R7RDWS1113WIFI STATION

Apple iOS devices / Android devices Motion JPEG about 10M from a WiFi connector device 2.4GHz band width Ad hoc mode WiFi IEEE802.11b/g/n(1T1R) Li-Polymer 3000mA 3.7V/370mA(battery),5V/900mA(DC in) 5V/200mA(WiFi Dongle) 3.5 hrs with 3000mA Li-Polymer battery 170.2g with Battery DWS-1113 WiFi Station Specification Contents Components Names and Function Compatible Host Devices Support UVC camera video stream format Camera operational range Frequency Access format Transmission protocol Battery 5V/2000 mA Adapter Power consumption Continuous operation time Weight DWS-1113 WiFi Station x1 Power adapter x1 User Guide x1 WiFi Dongle Reset Key Power Switch USB MJPEG Camera INPUT Power Bank Micro USB (For Charge) LAN Port (For Firmware update) 1 Pad Holder For Use LED Indicators Getting started iOS app operation WiFi Dongle Green: Power on and working. Power Bank Green: Normal with sufficient charge, or charging is complete Blinking Red: Low battery. Please plug in power adapter or WiFi Station will be off after 60 seconds. Orange: Battery is charging. WiFi Dongle LED Power Bank LED 1. Download the “S-Viewer” app from Apple App Store or Android ”Google Play”. 2. Turn on the power switch. WiFi Dongle LED will stay GREEN. 3. Connect your USB Microscope or USB camera to DWS-1113 WiFi Station. 4. Connect the mobile device to the WiFi network. (Please see the section on iOS/Android app operation) 1. Go to WiFi setting and choose WiFi setup 2. Select WiFi, and turn it on. 3. Select WiFi Station “SSID” 4. Key in the password. Connection is established. 5. Go back to main menu. 6. Find and hit the S-Viewer icon to access WiFi Station’s features. Remark: The initial SSID can be found on the label located on the bottom of the device. The initial password is 12345678. 2 Remark: The initial SSID can be found on the label located on the bottom of the device. The defult password is 12345678. Android app operation 1. Go to WiFi setting and choose WiFi setup. 2. Select WiFi, and turn it on. 3. Select WiFi Sation “SSID”. 4. Key in the password. Connection is established. 5. Go to the Home screen to show ALL apps. 6. Find and hit the S-Viewer icon to access WiFi Station’s features. 34 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement This device complies with FCC radiation exposure limits set forth for an uncontrolled environment and it also complies with Part 15 of the FCC RF Rules. This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provide with antenna installation instructions and consider removing the no-collocation statement. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution! Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

