RA8-BC013BT 4 IN 1 Multifunction Pack

Introduction: PB C10 is a portable Flashlight and Emergency power bank wi th Bluetooth Handsfree A2DP device, which is ba se d on DSP with echo cancelati on and noise reduction. PB C10 is handy in an y en vir onment such as office, home, or in the car . PB C10 is able to connect to an y mobile cell phone that supports Bluetooth. New Bluetooth version impels stable and steady Wi reless connection with high speed and high quality AD2P+AVRCP. PB C10 has a 2100mAh built-in chargeable ly-polymer battery wi th an USB Out-put port switching regulator 5V DC/DC. PB C10 is an efficient ch arger and bright LED flashlight. Appearance and Function (1) Speaker (2) Microphone (3) LED (4) Charging Socket (USB) (5) On/Off LED Flashlight But ton (6) MFB But ton (Multi-Function But ton) (7) Volume Increase (V+) (8) Volume Decrease (V-) (9) LED Flashlight Package content: - PB C10 3-in-1 Device - USB Cable - Holder - User Manual - Sun Visor Clip Power Bank Charging Instruction Charge PBC10: (1) Split LED flashlight apart fr om PBC10 (2) Put charger Jack into PBC10’s in-put (3) Charging takes no longer than 3 hours (4) Red LED stays on when PB C10 is charging, Red LED turns to of f when Bat tery is ful ly charged. (5) Low Vol tage Reminder: Red LED flashes ev ery 3 seconds when Bluetooth is on, and Vol tage Low. Please charge the battery to maintain battery efficiency. Important: PBC automatically turns off if de vice is not charged after Low Voltage Reminder indication shows up. PBC10 Charges other devices: (1) Split LED flashlight apart fr om PBC10 (2) Connect USB A type to PBC10, connect the other end to other devices(cell phone, IPod) (3) Pr ess ON/OFF key to launch charging function. When Gr een light stays ON, cell phone and IPod are being charged via DC 5V. Important: 1. Charging fun ct ion is end ed and Gree n light is OFF when PBC10 do es no t connect to anything. 2. In the Cha rgin g acti ons , PBC10 aut omatic ally st op s ou t-put DC 5V when ce ll phone, IPod is eith er di sc onnect ed or fully charged, and Gree n light is OFF. (Some devices are prog rammed to choose bei ng cha rged even if the ba tter y is already ful ly charged, in that case, PB C10 wi ll NOT stop charging and Gr een light will stay on until PBC10’s battery is dead.) Installing 13 2 5 4 7 6 PowerBlue PBC10 Flash light ON/OFF Instruction: (1) Make sure flashlight is completely mounted. (Head part) (2) Press ON/OFF to turn flashlight ON. (3) Press ON/OFF to turn flashlight OFF, or split flashlight apart fr om PBC10. Bluetooth Handsfree Launch and A2DP+AVRCP Instruction Turn on Bluetooth: PBC10 is under OFF mode Pr ess and hold MFB for 4 seconds until you hear a short beep, and then Blue LED wi ll stay ON for 3 seconds. PB C10 will automatically reconnect to the last mobile phone it paired. Turn OFF Bluetooth: PBC10 is under ON mode Pr ess and hold MFB for 3 seconds until you hear a short beep, and then Red LED wi ll stay ON for 3 seconds. Pair PBC10 to your mobile phone Prior to using the speakerphone for the first time, you must pair it wi th a Bluetooth- enabled mobile: (1) Place the PCB10 and mobile handset no more than 1 meter away. (2) Ensure PBC10 is under OFF mode. (3) Pr ess and hold the MFB for 6 seconds until you hear a long beep. The Red LED and Blue LED will flash alternately. It’s now ready for pairing. (4) Acti vate your mobile handse t’s Bluet oo th function by referring to your mobile handset user gu ide for det ai ls . Mean whil e, the handset will se arch for ac cessible Bluetooth devices. (5) Select “Spea kerphone” from the list. (6) Enter the pr e-programmed password “0000” and pr ess “OK” to pair the PCB10 and the handset. When pairing is completed, you may hear a long beep and LED wi ll flash blue 3 times. Now the PCB10 is under standby mode wi th Blue LED flashes ev ery 3 seconds. (7) Press “Ret urn” to go ba ck to you r handse t’s main menu. (For most of th e mobile handset models, a he adset ic on will be sh own on the sc reen.) You should now be able to make and receive cal ls thr ough the PCB10. Please place the mobile handset to the PCB10 no more than 10 meters. (Obstruction could cause shorter sensing distance.) Important: Under the pa iring mode, if the pa iri ng can not be completed withi n 2 min utes, th e PCB10’s LED wil l flash of f and PCB10 wi ll be under of f mode. Please repeat step (3) to (7) to pair the pcb10 and mobile handset again. Connection/Link between Speakerphone and Mobile Handset After pairing is completed, speakerphone is always under standby mode. Bef or e you place or answer a call, if the he adset ICON is not sh own on ph one sc reen, please follo w the simple steps to activate the Bluetooth connection/lin k th rough you r handset or speakerphone until the headset ICON is on the screen. 1. On Handset: Select “Speakerphone” fr om the paired list on your handset screen. 2. On Speakerphone: Short pr ess MFB and select “Accept” on handset sc reen to ac cept connection. Disconnection between Speakerphone and Mobile Handset Please fol low the steps below if you want to connect PCB10 to another cell phone. (a) Power off the PCB10. (b) Select “disconnecting” to remove previous connection fr om your mobile phone list. Important: To save energy , PCB10 automatically turns OFF 10 minutes after disconnection. Blue LED flashes 3 times every 2 seconds if PBC10 is not connected to any mobile. Answer Incoming call: To an sw er a ca ll, wait for the speakerphone to ring, then sho rt press the MFB to ac cept the call. Answer incoming call during a call activity: A. Duri ng a call activity, press MFB bu tton tw ice qu ick ly to an swer incoming call and meanwhile hold first line. B. Pr ess MFB button once to end first line and answer s econd line. Reject incoming call during a call activity: During a call activity, press and hold MFB for 3 seconds to reject incoming call. Switch Calls: Pr ess MFB twice quickly to switch between two lines. Pr ess MFB once to end call one line to continue with the…

