Bluetooth Speaker FCC ID:R2MHI-BOMB Users manual Volume up + / Button Volume down - / Button Micro USB plug Jack 3,5mm Michrophone Multifunction button Multifuntion LED until itself to the last paired device, if available, and the warning LED flash slowly in blue to confirm the connection. If there is Bluetooth® turns off in about 7 minutes in order to prevent battery from discharging. device. To pair for the first time, pair for a second time or to pair to signaled by the transparent fins flashing alternately and quickly red and blue. To activate the pairing mode you need holding the button until the transparent fins flash alternately the list of found devices on your device. As soon as the device is paired, the transparent fins flash slowly blue. Now it is possible to listen to music and to make calls* through at the same time. To do this, pair the first device as explained before, then repeat this step with another devices. At this point the two paired devices could be connected at the same time and priority is assigned to the last device that start streaming Switch on hi-Bomb Bluetooth®. To switch on hi-Bomb Bluetooth® hold the button transparent fins turns on and hi-Bomb Bluetooth® emits 4 acustic tones. Afterwards hi-Bomb automatically connects no available paired device or if it is out of range, hi-Bomb Pair hi-Bomb Bluetooth® with a compatible a different device, hi-Bomb must be set in pairing mode, to switch off hi-Bomb Bluetooth® and switch it on again red and blue. Now you can select hi-Bomb Bluetooth® from hi-Bomb Bluetooth® (*thanks to the integrated microphone). It is also possible to pair hi-Bomb Bluetooth® to 2 devices untill the transparent fins flash red. *Only if paired to a mobile phone. Bluetooth® functions. Playing music. to play, stop and control music on your device connected via Bluetooth. Moreover it is possible to adjust the volume. ‡To play:press shortly the button . ‡To adjust the volume: Press and hold the + to increase it or the volume button – to decrease it. ‡To move to the next song: press the button . To switch to the previous song in your playlist press the button . ‡To stop the music: press the button . During music reproduction the transparent fins are steady blue. Make and receive a call.* to hi-Bomb Bluetooth®. Switch off hi-Bomb Bluetooth®. To switch off hi-Bomb Bluetooth® hold the power button Thanks to the buttons of hi-Bomb Bluetooth® it is possible If hi-Bomb Bluetooth® is paired to a mobile phone it is possible to make and receive calls, as using a Bluetooth headset, thanks to the internal microphone and to the buttons on the side. ‡Answer a call: to answer a call press briefly the button . ‡End a call: to end a call press briefly the button during the call. ‡Reject an incoming call: To reject an incoming call hold the button for 2 second until you hear a long tone, then release the button the incoming call is rejected. ‡Activate voice dialing / voiceover / Siri: if your phone supports voice dialing / voiceover / Siri you can activate it if a phone call is not in progress. To activate voice dialing / voiceover / Siri hold the button until you hear a tone from can dictate the command. ‡Call the last selected number: press twice (double click) the button . *Only if paired to a mobile phone. of two Bluetooth devices. Connect the first device and then perform the same procedure for the second device. At this point you can connect simultaneously both paired devices. The last device connected will have the priority. Connection via 3,5mm stereo jack. features a line level input 3,5mm stereo jack. When the jack hi-Bomb Bluetooth®; when you hear the second tone you hi-Bomb Bluetooth ® supports the simultaneous connection In addition to Bluetooth connection, hi-Bomb Bluetooth® plug is connected the Bluetooth connection remains active Bluetooth® is used with the jack input, it is only possible to control the volume. All other functions must be controlled on the connected device. The power button act as MUTE button. Pressing it once will mute the volume (note: it does not stop the reproduction), pressing it once again will restore the previous volume setting. Note: input only, internal microphone is not active. It is not possible Note: In order to obtain the best listening experience from input, we suggest to set the EQ of your connected device to “small loudspeakers” setting. Bluetooth® automatically switches itself off in order to preserve the battery from discharging. If supported by paired devices, the charge status of hi- connected device. transparent fins(2) start flashing red. It indicates that in few the battery. To charge the battery connect the supplied hi- but the priority is given to the jack input. When hi-Bomb when hi-Bomb Bluetooth® is connected via jack line to use hi-Bomb Bluetooth® as phone handsfree. your hi-Bomb Bluetooth®, both via bluetooth and jack lin e If the jack cable remains connected to hi-Bomb Bluetooth® with no volume input, after about 10 minutes, hi-Bomb Recharging hi-Bomb Bluetooth®. Bomb Bluetooth® battery is displayed on the screen of the When hi-Bomb Bluetooth® battery is discharged the minutes hi-Bomb Bluetooth® will turn off in order to preserve USB port, or alternatively, to an USB port on your laptop/ it is in use. As soon as the charger cable is connected to the plug (8), the transparent fins(2) turn on red and they turn off once the charged it is possible to unplug it from the charger. Alternately to the cable included, it is possible to use every cable equipped with a micro USB connector. Caratteristiche tecniche: Battery life: 8 Hrs Input power: 5 Vdc Output power: 1 W Working distance: ~10 m Bluetooth version: V3.0 Product dimensions (WxDxH mm): 330x48.6x48.6 Product weight: 245 g Warnings Please read carefully this part in order to guarantee Bluetooth®. or humidity. Bomb Bluetooth® charger cable to a charger equipped with computer. It is possible to charge hi-Bomb Bluetooth® while charging is complete. When …

Text truncated - open the document above for the full version.

Avlink Industrial Co.,Ltd Jan.29, 2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID:_____ R2MHI-BOMB______ Product Name:___ hi-Bomb Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this Jan.29, 2015 By: Signature Title: Manager On behalf of : Avlink Industrial Co.,Ltd Telephone: +86 (0)755-29305259

External Photos TOTAL VIEW OF EUT TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT THE PORT OF EUT

FCC ID Label Location FCC ID: R2MHI-BOMB This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation.

Internal Photos OPEN VIEW OF EUT INTERNAL VIEW OF EUT-1 INTERNAL VIEW OF EUT-2 Antenna INTERNAL VIEW OF EUT-3

RF Exposure evaluation According to KDB 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Worse case is as below: [2480 MHz 1.13dBm（1.30mW） output power] (1.30mW /5mm) ·[√2.441(GHz)]= 0.41<3.0 for 1-g SAR Then SAR evaluation is not required
