R7PEC6R2S32-way Gas Module

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: R7PEC6R2S3 IC: 5294A-EC6R1S3 FCC Rule Part: 15.247, 15.249 IC Radio Standards Specification: RSS-210, RSS-247 ACS Project Number: 15-0160 Manufacturer: Landis+Gyr Technology, Inc. Model: GPR2 LANDIS+GYR CONFIDENTIAL INFORMATION GPR Installation Guide Publication: 98-1135 Rev AE Limitation on Warranties and Liability Information in this document is subject to change without notice. This manual or any part of it thereof may not be re- produced in any form unless permitted by contract or by written permission of Landis+Gyr. In no event will Landis+Gyr be liable for any incidental, indirect, special, or consequential damages (including lost prof- its) arising out of or relating to this publication or the information contained in it, even if Landis+Gyr has been advised, knew, or should have known of the possibility of such damages. © 2014-2015 Landis+Gyr, Inc. All Rights Reserved GPR Installation Guide Publication: 98-1135 Revision History Modification DateRevisionDescriptionAuthor 01/27/2014AAPre-Release DraftCharlie Goerges 02/20/2014AAReviewJake Harsha 06/19/2014AAReleasedCharlie Goerges 10/27/2014AB Updated Dresser Roots dial wheel installation; index cover part numbers Jake Harsha 12/15/2014ACReleasedCharlie Goerges 02/18/2015ADReleasedCharlie Goerges 05/08/2015AE Released - Updated tables, added images, removed Dresser Roots information, and added appendices C-F. Charlie Goerges Landis+Gyr Website: www.landisgyr.com E-mail: [email protected] Technical Support: 1-888-390-5733 © 2014-2015 Landis+Gyr All rights reserved. Installation Guide98-1135 Rev AE3 Table of Contents Chapter 1: Pre-Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Safety Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 FCC & Industry Canada Information to the User . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 FCC Class B. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 RF Exposure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Industry Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 GPR FCC Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Preliminary Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Site Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Required Installation Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Required Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 American Meters Required Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Index Cover Kits (Choose One). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Dial Wheels (Choose One) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 GPR + Brackets Kits (Choose One) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Rockwell Meters Required Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Index Cover Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Dial Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 GPR + Brackets Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Schlumberger Meters Required Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Index Cover Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Dial Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 GPR + Brackets Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Sprague Meters Required Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Index Cover Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Dial Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 GPR + Brackets Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Rotary Required Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Cable . . . . . . . . . . . . . . . . . . . . …

Text truncated - open the document above for the full version.

30000 Mill Creek Avenue, Suite 100 | Alpharetta, GA 30022 Tel: +1 678 258 1637 | Fax: +1 678 258 1681 Date: June 18, 2015 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Rd. Columbia, MD 21046 Dear Sir or Madam: I hereby appoint Sam Wismer at Advanced Compliance Solutions, Inc. to act as our agent in the preparation of an application for equipment authorization of FCC ID: R7PEC6R2S3 to the FCC Rules and Regulations. I certify that all exhibits contained within this filing properly describe the device or system for which authorization is sought. I further certify that appropriate arrangements have been made to assure that production units of this equipment bearing the name and FCC IDENTIFIER listed in this application will continue to comply with the Commission's requirements. I further certify by signature below that no party (per 47 CFR 1.2002(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Sincerely, Name: Richard Timko Title: Quality Engineer

30000 Mill Creek Avenue, Suite 100 | Alpharetta, GA 30022 Tel: +1 678 258 1637 | Fax: +1 678 258 1681 CONFIDENTIALITY REQUEST Federal Communications CommissionDate: June 18, 2015 Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: Landis+Gyr Technology, Inc. respectfully requests confidentiality of certain materials provided with the submission of the “GPR2” under FCC ID: R7PEC6R2S3 in accordance with 47 CFR 0.457(d) and 47 CFR 0.459. The confidentiality request applies to the System Block Diagram, Schematics, and Theory of Operation contained in this filing and included in the following files. 15-0160 – System Block Diagram.pdf 15-0160 – Theory of Operation.pdf 15-0160 – Schematics.pdf The “GPR2” has been developed at considerable effort and expense by Landis+Gyr Technology, Inc. These items are considered as Trade Secrets and therefore public access to the proprietary material could possibly result in duplication of equipment that could severely damage the company's business advantage. I appreciate your assistance in this matter. Sincerely, Name: Richard Timko Title: Quality Engineer

