R2LMT20WThe MT20w is a Credential Enrollment Reader for access control systems.

MT20w Enrollment Reader User Guide AptiQ • MT20w Enrollment Reader User Guide • 3 Table of Contents Overview ....................................................................................4 Operational Behavior .................................................................5 Communication .....................................................................5 Output ...................................................................................5 RF Field .................................................................................6 Configuration Card .....................................................................6 Specifications .............................................................................7 Reader Specifications ...........................................................7 Card Specifications ...............................................................7 Card Technologies Supported ...................................................8 125kHz Technologies ............................................................8 13.56MHz Technologies ........................................................8 Notes .........................................................................................9 4 • AptiQ • MT20w Enrollment Reader User Guide Overview Overview The aptiQ MT20w multi-technology enrollment reader is designed to simplify the enrollment of proximity and smart credentials by using a computer’s USB connection. The MT20w does not require software to operate, and will function on any operating system. The MT20w is an ISO14443 and ISO15963 contactless credential reader, and is compatible with aptiQ smart credentials (MIFARE Classic and MIFARE DESFire EV1), aptiQmobile credentials, PIV credentials, and most proximity credentials up to 37-bits. Connect the reader’s USB to your operating system. You will see a series of green/red LED flashes and beeps: zz2 green LED flashes. zz1 red LED flash, followed by a beep. zz3 red LED flashes, with each flash followed by a beep. The LED will then turn red and stay on, indicating that the reader is ready. If the LED and the beeper do not respond, check the cable connections. Put the cursor in the desired field to receive the output and present a valid credential. You will see a series of green/red LED flashes, along with a beep: zzRed LED will flash to green, followed by a beep. zzGreen LED will flash back to red and stay on, indicating the reader is again ready for the next valid credential. The enrollment reader output will place the information from the credential to the cursor’s location on the screen. If a non-valid credential is presented to the enrollment reader, the red LED will not change, and there will be no beep. Spanish and French translations are online at www.allegion.com/us. AptiQ • MT20w Enrollment Reader User Guide • 5 Operational Behavior Operational Behavior Communication The MT20w Enrollment Reader communicates over USB. Output The USB connection uses Human Interface Device (HID) Keyboard Interface that requires the user to put the cursor in the desired field to receive the output. The default output is (Hexadecimal) for the NDE “ENGAGE” product. There are other outputs available and they can be ordered when ordering the enrollment reader. If you ordered the default output and now require a different output, please contact Allegion Technical Support at 1-877-671-7011, option 2. The following are the outputs available. Output Examples: The examples provided were read from a 26 bit card FC 55, BID 1546 zzDefault Configuration - CE-401-073 z{For use with ENGAGEv Web Application Example - 26E0C15;26A;55;1546; zzOctal Output - CE-401-061 z{For use with Schlage Express Example - 0000000633406025 zzFC/BID Output - CE-401-060 (SUSB89 default) z{For use as Keystroke Emulator Example - 55000001546 zzBID Only - CE-401-069 z{For use as Keystroke Emulator Example - 000001546 Note: Please proceed to the following link to find a list of card formats supported by the ENGAGE (NDE) Web app. www.allegionengage.com 6 • AptiQ • MT20w Enrollment Reader User Guide Configuration CardOperational Behavior Configuration Card Using a Configuration Card to change enrollment readers output To change the enrollment reader output you will need a configuration card. zzPower cycle the reader zzAfter reader has powered up and within 60 seconds present the configuration card to the reader. zzThe reader will confirm the configuration change by: z{2 short beeps z{2 flashes of Red LED zzThe reader will then reset itself z{2 green LED flashes + beeps z{1 red LED flash + beep z{3 Red LED flashes + 3 beeps zzThe LED will then turn red and stay on, indicating that the reader is ready. RF Field Every 100ms the RF field turns on and the reader polls for cards. The 13.56 MHZ field is on for approximately 42 ms in the default reader configuration, which is maximum complexity. The 125 kHZ field is on for approximately 20 ms in the default reader configuration, which is maximum complexity. AptiQ • MT20w Enrollment Reader User Guide • 7 Reader SpecificationsSpecifications Specifications Reader Specifications Physical Dimensions(L x W x H) 5.56” x 2.00” x .695” Operating Temperatures0 to 40 C Frequency125 kHz & 13.56 MHz Weight4.1 oz Power SupplyConnect to powered USB port or via USB power InterfaceUSB Current Requirement110 mA Max Current Requirement275 mA Card Specifications Card Read Ranges Card FrequencyCard TypeRead Range 125 kHzASK, FSKUp to 2.5” (6.3 cm) 13.56 MHzISO 15693Up to 3.0” (7.6 cm) 13.56 MHzISO 14443A MIFARE ® StandardUp to 2.0” (5.1 cm) 13.56 MHzISO 14443A MIFARE ® DESFire EV1Up to 1” (2.5 cm) 8 • AptiQ • MT20w Enrollment Reader User Guide Card SpecificationsCard Technologies Supported Card Technologies Supported 125kHz Technologies GE ® /CASI ® Proximity HID ® Proximity (up to 37-bits) AWID ® Proximity LenelProx ® 13.56MHz Technologies ISO14443 MIFARE DESFire EV1 with PACSA enabled ISO14443 Secure MIFARE Classic: zzXCeedID MIFA…

Text truncated - open the document above for the full version.

