R5Y-EZWFM06ER802.11a/b/g WLAN Mini PCI Module

EAZIX, Inc. Unit 301 Plaz@ B, 6530 Northgate Avenue, Filinvest Corporate City, Alabang, Muntinlupa City, Philippines 1700 Document #: R.EZWFM06ER.HW11.01 Title: EZWFM06ER User Manual Page #: 1 of 22 COMPANY CONFIDENTIAL INFORMATION Copyright © 2006 EAZIX, Inc. All rights reserved. Uncontrolled and unofficial unless directly viewed from EAZIX eDMS NOTICE TO THE USER: *This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. The user is cautioned that changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. NOTICE TO OEM INTEGRATORS: *When this unit is placed inside of your host device, you must attach a label stating the following: "This device contains FCC ID: R5Y-EZWFM06ER" to the outside of the final product. FCC RF EXPOSURE INFORMATION WARNING! Read this information before using the device In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this device complies with the FCC guidelines and these international standards. Operating Requirements The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antennas or transmitters. Please maintain 20 cm separation distance from the antenna to meet FCC RF ex posure compliance requirements. Specifically: In order to comply with FCC RF exposure requirements, OEM integrators must install this mini PCI card in notebook PCs with the antenna mounted inside or on the LCD display 20 cm from the end user. In addition, OEM integrators must inform end users of the following: “In order too comply with FCC RF exposure requirements, this device must be operated in such a way that a minimum 20cm separation distance is maintained between the antenna, and all persons, during normal operation.” FCC Radio Frequency Interference Requirements This product is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz frequency range. FCC requires this product to be used indoors for the frequency range 5.15 to 5.25 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems. High power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can cause interference with and/ or damage this product. EAZIX, Inc. Unit 301 Plaz@ B, 6530 Northgate Avenue, Filinvest Corporate City, Alabang, Muntinlupa City, Philippines 1700 Document #: R.EZWFM06ER.HW11.01 Title: EZWFM06ER User Manual Page #: 2 of 22 COMPANY CONFIDENTIAL INFORMATION Copyright © 2006 EAZIX, Inc. All rights reserved. Uncontrolled and unofficial unless directly viewed from EAZIX eDMS Introduction The EAZIX EZWFM06ER is a cost effective wireless module with MiniPCI interface, which enables embedded solutions. It incorporates the IEEE.802.11a/b/g WLAN. It provides OFDM data rates of 54, 48, 36, 24, 18, 12, 9 and 6Mbps in both the 2.4 and 5GHz bands, as well as CCK data rates for backward- compatibility with any installed 802.11b WLAN base. OFDM also provides the speed required up to 54Mbps for today’s high-bandwidth applications. The EZWFM06ER Mini-PCI module is based on the Conexant PRISM WorldRadio chipset. Features: • IEEE 802.11a/b/g/h/j compliant • 64-, 128 bit WEP • WiFi Protected Access • Frequency Range: 2.412 to 2.484 GHz and 4.9GHz to 5.9GHz • Data Rates for 2.4GHz: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54 Mbps • Data Rates for 5GHz: 6, 9, 12, 18, 24, 36, 48, 54 Mbps • Modulation Techniques: OFDM with BPSK, QPSK, 16QAM, 64QAM; DBPSK, DQPSK, CCK • Outdoors range of up to 300 feet • Operating Temperature Range of -20° C to 70°C • Mini-PCI host interface with Type 3B form factor • Driver Support for Microsoft Windows 98SE/ME/NT/2000/XP 1 Installation Procedure 1.1 Installing the card into the host computer 1.1.1 Turn the host computer off; insert the WLAN card into the mini PCI slot, shown in Figure 1.1. Figure 1.1: Insertion and Removal of the Mini-PCI Board EAZIX, Inc. Unit 301 Plaz@ B, 6530 Northgate Avenue, Filinvest Corporate City, Alabang, Muntinlupa City, Philippines 1700 Document #: R.EZWFM06ER.HW11.01 Title: EZWFM06ER User Manual Page #: 3 of 22 COMPANY CONFIDENTIAL INFORMATION Copyright © 2006 EAZIX, Inc. All rights reserved. Uncontrolled and unofficial unless directly viewed from EAZIX eDMS The highlighted antenna port, shown in Figure 1.2, is the proper antenna port used for antenna connection during testing. Figure 1.2: Antenna port 1.2 Installing the software drivers 1.2.1 Boot PC with the mini-PCI unit. Log in to PC; assure that user has Administrator Level for a successful installation. Refer to related Windows OS document on how to set the User Level. 1.2.2 Windows will recognize the new device and will launch the New Hardware Found Wizard. Select Install from a list or specific location. Select Search for best drivers in this location. Specify the location of the Driver Package where Globespan Virata (GSV) driver SingleSource_Windows_Driver_Package_2.1.15.0) is located. 1.2.3 A message will appear specifying that the driver is not signed. Select Continue Installation and then Finish Installation when done. 1.2.4 To check if the device is successfully installed open the device manager and check under Network Adapters for the WLAN device as shown in Figure 2.1 2 Windows settings 2.1 The device should appear in the Device Manager list wh…