RF_160, Issue 02 Declaration of Authorization We Name: VAST TECHNOLOGIES INC. Address: 7F, NO.80,SEC.1,KUANG FU RD., SANCHUNG DIST., NEW TAIPEI CITY, Taiwan City: NEW TAIPEI CITY Country: Taiwan Declare that: Name Representative of agent: Ms. Cathy Wang Agent Company name: BTL Inc. Address: B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan City: Taipei Country: Taiwan is authorized to apply for Certification and signing related documents of the following product(s), including 731 form(s): Product description: WIFI STATION Type designation: DWS-1113 Trademark: VAST on our behalf. Date: 2014-8-11 City: NEW TAIPEI CITY Name: Bert Chang Function: Signature:  . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

Project No.: 1407011 Page 2 of 17 Project No.: 1407011 Page 3 of 17 Project No.: 1407011 Page 4 of 17 Project No.: 1407011 Page 5 of 17 Project No.: 1407011 Page 6 of 17 Project No.: 1407011 Page 7 of 17 Project No.: 1407011 Page 8 of 17 Project No.: 1407011 Page 9 of 17

Label location

Project No.: 1407011 Page 10 of 17 Project No.: 1407011 Page 11 of 17 Project No.: 1407011 Page 12 of 17 Wi-Fi Module Project No.: 1407011 Page 13 of 17 Project No.: 1407011 Page 14 of 17 Project No.: 1407011 Page 15 of 17 Project No.: 1407011 Page 16 of 17 Project No.: 1407011 Page 17 of 17

Proj Equ Mod App Add Ac c FC ject No. uipment del plicant dress cording: CC RF F : 140701 : WIFI ST : DWS-1 : VAST T : 7F, NO NEW T : FCC G C95.1 B1, No. 37 TEL: 0 F EXP FCC ID 11 TATION 113 TECHNOL .80,SEC.1 TAIPEI CIT Guideline B 7, Lane 365 0769-8318- Pa POSU D: R7R LOGIES IN ,KUANG F TY, Ta i w a n es for Hu BTL IN 5, YangGua Ta i p e i , Ta i w -3000 FA age 1 of 4 URE R RDWS1 C. FU RD., SA uman Ex NC. ng St., NeiH wan. AX: 0769-8 REPO 113 ANCHUNG xposure I Hu District 1 8319-6000 ORT G DIST., IEEE 14, M P Table f A PE CALC Calculat where: S = pow e P = powe G = powe R = distan for Filed An Ant. Br 1 Co CULATI ion Method er density er input to th er gain of th nce to the c ntenna rand ortec ION ME of RF Safe he antenna e antenna i center of rad Model N NB0159-A P a ETHOD: ety Distance in the direct diation of th Name A100BX age 2 of 4 : e: tion of intere he antenna Antenna T Printed est relative TypeCon d N to an isotro nector Ga N/A opic radiator ain(dBi) 3.0 r TEST EUT： Te m p e ra Te s t Vo lt Te s t M od Antenna Gain (dBi) 3 3 3 EUT： Te m p e ra Te s t Vo lt Te s t M od Antenna Gain (dBi) 3 3 3 T RESU ature： tage : de ： a Antenna (nume 1.995 1.995 1.995 ature： tage : de ： a Antenna (nume 1.995 1.995 1.995 ULTS WIFI STAT 25 °C AC 120V/6 TX B MOD a Gain eric) Pe Pow 53 53 53 WIFI STAT 25 °C AC 120V/6 TX G MOD a Gain eric) Pe Pow 53 53 53 TION 60Hz DE /CH01, C ak Output wer (dBm) 15.43 15.92 16.22 TION 60Hz DE /CH01, C ak Output wer (dBm) 23.53 23.35 23.33 Pa M R H06, CH11 Peak Out p Power (mW 34.9140 39.0841 41.8794 M R CH06, CH11 Peak Outp Power (mW 225.4239 216.2719 215.2782 age 3 of 4 Model Name Relative Hu put W) Po w Densi (mW / 0 0.0138 0.0155 4 0.0166 Model Name Relative Hu put W) Po w Densi (mW / 9 0.0895 9 0.0858 2 0.0854 e : DW midity: 55 wer ty (S) /cm 2 ) Lim D e (m 86597 52210 63223 e : DW midity: 55 wer ty (S) /cm 2 ) Lim D e (m 52625 