R8OB013L2ABallast

TDC Power Products CO., LTD User’s Manual/Bedienungsanleitung EBA120-013L2A 1.) Das Netzteil ist für den Betrieb mit Einrichtungen nach UL935 konzipiert. The Ballast is for use with equipment according to UL935 2.) Das Netzteil ist nur für den Betrieb in trockenen Räumen geeignet. The Ballast is for indoor use in dry locations. 3.) Der Steckdose soll nah zum Gerät eingebaut werden und einfach zu erreichensein. The socket-outlet shall be installed near the equipment and shall be not easily accessible. 4.) Dieses Gerät kann bis zu einer Umgebungstemperatur von maximal 40°C betrieben werden. Operate the Ballast only on maximum ambient temperature 40 °C, without any cover. 5.) Eine beschädigte Anschlußleitung kann nicht ersetzt werden. Das Netzteil darf nicht mehr betrieben werden The Ballast is not to be repaired and do not to be used any longer if it is damaged or defective. 6.) output connect: Output polarity: NO Output connect two Lamp,output connect mode the two red of output connect wire that they connect one lamp,and the other two wires is blue that they connect the other lamp. TDC POWER ELECTRNIC CO., LTD. ELETRONIC BALLAST SPECIFICATION MODEL NO.:EBA120-013L2AISSUE DATE:2005-3-28 REV:V1PAGE :1 OF 1 1. Electronic Specification: Supply Voltage/Frequency 120V±10% 50~60Hz Supply Current Wattage Power Pactor0.9 Crest Factor<2.7 For Load Lamp Type Load LampInput current (Max) PL13W*20.4A PL9W*20.25A PL7W*20.25A 2. Dielectric Withstand Test: 2-1 Input And Output to Enclosure: 1500V / 50Hz / 3mA / 2Sec. 2-2 Leakage Current: 0.25mA Max. 3. Environmental Condition: 3-1 Operating Temperature: 0 to +40 3-2 Storage Temperature: -15 to +40 3-3 Operating Humidity:85% RH.Non-Condensing 3-4 Storage Humidity:85% RH.Non-Condensing 5. Mechanical Specification: 5-1 Dimension :188 (L) X 21 (W) X27(H) mm

TDC Power Products Co., Ltd.________________________________________ Rm.C13, 5F, #210, Sect.3, Ta-tung Rd., Shi-chih, Taipei Hsien, Taiwan. Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: R8OB013L2A To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Best Regards

Report Number: SZ050428B03-EF May 31, 2005 LAB CODE:200577-0 Page23 Rev. 00 Report Number: SZ050428B03-EF May 31, 2005 LAB CODE:200577-0 Page24 Rev. 00 Report Number: SZ050428B03-EF May 31, 2005 LAB CODE:200577-0 Page25 Rev. 00

LABEL OF EBA120-013L2A - PL SCAMEIL NO:050322115 FCC ID:R8OB013L2A E181948 PL/13W* 2 0.40A (Max) TYPE I OUTDOORMADE IN CHINA PL/7W* 2 0.25A (Max) PL/9W* 2 0.30A (Max) ELECTRONIC BALLAST LAMP: CURRENT INPUT:120Vac ± 10% 50/60Hz MODEL NO:EBA120-013L2A - PL C YELLOWAND GREEN BLACX WHITE INPUT BLUE OUTPUT RED L US R U LISTED

