R38YLCP12PSmart phone

1 User's Guide Contents Getting Started ......................................................... 3 Overview .......................................................................... 3 Key Explainrd ................................................................... 4 Starting up........................................................................ 4 Switching Your Phone On/Off .......................................... 6 Getting Around Your Phone ............................................. 7 Phone Calls .............................................................. 8 Calling from the Phone .................................................... 8 Calling from Your Contacts .............................................. 8 Calling from a Text Message ........................................... 8 Receiving Calls ................................................................ 9 Contacts ................................................................... 9 Messaging .............................................................. 10 The Message Box .......................................................... 10 Sending an Message ..................................................... 10 Message Settings .......................................................... 11 Touch Input Settings ...................................................... 11 2 Getting Connected to the Internet ........................ 11 Adding a New Network Connection ..................... 11 Turning On Wi-Fi ........................................................... 12 Connecting to a Wi-Fi Network ...................................... 12 Checking the Wi-Fi Network Status ............................... 12 USB tethering & portable hotspot .................................. 12 Browsing the Internet ............................................ 13 Making the Most of Multimedia ............................. 14 Camera .......................................................................... 14 FM ................................................................................. 14 Playing Music ................................................................ 14 Gallery ........................................................................... 15 Sund Recorder .............................................................. 15 Sorting out Your Phone Settings .......................... 15 Bluetooth ....................................................................... 15 Setting Date and Time ................................................... 16 Display Settings ............................................................. 16 Sound Settings .............................................................. 16 Language Settings ........................................................ 16 Security Settings ........................................................... 17 Managing Your Device Memory .................................... 17 Reset to Factory Settings .............................................. 17 Google ........................................................................... 18 Clock.............................................................................. 18 Calculator ...................................................................... 18 3 Screen record ................................................................ 18 For Your Safety ...................................................... 19 General Safety ............................................................... 19 Distraction ...................................................................... 20 Product Handling ........................................................... 20 Electrical Safety ............................................................. 23 Interference .................................................................... 24 Explosive Environments ................................................ 25 System update ............................................................... 26 Common fault diagnosis ................................................ 26 Getting Started Overview 4 Key Explainrd Key Function Power Key • Press to turn on or off • Press to restart your phone • Press to Screenshot • Press to Emergency Home Key • Press to return to the Home Screen from any application or screen. Menu Key Hold to see recently used applications. Back Key Press to go to the previous screen. Volume Keys Press or hold to turn the volume up or down. Starting up Status and Notification lcons Your phone will tell you exactly what’s going on by showing you simple icons. Here’s what they mean USB connected Missed call 5 Airplane mode Signal strength Battery charge New message Meeting mode Wi-Fi network Alarm set Earphone insert Silent mode New Wi-Fi network detected Bluetooth icon USB debugging connected Installing the SIM/SD Switch off your phone before installing or replacing the battery, SIM, or memory card. 1.Remove the back cover 2.Hold the SIM card with the cut corner oriented as shown and slip it into the card holder. 3.Insert the memory card into the card slot with the metal contacts facing down until it inserts to the right position. 4.Press the cover gently back into place until you hear a click. Charging the Battery When you first get your new phone you’ll need to charge the battery. Connect the adapter to the charger jack. Ensure that the adapter is inserted with the correct orientation. Do not force the connector into the charger jack. Connect the charger to a standard AC wall outlet. 6 Disconnect the charger when the battery is fully charged. Switching Your Phone On/Off Make sure the SIM card is in your device and the battery is charged. 1. Hold Power Key to switch on your phone. 2. To switch it off, hold Power Key to get the phone options. Select Power off, and then tap OK. Setting Up Your Phone for the First Time When you first power on your phone after you purchase it or reset it to factory settings (see chapter Sorting out Your Phone S…

Text truncated - open the document above for the full version.