89154 49690 WS-1113 % it of Power ensity (S) mW/cm 2 ) 1 1 1 WS-1113 % it of Power ensity (S) mW/cm 2 ) 1 1 1 Te s t Result Complies Complies Complies Te s t Result Complies Complies Complies EUT： Tempera Te s t Vo lt Te s t M od Antenna Gain (dBi) 3 3 3 EUT： Tempera Te s t Vo lt Te s t M od Antenna Gain (dBi) 3 3 3 Note: th e ature: tage : de : a Antenna (nume 1.995 1.995 1.995 ature: tage : de : a Antenna (nume 1.995 1.995 1.995 e calculated WIFI STAT 25 °C AC 120V/6 TX N-20M a Gain eric) P e Pow 53 53 53 WIFI STAT 25 °C AC 120V/6 TX N-40M a Gain eric) Pe Pow 53 53 53 d distance is TION 60Hz MODE_ To eak Output wer (dBm) 20.4 20.8 20.9 TION 60Hz MODE_Tot ak Output wer (dBm) 20.56 20.34 20.81 s 20 cm. Pa M R otal /CH01, Peak Outp Power (mW 109.6478 120.2264 123.0269 M R tal /CH03, C Peak Outp Power (mW 113.7627 108.1434 120.5036 age 4 of 4 Model Name Relative Hu CH06, CH1 put W) Po w Densi (mW/ 8 0.0435 4 0.0477 9 0.0488 Model Name Relative Hu CH06, CH0 put W) Po w Densi (mW / 7 0.0451 4 0.0429 6 0.0478 e : DW midity: 55 11 wer ity (S) /cm 2 ) Li m De (m 54621 74747 85965 e : DW midity: 55 9 wer ty (S) /cm 2 ) Lim D e (m 18043 94873 85754 WS-1113 % mit of Power ensity (S) mW/cm 2 ) 1 1 1 WS-1113 % it of Power ensity (S) mW/cm 2 ) 1 1 1 Te s t Result Complies Complies Complies Te s t Result Complies Complies Complies

Report No.: BTL-FCCP-1-1407011 Page 1 of 120 FCC Radio Test Report FCC ID: R7RDWS1113 This report concerns (check one): Original Grant Class II Change Project No. : 1407011 Equipment : WIFI STATION Model Name : DWS-1113 Applicant : VAST TECHNOLOGIES INC. Address : 7F, NO.80,SEC.1,KUANG FU RD.SANCHUNG, TAIPEI,TAIWAN,R.O.C. Date of Receipt : Jul. 03, 2014 Date of Test : Jul. 03, 2014 ~ Aug. 08, 2014 Issued Date : Aug. 11, 2014 Tested by : BTL Inc. Testing Engineer : (Josh Lin) Technical Manager : (Jeff Yang) Authorized Signatory : (Andy Chiu) BTL INC. B1, No. 37, Lane 365, YangGuang St. NeiHu District 114, Taipei, Taiwan. TEL: +886-2-2657-3299 FAX: +886-2-2657-3331 Report No.: BTL-FCCP-1-1407011 Page 2 of 120 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. BTL’s reports must not be used by the client to claim product endorsement by the authorities or an y agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: BTL-FCCP-1-1407011 Page 3 of 120 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 12 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 3.5 DESCRIPTION OF SUPPORT UNITS 14 4 . EMC EMISSION TEST 15 4.1 CONDUCTED EMISSION MEASUREMENT 15 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 15 4.1.2 TEST PROCEDURE 15 4.1.3 DEVIATION FROM TEST STANDARD 15 4.1.4 TEST SETUP 16 4.1.5 EUT OPERATING CONDITIONS 16 4.1.6 EUT TEST CONDITIONS 16 4.1.7 TEST RESULTS 16 4.2 RADIATED EMISSION MEASUREMENT 17 4.2.1 RADIATED EMISSION LIMITS 17 4.2.2 TEST PROCEDURE 18 4.2.3 DEVIATION FROM TEST STANDARD 18 4.2.4 TEST SETUP 18 4.2.5 EUT OPERATING CONDITIONS 19 4.2.6 EUT TEST CONDITIONS 