RF Exposure TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Date: Mar. 05, 2015 ATTN: Reviewing Engineer RF exposure information for FCC ID: R3A-ROT114 Model: ROT114 1. Introduction: The device ROT114 (FCC ID: R3A-ROT114) is designed to be used in portable exposure conditions. This product integrates a ANT+ transmitter operated in 2457 MHz frequency band. 2. Output power considerations: ANT+ transmitter: 1.35 dBm (1.365 mW) Conducted / -6.32 dBm (0.233 mW) eirp 3. Compliance criteria: Transmitter is deeded to comply with FCC § 2.1093 requirements and IC RSS-102 Issue 5 as the output power of the device meets the conditions specified in section 4.3.1 (SAR test exclusion) considerations of the document “KDB 447498 D01 General RF Exposure Guidance v05r02” and in section 2.5.1 (Exemption from Routine Evaluation Limits – SAR Evaluation) of RSS-102 Issue 5. [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0
[1.365/5] · [√2.457] = 0.428 ≤ 3 Signed on behalf of ROTOR COMPONENTES TECNOLOGICOS SL, p.a. Contact Name: Mr DAVID MARTINEZ GARCIA Contact Position: ENGINEERING MANAGER Contact Email: [email protected] ContactPhone: +34662116549

AT4 wireless, S.A. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España www.at4wireless.com · C.I.F. A29 507 456 Report No: (NIE) 42753RRF.001 Page 1 of 28 2015-02-02 FCC LISTED, REGISTRATION NUMBER: 720267 IC LISTED REGISTRATION NUMBER IC 4621A-1 Informe de ensayo nº: Test report No: NIE: 42753RRF.001 Test report USA FCC Part 15.247, 15.209 CANADA RSS-210, RSS-Gen Radio Frequency Devices. Operation within the bands 902 - 928 MHz, 2400 -2483.5 MHz, and 5725 - 5850 MHz. Licence-Exempt Radio Apparatus (All Frequency Bands): Category I Equipment. General Requirements and Information for the Certification of Radio Apparatus. Identificación del objeto ensayado ...................... : Identification of item tested Torque and power sensor for bicycles Marca ................................................................... : Trade ROTOR Modelo y/o referencia tipo .................................. : Model and /or type reference ROT114 Other identification of the product .................... : Commercial name: IN POWER FCC ID: R3A-ROT114 IC: 10992A-ROT114 Final HW version ................................................ : 1.0 Final SW version ................................................. : 1.0 Serial number ...................................................... : --- Características ..................................................... : Features 2.4 GHz band. Single cannel 2457 MHz transmitter. DC power supply from battery Peticionario ......................................................... : Applicant ROTOR COMPONENTES TECNOLOGICOS SL C/ MINO 16-18.POL. IND. CONMAR 28864. AJALVIRM. SPAIN. Contact person: David Martínez García Telephone: +34 662116549 e-mail: [email protected] Método de ensayo solicitado, norma ................... : Test method requested, standard USA FCC Part 15.247 10-1-13 Edition: Operation within the bands 902 - 928 MHz, 2400 -2483.5 MHz, and 5725 - 5850 MHz. USA FCC Part 15.209 10-1-13 Edition: Radiated emission limits; general requirements. CANADA RSS-210 Issue 8 (December 2010). CANADA RSS-Gen Issue 4 (November 2014). Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247 558074 D01 DTS Meas Guidance v03r02 dated 05/06/2014. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices. AT4 wireless, S.A. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España www.at4wireless.com · C.I.F. A29 507 456 Report No: (NIE) 42753RRF.001 Page 2 of 28 2015-02-02 Resultado .............................................................. : Summary IN COMPLIANCE Aprobado por (nombre / cargo y firma) ........... : Approved by (name / position & signature) A. Llamas RF Lab. Manager Fecha de realización ........................................... : Date of issue 2015-02-02 Formato de informe No. ...................................... : Report template No FDT08_15 AT4 wireless, S.A. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España www.at4wireless.com · C.I.F. A29 507 456 Report No: (NIE) 42753RRF.001 Page 3 of 28 2015-02-02 Index Competences and guarantees ......................................................................................................................... 4 General conditions ......................................................................................................................................... 4 Uncertainty .................................................................................................................................................... 4 Usage of samples ........................................................................................................................................... 4 Test sample description ................................................................................................................................. 5 Test samples supplier .................................................................................................................................... 5 Testing period ................................................................................................................................................ 5 Environmental conditions .............................................................................................................................. 5 Remarks and comments ................................................................................................................................. 6 Testing verdicts ............................................................................................................................................. 7 Appendix A – Test result ............................................................................................................................... 8 AT4 wireless, S.A. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España www.at4wireless.com · C.I.F. A29 507 456 Report No: (NIE) 42753RRF.001 Page 4 of 28 2015-02-02 Competences and guarantees AT4 wireless is a laboratory with a measurement facility in compliance with the requirements of Section 2.948 of the FCC rules and has been added to the list of facilities whose measurements data will be accepted in conjuction with applications for Certification under Parts 15 or 18 of the Commission's Rules. Registration Number: 720267. AT4 wireless is a laboratory with a measurement site in compliance with the requirements of RSS 212, Issue 1 (Provisional) and has been added to the list of filed sites of the Canadian Certification and Engineering Bureau. Reference File Number: IC 4621A-1. In order to assure the traceability to other national and international laboratories, AT4 wireless has a calibration and maintenance program for its measurement equipment. AT4 wireless guarantees the reliability of the data presented in this repo…