Attestation Statements 2023/3/23 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (FCC ID: R38YLCP12P) Yulong Computer Telecommunication Scientific (Shenzhen) Co., Ltd, the undersigned, hereby authorize Coolpad Technologies Inc to act as our designated U.S. agent for service of process, Yulong Computer Telecommunication Scientific (Shenzhen) Co., Ltd accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Coolpad Technologies Inc accepts the responsibility to act as designated U.S. agent for service of process. Applicant Information ： Company name: Yulong Computer Telecommunication Scientific (Shenzhen) Co., Ltd Contact Name: Yentl Chen Address: Floor 21, Block A, Coolpad Building, Intersection of Keyuan Avenue and Baoshen Road, North High-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, China Telephone No: 15927320221 Email: [email protected] Signature: Yentl Chen U.S. Agent Information: Company Name: Coolpad Technologies Inc Address: 530 Technology Drive Suite100，Irvine，CALIFORNIA FRN: 0033414293 Contact Name: Brandy Cudd Telephone No: 9724362126 Email: [email protected] Signature:

Yulong Computer Telecommunication Scientific (Shenzhen) Co., Ltd 2023/3/29 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: R38YLCP12TP) Yulong Computer Telecommunication Scientific (Shenzhen) Co., Ltd (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signature: Yentl Chen Yulong Computer Telecommunication Scientific (Shenzhen) Co., Ltd 2023/3/29 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: R38YLCP12TP) Yulong Computer Telecommunication Scientific (Shenzhen) Co., Ltd (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature: Yentl Chen

Yulong Computer Telecommunication Scientific (Shenzhen) Co., Ltd 2023.3.29 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen LGT Test Service Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Date: 2023. 03.29 Name: Yentl Chen Title: Engineer Company: Yulong Computer Telecommunication Scientific (Shenzhen) Co., Ltd

Yulong Computer Telecommunication Scientific (Shenzhen) Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023.3.23 Subject; Request for Confidentiality FCC ID:R38YLCP12P To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description Tune-up Procedure Part List SOFTWARE SECURITY REQUIREMENTS In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name:Yentl Chen/Yulong Computer Telecommunication Scientific (Shenzhen) Co., Ltd Title:Engineer

Page 1 of 5 Report No.: LGT23C004 Appendix - External Photographs of EUT Constructional Details Model: CP12p Photo 1 Photo 2 Page 2 of 5 Report No.: LGT23C004 Photo 3 Photo 4 Page 3 of 5 Report No.: LGT23C004 Photo 5 Photo 6 Page 4 of 5 Report No.: LGT23C004 Photo 7 Photo 8 Page 5 of 5 Report No.: LGT23C004 Photo 9

Label Smart Phone Model:CP12p FCC ID:R38YLCP12P Manufacturer:Yulong Computer Telecommunication Scientific (Shenzhen) Co., Ltd Floor 21, Block A, Coolpad Building, Intersection of Keyuan Avenue and Baoshen Road, North High-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, China Importer:XXXXXXXXX Address:XXXXXXXXXXXXXXXXX

Page 1 of 9 Report No.: LGT23C004 Appendix - Internal Photographs of EUT Constructional Details Model: CP12p Photo 1 Photo 2 Page 2 of 9 Report No.: LGT23C004 Photo 3 Photo 4 DIV ANT BT/Wi-Fi ANT GSM/WCDMA/LTE MAIN ANT Page 3 of 9 Report No.: LGT23C004 Photo 5 Photo 6 Page 4 of 9 Report No.: LGT23C004 Photo 7 Photo 8 Page 5 of 9 Report No.: LGT23C004 Photo 9 Photo 10 Page 6 of 9 Report No.: LGT23C004 Photo 11 Photo 12 Page 7 of 9 Report No.: LGT23C004 Photo 13 Photo 14 Page 8 of 9 Report No.: LGT23C004 Photo 15 Photo 16 Page 9 of 9 Report No.: LGT23C004 Photo 17 Photo 18

