R68E213WE210 Series

E210 Series Cellular Router User Guide Part Number PMD-00017 Revision B February 2021 E210 Series Cellular Router User Guide 1 Intellectual Property © 2019-2021 Lantronix, Inc. All rights reserved. No part of the contents of this publication may be transmitted or reproduced in any form or by any means without the written permission of Lantronix. Lantronix is a registered trademark of Lantronix, Inc. in the United States and other countries. Patented: https://www.lantronix.com/legal/patents/ . Additional patents pending. Windows and Internet Explorer are registered trademarks of Microsoft Corporation. Firefox is a registered trademark of the Mozilla Foundation. Chrome is a trademark of Google Inc. All other trademarks and trade names are the property of their respective holders. Warranty For details on the Lantronix warranty policy, please go to our web site at https://www.lantronix.com/support/warranty . Contacts Lantronix, Inc. 7535 Irvine Center Drive, Suite 100 Irvine, CA 92618, USA Toll Free: 800-526-8766 Phone: 949-453-3990 Fax: 949-453-3995 Technical Support Online: www.lantronix.com/support Sales Offices For a current list of our domestic and international sales offices, go to the Lantronix web site at www.lantronix.com/about-us/contact Disclaimer All information contained herein is provided “AS IS.” Lantronix undertakes no obligation to update the information in this publication. Lantronix does not make, and specifically disclaims, all warranties of any kind (express, implied or otherwise) regarding title, non-infringement, fitness, quality, accuracy, completeness, usefulness, suitability or performance of the information provided herein. Lantronix shall have no liability whatsoever to any user for any damages, losses and causes of action (whether in contract or in tort or otherwise) in connection with the user’s access or usage of any of the information or content contained herein. The information and specifications contained in this document are subject to change without notice. E210 Series Cellular Router User Guide 2 Open Source Software Some applications are Open Source software licensed under the Berkeley Software Distribution (BSD) license, the GNU General Public License (GPL) as published by the Free Software Foundation (FSF), or the Python Software Foundation (PSF) License Agreement for Python 2.7.3 (Python License). Lantronix grants you no right to receive source code to the Open Source software; however, in some cases, rights and access to source code for certain Open Source software may be available directly from Lantronix’ licensors. Your use of each Open Source component or software is subject to the terms of the applicable license. The BSD license is available at http://opensource.org/licenses . The GNU General Public License is available at http://www.gnu.org/licenses/. The Python License is available at http://cmpt165.csil.sfu.ca/Python-Docs/license.html. Your use of each Open Source component or software is subject to the terms of the applicable license. OPEN SOURCE SOFTWARE IS DISTRIBUTED WITHOUT ANY WARRANTY, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. SEE THE APPLICABLE LICENSE AGREEMENT FOR ADDITIONAL INFORMATION. You may request a list of the open source components and the licenses that apply to them. Contact your regional Lantronix sales associate. https://www.lantronix.com/about-us/contact/ Revision History Date Rev. Comments Sep., 2017 1.0 First release Oct., 2017 1.1 RAM size and model list Nov., 2017 1.2 Compatible models Jun., 2018 1.3 Compatible models Apr., 2019 1.4 Power consumption, Accessories and LED Status Indicator. October 2019 A Initial Lantronix document. Added Lantronix document part number, Lantronix logo, branding, contact information, and links. February 2021 B Updated the compatible models, accessories, LED states, reset button behavior, physical installation procedures, default login credentials, and Web Admin console screenshots. Reorganized content and made document enhancements. For the latest revision of this product document, please check our online documentation at www.lantronix.com/support/documentation . E210 Series Cellular Router User Guide 3 Contents 1 Safety Precautions 4 1.1 General Precautions ________________________________________ 4 1.2 Using the Router in Vehicles __________________________________ 4 1.3 Protecting Your Router_______________________________________ 4 2 About this Guide 5 2.1 Purpose and Audience _______________________________________ 5 2.2 Additional Documentation ____________________________________ 5 3 E210 Series Compatible Models 6 4 Product Features 7 4.1 General Specification ________________________________________ 7 4.2 Power Consumption (mA) ____________________________________ 7 4.3 Back Panel Connections _____________________________________ 9 4.4 Front Panel Connections ____________________________________ 10 4.5 LED Status Indicators ______________________________________ 11 5 Installation 12 5.1 Package Contents _________________________________________ 12 5.2 User Supplied Items ________________________________________ 12 5.3 Optional Add-on ___________________________________________ 12 5.4 Accessories ______________________________________________ 12 5.5 Preparing to Install _________________________________________ 14 5.5.1 Enabling DHCP on Your Personal Computer ________________ 14 5.6 Connecting the E210 Router _________________________________ 15 5.6.1 Insert SIM Cards ______________________________________ 15 5.6.2 Connect the Antennas _________________________________ 16 5.6.3 Connect the AC Power _________________________________ 17 5.6.4 Connect the Router to a Computer _______________________ 17 5.6.5 Quick Setup _________________________________________ 19 5.6.6 Default Configuration __________________________________ 21 5.6.7 SNAP CAP™ RS-485 __________________________________ 22 E210 Series Cellular Router User Guide 4 1 Safety …