5015 B. U. Bowman Dr. Buford, GA 30518 June 19, 2015 ACS TCB 5015 B.U. Bowman Drive Buford, GA 30518 Re: FCC ID: R7PEC6R2S3 To Whom It May Concern: The following application is submitted on behalf of our client, Landis+Gyr Technology, Inc., for evaluation of their model GPR2 for certification under FCC Part 15.247 and 15.249. The GPR2 is a battery-powered 2-way gas frequency hopping module that operates in the frequency range of 902 – 928 MHz. The GPR2 is designed to provide two-way communications within the Landis+Gyr Gridstream RF network, and can communicate with electric meters, routers, mesh extenders or radios on distribution automation devices. The GPR2 operates utilizing a high power frequency hopping mode under FCC Part 15.247 and low power single channel mode under FCC Part 15.249. The GPR2 was tested in full to the requirements of the aforementioned rules and was found to be in compliance. Sincerely, Sam Wismer Vice President, Technology Advanced Compliance Solutions, Inc.

30000 Mill Creek Avenue, Suite 100 | Alpharetta, GA 30022 Tel: +1 678 258 1637 | Fax: +1 678 258 1681 To:File From:Richard Timko Subject:GPR2, FCC ID: R7PEC6R2S3 Modular Approval RequestJune 18, 2015 Scope 47CFR 15.212 communicates requirements for products requesting modular approval. In particular, eight requirements are enumerated along with a request that each of the eight be explained for any product requesting such approval. It is the purpose of this document to respond to those eight requirements in regard to the Landis+Gyr product: GPR2. Modular Approval Requirements 1.1 RF Shielding The GPR2 module is self-shielding and is not dependent on any component or characteristic of the device into which it is embedded. Shielding is accomplished through a combination of metallic self-shielding components, copper planes, guards, and vias in the PCB. The result is a design that has been proven to be neither sensitive to outside influence nor capable of introducing interference into outside components. 1.2Buffered Modulation / Data Inputs The GPR2 module does not have external modulation or data inputs. Rather, the RF sections are driven by an on-board microprocessor which directly controls the RF data lines and operates so as to not allow excessive modulation. 1.3Power Supply Regulation The GPR2 module uses linear, low-dropout regulators to provide all the electronics with a supply that is fixed, even when the input voltage is varied. 1.4Antenna Requirement The GPR2 module utilizes an internal, integrated, inverted-F antenna. 1.5Stand-Alone Testing All testing on the GPR2 module was conducted standalone. No shields or enclosures were used, other than those fully integrated into the modules themselves. No ferrites were used on data or power lines during testing. These devices are DC powered, and exceed applicable conducted emission requirements. 1.6Labeling As indicated, each GPR2 module will have its own FCC ID label. In addition, devices into which they are placed will have labels indicating that this module is contained within. Exact text will be as specified in 47CFR 15.212. 1.7Specific Rules and Operating Requirements The GPR2 module complies with all pertinent rules for its section. 1.8RF Exposure Requirements The GPR2 module complies with all exposure requirements. As a component used in the Utility industry, this product is not intended for use near human operators. 2.0In Reference to 15.212(b) The GPR2 module is always professionally installed and is not sold to the general public. This module undergoes continuous, rigorous testing to ensure that full compliance is always maintained. Sincerely, Title: Quality Engineer

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: R7PEC6R2S3 IC: 5294A-EC6R1S3 FCC Rule Part: 15.247, 15.249 IC Radio Standards Specification: RSS-210, RSS-247 ACS Project Number: 15-0160 Manufacturer: Landis+Gyr Technology, Inc. Model: GPR2 Model: GPR2FCC ID: R7PEC6R2S3IC: 5294A-EC6R1S3 ACS Project: 15-0160Advanced Compliance SolutionsPage 2 Figure 1: External Photo Figure 2: External Photo Model: GPR2FCC ID: R7PEC6R2S3IC: 5294A-EC6R1S3 ACS Project: 15-0160Advanced Compliance SolutionsPage 3 Figure 3: External Photo Figure 4: External Photo Model: GPR2FCC ID: R7PEC6R2S3IC: 5294A-EC6R1S3 ACS Project: 15-0160Advanced Compliance SolutionsPage 4 Figure 5: External Photo Figure 6: External Photo