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China SAR TEST REPORT Product Name: Smart Phone Model Name: CP12p FCC ID: R38YLCP12P Issued For : Yulong Computer Telecommunication Scientific (Shenzhen) Co., Ltd Floor 21, Block A, Coolpad Building, Intersection of Keyuan Avenue and Baoshen Road, North High-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, China Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China Report Number: LGT23C004HA01 Sample Received Date: Mar. 03, 2023 Date of Test:Mar. 11, 2023~ Mar. 25, 2023 Date of Issue: Mar. 27, 2023 Max. SAR (1g): Head: 0.909 W/kg Body: 1.219 W/kg Report No.: LGT23C004HA01 Page 2 of 121 Table of Contents 1. General Information 5 1.1 EUT Description 5 1.2 Test Environment 7 1.3 Test Factory 7 2. Test Standards and Limits 8 3. SAR Measurement System 9 3.1 Definition of Specific Absorption Rate (SAR) 9 3.2 SAR System 9 4. Tissue Simulating Liquids 12 4.1 Simulating Liquids Parameter Check 12 5. SAR System Validation 14 5.1 Validation System 14 5.2 Validation Result 15 6. SAR Evaluation Procedures 16 7. EUT Antenna Location Sketch 17 7.1 SAR test exclusion consider table 18 8. EUT Test Position 24 8.1 Define Two Imaginary Lines on the Handset 24 8.2 Hotspot mode exposure position condition 25 9. Uncertainty 26 9.1 Measurement Uncertainty 26 9.2 System validation uncertainty 27 10. Conducted Power Measurement 28 10.1 Test Result: 28 11. EUT and Test Setup Photo 50 11 .1 EUT Photos 50 11.2 Setup Photos 53 12. SAR Result Summary 59 12.1 Head SAR 59 12.2 Body-worn and Hotspot SAR 62 13. Equipment List 70 Appendix A. System Validation Plots 71 Appendix B. SAR Test Plots 87 Report No.: LGT23C004HA01 Page 3 of 121 Revision History Rev. Issue Date Contents 00Mar. 27 , 2023 Initial Issue Report No.: LGT23C004HA01 Page 4 of 121 TEST REPORT CERTIFICATION Applicant Yulong Computer Telecommunication Scientific (Shenzhen) Co., Ltd Address Floor 21, Block A, Coolpad Building, Intersection of Keyuan Avenue and Baoshen Road, North High-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, China Manufacture Yulong Computer Telecommunication Scientific (Shenzhen) Co., Ltd Address Floor 21, Block A, Coolpad Building, Intersection of Keyuan Avenue and Baoshen Road, North High-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, China Product Name Smart Phone Trademark coolpad Model NameCP12 p Sample number LGT2303006 APPLICABLE STANDARDS STANDARD TEST RESULTS ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 (2.1093) IEEE 1528: 2013 PASS Prepared by: Approved by: Zane Shan Engineer Vita Li Manager Report No.: LGT23C004HA01 Page 5 