Text truncated - open the document above for the full version.

Eazix, Inc. Unit 301 Plaz@ B, 6530 Northgate Avenue, Filinvest Corporate City, Alabang, Muntinlupa City, Philippines 1700 March 22, 2006 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re: EAZIX, Inc. FCC ID: R5Y-EZWFM06ER Modular Transmitter Approval Gentlemen: With regards to our application for equipment authorization of the Mini PCI module, listed below are the modular approval requirements with which the EUT complies: a. The modular transmitter has its own RF shielding. The shield is made of steel, tin coated. This is intended to ensure that the modules do not have to rely upon the shielding provided by the device into which it is installed in order for all modular coupling between the RF circuitry of the module and any wires or circuits in the device into which the module is installed. Such coupling may result in non-compliant operation. b. The modular transmitter has buffered modulation/data inputs to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. This is taken care of the Baseband Processor (BBP) chipset used. c. The modular transmitter has its own power supply regulation provided by voltage regulator ISL6414IR. This is intended to ensure that the module will comply with Part 15 requirements regardless of the power supplying circuitry in the device into which the module is installed. d. The modular transmitter complies with the antenna requirements or Section 15.203 and 15.204(c). The antenna employs a “unique” antenna coupler Mini Eazix, Inc. Unit 301 Plaz@ B, 6530 Northgate Avenue, Filinvest Corporate City, Alabang, Muntinlupa City, Philippines 1700 PCB between the cable and the antenna, and a proprietary connector between the cable and the EUT. A single antenna, as described in the filing, is the only one currently approved for use with the EUT. e. The modular transmitter has been tested in a stand-alone configuration, i.e. the module was completely uncovered inside the host pc during testing. This demonstrates that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. The transmitter module complies with the AC line conducted requirements found in Section 15.207. The antenna cable connected to the module does not contain ferrites. f. The modular transmitter is labeled with its own FCC ID number, and the OEM is instructed to provide an exterior label to be placed on the device into which the EUT is installed. g. There are no specific rules or operating requirements applicable to the transmitter with respect to user operation. h. The modular transmitter complies with the applicable RF exposure requirements, as specified in Section 15.247. The EUT is a mobile device. The installation instructions caution the user to install and operate the EUT in such a way that a minimum 20 cm separation distance is maintained between the antenna and all persons during normal operation. Sincerely, Arnel G. Lampa Senior Division Manager EAZIX, Inc.

Eazix FCC ID: R5Y-EZWFM06ER EUT Photographs © 2006 PCTEST Lab. 802.11 a/b/g WLAN Mini PCI Module NVLAP Lab Code: 100431-0