Text truncated - open the document above for the full version.

Sunitec Enterprise Co., Ltd. 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County 23581, Ta i w a n FCC Authorization Letter Number: CF304 Version: V01 Date: 2012-4-18 We, (the approval holder) Company name Sunitec Enterprise Co., Ltd. Addresss 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County23581, Taiwan City Jhonghe Country Ta i w a n declare that the following representative (agent): Name (person) Aven zhou Function Supervisor Company name Compliance Certification Services (Shenzhen) Inc. Addresss No10-1, Mingkeda Logistics Park, No.18 Huanguan South RD. Guan lan Town, Baoan District, Shenzhen China City Shenzhen Country China is hereby authorized to apply the following equipment for certification on our behalf: Product Description BT 4 IN 1 Multifunction Pack Type or Model(s) PBC10，5499516， Tradename or Brand(s) sunitec We also authorize Teleconformity, Mr. M. Koop, (address: Rietven 31, 7534NH Enschede, Netherlands) to process this application. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Jhonghe，Ta i w a n July 12, 2012 Tom Chien General Manager

Sunitec Enterprise Co., Ltd. 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County 23581, Ta i w a n FCC Confidentiality Request Number: CF303 Version: V01 Date: 2012-4-18 To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name Sunitec Enterprise Co., Ltd. Addresss 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County23581, Taiwan City Jhonghe Country Ta i w a n request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: RA8 - BC013 of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) Operational Description Block Diagrams Schematics Diagrams Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Jhonghe，Ta i w a n July 12, 2012 Tom Chien General Manager

Report No.: SZ120628B02-RP Page 1 / 4 Report No.: SZ120628B02-RP Page 2 / 4 Report No.: SZ120628B02-RP Page 3 / 4 Report No.: SZ120628B02-RP Page 4 / 4

20.0 mm 14.0 mm Sunitec Enterp rise CO., Lt d. BT 4 IN 1 Multifunction Pack Model No.: PBC10 Made in Chi na Input DC: 5V 300mA IC : 8486A-PBC10 FCC ID:RA8-BC013 Sunitec Enterp rise CO., Lt d. BT 4 IN 1 Multifunction Pack Model No.: PBC10 Made in Chi na Input DC: 5V 300mA IC : 8486A-PBC10 FCC ID:RA8-BC013