of 121 1. General Information Environmental evaluation measurements of specific absorption rate (SAR) distributions in emulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 1.1 EUT Description Product Name Smart Phone Trademark coolpad Model Name CP12p Series Model N/A Model Difference N/A Device Category Portable Product stage Production unit RF Exposure Environment General Population/Uncontrolled IMEI IMEI 1: 868405062509015 IMEI 2: 868405066581671 Hardware Version V1.0 Software Version CP12p.230327.0S.SE Frequency Range GSM 850: 824 ~ 849 MHz PCS 1900: 1850 ~ 1910 MHz WCDMA Band II: 1850 ~ 1910 MHz WCDMA Band IV:1710 ~ 1755 MHz WCDMA Band V: 824 ~ 849 MHz LTE Band 2:1850 ~1910MHz LTE Band 4:1710 ~1755MHz LTE Band 5:824 ~ 849MHz LTE Band 7:2500 ~ 2570MHz LTE Band 12:699~716MHz LTE Band 13:777~787MHz LTE Band 17:704 ~ 716MHz LTE Band 66:1710~1780MHz WLAN 802.11b/g/n20: 2412MHz ~ 2462 MHz WLAN 802.11n40: 2422 MHz ~ 2452 MHz WLAN 802.11a/n20/n40/ac20/ac40/ac80: 5150 ~ 5250 MHz WLAN 802.11a/n20/n40/ac20/ac40/ac80: 5725 ~ 5850 MHz Bluetooth: 2402 ~ 2480 MHz Max. Reported SAR(1g): (Limit:1.6W/kg) Test distance: Head:0mm Body:10mm Mode Head(W/ kg) Body Worn and Hotspot (W/ kg) GSM 850 0.156 0.305 PCS 1900 0.038 0.285 WCDMA Band II 0.087 0.27 WCDMA Band IV 0.114 0.676 WCDMA Band V 0.077 0.14 LTE Band 2 0.136 0.487 LTE Band 4 0.146 0.605 LTE Band 5 0.149 0.204 LTE Band 70.0661.219 LTE Band 12 0.075 0.185 LTE Band 13 0.075 0.119 LTE Band 17 0.078 0.203 Report No.: LGT23C004HA01 Page 6 of 121 LTE Band 66 0.147 0.657 2.4G WLAN 0.233 0.038 Bluetooth 0.087 0.026 5.2G WLAN 0.437 0.046 5.8G WLAN 0.909 0.034 1-g Sum SAR 1.065 1.265 Battery Rated Voltage:3.85V Capacity: 4500mAh Description test modes SIM 1 and SIM 2 is a chipset unit and tested as single chipset, SIM 1 is used to tested Operating Mode: GSM: GSM Voice; GPRS/EGPRS Class 12 WCDMA: RMC, HSDPA, HSUPA Release 6 LTE: QPSK, 16QAM 2.4G WLAN: 802.11b(DSSS): CCK, DQPSK, DBPSK 802.11g(OFDM): BPSK, QPSK,16-QAM,64-QAM 802.11n(OFDM): BPSK, QPSK,16-QAM,64-QAM 5G WLAN: 802.11a(OFDM): BPSK, QPSK,16-QAM,64-QAM 802.11n(OFDM): BPSK, QPSK,16-QAM,64-QAM 802.11ac (OFDM): BPSK, QPSK,16-QAM,64-QAM,256-QAM Bluetooth: GFSK +π/4 DQPSK+8DPSK BLE: GFSK Antenna Specification GSM/WCDMA/LTE: FPC Antenna Bluetooth: FPC Antenna WLAN: FPC Antenna Operating Mode Maximum Continuous Output SIM Card Support dual-SIM, dual standby, the multiple SIM card with two lines cannot transmitting at the same time Hotspot Mode Support DTM Mode Not Support Report No.: LGT23C004HA01 Page 7 of 121 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Temperature (°C) 18…

