RV-0000000 Report No.: NEI-FCCP-1-1211074 Page 129 of 132 Neutron Engineering Inc. 10 RF EXPOSURE COMPLIANCE 10.1 LIMIT Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 NOTE: f = frequency in MHz ; *Plane-wave equivalent power density. 10.2 MEASUREMENT INSTRUMENTS LIST Item Kind of EquipmentManufacturer Type No. Serial No. Calibrated until 1 Power Meter Anritsu ML2495A 1128008 Feb. 20,2013 2 Power Meter Sensor Anritsu MA2411B 1126001 Feb. 20,2013 NOTE: N/A: denotes No Model Name, No Serial No. or No Calibration specified. 10.3 MPE CALCULATION METHOD E (V/m) ＝ d GP30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Peak RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP   From the peak EUT RF output power, the minimum mobile separation distance, as well as the gain of the used antenna, the RF power density can be obtained RV-0000000 Report No.: NEI-FCCP-1-1211074 Page 130 of 132 Neutron Engineering Inc. 10.4 TEST SETUP LAYOUT 10.5 DEVIATION FROM TEST STANDARD No deviation 10.6 EUT OPERATING CONDITIONS The EUT tested system was configured as the statements of 4.6 Unless otherwise a special operating condition is specified in the follows during the testing. 10.7 TEST RESULTS - 2400-2483.5 MHZ The highest output power of this equipment is below threshold of 24mW (60/f GHz), therefore SAR test is not required.