19 4.2.7 TEST RESULTS (9KHZ TO 30MHZ) 20 4.2.8 TEST RESULTS (BETWEEN 30MHZ TO 1000 MHZ) 20 4.2.9 TEST RESULTS (ABOVE 1000 MHZ) 20 5 . BANDWIDTH TEST 21 5.1 APPLIED PROCEDURES 21 5.1.1 TEST PROCEDURE 21 5.1.2 DEVIATION FROM STANDARD 21 5.1.3 TEST SETUP 21 5.1.4 EUT OPERATION CONDITIONS 21 5.1.5 EUT TEST CONDITIONS 21 5.1.6 TEST RESULTS 21 Report No.: BTL-FCCP-1-1407011 Page 4 of 120 Table of Contents Page 6 . MAXIMUM OUTPUT POWER TEST 22 6.1 APPLIED PROCEDURES / LIMIT 22 6.1.1 TEST PROCEDURE 22 6.1.2 DEVIATION FROM STANDARD 22 6.1.3 TEST SETUP 22 6.1.4 EUT OPERATION CONDITIONS 22 6.1.5 EUT TEST CONDITIONS 22 6.1.6 TEST RESULTS 22 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 23 7.1 APPLIED PROCEDURES / LIMIT 23 7.1.1 TEST PROCEDURE 23 7.1.2 DEVIATION FROM STANDARD 23 7.1.3 TEST SETUP 23 7.1.4 EUT OPERATION CONDITIONS 23 7.1.5 EUT TEST CONDITIONS 23 7.1.6 TEST RESULTS 23 8 . POWER SPECTRAL DENSITY TEST 24 8.1 APPLIED PROCEDURES / LIMIT 24 8.1.1 TEST PROCEDURE 24 8.1.2 DEVIATION FROM STANDARD 24 8.1.3 TEST SETUP 24 8.1.4 EUT OPERATION CONDITIONS 24 8.1.5 EUT TEST CONDITIONS 24 8.1.6 TEST RESULTS 24 9 . MEASUREMENT INSTRUMENTS LIST 25 10 . EUT TEST PHOTO 27 ATTACHMENT A - CONDUCTED EMISSION 29 ATTACHMENT C - RADIATED EMISSION (30MHZ TO 1000MHZ) 32 ATTACHMENT D - RADIATED EMISSION (ABOVE 1000MHZ) 35 ATTACHMENT E - BANDWIDTH 84 ATTACHMENT F - MAXIMUM OUTPUT POWER 93 ATTACHMENT G - ANTENNA CONDUCTED SPURIOUS EMISSION 95 ATTACHMENT H - POWER SPECTRAL DENSITY 112 Report No.: BTL-FCCP-1-1407011 Page 5 of 120 REPORT ISSUED HISTORY Issued No. Description Issued Date BTL-FCCP-1-1407011 Original Issue. Aug. 11, 2014 Report No.: BTL-FCCP-1-1407011 Page 6 of 120 1. CERTIFICATION Equipment : WIFI STATION Brand Name : VAST Model Name : DWS-1113 Applicant : VAST TECHNOLOGIES INC. Date of Test : Jul. 03, 2014 ~ Aug. 08, 2014 Test Sample : ENGINEERING SAMPLE Standard(s) : FCC Part15, Subpart C: 2013 (15.247) / ANSI C63.4-2009 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. BTL-FCCP-1-1407011) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Report No.: BTL-FCCP-1-1407011 Page 7 of 120 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): Applied Standard(s): FCC Part15 (15.247) , Subpart C: 2013 Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(d) Antenna conducted Spurious Emission PASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(b)(3) Peak Output Power PASS 15.247(e) Power Spectral Density PASS 15.203 Antenna Requirement PASS 15.209/15.205 Transmitter Radiated Emissions PASS NOTE: (1)” N/A” denotes test is not applicable in this test report. (2) T…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-1-1407011 Page 71 of 120 Orthogonal Axis : X Test Mode : TX N-20M MODE 2462MHz Horizontal Report No.: BTL-FCCP-1-1407011 Page 72 of 120 Orthogonal Axis : X Test Mode : TX N-40M MODE 2422MHz Vertical Report No.: BTL-FCCP-1-1407011 Page 73 of 120 Orthogonal Axis : X Test Mode : TX N-40M