RA8-BC012Solar Powered BT Speakerphoe with TTS

13 2 5 4 7 6 User Manual 1. About Bluetooth Speakerphone The Bluetooth TTS Speakerphone is compatible wi th most Bluetooth mobile phones. The Tex t-To-Speech system announces instructions for the users in 5 different languages and also indicates the status of the Bluetooth device. It also announces the name of the incoming cal ler (or phone number if the contact is not loaded into the Speakerphone’s phone book). Fu lly po rt ab le, it is an ideal wi reless communicati on solution for in-car or office use within a maximum range of 10 meters. Buil t-in with Ec ho Cancellation an d Noise Suppression, the Bluetooth Speakerphone provides you with impeccable sound quality in ful l duplex mode. Make sure that your Speakerphone is ful ly charged befor e using it. Use only the charger provided - do not use chargers fr om an y other devices as this might damage the device. A ful l charge is approximately 2.5 hours. 2. Appearance and Function (1) Speaker (2) Microphone (3) LED (4) Charging Socket (5-pin USB) (5) MFB But ton (Multi-Function But ton) (6) Volume Increase (V+) (7) Volume Decrease (V-) (8) Solar Panel 3. Recommend Installation Position It is recommended that the speakerphone is positioned on to the top of the left side of the windshield as shown in the pictures below: WARNING: Do not place or store the speakerphone over the area of the automobiles safet y airbag deployment, or it may cause serious injury when a safet y airbag deploys. 4. Charging Your Bluetooth Speakerphone The Bluetooth speakerphone comes with a built-in rechargeable battery. Prior to using the speakerphone, it is recommended to charge the battery ful ly for the first time. Using the car charger • Insert the car charger completely into the charging slot until the red LED goes on. • Normal ful l charge time is 2 hours. (approx. ), and the red LED goes off when charge is completed. Using solar power • Direct the solar panel on the back side of the speakerphone towar d sun. (Please refer to the recommended installation position, as mentioned above.) • If the speakerphone receives sufficient sunlight for 2 hours, you can talk for duration of up to 1 hour. Using solar power charge, the operation time (the talk time and the standby time) will be extended continuously without any additional charge required by the car charge r. WARNING: Do not at tempt to charge the speakerphone wi th an y charger other than the one provided. Using another charger may damage or destro y the speakerphone. 5. Turning On/Off the Speakerphone (1) To turn ON the Speakerphone Press and hold th e “MFB” bu tton for fou r se conds and the blue LED flashing 3 seconds light indicator comes on (“Power On” is announced). (2) To Turn OFF the Speakerphone Pr ess and hold the “MFB” button until the red LED flashing 3 seconds light indication goes of f (“Power Of f” is announced). 6. Pairing instructions for a typical Bluetooth enabled mobile phone. (1) Place the speakerphone and mobile phone no more than 1 meter (3 feet) apart. (2) Ensure the speakerphone is turned off. (3) Pr ess and hold the “MFB” button for 6 seconds until the LED flash red and blue al ternatively, it is now ready for pairing. (“Pairing phone please put your phone in pairing mode and enter PIN code “0000” is announced). (4) Activate the Bluetooth function on your mobile phone and search for accessible Bluetooth device by ref erring to your mobile phone user guide for details. (5) Select “BT Speaker” from the list of searched devices. (6) Enter the pre-programmed code “0000” and press “OK” to pair the speakerphone and the phone. (7) When pairing is completed, the speakerphone is under the standby mode with the blue LED flashes in every 3 seconds. Please place the mobile phone and the speakerphone within 10 meters (32 feet) sensing distance. (“Pairing Successful” is announced). NOTE: 1. If the pairing cannot be completed within 2 minutes after the pairing mode is activated, the speakerphone will power off automatically. Please repeat steps above to pair the speakerphone and mobile phone again. 2. When first time using the speakerphone and after restore to default settings, the speakerphone will automatically enter pairing mode after power on. 7. Connection Link/Between Speakerphone And Mobile Phone After pairing is completed, speakerphone is always under st and by mode. Before you place or answer a cal l, if the headset icon is not shown on phone screen, please follow the steps below to activate the Bluetooth connection/link thr ough your mobile phone or speakerphone until the headset icon is on the screen. • On phone: Select the “BT Speaker ” fr om the paired list on your mobile phone’s Bluetooth menu. • On speakerphone: Short press the “MFB” and select “Ac cept” on phone screen to ac cept connection. NOTE: 1. Your speakerphone will be automatically switched off when it is disconnected fr om a paired device for more than 10 minutes. This special feature is incorporated to maximize your speakerphone’s standby/talk time. To r einstate the connection, simply r epeat the process for turning speakerphone on. 2. If your speakerphone is set as an authorized Bluetooth device on your mobile phone, an automatic reconnection can be established by pressing the speakerphone’s “MFB” button once. 8. Using the Speakerphone (Most 0functions will be audibly announced) (1) Answering a Call When your mobile phone rings, pr ess the “MFB” button on the Speakerphone to connect the call. (2) Making Calls fr om your mobile phone Dial directly fr om your mobile phone. The cal l is automatically connected to your Speakerphone. (3) Reject a Call Hold onto the “MFB” button for 3 seconds to reject an incoming call. (4) Ending Calls When you have fi ni shed you r call, press the “MFB” bu tton on th e receiver to disconnect the call. (5) Making calls using voice dial ing (De pendent on mobile phone support ) P ress the “MFB” button once and call out the name of the person for the call to be placed. (6) Redial Last Outgoin…