Text truncated - open the document above for the full version.

Antenna Specification Ruisheng Precision Manufacturing Technology (Changzhou) Co., LTD Product Name: Smart Phone Model Name: CP12p FCC ID: R38YLCP12P Antenna Specification: GSM/WCDMA/LTE: FPC Antenna; Bluetooth: FPC Antenna; WLAN: FPC Antenna 第 11 页 天线增益(Antenna Gain) Standard Band Frequency Gain（dbi） FDD-LTE FDD-B1 2090 0.42 FDD-LTE FDD-B2 1970 -0.51 FDD-LTE FDD-B3 1880 -1.75 FDD-LTE FDD-B4 2690 0.42 FDD-LTE FDD-B5 870 -1.96 FDD-LTE FDD-B7 2500 -1.85 FDD-LTE FDD-B8 915 -1.87 FDD-LTE FDD-B12 735 -1.94 FDD-LTE FDD-B13 755 -2.03 FDD-LTE FDD-B17 735 -1.94 FDD-LTE FDD-B25 1970 -0.51 FDD-LTE FDD-B26 870 -1.96 FDD-LTE FDD-B28 735 -1.94 FDD-LTE FDD-66 2090 0.42 WCDMA WCDMA-B1 2090 0.42 WCDMA WCDMA-B2 1970 -0.51 WCDMA WCDMA-B4 2690 0.42 WCDMA WCDMA-B5 870 -1.96 WCDMA WCDMA-B8 915 -1.87 GSM GSM 850 870 -1.96 GSM GSM 900 915 -1.87 GSM DCS 1800 1880 -1.75 GSM PCS 1900 1970 -0.51 GPS 2440 0.08 2.4G 1560 -1.7 5G 5170 -1.7 第 12 页 Total Resp o n se (d B) -12 2 -10 -8 -6 -4 -2 0 X Z Y Azi m uth = -96.5 El evati on = -34.3 Rol l = 76.8 Total Resp o n se (d B) -10 0 -9 -8 -7 -6 -5 -4 -3 -2 -1 X Z Y Azi m uth = -96.5 El evati on = -34.3 Rol l = 76.8 2090 LTE B1/4/B66 WCDMA 1/4 1970 LTE B2/B25 PCS 1900 WCDMA-2 第 13 页 Total Resp o n se (d B) -11 -1 -10 -9 -8 -7 -6 -5 -4 -3 -2 X Z Y Azi m uth = -96.5 El evati on = -34.3 Rol l = 76.8 Total Resp o n se (d B) -24 -2 -22 -20 -18 -16 -14 -12 -10 -8 -6 -4 X Z Y Azi m uth = 90.0 El evati on = -90.0 Rol l = -90.0 Total Resp o n se (d B) -20 -2 -18 -16 -14 -12 -10 -8 -6 -4 XY Z Azi m uth = 90.0 El evati on = -180.0 Rol l = -90.0 1880 LTE B3 DCS 1800 870 LTE B5/26 GSM 850 WCDMA-5 2500 LTE B7 第 14 页 Total Resp o n se (d B) -30 -10 -28 -26 -24 -22 -20 -18 -16 -14 -12 X Z Y Azi m uth = 90.0 El evati on = -90.0 Rol l = -90.0 Total Resp o n se (d B) -24 -2 -22 -20 -18 -16 -14 -12 -10 -8 -6 -4 X Z Y Azi m uth = 90.0 El evati on = -90.0 Rol l = -90.0 Total Resp o n se (d B) -24 -2 -22 -20 -18 -16 -14 -12 -10 -8 -6 -4 X Z Y Azi m uth = -146.3 El evati on = -84.1 Rol l = 33.7 915 LTE B8 GSM 900 WCDMA-8 735 LTE B12/17/28 755 LTE B13 第 15 页