Text truncated - open the document above for the full version.

Date: September 28, 2022 We, lantronix declare that the device does not support channel 12 ~ 13 in 2.4GHz band and any non-US channels in all the operational mode(s) for the following product. FCC ID: R68E213W If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! ----------------------------------- Fathi Hakam, VP of Engineering lantronix Tel: 949-453-3990 Fax: 949-453-3995 E- mail: [email protected]

Date: 2022-09-28 FCC ID: R68E213W To the attention of Federal Communications Commission Authorization and Evaluation Division Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ----------------------------------- Fathi Hakam, VP of Engineering lantronix Tel: 949-453-3990 Fax: 949-453-3995 E- mail: [email protected]

Date: 2022-09-28 FCC ID: R68E213W AUTHORIZATION LETTER To Whom It May Concern: lantronix hereby authorizes Emerald Chen / Specialist of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (“BV CPS Taoyuan”), to act on its behalf in all matters relating to the Federal Communication Commission (“FCC”) application for equipment authorization in connection with the FCC ID listed above, including signing of all documents relating to these matters. Any and all acts carried out by Emerald Chen / Specialist of BV CPS Taoyuan on Lantronix, Inc.’s behalf, within the scope of the powers granted herein, shall have the same effect as acts of its own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, ----------------------------------------------- Fathi Hakam , VP of Engineering lantronix Tel: 949-453-3990 Fax: 949-453-3995 E-mail: [email protected]

Date: 11/03/2022 We, LANTRONIX, hereby declare that our product with FCC ID: R68E213W contains certified WWAN module that FCC ID: R68E213 which support GSM, GPRS and LTE Bands 2/4/5/12/13/25/26/66. Our product only enabled in GSM, GPRS and LTE Bands 2/4/5/12/13/25/26 via software when sold to the USA. Software cannot be modified by end-users or any other third parties. If you have any questions regarding the authorization, please do not hesitate to contact us. Thank you! ---------------------------------------- Fathi Hakam, VP of Engineering LANTRONIX Tel: +1 (949) 453-3990 Fax: +1 (949) 453-3995 E-mail: [email protected]

Reference No.: BHAT-WTW-P21060603_EXT 1 of 7 CONSTRUCTION PHOTOS OF EUT Reference No.: BHAT-WTW-P21060603_EXT 2 of 7 Reference No.: BHAT-WTW-P21060603_EXT 3 of 7 Reference No.: BHAT-WTW-P21060603_EXT 4 of 7 Reference No.: BHAT-WTW-P21060603_EXT 5 of 7 Reference No.: BHAT-WTW-P21060603_EXT 6 of 7 Reference No.: BHAT-WTW-P21060603_EXT 7 of 7

Bottom of EUT

Reference No.: BHAT-WTW-P21060603_INT 1 of 5 CONSTRUCTION PHOTOS OF EUT Reference No.: BHAT-WTW-P21060603_INT 2 of 5 Reference No.: BHAT-WTW-P21060603_INT 3 of 5 Reference No.: BHAT-WTW-P21060603_INT 4 of 5 Reference No.: BHAT-WTW-P21060603_INT 5 of 5