Text truncated - open the document above for the full version.

Sunitec Enterprise Co., Ltd. 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County 23581, Ta i w a n FCC Authorization Letter Number: CF304 Version: V01 Date: 2012-4-18 We, (the approval holder) Company name Sunitec Enterprise Co., Ltd. Addresss 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County23581, Taiwan City Jhonghe Country Ta i w a n declare that the following representative (agent): Name (person) Aven zhou Function Supervisor Company name Compliance Certification Services (Shenzhen) Inc. Addresss No10-1, Mingkeda Logistics Park, No.18 Huanguan South RD. Guan lan Town, Baoan District, Shenzhen China City Shenzhen Country China is hereby authorized to apply the following equipment for certification on our behalf: Product Description Solar Powered BT Speakerphone with TTS Type or Model(s) BC960S，5506743 Tradename or Brand(s) sunitec We also authorize Teleconformity, Mr. M. Koop, (address: Rietven 31, 7534NH Enschede, Netherlands) to process this application. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Jhonghe，Ta i w a n July 02, 2012 Tom Chien General Manager

Sunitec Enterprise Co., Ltd. 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County 23581, Ta i w a n FCC Confidentiality Request Number: CF303 Version: V01 Date: 2012-4-18 To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name Sunitec Enterprise Co., Ltd. Addresss 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County23581, Taiwan City Jhonghe Country Ta i w a n request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: RA8 - BC012 of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) Operational Description Block Diagrams Schematics Diagrams Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Jhonghe，Ta i w a n July 02, 2012 Tom Chien General Manager

Report No.: SZ120628B01-RP Page 1 / 6 Report No.: SZ120628B01-RP Page 2 / 6 Report No.: SZ120628B01-RP Page 3 / 6 Report No.: SZ120628B01-RP Page 4 / 6 Report No.: SZ120628B01-RP Page 5 / 6 Report No.: SZ120628B01-RP Page 6 / 6

BC960S 20.0 mm 14.0 mm Sunitec Enterp rise CO., Lt d. Solar Powered BT Speakerphone with TTS Model No.: BC960S Made in Chi na Input DC: 5V 300mA IC : 8486A-BC960S FCC ID:RA8-BC012 Sunitec Enterp rise CO., Lt d. Solar Powered BT Speakerphone with TTS Model No.: BC960S Made in Chi na Input DC: 5V 300mA IC ID: 8486A-BC960S FCC ID:RA8-BC012

Report No.: SZ120628B01-RP Page 1 / 4 Internal Photos of EUT Report No.: SZ120628B01-RP Page 2 / 4 Report No.: SZ120628B01-RP Page 3 / 4 Report No.: SZ120628B01-RP Page 4 / 4

