Exhibit A: Cover Letter From Agent FCC ID: QYUELITEHRM NORTHWEST EMC, INC. 22975 NW Evergreen Parkway, Suite 400 Hillsboro, OR 97124 March 13, 2003 Dear Application Examiner: On behalf of Nike, Northwest EMC Inc is submitting this application for the certification of Nike’s SMA010 transmitter, FCC ID: QYUELITEHRM. It operates 916.5 MHz (center frequency) utilizing On-Off-Keying (OOK) modulation. The transmitter is contained in a chest strap and is intended to be used with a watch receiver (that has FCC authorization) to display real time heart rate data on the watch during exercise. When the strap is worn on the chest and powered on, it transmits the users current heart rate in beats per minute to the watch, about 1 meter away. The transmitter contains an integral antenna that is etched onto the circuit board. This satisfies the requirements of 47 CFR 15.203. The Northwest EMC technical report is supplied in support of this antenna. The technical reports and exhibits demonstrate compliance with FCC rules 47 CFR 15.249. To facilitate the review process, an index of exhibits has been provided. Your efforts in reviewing this application are greatly appreciated. Best regards, Greg Kiemel, Director of Engineering Northwest EMC, Inc.

Northwest EMC TCB Compliance Opinion Revision 1/3/03 NIKE0003 Information about the Applicant Company Name Nike Address 1 Bowerman Drive, Miam Hamm Building, Floor 2 City, State, Zip Beaverton, OR, 97005 Requested By Charlie Case Job Number NIKE0003 Model Triax Elite - Heart Rate Monitor FCC ID QYUELITEHRM Agent Northwest EMC, Inc. Approval Type Original Grant Equipment Type Low Power Communications Device Transmitter operating below 1 GHz Rule Part 15.249 (15C) Overview The Nike Triax Elite – Heart Rate Monitor is a body worn device, which incorporates Nike’s SMA010 transmitter to send heart rate data to a receiver. This transmitter operates a 916.5 MHz utilizing OOK modulation. Recommendation All items have been resolved and completed to my satisfaction; therefore I recommend this application for approval. 3/13/03 _______________________________ ________________ Name Date Northwest EMC TCB Compliance Opinion Revision 1/3/03 NIKE0003 Opinion Specification Requirements Description 47 CFR 15.207(d) Conducted Emissions Opinion: The Equipment does not connect to the A.C mains, therefore is exempt from this requirement. Discussion: The product is exempt. Specification Requirements Description 47 CFR 15.249 Field Strength of Fundamental Opinion: The Equipment meets the intent specified by the requirements listed above. Discussion: The product was tested and shown to be compliant. Reference: Exhibit M Specification Requirements Description 47 CFR 2.1093 RF Hazard Opinion: This product meets the requirements. Discussion: Since this device qualifies under CFR 47 Part 15 Subpart C, the field strength is limited and therefore causes no RF exposure hazard. The output power is < 1 mW EIRP. Reference: Exhibit H

Exhibit L: Request for Confidentiality Letter FCC ID: QYUELITEHRM

Exhibit C: External Photos FCC ID: QYUELITEHRM

Exhibit B: FCC ID Label & Location on Radio FCC ID: QYUELITEHRM Actual Artwork Below Placement on Str ap Below

Exhibit D: Internal Photos FCC ID: QYUELITEHRM

Exhibit G: Antenna Description FCC ID: QYUELITEHRM Nike Digital Heart Rate Monitor Antenna Info Antenna Description : The only antenna that can be used with the device is a 0 dBi, half wave tuned, dipole etched on the internal circuit board (integral to the unit). The RF output of the radio chip is permanently attached to the antenna via circuit board etch;. thus satisfying the requirements of 15.203. Antenna Etched on Circuit Board

Exhibit H: RF Exposure FCC ID: QYUELITEHRM RF Exposure Nike Triax Elite Digital Heart Rate Monitor Date: March 11,2003 Summary of RF Exposure This device is operated in a manner that ensures the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. This device is categorically excluded from routine environmental evaluation. This device operates in a body-worn configuration under 47 CFR 15.249, and is therefore excluded from SAR evaluation based upon 2.1093(c) and its low EIRP (< 1mW).

