQUENCY HOPPING SPREAD SPECTRUM TRANSMITTER EQUIPMENT: Truck Radio PROJECT NO.: 2L0389RUS1 Page 8 of 37 Test Data – Channel Separation Data Plot Page 1 of 4 Completex Job No.:3L0389R Date:9/2/2003Preliminary: Specification:15.247Temperature(°C):22 Tested By:Eldon BerryRelative Humidity(%)65 E.U.T.: Configuration: Sample Number:1 Location:AC 3RBW: Refer to plotsMeasurement Detector Type:PeakVBW: Refer to plots Distance: NAm Test Equipment Used Antenna:1304Directional Coupler: Pre-Amp: Cable #1:1484 Filter: Cable #2:1485 Receiver:1464Cable #3: Attenuator #1 Cable #4: Attenuator #2: Mixer: Additional equipment used: Measurement Uncertainty:+/-1.7 dB Notes: TruckRadio TX Channel Seperation CHANNEL SEPERATION Nemko Dallas FCC PART 15, SUBPART C FREQUENCY HOPPING SPREAD SPECTRUM TRANSMITTER EQUIPMENT: Truck Radio PROJECT NO.: 2L0389RUS1 Page 9 of 37 Section 4. Pseudorandom Hopping Algorithm NAME OF TEST: Pseudorandom Hopping Algorithm PARA. NO.: 15.247(a)(1) TESTED BY: Supplied by applicant DATE: Test Results: Complies. Measurement Data: See sample hopping sequence. Number of Hopping Frequencies: 50 (See attached plots) Refe…