9/28/2015 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Section 0.457 and Section 0.459 pertaining to confidential material. XceedID Corporation would like the following documents regarding this submission for FCC ID: R2LMT20W to be kept confidential. 1. All Schematics 2. All Block Diagrams 3. All Operational Descriptions 4. All Parts Lists 5. All Tune-up Procedure Documents The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Bryan Hoff Engineer Allegion, PLC 500 Golden Ridge Rd. Building #1, Suite 160 Golden, CO 80401 TEL: 303-640-2679

Allegion PLC 500 Golden Ridge Rd BLDG#1 Suite 160 Golden, Co. 80401 Office 303.640.2677 Fax 303.273.9937 allegion.com November 13, 14 Dear Regulatory Agencies, This letter is to provide a brief explanation for the company name confusion.. XceedID Corporation was purchased by Ingersoll Rand in 2008. The XceedID Corporation name and brand continued to be used while under the Ingersoll Rand corporate umbrella. At the end of 2013 the Securities Technology business unit of Ingersoll Rand was spun out to create a new entity, Allegion PLC. XceedID Corporation was part of the Securities Technology unit. The XceedID Corporation will remain a legal entity under Allegion PLC. Thus the company name used for regulatory filings should be XceedID Corporation. Regards, Bryan Hoff

XceedID Corporation MT20w Access Control Reader FCC Part 11, 15, 18 Certification 2.1033(b) (4) 08/30/2015 The information contained in this report is considered to be Proprietary and Confidential information of XceedID Corporation. Due to the sensitive nature of this information, XceedID Corporation requests that the information not be revealed to the general public in any form. 1. Device and circuit Operation (2.1033(b) (4)): The XceedID Corporation MT20w Credential Enrollment reader is a multi- frequency device that operates at 125kHz, 13.56 MHz, and 2.4 GHz. The readers operate by emitting an AC magnetic field at the specified frequency. When a transponder designed to operate with the reader enters either the 125kHZ or 13.56MHz field, the reader and transponder antenna coils become mutually inductively coupled. The energy transfer resulting from this mutual coupling provides a power source to an integrated circuit attached to the transponder antenna. This power source is used to power the transponder chip. For example, a 13.56 MHz transaction, the reader modulates the interrogation field to send commands to the transponder chip. The transponder chip then responds by load modulating the antenna coil to transmit the identification data from the transponder to the reader. The MT20w device will send approximately 8 polls per second at 13.56 MHz and 8 polls per second at 125 kHz, while in normal operating mode. It alternates which is polled. The timing of these polls is fixed at 125 ms intervals for each frequency. The duration of each poll without a transponder in the field at 13.56MHz is approximately 68 milliseconds and at 125 kHz it is 24 milliseconds. Example: 13.56 MHz polls at 0ms, 125ms, 250ms, 375ms... and 125 kHz polls at 72ms, 197ms, 322ms... The 13.56 MHz antenna is a balanced 3 turn antenna. The antenna is floating when not being driven by the RF chip. The antenna is tuned to minimum impedance of 40 ohms at a frequency of 14.675 MHz. The antenna is constructed from a pcb trace around the perimeter of the antenna pcb. All readers are constructed with a dual pcb subassembly. The ground system on the base board consists of several ground planes. To these planes, the reader ground is terminated. There are also two modules on the design, one a BLE module and the second a Wi-Fi module. Each module operates according to the standards of their respective technologies, Bluetooth LE 4.0 and 802.11 respectively. Only one module is transmitting at a time.

This report contains a total of 58 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. Allegion EMC TEST REPORT FOR MT20w Tested To The Following Standards: FCC Part 15 Subpart C Section(s) 15.207, 15.209, & 15.225 Report No.: 96765-7 Date of issue: September 10, 2015 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of EMC testing for CKC Laboratories, Inc. We strive to create long-term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2 of 58 Report No.: 96765-7 TABLE OF CONTENTS Administrative Information .......................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Software Versions ...................................................................................................................................................... 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Modifications During Testing ..................................................................................................................................... 6 Conditions During Testing.......................................................................................................................................... 6 Equipment Under Test ............................................................................................................................................... 6 FCC Part 15 Subpart C ................................................................................................................................... 7 13.56MHz ...................................................................................................................................................... 7 15.207 AC Conducted Emissions ................................................................................................................................ 7 15.215(c) 20dB Bandwidth ...................................................................................................................................... 16 15.225 (a)-(c) Field Strength of Fundamental .......................................................................................................... 19 15.225(d) Radiated Spurious Emissions ................................................................................................................... 25 15.225(e) Frequency Stability .................................................................................................................................. 31 125kHz......................................................................................................................................................... 34 15.207 AC Conducted Emissions .............................................................................................................................. 34 15.209(a) Radiated Spurious Emissions / Fundamental .......................................................................................... 43 15.209 Radiated Spurious Emissions ....................................................................................................................... 48 15.215(c) 20dB Bandwidth ...................................................................................................................................... 54 Supplemental Information .......................................................................................................................... 57 Emissions Test Details .............................................................................................................................................. 57 Page 3 of 58 Report No.: 96765-7 ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: Allegion 500 Golden Ridge Road, Bldg 1, Suite 160 Golden, CO 80401 Terri Rayle CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 REPRESENTATIVE: Bryan Hoff Project Number: 96765 Customer Reference Number: 4054685 DATE OF EQUIPMENT RECEIPT: July 28, 2015 DATE(S) OF TESTING: July 28 – August 14, 2015 Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 4 of 58 Report No.: 96765-7 Test Facility Information Our laboratories are configured to effectively test a wide variety of product types. CKC utilizes first class test equipment, anechoic chambers, data…