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: R7PEC6R2S3 IC: 5294A-EC6R1S3 FCC Rule Part: 15.247, 15.249 IC Radio Standards Specification: RSS-210, RSS-247 ACS Project Number: 15-0160 Manufacturer: Landis+Gyr Technology, Inc. Model: GPR2 GPR2 FCC Host Label and Location

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: R7PEC6R2S3 IC: 5294A-EC6R1S3 FCC Rule Part: 15.247, 15.249 IC Radio Standards Specification: RSS-210, RSS-247 ACS Project Number: 15-0160 Manufacturer: Landis+Gyr Technology, Inc. Model: GPR2 Model: GPR2FCC ID: R7PEC6R2S3IC: 5294A-EC6R1S3 ACS Project: 15-0160Advanced Compliance SolutionsPage 2 Figure 1: Internal Photo – Shield Removed Model: GPR2FCC ID: R7PEC6R2S3IC: 5294A-EC6R1S3 ACS Project: 15-0160Advanced Compliance SolutionsPage 3 Figure 2: Internal Photo – Shield Removed

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: R7PEC6R2S3 FCC Rule Part: 15.247, 15.249 ACS Project Number: 15-0160 Manufacturer: Landis+Gyr Technology, Inc. Model: GPR2 Model: GPR2FCC ID: R7PEC6R2S3 ACS Project: 15-0160Advanced Compliance SolutionsPage 2 General Information: Applicant:Landis+Gyr Technology, Inc. Device Category:Mobile Environment:General Population/Uncontrolled Exposure Technical Information: Antenna Type: Inverted F-type Antenna Gain: 2dBi Maximum Transmitter Conducted Power: 24.05 dBm, 254.10 mW Maximum System EIRP: 26.05 dBm, 402.72 mW Exposure Conditions: Greater than 20 centimeters MPE Calculation The Power Density (mW/cm 2 ) is calculated as follows: S = 2 4R PG  Where: S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) MPE Calculator for Mobile Equipment Limits for General Population/Uncontrolled Exposure* 91524.050.61254.1021.585 200.080 Power Density (mW/cm^2) Distance (cm) Transmit Frequency (MHz) Radio Power (dBm) Power Density Limit (mW/Cm2) Radio Power (mW) Antenna Gain (dBi) Antenna Gain (mW eq.) Installation Guidelines The installation manual should contain text similar to the following advising how to install the equipment to maintain compliance with the FCC RF exposure requirements: RF Exposure In accordance with FCC requirements of human exposure to radio frequency fields, the radiating element shall be installed such that a minimum separation distance of 20 centimeters will be maintained. Conclusion This device complies with the MPE requirements by providing adequate separation between the device, any radiating structure and the general population.

