Start Guide Sync UP connected by What’s InsideGet to know your trackerLED IndicatorHow to charge Power button 1 IMEI number 5 Personal ID 6 LED indicator 2 Speaker 3 Light sensor 4 QR code 8 Magnetic charging strip 7 1. Power button- Press and hold the Power button for 3 seconds to turn the device on/off 2. LED indicator- Display the current status of the tracker. For more details refer to page 3 3. Speaker- Press the play sound button on the app to play a sound on the tracker 4. Light sensor- Detects changes in light 5. IMEI Number- Enter this number during the manual pairing process 6. Personal ID- Write your initials or belongings you are tracking 7. Magnetic charging strip- Align the included charger with the magnetic charging strip 8. QR Code- Used to pair the device during onboarding. Just scan and go Solid yellow: Battery charging Solid green: Battery fully charged Blinking red: Low Battery or alert Blinking green: Pairing mode Solid green for 2s: Paired Solid red: Recieved Find My Device command No light: Standby • Align the magnetic charging pins of the USB cable with the magnetic charging port on the back of the device. • They will be automatically aligned. • Once those are aligned, connect the USB end to the charging block (included). • Connect the travel adapter to an electrical outlet to fully charge the device. • The LED indicator will light up yellow when charging. Get Started To get started with SyncUP TRACKER, follow these steps 1. Charge your tracker for at least 2 hours 2. Download the app via Apple Appstore or Google Play and sign into your profile with your T-Mobile account credentials 3. Add a new tracker by following the app’s onscreen instructions for a quick scan and connection to the T-Mobile network 4. Personalize your tracker by selecting what you are tracking, naming the tracker, picking a custom avatar, and energy/performance setting Additional informationSet up a profileSupport What are you tracking? After signing into the app and adding your tracker, you can customize what you are tracking. Easily create a custom tracker profile Have fun and personalize your tracker Name, Screen Image (icon type/color or picture), and the Energy/Performance level, or simply choose the default settings for what you want to track. Approved firmware Versions This device will only operate with firmware versions that have been approved for use by T-Mobile and the device manufacturer. If unauthorized firmware is placed on the device, it will not function. Additional information Qualifying plan, app and GPS signal is required. All illustrations and images simulated. Coverage not available in some areas. See Terms and conditions (including Arbitration Provision) at T-Mobile.com, for additional information, and restrictions and details. T-Mobile, the T logo, Magenta and the magenta color are registered trademarks or Deutsche Telekom AG. SyncUP TRACKER and SyncUP TRACKER logo are trademarks of T-Mobile. Still need help? Reach out to our T-Mobile Team of Experts, who are available 24/7 How to reach us: From your T-Mobile phones, please dial 611, or from any phone dial 1-800-936-8997 Call Us-TTY TTY service is available for the hearing and speech impaired. Hours are 5:00am to 10:00pm PT, daily. Call us toll free at 1-877-296-1018. For access to our T—Mobile Support Community, visit: https://support.t-mobile.com 12 12 Get the App Search for “SyncUP TRACKER” In the Apple, Google Play Store: or visit: www.t-mobile.com/syncuptracker Open SyncUP TRACKER App on your smartphone and follow the step-by-step instructions to set up your tracker. Verify your smartphone is up to date with the latest operating system and meets the minimum technical requirements. P763554 FPO FPO FPO FPO FPO NOTE: For legal review only, not for layout/design TrackerChargerLanyard Cover: Prints T-Mobile Magenta Logo and Text K/O to White Header prints T-Mobile Magenta Text prints Black Images print CMYK Cover: Prints T-Mobile Magenta Logo and Text K/O to White Tracker overprints Black URLs prints T-Mobile Magenta Artwork scale Date created Modified date Version 100% 08/04/20 v1 IMPORTANT NOTES: Please check this artwork proof thoroughly, including all copy, colors, dielines and legal/mandatory information, prior to approval. Once the artwork has been approved by you and released by Pearlsher, we can no longer take responsibility for any errors or omissions, as outlined in our terms and conditions. If you have any questions relating to this or if you require any guidance on checking artwork proofs, then please let us know and we will happily advise. Barcode shown is for positional only and should be set by printer according to client's specications. Client / Project T-Mobile/ SyncUp Tracker Start Guide Font Foundry Telegrotesk Next URW Filename: 200817_TMO_SyncUp-Tracker_Start-Guide.ai FILE NOTES: Color laser copy is for layout purposes only. A color calibrated print-match sample will be supplied alongside this artwork if appropriate. Printing Inks & Finishes Information Non-Adobe Fonts Used Die Reference: 314AT Tracker 2 QSG Dieline.ai Paper | Lithographic | 4-Color + SpotMatch PANTONE Process Cyan Process Magenta Process Yellow Process Black T-Mobile Magenta