Exhibit M: Technical Report FCC ID: QYUELITEHRM Nike Triax Elite - Heart Rate Monitor March 11, 2003 Report No. NIKE004 Report Prepared By: 1-888-EMI-CERT 22975 NW Evergreen Parkway Suite 400 Hillsboro, Oregon 97124 Certificate of Test Issue Date: March 11, 2003 Nike Model : Triax Elite - Heart Rate Monitor Report No: NIKE0004 Emissions Description Pass Fail FCC 15.249, Field Strength of Fundamental FCC 15.249, Field Strength of Spurious Emissions The equipment was tested in the configuration and mode(s) of operation provided by the client. The specific tests and test levels were specified by the client. Any additional tests, or product configurations that should be tested are the responsibility of the client. Product compliance is the responsibility of the client. List of Modifications to equipment under test required to meet the requirements: • No EMI suppression devices were added or modified. The EUT was tested as delivered. Deviations to the test standard • No deviations were made to the test standard Test Facility • The measurement facility used to collect the data is located at: Northwest EMC, Inc.; 22975 NW Evergreen Parkway, Suite 400; Hillsboro, OR 97124 Phone: (503) 844-4066 Fax: 844-3826 This site has been fully described in a report filed with the FCC (Federal Communications Commission), and accepted by the FCC in a letter maintained in our files. Approved By: Don Facteau, IS Manager This Report may only be duplicated in its entirety. The results of this test pertain only to the sample(s) tested, the specific description is noted in each of the individual sections of the test report supporting this certificate of test. 22975 NW Evergreen Parkway Suite 400 Hillsboro, Oregon 97124 Revision History Nike Triax Elite - Heart Rate Monitor Report No: NIKE0004 Revision Number Description Date Page Number 00 None Northwest EMC Accreditations and Authorizations Revision 03/05/03 FCC: The Open Area Test Sites, and conducted measurement facilities, have been fully described in reports filed with the FCC and accepted by the FCC in letters maintained in our files. TCB: Northwest EMC has been accredited by ANSI to ISO/IEC Guide 65 as a product certifier. We have been designated by the FCC as a Telecommunications Certification Body (TCB). This allows Northwest EMC to certify transmitters to FCC specifications in accordance with 47 CFR 2.960 and 2.962. A2LA: Accreditation has been granted to Northwest EMC, Inc. to perform the Electromagnetic Compatibility (EMC) tests described in the Scope of Accreditation. Assessment performed to ISO/IEC 17025. Certificate Number: 1936-01, Certificate Number: 1936-02, Certificate Number 1936-03 Australia/New Zealand: The National Association of Testing Authorities (NATA), Australia has been appointed by the ACA as an accreditation body to accredit test laboratories and competent bodies for EMC standards. Accredited test reports or assessments by competent bodies must carry the NATA logo. Test reports made by an overseas laboratory that has been accredited for the relevant standards by an overseas accreditation body that has a Mutual Recognition Agreement (MRA) with NATA are also accepted as technical grounds for product conformity. The report should be endorsed with the respective logo of the accreditation body. (A2LA) TÜV Product Service: Included in TUV Product Service Group's Listing of Recognized Laboratories. It qualifies in connection with the TUV Certification after Recognition of Agent's Testing Program for the product catergories and/or standards shown in TUV's current Listing of CARAT Laboratories available from TUV. A certificate was issued to represent that this laboratory continues to meet TUV's CARAT Program requirements. Certificate No. USA070102 TÜV Rheinland: Authorized to carryout EMC tests by order and under supervision of TÜV Rheinland. This authorization is based on "Conditions for EMC-Subcontractors" of November 1992. NEMKO: Assessed and accredited by NEMKO (Norwegian testing and certification body) for European emissions and immunity testing. As a result of NEMKO's laboratory assessment, they will accept test results from Northwest EMC, Inc. for product certification (Authorization No. ELA 119). Northwest EMC Accreditations and Authorizations Revision 03/05/03 Technology International: Assessed in accordance with ISO Guide 25 defining the general international requirements for the competence of calibration and testing laboratories and with ITI assessment criteria LACO196. Based upon that assessment Interference Technology International, Ltd., has granted approval for specifications implementing the EU Directive on EMC (89/336/EEC and amendments). The scope of the approval was provided on a Schedule of Assessment supplied with the certificate and is available upon request. Industry Canada: Accredited by Industry Canada for performance of radiated measurements. Our open area test sites comply with RSP 100, Issue 7, section 3.3. VCCI: Accepted as an Associate Member to the VCCI, Acceptance No. 564. Conducted and radiated measurement facilities have been registered in accordance with Regulations for Voluntary Control Measures, Article 8. (Registration Nos. - Evergreen: C-1071 and R-1025, Trails End: C-694 and R-677, Sultan: C-905, R-871 and R-1172, North Sioux City C-1246, R-1185 and R-1217) BSMI: Northwest EMC has been designated by NIST and validated by C- Taipei (BSMI) as a CAB to conduct tests as described in the APEC Mutual Recognition Agreement. License No.SL2-IN-E-1017. CAB: Designated by NIST and validated by the European Commission as a Conformity Assessment Body (CAB) to conduct tests and approve products to the EMC directive and transmitters to the R&TTE directive, as described in the U.S. - EU Mutual Recognition Agreement GOST: Northwest EMC, Inc. has been assessed and accredited by the Russian Certification bodies Certinform VNIINMASH, CERTINFO, SAMTES, and Federal CHEC, to perform EMC and Hygienic testing for Information Tec…