MODE 2422MHz Vertical Report No.: BTL-FCCP-1-1407011 Page 74 of 120 Orthogonal Axis : X Test Mode : TX N-40M MODE 2422MHz Horizontal Report No.: BTL-FCCP-1-1407011 Page 75 of 120 Orthogonal Axis : X Test Mode : TX N-40M MODE 2422MHz Horizontal Report No.: BTL-FCCP-1-1407011 Page 76 of 120 Orthogonal Axis : X Test Mode : TX N-40M MODE 2437MHz Vertical Report No.: BTL-FCCP-1-1407011 Page 77 of 120 Orthogonal Axis : X Test Mode : TX N-40M MODE 2437MHz Vertical Report No.: BTL-FCCP-1-1407011 Page 78 of 120 Orthogonal Axis : X Test Mode : TX N-40M MODE 2437MHz Horizontal Report No.: BTL-FCCP-1-1407011 Page 79 of 120 Orthogonal Axis : X Test Mode : TX N-40M MODE 2437MHz Horizontal Report No.: BTL-FCCP-1-1407011 Page 80 of 120 Orthogonal Axis : X Test Mode : TX N-40M MODE 2452MHz Vertical Report No.: BTL-FCCP-1-1407011 Page 81 of 120 Orthogonal Axis : X Test Mode : TX N-40M MODE 2452MHz Vertical Report No.: BTL-FCCP-1-1407011 Page 82 of 120 Orthogonal Axis : X Test Mode : TX N-40M MODE 2452MHz Horizontal Report No.: BTL-FCCP-1-1407011 Page 83 of 120 Orthogonal Axis : X Test Mode : TX N-40M MODE 2452MHz Horizontal Report No.: BTL-FCCP-1-1407011 Page 84 of 120 ATTACHMENT E - BANDWIDTH Report No.: BTL-FCCP-1-1407011 Page 85 of 120 Test Mode : TX B Mode_CH01/06/11 6dB Bandwidth 99% Occupied BW Min. LimitTest Result (MHz)(MHz)(kHz) 2412 MHz10.1014.92500Complies 2437 MHz10.1014.92500Complies 2462 MHz 10.1014.96 500Complies Frequency TX CH01 Report No.: BTL-FCCP-1-1407011 Page 86 of 120 TX CH06 TX CH11 Report No.: BTL-FCCP-1-1407011 Page 87 of 120 Test Mode: TX G Mode_CH01/06/11 6dB Bandwidth 99% Occupied BW Min. LimitTest Result (MHz)(MHz)(kHz) 2412 MHz16.5716.48500Complies 2437 MHz16.6116.48500Complies 2462 MHz 16.5716.48 500Complies Frequency TX CH01 Report No.: BTL-FCCP-1-1407011 Page 88 of 120 TX CH06 TX CH11 Report No.: BTL-FCCP-1-1407011 Page 89 of 120 Test Mode : TX N-20MHz Mode_CH01/06/11 6dB Bandwidth 99% Occupied BWMin. LimitTest Result (MHz)(MHz)(kHz) 2412 MHz17.8417.72500Complies 2437 MHz17.8017.72500Complies 2462 MHz 17.8017.68 500Complies Frequency TX CH01 Report No.: BTL-FCCP-1-1407011 Page 90 of 120 TX CH06 TX CH11 Report No.: BTL-FCCP-1-1407011 Page 91 of 120 Test Mode : TX N-40MHz Mode_CH03/06/09 6dB Bandwidth 99% Occupied BWMin. LimitTest Result (MHz)(MHz)(kHz) 2422 MHz36.3136.30500Complies 2437 MHz36.2536.16500Complies 2452 MHz 36.4136.16 500Complies Frequency TX CH03 Report No.: BTL-FCCP-1-1407011 Page 92 of 120 TX CH06 TX CH09 Report No.: BTL-FCCP-1-1407011 Page 93 of 120 ATTACHMENT F - MAXIMUM OUTPUT POWER Report No.: BTL-FCCP-1-1407011 Page 94 of 120 Frequency Conducted Power (dBm) Conducted Power (W) Max. Limit(dBm)Max. Limit(W)Result 2412 MHz15.430.034930.001.00Complies 2437 MHz15.920.039130.001.00Complies 2462 MHz16.220.041930.001.00Complies Test Mode : TX B Mode Frequency Conducted Power (dBm) Conducted Power (W) Max. Limit(dBm)Max. Limit(W)Result 2412 MHz23.530.225430.001.00Complies 