RV-0000000 Report No.: NEI-FCCP-1-1211074 Page 1 of 132 Neutron Engineering Inc. 2.4 GHz WLAN Test Report FCC ID: R7RDMC2313 This report concerns (check one) : Original Grant Class II Change Issued Date : Dec. 07, 2012 Project No. : 1211074 Equipment : WiFi Microscope Model Name : DMC-2313 Applicant : VAST TECHNOLOGIES INC. Address : 7F, NO. 80, SEC. 1, KUANG FU RD.SANCHUNG, TAIPEI, TAIWAN, R.O.C. Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Nov. 19, 2012 Date of Test: Nov. 19, 2012 ~ Nov. 30, 2012 Testing Engineer : (Rush Kao) Technical Manager : (Jeff Yang) Authorized Signatory : (Andy Chiu) Neutron Engineering Inc. B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan. TEL: +886-2-2657-3299 FAX: +886-2-2657-3331 RV-0000000 Report No.: NEI-FCCP-1-1211074 Page 2 of 132 Neutron Engineering Inc. Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences or generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. RV-0000000 Report No.: NEI-FCCP-1-1211074 Page 3 of 132 Neutron Engineering Inc. Table of Contents REPORT ISSUED HISTORY 5 1 CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 12 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 3.5 DESCRIPTION OF SUPPORT UNITS 14 4 ANTENNA CONDUCTED SPURIOUS EMISSION 15 4.1 LIMIT 15 4.2 MEASUREMENT INSTRUMENTS LIST 15 4.3 TEST PROCEDURES 15 4.4 TEST SETUP LAYOUT 15 4.5 DEVIATION FROM TEST STANDARD 15 4.6 EUT OPERATING CONDITIONS 15 4.7 TEST RESULTS - 2400-2483.5 MHZ 16 5 6 DB BANDWIDTH 32 5.1 LIMIT 32 5.2 MEASUREMENT INSTRUMENTS LIST 32 5.3 TEST PROCEDURES 32 5.4 TEST SETUP LAYOUT 32 5.5 DEVIATION FROM TEST STANDARD 32 5.6 EUT OPERATING CONDITIONS 32 5.7 TEST RESULTS - 2400-2483.5 MHZ 33 6 MAXIMUM PEAK CONDUCTED OUTPUT POWER 41 6.1 LIMIT 41 6.2 MEASUREMENT INSTRUMENTS LIST 41 6.3 TEST PROCEDURES 41 6.4 TEST SETUP LAYOUT 41 6.5 DEVIATION FROM TEST STANDARD 41 6.6 EUT OPERATING CONDITIONS 41 6.7 TEST RESULTS - 2400-2483.5 MHZ 42 7 RADIATED SPURIOUS EMISSION (9 KHZ TO 1 GHZ) 46 7.1 LIMIT 46 7.2 MEASUREMENT INSTRUMENTS LIST 47 RV-0000000 Report No.: NEI-FCCP-1-1211074 Page 4 of 132 Neutron Engineering Inc. Table of Contents 7.3 MEASURING INSTRUMENTS SETTING 47 7.4 TEST PROCEDURES 48 7.5 DEVIATION FROM TEST STANDARD 48 7.6 TEST SETUP LAYOUT 48 7.7 EUT OPERATING CONDITIONS 49 7.8 TEST RESULTS - 2400-2483.5 MHZ 50 8 RADIATED SPURIOUS EMISSION (ABOVE 1 GHZ) 52 8.1 LIMIT 52 8.2 MEASUREMENT INSTRUMENTS LIST 53 8.3 MEASURING INSTRUMENTS SETTING 53 8.4 TEST PROCEDURES 54 8.5 DEVIATION FROM TEST STANDARD 54 8.6 TEST SETUP LAYOUT 54 8.7 EUT OPERATING CONDITIONS 55 8.8 TEST RESULTS - 2400-2483.5 MHZ 56 8.9 TEST RESULTS (RESTRICTED BANDS) 104 9 POWER SPECTRAL DENSITY 120 9.1 LIMIT 120 9.2 MEASUREMENT INSTRUMENTS LIST 120 9.3 TEST PROCEDURES 120 9.4 TEST SETUP LAYOUT 120 9.5 DEVIATION FROM TEST STANDARD 120 9.6 EUT OPERATING CONDITIONS 120 9.7 TEST RESULTS - 2400-2483.5 MHZ 121 10 RF EXPOSURE COMPLIANCE 129 10.1 LIMIT 129 10.2 MEASUREMENT INSTRUMENTS LIST 129 10.3 MPE CALCULATION METHOD 129 10.4 TEST SETUP LAYOUT 130 10.5 DEVIATION FROM TEST STANDARD 130 10.6 EUT OPERATING CONDITIONS 130 10.7 TEST RESULTS - 2400-2483.5 MHZ 130 11 EUT TEST PHOTO 131 RV-0000000 Report No.: NEI-FCCP-1-1211074 Page 5 of 132 Neutron Engineering Inc. REPORT ISSUED HISTORY Revised Version No. Description Issued Date - Initial Issue. Dec. 07, 2012 RV-0000000 Report No.: NEI-FCCP-1-1211074 Page 6 of 132 Neutron Engineering Inc. 1 CERTIFICATION E q u i p m e n t : WiFi Microscope Model Name : DMC-2313 A p p l i c a n t : VAST TECHNOLOGIES INC. Date of Test : Nov. 19, 2012 ~ Nov. 30, 2012 Standards : FCC Part 15, Subpart C: 2010 ANSI C63.4: 2009 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1211074) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of NVLAP and TAF according to the ISO-17025 quality assessment standard and technical standard(s). RV-0000000 Report No.: NEI-FCCP-1-1211074 Page 7 of 132 Neutron Engineering Inc. 2. SUMMARY OF TEST RESULTS Standard Clause Test Item Result 15.207 Conducted Emission N/A 15.247 (c) Antenna conducted Spurious Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Maximum Peak Conducted Output Power PASS 15.2…

Text truncated - open the document above for the full version.

RV-0000000 Report No.: NEI-FCCP-1-1211074 Page 132 of 133 Neutron Engineering Inc. 11 EUT TEST PHOTO Radiated spurious emission test photos Below 1 GHz 1211074 1211074 RV-0000000 Report No.: NEI-FCCP-1-1211074 Page 133 of 133 Neutron Engineering Inc. Radiated spurious emission test photos Above 1 GHz 1211074 1211074