Report No.: MFBHAT-WTW-P21060603 Page No. 1 / 6 Report Format Version: 6.1.1 RF Exposure Report Report No.: MFBHAT-WTW-P21060603 FCC ID: R68E213W Test Model: E213F102S Received Date: Oct. 14, 2021 Date of Evaluation: Jul. 04, 2022 Issued Date: Sep. 30, 2022 Applicant: Lantronix Address: 7535 Irvine Center Drive, Suite 100, Irvine, CA 92618 USA Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, TAIWAN FCC Registration / Designation Number: 788550 / TW0003 This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Report No.: MFBHAT-WTW-P21060603 Page No. 2 / 6 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits for Maximum Permissible Exposure (MPE) .............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 3 Calculation Result of Maximum Conducted Power ........................................................................... 6 Report No.: MFBHAT-WTW-P21060603 Page No. 3 / 6 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued MFBHAT-WTW-P21060603 Original Release Sep. 30, 2022 Report No.: MFBHAT-WTW-P21060603 Page No. 4 / 6 Report Format Version: 6.1.1 1 Certificate of Conformity Product: E210 Series Brand: LANTRONIX Test Model: E213F102S Sample Status: Identical Prototype Applicant: Lantronix Date of Evaluation: Jul. 04, 2022 FCC Rule Part: FCC Part 2 (Section 2.1091) Standards: KDB 447498 D01 General RF Exposure Guidance v06 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s RF characteristics under the conditions specified in this report. Prepared by : , Date: Sep. 30, 2022 Vera Huang / Specialist Approved by : , Date: Sep. 30, 2022 Jeremy Lin / Project Engineer Report No.: MFBHAT-WTW-P21060603 Page No. 5 / 6 Report Format Version: 6.1.1 2 RF Exposure 2.1 Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f 2 )* 30 30-300 27.5 0.073 0.2 30 300-1500 ... ... f/1500 30 1500-100,000 ... ... 1.0 30 f = Frequency in MHz; *Plane-wave equivalent power density 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: MFBHAT-WTW-P21060603 Page No. 6 / 6 Report Format Version: 6.1.1 3 Calculation Result of Maximum Conducted Power Band Max AV Power (dBm) Duty Cycle Time-Average Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) GPRS 850 33.5 25% 27.48 1 20 0.140 0.55 GPRS 1900 30.5 25% 24.48 3 20 0.111 1.00 LTE B2 24.5 100% 24.5 6 20 0.223 1.00 LTE B4 24.5 100% 24.5 6 20 0.223 1.00 LTE B5 24.5 100% 24.5 4 20 0.141 0.55 LTE B12 24.5 100% 24.5 3 20 0.112 0.46 LTE B13 24.5 100% 24.5 3 20 0.112 0.52 LTE B25 24.5 100% 24.5 6 20 0.223 …

Text truncated - open the document above for the full version.