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China RF TEST REPORT Product Name: Smart Phone Model Name: CP12p FCC ID: R38YLCP12P Issued For : Yulong Computer Telecommunication Scientific (Shenzhen) Co., Ltd Floor 21, Block A, Coolpad Building, Intersection of Keyuan Avenue and Baoshen Road, North High-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, China Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China Report Number: LGT23C004RF04 Sample Received Date: Mar. 02, 2023 Date of Test: Mar. 02, 2023 ~ Mar. 23, 2023 Date of Issue: Mar. 23, 2023 Report No.: LGT23C004RF04 Page 2 of 68 TEST REPORT CERTIFICATION Applicant Yulong Computer Telecommunication Scientific (Shenzhen) Co., Ltd Address Floor 21, Block A, Coolpad Building, Intersection of Keyuan Avenue and Baoshen Road, North High-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, China Manufacturer Yulong Computer Telecommunication Scientific (Shenzhen) Co., Ltd Address Floor 21, Block A, Coolpad Building, Intersection of Keyuan Avenue and Baoshen Road, North High-Tech Industrial Park, Nanshan District, Shenzhen, Guangdong, China Product Name Smart Phone Trademark coolpad Model Name CP12p Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.407, Subpart E ANSI C63.10-2013 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT23C004RF04 Page 3 of 68 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2 . GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 11 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.2 RADIATED EMISSION AND ( BANDEDGE) MEASUREMENT 17 4. POWER SPECTRAL DENSITY TEST 29 4.1 LIMIT 29 4.2 TEST PROCEDURE 29 4.3 DEVIATION FROM STANDARD 29 4.4 TEST SETUP 29 4.5 EUT OPERATION CONDITIONS 30 4.6 TEST RESULTS 30 5. BANDWIDTH MEASUREMENT 31 5.1 EMISSION BANDWIDTH (EBW) 26 BANDWID PROCEDURES / LIMIT 31 5.2 OCCUPIED BANDWIDTH ( 99%) TEST APPLIED PROCEDURES / LIMIT 32 5.3 MINIMUM EMISSION BANDWIDTH(6 DB) PROCEDURES / LIMIT 33 6. MAXIMUM CONDUCTED OUTPUT POWER 34 6.1 LIMIT 34 6.2 TEST PROCEDURE 34 6.3 DEVIATION FROM STANDARD 34 6.4 TEST SETUP 34 6.5 EUT OPERATION CONDITIONS 34 6.6 TEST RESULTS 34 7. AUTOMATICALLY DISCONTINUE TRANSMISSION 35 7.1 LIMIT OF AUTOMATICALLY DISCONTINUE TRANSMISSION 35 7.2 TEST RESULT OF AUTOMATICALLY DISCONTINUE TRANSMISSION 35 8. ANTENNA REQUIREMENT 36 Report No.: LGT23C004RF04 Page 4 of 68 Table of Contents Page 8.1 STANDARD REQUIREMENT 36 8.2 EUT ANTENNA 36 APPENDIX I:TEST RESULTS 37 DUTY CYCLE 37 MAXIMUM CONDUCTED OUTPUT POWER 44 -26DB BANDWIDTH 45 OCCUPIED CHANNEL BANDWIDTH 49 MAXIMUM POWER SPECTRAL DENSITY LEVEL 56 -6DB BANDWIDTH 63 APPENDIX II:PHOTOS OF TEST SETUP 67 Report No.: LGT23C004RF04 Page 5 of 68 Revision History Rev. Issue Date Contents 00 Mar. 23, 2023 Initial Issue Report No.: LGT23C004RF04 Page 6 of 68 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: Part 15.407,KDB 789033 D02 General U-NII Test Procedures New Rules v02r01 FCC Part 15.407 FCC standard Test Item Results 15.207 AC Conducted Emission PASS 15.407 (a) /15.407 (e) 26dB/6dB &99% Bandwidth PASS 15.407(a) Maximum Conducted Output Power PASS 15.407(b)/15.205/15.209 Radiated Emission And (bandedge Emissions) Measurement PASS 15.407(a) Power Spectral Density PASS 15.407(c) Automatically Discontinue Transmission PASS 15.203/15.204 Antenna Requirement PASS NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Report No.: LGT23C004RF04 Page 7 of 68 1.1 TEST FACTORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China Accreditation Certificate: A2LA Certificate No.: 6727.01 FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.68dB 2 Unwanted Emissions, conducted ±2.988dB 3 All emissions, radiated 9K-30MHz ±2.84dB 4 All emissions, radiated 30M-1GHz ±4.39dB 5 All emissions, radiated 1G-6GHz ±5.10dB 6 All emissions, radiated>6G ±5.48dB 7 Conducted Emission (9KHz-150KHz) ±2.79dB 8 Conducted Emission (150KHz-30MHz) ±2.80dB Report No.: LGT23C004RF04 Page 8 of 68 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name Smart Phone Trademark coolpad Model Name CP12p Series Model N/A Model Difference N/A Product Description The EUT is a Smart Phone Operation Frequency: IEEE 802.11a/n(HT20)/ac(VHT20): 5.180GHz- 5.240GHz IEEE 802.11n(HT40)/ac(VHT40): 5.190GHz- 5.230GHz IEEE 802.11ac(VHT80): 5.210GHz I IEEE 802.11a/n(HT20)/ac(VHT20): 5.745GHz-5.825GHz IEEE 802.11a/n(HT40)/ac(VHT40): 5.755GHz-5.795GHz IEEE 802.11ac(VHT80): 5.775GHz Modulation Type: 802.11a(OFDM): BPSK, QPSK, 16-QAM, 64-QAM 802.11n(OFDM): BPSK, QPSK, 16-QAM, 64-QAM 802.11ac (OFDM): BPSK, QPSK, 16-QAM, 64- QAM, 256-QAM Antenna Designation: …