Report Number: SZ050428B03-EF May 31, 2005 LAB CODE:200577-0 Page27 Rev. 00

Compliance Certification Services(ShenZhen) Inc. Report No.: SZ050428B03-EF FCC ID: R8OB013L2A Date of Issue: May 17, 2005 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Service Inc. . This document may be altered or revised by Compliance Certification Service Inc. personnel only, and shall be noted in the revision section of the document. Page 1of 33 Rev. 00 FCC CFR47 PART 18 SUBPART C ISM EQUIPMENT for Electromagnetic Emissions of BALLAST Trade Name : TDC POWER Model Number : EBA120-013L2A-PL Serial Number : N/A Report Number : SZ050428B03-EF Date : May 31,2005 Prepared for : TDC POWER PRODUCTS CO., LTD. DONGHANG 3 RD, INDUSTRIAL, DISTRICT DONG HANG, DONG GUAN CITY, GUANG DONG PROVINCE, CHINA Prepared by : COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. NO.6 JINAO INDUSTRIAL PARK, NO.35 JUKENG ROAD, DASHUIKENG VILLAGE,GUANLAN TOWN, BAOAN DISTRICT, SHENZHEN, CHINA TEL:86-755-28055000 FAX:86-755-28055221 LAB CODE:200577-0 Compliance Certification Services(ShenZhen) Inc. Report No.: SZ050428B03-EF FCC ID: R8OB013L2A Date of Issue: May 17, 2005 Page2 Rev. 00 TABLE OF CONTENTS DESCRIPTION PAGE VERIFICATION OF COMPLIANCE 3 SYSTEM DESCRIPTION 4 PRODUCT INFORMATION 5 SUPPORT EQUIPMENT 6 SECTION 1 FCC (LINE CONDUCTED & RADIATED EMISSION) 7 MEASUREMENT PROCEDURE & LIMIT (LINE CONDUCTED EMISSION TEST) 7 MEASUREMENT PROCEDURE & LIMIT (RADIATED EMISSION TEST) 10 SUMMARY DATA 13 TEST FACILITY 15 TEST EQUIPMENT LIST 16 BLOCK DIAGRAM OF TEST SETUP 17 APPENDIX 1 PHOTOGRAPHS (TEST SETUP OF LINE CONDUCTED EMISSION) 18 APPENDIX 2 PHOTOGRAPHS (TEST SETUP OF RADIATED EMISSION) 20 APPENDIX 3 EXTERNAL PHOTOGRAPHS OF EUT 22 APPENDIX 4 INTERNAL PHOTOGRAPHS OF EUT 26 APPENDIX 5 NVLAP CERTIFICATE OF ACCREDITATION 28 Compliance Certification Services(ShenZhen) Inc. Report No.: SZ050428B03-EF FCC ID: R8OB013L2A Date of Issue: May 17, 2005 Page3 Rev. 00 VERIFICATION OF COMPLIANCE Equipment Under Test: BALLAST Trade Name: TDC POWER Model Number: EBA120-013L2A-PL Serial Number: N/A Applicant: TDC POWER PRODUCTS CO., LTD. DONGHANG 3 RD, INDUSTRIAL, DISTRICT DONG HANG, DONG GUAN CITY, GUANG DONG PROVINCE, CHINA Manufacturer: TDC POWER PRODUCTS CO., LTD. DONGHANG 3 RD, INDUSTRIAL, DISTRICT DONG HANG, DONG GUAN CITY, GUANG DONG PROVINCE, CHINA Type of Test: FCC CFR47 PART 18 SUBPART C ISM EQUIPMENT Technical Limit: SUBPART C FCC Rules: Part 18 Measurement Procedure: ANSI C63.4 File Number: SZ050428B03-EF Date of test: May 11-31,2005 Deviation: None Condition of Test Sample: Normal The above equipment was tested by Compliance Certification Services (Shenzhen) Inc. for compliance with the requirements set forth in the FCC Rules and Regulations Part 15, Subpart B and the measurement procedure according to ANSI C63.4. This said equipment in the configuration described in this report shows the maximum emission levels emanating from equipment are within the compliance requirements. The test results of this report relate only to the tested sample identified in this report. Approved by Authorized Signatory: Clinton. Kao / Q.A. Manager Compliance Certification Services(ShenZhen) Inc. Report No.: SZ050428B03-EF FCC ID: R8OB013L2A Date of Issue: May 17, 2005 Page4 Rev. 00 SYSTEM DESCRIPTION EUT Test Program: EUT worked with two lamps, and make sure EUT worked normally. PRODUCT INFORMATION Compliance Certification Services(ShenZhen) Inc. Report No.: SZ050428B03-EF FCC ID: R8OB013L2A Date of Issue: May 17, 2005 Page5 Rev. 00 Housing Type: Metal EUT Power Rating: AC120V/60Hz Power during Test: AC120V/60Hz AC Power Cord Type: N/A OSC/Clock Frequencies: N/A I/O Port of EUT: I/O Port Type Q’TY Tested with 1) AC in 2 2 2) AC out 4 4 Difference between model numbers as below: Note: There are different output power and output modes between the model names. Model Number Trade Name 1 EBA120-009L2A-PL TDC Power 2 EBA120-007L2A-PL TDC Power 3 EBA120-013L1A-PL TDC Power 4 EBA120-009L1A-PL TDC Power 5 EBA120-007L1A-PL TDC Power Compliance Certification Services(ShenZhen) Inc. Report No.: SZ050428B03-EF FCC ID: R8OB013L2A Date of Issue: May 17, 2005 Page6 Rev. 00 SUPPORT EQUIPMENT No. Equipment Model # Serial # Trade NameData Cable Power Cord FCC ID 1) LAMP PL-13W N/A N/A N/A N/A N/A **Note: All the above equipment/cables were placed in worse case positions to maximize emission signals during emission test. Grounding: Grounding was in accordance with the manufacturer’s requirements and conditions for the intended use. Compliance Certification Services(ShenZhen) Inc. Report No.: SZ050428B03-EF FCC ID: R8OB013L2A Date of Issue: May 17, 2005 Page7 Rev. 00 SECTION 1 FCC (LINE CONDUCTED & RADIATED EMISSION) MEASUREMENT PROCEDURE (PRELIMINARY LINE CONDUCTED EMISSION TEST) 1) The equipment was set up as per the test configuration to simulate typical actual usage per the user’s manual. When the EUT is a tabletop system, a wooden table with a height of 0.8 meters is used and is placed on the ground plane as per ANSI C63.4 (see Test Facility for the dimensions of the ground plane used). When the EUT is a floor-standing equipment, it is placed on the ground plane which has a 3-12 mm non-conductive covering to insulate the EUT from the ground plane. 2) Support equipment, if needed, was placed as per ANSI C63.4 3) All I/O cables were positioned to simulate typical actual usage as per ANSI C63.4. 4) The EUT received AC120V/60Hz power through a Line Impedance Stabilization Network (LISN) which supplied power source and was grounded to the ground plane. 5) All support equipments received AC120V/60Hz power from a second LISN supplying power, if any. 6) The EUT test program was started. Emissions were measured on each current carrying line of the EUT using a spectrum Analyzer / Receiver connected to the LISN powering the EUT. The LISN has two monitoring points: Line 1 (Hot Side) and Line 2 (Neutral Side). Two scans were taken: one with Line 1 connected to Analyzer / Receiver and Line 2 connected t…

Text truncated - open the document above for the full version.

Report Number: SZ050428B03-EF May 31, 2005 LAB CODE:200577-0 Page21 Rev. 00 RADIATED EMISSION TEST SZ050428B03-EF SZ050411B01-EF