Report No.: SZ120628B01-RP Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NVLAP, NIST or any government agencies. The test result of this report relate only to the tested sample identified in this report. FCC ID: RA8-BC012 Page 1 / 59 FCC 47 CFR PART 15 SUBPART C TEST REPORT For Solar Powered BT Speakerphone with TTS Model: BC960S,5506743 Brand: N/A Test Report Number: SZ120628B01-RP Prepared for Sunitec Enterprise Co., Ltd 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County, 23581, Taiwan Prepared by COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. No.10-1, Mingkeda Logistics Park, No.18, Huanguan South Rd., Guan Lan Town, Baoan District, Shenzhen, China TEL: 86-755-28055000 FAX: 86-755-28055221 Issued Date: July 9,2012 Report No.: SZ120628B01-RP FCC ID: RA8-BC012 Page 2 of 59 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue No. Revisions Effect Page Revised By 00 SZ120628B01-RP Initial Issue ALL Anna Liu Report No.: SZ120628B01-RP FCC ID: RA8-BC012 Page 3 of 59 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION .....................................................................................4 2. EUT DESCRIPTION..........................................................................................................5 3. TEST METHODOLOGY....................................................................................................6 3.1 DESCRIPTION OF TEST MODES ................................................................................6 4. FACILITIES AND ACCREDITATIONS .............................................................................7 4.1 FACILITIES....................................................................................................................7 4.2 ACCREDITATIONS .......................................................................................................7 4.3 MEASUREMENT UNCERTAINTY ................................................................................7 5. SETUP OF EQUIPMENT UNDER TEST ..........................................................................8 5.1 SETUP CONFIGURATION OF EUT .............................................................................8 5.2 SUPPORT EQUIPMENT .............................................................................................8 6. FCC PART 15.247 REQUIREMENTS ..............................................................................9 6.1 20dB BANDWIDTH........................................................................................................9 6.2 PEAK POWER.............................................................................................................14 6.3 PEAK POWER SPECTRAL DENSITY ........................................................................15 6.4 BAND EDGES MEASUREMENT ................................................................................17 6.5 FREQUENCY SEPARATION ......................................................................................27 6.6 NUMBER OF HOPPING FREQUENCY ......................................................................30 6.7 TIME OF OCCUPANCY (DWELL TIME) .....................................................................33 6.8 SPURIOUS EMISSIONS .............................................................................................40 6.9 POWERLINE CONDUCTED EMISSIONS ..................................................................58 Report No.: SZ120628B01-RP FCC ID: RA8-BC012 Page 4 of 59 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1. TEST RESULT CERTIFICATION Product: Solar Powered BT Speakerphone with TTS Model: BC960S,5506743 Brand: N/A Tested: June 28~July 9,2012 Applicant: Sunitec Enterprise Co., Ltd 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County, 23581, Taiwan Manufacturer: Sunitec Enterprise Co., Ltd No.2,Qilin Road 2, RunTang Ind, Dan-Keng Village Fu Min Community, Guan-Lan Town, BaoAn District, Shenzhen Guangdong China APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4:2009 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.207, 15.209 and 15.247. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Tom Gan Supervisor of EMC Dept. Compliance Certification Service Inc. Aven Zhou Supervisor of Report Dept. Compliance Certification Service Inc. Report No.: SZ120628B01-RP FCC ID: RA8-BC012 Page 5 of 59 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 2. EUT DESCRIPTION Product Solar Powered BT Speakerphone with TTS Model Number BC960S,5506743 Brand N/A Model Discrepancy Just their model name was different. Identify Number SZ120628B01-RP USB Cable Unshielded, 1.00m Power Supply DC12/24V supplied by the car charger or DC3.7V supplied by the battery Received Date June 28,2012 Frequency Range 2402 ~ 2480 MHz Transmit Power GFSK :6.85dBm 8DPSK :5.02dBm Modulation Technique FHSS (GFSK for 1Mbps, π/4-DQPSK for 2Mbps, 8DPSK…

Text truncated - open the document above for the full version.

Report No.: SZ120628B01-RP FCC ID: RA8-BC012 Page 1 / 1 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST Below 1GHz Above 1GHz