SPE-11-8-125/G/WY Page 1 of 28 SPECIFICATION Part No. : GW.71.5153 Product Name : 2.4GHz/5.8GHz Dipole Antenna for ISM Band and WLAN IEEE 802.11a/b/g/h Feature : 5dBi High Performance Antenna RP-SMA(M) Hinged Antenna RoHS Compliant Address: Old Finglas Road, Glasnevin, Dublin 11 D11 KXN4 SPE- 11-8-125/G/WY Page 2 of 28 1. Introduction Many module manufacturers specify peak gain limits for any antennas that are to be connected to that module. Those peak gain limits are based on free-space conditions. In practice, the peak gain of an antenna tested in free-space can degrade by at least 1 or 2dBi when put inside a device. So ideally you should go for a slightly higher peak gain antenna than mentioned on the module specification to compensate for this effect, giving you better performance. Upon testing of any of our antennas with your device and a selection of appropriate layout, integration technique, or cable, Taoglas can make sure any of our antennas’ peak gain will be below the peak gain limits. Taoglas can then issue a specification and/or report for the selected antenna in your device that will clearly show it complying with the peak gain limits, so you can be assured you are meeting regulatory requirements for that module. For example, a module manufacturer may state that the antenna must have less than 2dBi peak gain, but you don’t need to select an embedded antenna that has a peak gain of less than 2dBi in free-space. This will give you a less optimized solution. It is better to go for a slightly higher free-space peak gain of 3dBi or more if available. Once that antenna gets integrated into your device, performance will degrade below this 2dBi peak gain due to the effects of GND plane, surrounding components, and device housing. If you want to be absolutely sure, contact Taoglas and we will test. Choosing a Taoglas antenna with a higher peak gain than what is specified by the module manufacturer and enlisting our help will ensure you are getting the best performance possible without exceeding the peak gain limits. SPE- 11-8-125/G/WY Page 3 of 28 2. Specification ELECTRICAL Frequency 2.4 ~ 2.5GHz, 4.9 ~ 5.8GHz VSWR <2 <2.1 Peak Gain (straight) 3.3dBi 4.9dBi Peak Gain (bend) 3.32dBi 5.5dBi Average Gain (straight) -0.9dBi-1.5dBi Average Gain (bend) -0.7dBi-0.0dBi Efficiency (straight) 80% 71% Efficiency (bend) 86% 83% Polarization Linear Impedance 50 Ohms Radiation Pattern Omni Input Power 2W max. MECHANICAL Antenna Length 194mm Antenna Diameter 12.8mm Weight 24.6g Antenna Body Material TPU ENVIRONMENTAL Temperature Range -40°C to 85°C Humidity Non-condensing 65°C 95% RH SPE- 11-8-125/G/WY Page 4 of 28 3.Antenna S11 Property 3.1. Return Loss -40 -35 -30 -25 -20 -15 -10 -5 0 200025003000350040004500500055006000 (MHz) (dB) straight bend 3.2. VSWR 1 2 3 4 5 6 7 8 200025003000350040004500500055006000 (MHz) straight bend SPE- 11-8-125/G/WY Page 5 of 28 4.3D Radiation Property 4.1. Radiation Efficiency 0 10 20 30 40 50 60 70 80 90 100 2300235024002450250025502600 (%) straight bend (MHz) 0 10 20 30 40 50 60 70 80 90 100 4800500052005400560058006000 (%) straight bend (MHz) SPE- 11-8-125/G/WY Page 6 of 28 4.2. Peak Gain 0 1 2 3 4 5 2300235024002450250025502600 (dBi) striaght bend (MHz) 1 2 3 4 5 6 4800500052005400560058006000 (dBi) straight bend (MHz) SPE- 11-8-125/G/WY Page 7 of 28 4.3. Average Gain -5 -4 -3 -2 -1 0 2300235024002450250025502600 (dBi) straight bend (MHz) -5 -4 -3 -2 -1 0 4800500052005400560058006000 (dBi) straight bend (MHz) SPE- 11-8-125/G/WY Page 8 of 28 4.4. Radiation Pattern E-Plane Radiation of Straight Position -35 -30 -25 -20 -15 -10 -5 0 5 0 30 60 90 120 150 180 210 240 270 300 330 2.45GHz 5.0GHz 5.8GHz SPE- 11-8-125/G/WY Page 9 of 28 H-Plane Radiation of Straight Position -35 -30 -25 -20 -15 -10 -5 0 5 0 30 60 90 120 150 180 210 240 270 300 330 2.45GHz 5.0GHz 5.8GHz E-Plane Radiation of Bend Position -35 -30 -25 -20 -15 -10 -5 0 5 0 30 60 90 120 150 180 210 240 270 300 330 2.45GHz 5.0GHz 5.8GHz SPE- 11-8-125/G/WY Page 10 of 28 H-Plane Radiation of Bend Position -35 -30 -25 -20 -15 -10 -5 0 5 0 30 60 90 120 150 180 210 240 270 300 330 2.45GHz 5.0GHz 5.8GHz SPE- 11-8-125/G/WY Page 11 of 28 5.Ground Plane Effect Three ground setups are used to see the affect of positioning GW.71 close to ground - 1.Small Ground (15 x 9cm) – common size of CPE devices. GW.71 is mounted at the longer edge for testing. 2.Big Ground Edge (45 x 30cm) – simulate the effect of mounting antenna on a base station device. GW.71 is mounted at the centre of the longer edge. 3.Big Ground Centre (45 x 30cm) – simulate the effect of mounting antenna in a centre of a big ground plane, such as vehicle top. Free space Small ground edge Big ground edge Big ground center SPE- 11-8-125/G/WY Page 12 of 28 6. Radiation Property of GW.71 with Different Ground 6.1. Radiation Efficiency of Straight GW.71 0 10 20 30 40 50 60 70 80 90 100 2300235024002450250025502600 (%) free space small gnd edge big gnd edge big gnd center (MHz) 0 10 20 30 40 50 60 70 80 90 100 4800500052005400560058006000 (%) free space small gnd edge big gnd edge big gnd center (MHz) SPE- 11-8-125/G/WY Page 13 of 28 6.2. Radiation Efficiency of Bend GW.71 0 10 20 30 40 50 60 70 80 90 100 2300235024002450250025502600 (%) free space small gnd edge big gnd edge big gnd center (MHz) 0 10 20 30 40 50 60 70 80 90 100 4800500052005400560058006000 (%) free space small gnd edge big gnd edge big gnd center (MHz) SPE- 11-8-125/G/WY Page 14 of 28 6.3. Peak Gain of Straight GW.71 0 1 2 3 4 5 6 7 8 2300235024002450250025502600 (dBi) free space small gnd edge big gnd edge big gnd center (MHz) 0 1 2 3 4 5 6 7 8 4800500052005400560058006000 (dBi) free space small gnd edge big gnd edge big gnd center (MHz) SPE- 11-8-125/G/WY Page 15 of 28 6.4. Peak Gain of Bend GW.71 0 1 2 3 4 5 6 7 8 2300235024002450250025502600 (dBi) free space small gnd edge big gnd edge big gnd center (MHz) 0 1 2 3 4 5 6 7 8 4800500052005400560058006000 (dBi) free space small gnd edge big gnd…