2437 MHz23.350.216330.001.00Complies 2462 MHz23.330.215330.001.00Complies Test Mode : TX G Mode Frequency Conducted Power (dBm) Conducted Power (W) Max. Limit(dBm)Max. Limit(W)Result 2412 MHz20.400.109630.001.00Complies 2437 MHz20.800.120230.001.00Complies 2462 MHz20.900.123030.001.00Complies Test Mode : TX N-20M Mode Frequency Conducted Power (dBm) Conducted Power (W) Max. Limit(dBm)Max. Limit(W)Result 2422 MHz20.560.113830.001.00Complies 2437 MHz20.340.108130.001.00Complies 2452 MHz20.810.120530.001.00Complies Test Mode : TX N-40M Mode Report No.: BTL-FCCP-1-1407011 Page 95 of 120 ATTACHMENT G - ANTENNA CONDUCTED SPURIOUS EMISSION Report No.: BTL-FCCP-1-1407011 Page 96 of 120 Test Mode : TX B Mode Report No.: BTL-FCCP-1-1407011 Page 97 of 120 TX B mode CH01 TX B mode CH11 Report No.: BTL-FCCP-1-1407011 Page 98 of 120 TX B mode CH01 (10 Harmonic of the frequency) TX B mode CH06 (10 Harmonic of the frequency) Report No.: BTL-FCCP-1-1407011 Page 99 of 120 TX B mode CH11 (10 Harmonic of the frequency) Report No.: BTL-FCCP-1-1407011 Page 100 of 120 Test Mode : TX G Mode Report No.: BTL-FCCP-1-1407011 Page 101 of 120 TX G mode CH01 TX G mode CH11 Report No.: BTL-FCCP-1-1407011 Page 102 of 120 TX G mode CH01 (10 Harmonic of the frequency) TX G mode CH06 (10 Harmonic of the frequency) Report No.: BTL-FCCP-1-1407011 Page 103 of 120 TX G mode CH11 (10 Harmonic of the frequency) Report No.: BTL-FCCP-1-1407011 Page 104 of 120 Test Mode : TX N-20M Mode Report No.: BTL-FCCP-1-1407011 Page 105 of 120 TX HT20 mode CH01 TX HT20 mode CH11 Report No.: BTL-FCCP-1-1407011 Page 106 of 120 TX HT20 mode CH01 (10 Harmonic of the frequency) TX HT20 mode CH06 (10 Harmonic of the frequency) Report No.: BTL-FCCP-1-1407011 Page 107 of 120 TX HT20 mode CH11 (10 Harmonic of the frequency) Report No.: BTL-FCCP-1-1407011 Page 108 of 120 Test Mode : TX N-40M Mode Report No.: BTL-FCCP-1-1407011 Page 109 of 120 TX HT40 mode CH03 TX HT40 mode CH09 Report No.: BTL-FCCP-1-1407011 Page 110 of 120 TX HT40 mode CH03 (10 Harmonic of the frequency) TX HT40 mode CH06 (10 Harmonic of the frequency) Report No.: BTL-FCCP-1-1407011 Page 111 of 120 TX HT40 mode CH09 (10 Harmonic of the frequency) Report No.: BTL-FCCP-1-1407011 Page 112 of 120 ATTACHMENT H - POWER SPECTRAL DENSITY Report No.: BTL-FCCP-1-1407011 Page 113 of 120 Test Mode :TX B Mode_CH01/06/11 Frequency Power Density (dBm/3kHz) Power Density (mW/3kHz) Max. Limit (dBm)Result 2412 MHz-18.450.018.00Complies 2437 MHz -18.290.018.00Complies 2462 MHz -18.360.018.00Complies TX CH01 Report No.: BTL-FCCP-1-1407011 Page 114 of 120 TX CH06 TX CH11 Report No.: BTL-FCCP-1-1407011 Page 115 of 120 Test Mode :TX G Mode_CH01/06/11 Frequency Power Density (dBm/3kHz) Power Density (mW/3kHz) Max.…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-1-1407011 Page 27 of 120 10. EUT TEST PHOTO Conducted Measurement Photos Report No.: BTL-FCCP-1-1407011 Page 28 of 120 Radiated Measurement Photos