CONFIDENTIAL PROPERTY OF PCTEST UNLICENSED NATIONAL INFORMATION INFRASTRUCTURE (NII), FCC RULE PART 15.407 PCTEST LAB TEST REPORT 15.407 FCC CERTIFICATION REPORT Reviewed by: Quality Manager Filename: 0604030221 Test Dates: May 9-23, 2006 EUT Type: 802.11a/b/g WLAN Mini PCI Module FCC ID: R5Y-EZWFM06ER Page 28 of 34 © 2006PCTEST Engineering Laboratory, Inc. EXHIBIT B – Labeling Requirements Sample Label & Location New Labeling Requirements Per 2.1074 & 15.19; Docket 95-19 The sample label shown below shall be permanently affixed at a conspicuous location on the device; instruction manual or pamphlet supplied to the user and be readily visible to the purchaser at the time of purchase. However, when the device is so small wherein placement of the label with specified statement is not practical, only the trade name, FCC ID, and the FCC logo must be displayed on the device per Section 15.19 (b)(2). CONFIDENTIAL PROPERTY OF PCTEST UNLICENSED NATIONAL INFORMATION INFRASTRUCTURE (NII), FCC RULE PART 15.407 PCTEST LAB TEST REPORT 15.407 FCC CERTIFICATION REPORT Reviewed by: Quality Manager Filename: 0604030221 Test Dates: May 9-23, 2006 EUT Type: 802.11a/b/g WLAN Mini PCI Module FCC ID: R5Y-EZWFM06ER Page 29 of 34 © 2006PCTEST Engineering Laboratory, Inc. EXHIBIT B – Labeling Requirements (Cont.) Sample Label & Location FCC ID LABEL

Eazix FCC ID: R5Y-EZWFM06ER EUT Photographs © 2006 PCTEST Lab. 802.11 a/b/g WLAN Mini PCI Module NVLAP Lab Code: 100431-0 Eazix FCC ID: R5Y-EZWFM06ER EUT Photographs © 2006 PCTEST Lab. 802.11 a/b/g WLAN Mini PCI Module NVLAP Lab Code: 100431-0 Eazix FCC ID: R5Y-EZWFM06ER EUT Photographs © 2006 PCTEST Lab. 802.11 a/b/g WLAN Mini PCI Module NVLAP Lab Code: 100431-0 Eazix FCC ID: R5Y-EZWFM06ER EUT Photographs © 2006 PCTEST Lab. 802.11 a/b/g WLAN Mini PCI Module NVLAP Lab Code: 100431-0

© 2006 CTEST Engineering Laboratory, Inc. RF Exposure Evaluation - Maximum Permissible Exposure (MPE) 1. Introduction This document attempts to prove the safety of radiation generated by RF devices to the human body. The limit for Maximum Permissible Exposure (MPE), specified in FCC 1.1210, is listed below. The power generated by this product is measured by a power meter. Through use of the Friis transmission formula and the maximum gain of the antenna, the distance from the product at which compliance with the MPE limit is achieved may be calculated. Alternatively, near field measurements may be performed to demonstrate compliance at a specific measurement distance. Near field probe: Wandel & Goltermann EMR-20. 2. RF Exposure Limit According to FCC 1.1310: the criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits For Occupational / Control Exposures 30-300 61.4 .163 1.0 6 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B) Limits For General Population / Uncontrolled Exposure 30-300 27.5 .073 .2 30 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. Friis Formula Friis transmission formula: Pd = (P out *G) / (4πr 2 ) Where: Pd = power density in mW/cm 2 (MPE limit) P out = output power to antenna in mW G = gain of antenna in linear scale π = 3.1416 r = distance between observation point and center of the radiator in cm Ref.: David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11.133) © 2006 CTEST Engineering Laboratory, Inc. 4. EUT Operating Condition Software provided by the client enabled the EUT to transmit and receive data at lowest, middle, and highest channels individually. 5. Climate Condition The temperature and relative humidity: 22 ̊C and 78% RH 6. Measurement Results Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) 11 2437 40.0 .008 11 2437 35.6 .007 157 5785 25.2 .005 1. Data taken with all transmitters operating simultaneously 7. Conclusion The device meets the mobile 20cm separation distance as specified in Section 2.1091 of the FCC Rules. An appropriate RF exposure compliance statement will be placed in the user’s manual.