Text truncated - open the document above for the full version.

Report No.: LGT23C004RF04 Page 23 of 68 Project: LGT23C004 Test Engineer: Dylan.shi EUT: Smart Phone Temperature: 26.7°C M/N: CP12p Humidity: 52%RH Test Voltage: Battery Test Data: 2023-03-12 Test Mode: 802.11a 5240 Note: No. Frequency Reading dBuV Factor dB/m Level dBuV/m Limit dBuV/m Margin dB Detector Polar 1* 5.246GHz 53.78 -6.93 46.85 74.00 -27.15 PK Hor 2* 9.007GHz 52.76 -1.17 51.59 74.00 -22.41 PK Hor 3* 17.917GHz 45.50 8.46 53.96 74.00 -20.04 PK Hor 4* 17.917GHz 36.04 8.46 44.50 54.00 -9.50 AV Hor No. Frequency Reading dBuV Factor dB/m Level dBuV/m Limit dBuV/m Margin dB Detector Polar 1* 4.848GHz 52.79 -6.02 46.77 74.00 -27.23 PK Ver 2* 8.091GHz 55.24 -3.74 51.50 74.00 -22.50 PK Ver 3* 17.809GHz 46.17 8.39 54.56 74.00 -19.44 PK Ver 4* 17.809GHz 35.21 8.39 43.60 54.00 -10.40 AV Ver Project: LGT23C004 Test Engineer: Dylan.shi EUT: Smart Phone Temperature: 26.7°C M/N: CP12p Humidity: 52%RH Test Voltage: Battery Test Data: 2023-03-12 Test Mode: 802.11a 5745 Note: No. Frequency Reading dBuV Factor dB/m Level dBuV/m Limit dBuV/m Margin dB Detector Polar 1* 5.252GHz 53.16 -6.95 46.21 74.00 -27.79 PK Hor 2* 8.901GHz 52.75 -1.45 51.30 74.00 -22.70 PK Hor 3* 17.822GHz 46.40 8.40 54.80 74.00 -19.20 PK Hor 4* 17.822GHz 35.90 8.40 44.30 54.00 -9.70 AV Hor No. Frequency Reading dBuV Factor dB/m Level dBuV/m Limit dBuV/m Margin dB Detector Polar 1* 4.751GHz 52.60 -5.95 46.65 74.00 -27.35 PK Ver 2* 11.491GHz 49.50 1.92 51.42 74.00 -22.58 PK Ver 3* 17.921GHz 46.52 8.46 54.98 74.00 -19.02 PK Ver 4* 17.921GHz 37.04 8.46 45.50 54.00 -8.50 AV Ver Report No.: LGT23C004RF04 Page 24 of 68 Project: LGT23C004 Test Engineer: Dylan.shi EUT: Smart Phone Temperature: 26.7°C M/N: CP12p Humidity: 52%RH Test Voltage: Battery Test Data: 2023-03-12 Test Mode: 802.11a 5785 Note: No. Frequency Reading dBuV Factor dB/m Level dBuV/m Limit dBuV/m Margin dB Detector Polar 1* 4.783GHz 52.85 -5.97 46.88 74.00 -27.12 PK Hor 2* 8.922GHz 52.85 -1.39 51.46 74.00 -22.54 PK Hor 3* 17.915GHz 46.32 8.46 54.78 74.00 -19.22 PK Hor 4* 17.915GHz 36.64 8.46 45.10 54.00 -8.90 AV Hor No. Frequency Reading dBuV Factor dB/m Level dBuV/m Limit dBuV/m Margin dB Detector Polar 1* 4.608GHz 52.38 -5.84 46.54 74.00 -27.46 PK Ver 2* 8.922GHz 53.27 -1.39 51.88 74.00 -22.12 PK Ver 3* 17.902GHz 46.27 8.45 54.72 74.00 -19.28 PK Ver 4* 17.902GHz 36.85 8.45 45.30 54.00 -8.70 AV Ver Project: LGT23C004 Test Engineer: Dylan.shi EUT: Smart Phone Temperature: 26.7°C M/N: CP12p Humidity: 52%RH Test Voltage: Battery Test Data: 2023-03-12 Test Mode: 802.11a 5825 Note: No. Frequency Reading dBuV Factor dB/m Level dBuV/m Limit dBuV/m Margin dB Detector Polar 1* 5.378GHz 53.70 -7.35 46.35 74.00 -27.65 PK Hor 2* 11.266GHz 50.46 1.79 52.25 74.00 -21.75 PK Hor 3* 17.790GHz 46.67 8.37 55.04 74.00 -18.96 PK Hor 4* 17.790GHz 36.53 8.37 44.90 54.00 -9.10 AV Hor No. Frequency Reading dBuV Factor dB/m Level dBuV/m Limit dBuV/m Margin dB Detector Polar 1* 4.710GHz 53.70 -5.92 47.78 74.00 -26.22 PK Ver 2* 8.977GHz 52.62 -1.23 51.39 74.00 -22.61 PK Ver 3* 17.966GHz 45.63 8.50 54.13 74.00 -19.87 PK Ver 4* 17.966GHz 36.30 8.50 44.80 54.00 -9.20 AV Ver Note：The 18-40GHz emission of peak points that did not show above the forms are at least 20dB below the limit, the frequency emission is mainly from the environment noise Report No.: LGT23C004RF04 Page 25 of 68 3.2.7 TEST RESULTS(Band edge Requirements) Project: LGT23C004 Test Engineer: Dylan.shi EUT: Smart Phone Temperature: 25.7°C M/N: CP12p Humidity: 47%RH Test Voltage: Batter…