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Test Report FCC ID: R7PEC6R2S3 IC: 5294A-EC6R1S3 FCC Rule Part: 15.249 IC Radio Standards Specification: RSS-210 ACS Report Number: 15-0160.W06.2A Manufacturer: Landis+Gyr Technology, Inc. Model: GPR2 Test Begin Date: April 27, 2015 Test End Date: April 29, 2015 Report Issue Date: June 19, 2015 FOR THE SCOPE OF ACCREDITATION UNDER LAB Code 200612-0 This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Reviewed by: Kirby Munroe Director, Wireless Certifications ACS, Inc. This test report shall not be reproduced except in full. This report may be reproduced in part with prior written consent of ACS, Inc. The results contained in this report are representative of the sample(s) submitted for evaluation. This report contains 16 pages 5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 TABLE OF CONTENTS 1 GENERAL ............................................................................................................................................ 3 1.1 PURPOSE .......................................................................................................................................... 3 1.2 PRODUCT DESCRIPTION ................................................................................................................... 3 1.3 TEST METHODOLOGY AND CONSIDERATIONS ................................................................................. 4 2 TEST FACILITIES .............................................................................................................................. 5 2.1 LOCATION ....................................................................................................................................... 5 2.2 LABORATORY ACCREDITATIONS/RECOGNITIONS/CERTIFICATIONS ................................................ 5 2.3 RADIATED EMISSIONS TEST SITE DESCRIPTION .............................................................................. 6 2.3.1 Semi-Anechoic Chamber Test Site .......................................................................................... 6 2.3.2 Open Area Tests Site (OATS) ................................................................................................. 7 2.4 CONDUCTED EMISSIONS TEST SITE DESCRIPTION ........................................................................... 8 3 APPLICABLE STANDARD REFERENCES .................................................................................... 8 4 LIST OF TEST EQUIPMENT ............................................................................................................ 9 5 SUPPORT EQUIPMENT ...................................................................................................................10 6 EQUIPMENT UNDER TEST SETUP BLOCK DIAGRAM ..........................................................10 7 SUMMARY OF TESTS ......................................................................................................................11 7.1 ANTENNA REQUIREMENT – FCC 15.203 ........................................................................................11 7.2 POWER LINE CONDUCTED EMISSIONS – FCC 15.207; IC RSS-GEN 8.8 .........................................11 7.3 20DB / 99% BANDWIDTH – FCC 15.215; IC RSS-GEN 6.6.............................................................11 7.3.1 Measurement Procedure ........................................................................................................11 7.3.2 Measurement Results .............................................................................................................11 7.4 FUNDAMENTAL FIELD STRENGTH – FCC 15.249(A); IC RSS-210 A2.9(A) ....................................13 7.4.1 Measurement Procedure ........................................................................................................13 7.4.2 Measurement Results .............................................................................................................13 7.5 RADIATED SPURIOUS EMISSIONS – FCC 15.249(A)(D)(E); IC RSS-210 A2.9(A)(B) .......................14 7.5.1 Measurement Procedure ........................................................................................................14 7.5.2 Measurement Results .............................................................................................................14 7.5.3 Sample Calculation: ..............................................................................................................15 8 CONCLUSION ....................................................................................................................................16 Model: GPR2 FCC ID: R7PEC6R2S3 IC: 5294A-EC6R1S3 ACS Report: 15-0160.W06.2A Advanced Compliance Solutions Page 3 1 GENERAL 1.1 Purpose The purpose of this report is to demonstrate compliance with Part 15 Subpart C of the FCC’s Code of Federal Regulations and Industry Canada’s Radio Standards Specification RSS-210 for modular approval certification. 1.2 Product description The GPR2 is a battery-powered 2-way gas module that operates in the frequency range of 902.3 – 927.5 MHz. The GPR2 is designed to provide two-way communications within the Landis+Gyr Gridstream RF network, and can communicate with electric meters, routers, mesh extenders or radios on distribution automation devices. Technical Information: The model 2 provides two distinct modes of operation; frequency hopping mode at high power, and single channel mode at low power. This report addresses the single channel mode as outlined below. Mode of Operation Frequency Range (MHz) Number of Channels Channel Separation (kHz) Data Rates Supported (kbps) 1 902.3 - 927.5 64 400 115.2 Modulation Format: FSK/GFSK Antenna Type / Gain: Inverted F / 2dBi gain Operating Voltage: 3VDC (Internal Batt…

Text truncated - open the document above for the full version.

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: R7PEC6R2S3 IC: 5294A-EC6R1S3 FCC Rule Part: 15.247, 15.249 IC Radio Standards Specification: RSS-210, RSS-247 ACS Project Number: 15-0160 Manufacturer: Landis+Gyr Technology, Inc. Model: GPR2 Model: GPR2FCC ID: R7PEC6R2S3IC: 5294A-EC6R1S3 ACS Project: 15-0160Advanced Compliance SolutionsPage 2 Figure 1: Radiated Emissions Figure 2: Radiated Emissions Model: GPR2FCC ID: R7PEC6R2S3IC: 5294A-EC6R1S3 ACS Project: 15-0160Advanced Compliance SolutionsPage 3 Figure 3: Radiated Emissions