CONFIDENTIAL PROPERTY OF PCTEST UNLICENSED NATIONAL INFORMATION INFRASTRUCTURE (NII), FCC RULE PART 15.407 PCTEST ENGINEERING LABORATORY, INC. 6660 – B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE MANUFACTURER NAME & ADDRESS: DATE & LOCATION OF TESTING: EAZIX, INC. Date(s) of Tests: May 9-23, 2006 Unit 301 Plaz@ B, 6530 Northgate Avenue, Test Report S/N: 0604030221 Filinvest Corporate City, Alabang, Test Site: PCTEST Lab, Columbia, MD Multinlupa City, Philippines 1770 FCC ID: R5Y-EZWFM06ER APPLICANT: EAZIX, INC. - SUMMARY: Model: EZWFM06ER Equipment EUT Type: 802.11a/b/g WLAN Mini PCI Module Max. Output Power: 15.1 dBm (Peak) Conducted (Low Band) 16.0 dBm (Peak) Conducted (High Band) Frequency Range: 5180 – 5240 MHz (Low Band) 5260 – 5320 MHz (High Band) FCC Classification: Unlicensed National Information Infrastructure (NII) FCC Rule Part(s): Parts 15.407; ANSI C-63.4-2003 Test Device Serial No.: S/N: 050722C00358 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C-63.4-2003. The EUT was tested with cover for the mini PCI access slot removed. I authorize and attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. CONFIDENTIAL PROPERTY OF PCTEST UNLICENSED NATIONAL INFORMATION INFRASTRUCTURE (NII), FCC RULE PART 15.407 Page i © 2006PCTEST Engineering Laboratory, Inc. TABLE OF CONTENTS ATTESTATION STATEMENTS.............................................................................................................................1 FCC PART 15 E MEASUREMENT REPORT COVER PAGE......................................................................................2 1.0 INTRODUCTION............................................................................................................................................3 1.1 EVALUATION PROCEDURE........................................................................................................................................................3 1.2 SCOPE...........................................................................................................................................................................................3 1.3 PCTEST TEST LOCATION.............................................................................................................................................................3 2.0 PRODUCT INFORMATION...........................................................................................................................4 2.1 EQUIPMENT DESCRIPTION........................................................................................................................................................4 2.2 ENCLOSURE.................................................................................................................................................................................4 2.3 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS.......................................................................................................................4 3.0 DESCRIPTION OF TEST.................................................................................................................................5 3.1 CONDUCTED EMISSIONS..........................................................................................................................................................5 3.2 RADIATED EMISSIONS................................................................................................................................................................6 4.0 ANTENNA REQUIREMENTS..........................................................................................................................7 5.0 TEST EQUIPMENT CALIBRATION DATA.....................................................................................................8 6.1 CONCLUSION.....................................................................................................................9 EXHIBIT A. SUMMARY OF TEST RESULTS.................................................................................................................10 EXHIBIT A. 26dB BANDWIDTH MEAUREMENT.........................................................................................................11-13 EXHIBIT A. OUTPUT POWER MEASUREMENT...........................................................................................................14-15 EXHIBIT A. FREQUENCY STABILITY..........................................................................................................................16-17 EXHIBIT A. PEAK POWER SPECTRAL DENSITY...........................................................................................................18-20 EXHIBIT A. PEAK EXCURSION RATIO DENSITY.........................................................................................................21-23 EXHIBIT A. UNDESIREABLE EMMISSIONS.................................................................................................................24-27 EXHIBIT A. LINE CONDUCTED.. ....................................................................................................................28 EXHIBIT B. LABELING REQUIREMENTS....................................................................................................................29-30 EXHIBIT C. BLOCK DIAGRAMS…

Text truncated - open the document above for the full version.

Eazix FCC ID: R5Y-EZWFM06ER EUT Photographs © 2006 PCTEST Lab. 802.11 a/b/g WLAN Mini PCI Module NVLAP Lab Code: 100431-0 Eazix FCC ID: R5Y-EZWFM06ER EUT Photographs © 2006 PCTEST Lab. 802.11 a/b/g WLAN Mini PCI Module NVLAP Lab Code: 100431-0 Eazix FCC ID: R5Y-EZWFM06ER EUT Photographs © 2006 PCTEST Lab. 802.11 a/b/g WLAN Mini PCI Module NVLAP Lab Code: 100431-0 Eazix FCC ID: R5Y-EZWFM06ER EUT Photographs © 2006 PCTEST Lab. 802.11 a/b/g WLAN Mini PCI Module NVLAP Lab Code: 100431-0 Eazix FCC ID: R5Y-EZWFM06ER EUT Photographs © 2006 PCTEST Lab. 802.11 a/b/g WLAN Mini PCI Module NVLAP Lab Code: 100431-0