Text truncated - open the document above for the full version.

Report No.: RFBHAT-WTW-P21060603 Page No. 1 / 54 Report Format Version: 7.1.0 TEST REPORT CERTIFICATE OF CONFORMITY Standard: 47 CFR FCC Part 15, Subpart C (Section 15.247) Report No.: RFBHAT-WTW-P21060603 FCC ID: R68E213W Model No.: E213F102S Received Date: 2021/10/14 Test Date: 2022/6/14 ~ 2022/6/16 Issued Date: 2022/9/30 Applicant: Lantronix Address: 7535 Irvine Center Drive, Suite 100, Irvine, CA 92618 USA Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kewi Shan Dist., Taoyuan City 33383, Taiwan FCC Registration / Designation Number: 788550 / TW0003 Approved by: , Date: 2022/9/30 Jeremy Lin / Project Engineer This test report consists of 54 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. Prepared by : Vera Huang / Specialist This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our- business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Report No.: RFBHAT-WTW-P21060603 Page No. 2 / 54 Report Format Version: 7.1.0 Table of Contents Release Control Record ....................................................................................................................................................... 4 1 Certificate .................................................................................................................................................................... 5 2 Summary of Test Results .......................................................................................................................................... 6 2.1 Measurement Uncertainty ........................................................................................................................................ 6 2.2 Supplementary Information ...................................................................................................................................... 6 3 General Information ................................................................................................................................................... 7 3.1 General Description .................................................................................................................................................. 7 3.2 Antenna Description of EUT ..................................................................................................................................... 8 3.3 Channel List .............................................................................................................................................................. 8 3.4 Test Mode Applicability and Tested Channel Detail .................................................................................................. 9 3.5 Duty Cycle of Test Signal ........................................................................................................................................ 10 3.6 Test Program Used and Operation Descriptions .................................................................................................... 11 3.7 Connection Diagram of EUT and Peripheral Devices ............................................................................................ 11 3.8 Configuration of Peripheral Devices and Cable Connections ................................................................................ 11 4 Test Instruments ...................................................................................................................................................... 12 4.1 RF Output Power .................................................................................................................................................... 12 4.2 Power Spectral Density .......................................................................................................................................... 12 4.3 6 dB Bandwidth ...................................................................................................................................................... 12 4.4 Conducted Out of Band Emissions .....................…

Text truncated - open the document above for the full version.

Report No.: RFBHAT-WTW-P21060603-5 Page No. 1 / 40 Report Format Version: 6.1.1 FCC Test Report (Co-Located) Report No.: RFBHAT-WTW-P21060603-5 FCC ID: R68E213W Test Model: E213F102S Received Date: Oct. 14, 2021 Test Date: Oct. 24, 2022 Issued Date: Nov. 03, 2022 Applicant: Lantronix Address: 7535 Irvine Center Drive, Suite 100, Irvine, CA 92618 USA Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 70, Wenming Rd., Guishan Dist., Taoyuan City 333, Taiwan (R.O.C.) FCC Registration / Designation Number: 281270 / TW0032 This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Report No.: RFBHAT-WTW-P21060603-5 Page No. 2 / 40 Report Format Version: 6.1.1 Table of Contents Release Control Record ...........…

Text truncated - open the document above for the full version.