Report No.: SZ120628B02-RP Page 1 / 4 Internal Photos of EUT Report No.: SZ120628B02-RP Page 2 / 4 Report No.: SZ120628B02-RP Page 3 / 4 Report No.: SZ120628B02-RP Page 4 / 4

Report No.: SZ120628B02-RP Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NVLAP, NIST or any government agencies. The test result of this report relate only to the tested sample identified in this report. FCC ID: RA8-BC013 Page 1 / 60 FCC 47 CFR PART 15 SUBPART C TEST REPORT For BT 4IN 1 Multifunction Pack Model: PBC10,5499516 Brand: N/A Test Report Number: SZ120628B02-RP Prepared for Sunitec Enterprise Co., Ltd 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County, 23581, Taiwan Prepared by COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. No.10-1, Mingkeda Logistics Park, No.18, Huanguan South Rd., Guan Lan Town, Baoan District, Shenzhen, China TEL: 86-755-28055000 FAX: 86-755-28055221 Issued Date: July 10,2012 Report No.: SZ120628B02-RP FCC ID: RA8-BC013 Page 2 of 60 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue No. Revisions Effect Page Revised By 00 SZ120628B02-RP Initial Issue ALL Anna Liu Report No.: SZ120628B02-RP FCC ID: RA8-BC013 Page 3 of 60 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION .....................................................................................4 2. EUT DESCRIPTION..........................................................................................................5 3. TEST METHODOLOGY....................................................................................................6 3.1 DESCRIPTION OF TEST MODES ................................................................................6 4. FACILITIES AND ACCREDITATIONS .............................................................................7 4.1 FACILITIES....................................................................................................................7 4.2 ACCREDITATIONS .......................................................................................................7 4.3 MEASUREMENT UNCERTAINTY ................................................................................7 5. SETUP OF EQUIPMENT UNDER TEST ..........................................................................8 5.1 SETUP CONFIGURATION OF EUT .............................................................................8 5.2 SUPPORT EQUIPMENT .............................................................................................8 6. FCC PART 15.247 REQUIREMENTS ..............................................................................9 6.1 20dB BANDWIDTH........................................................................................................9 6.2 PEAK POWER.............................................................................................................14 6.3 PEAK POWER SPECTRAL DENSITY ........................................................................15 6.4 BAND EDGES MEASUREMENT ................................................................................17 6.5 FREQUENCY SEPARATION ......................................................................................27 6.6 NUMBER OF HOPPING FREQUENCY ......................................................................30 6.7 TIME OF OCCUPANCY (DWELL TIME) .....................................................................33 6.8 SPURIOUS EMISSIONS .............................................................................................40 6.9 POWERLINE CONDUCTED EMISSIONS ..................................................................58 Report No.: SZ120628B02-RP FCC ID: RA8-BC013 Page 4 of 60 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1. TEST RESULT CERTIFICATION Product: BT 4IN 1 Multifunction Pack Model: PBC10,5499516 Brand: N/A Tested: June 28~July 10,2012 Applicant: Sunitec Enterprise Co., Ltd 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County, 23581, Taiwan Manufacturer: Sunitec Enterprise Co., Ltd No.2,Qilin Road 2, RunTang Ind, Dan-Keng Village Fu Min Community, Guan-Lan Town, BaoAn District, Shenzhen Guangdong China APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4:2009 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.207, 15.209 and 15.247. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Tom Gan Supervisor of EMC Dept. Compliance Certification Service Inc. Aven Zhou Supervisor of Report Dept. Compliance Certification Service Inc. Report No.: SZ120628B02-RP FCC ID: RA8-BC013 Page 5 of 60 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 2. EUT DESCRIPTION Product BT 4IN 1 Multifunction Pack Model Number PBC10,5499516 Brand N/A Model Discrepancy Just their model name was different. Identify Number SZ120628B02-RP USB Cable Unshielded, 1.00m Power Supply DC3.7V supplied by the battery or DC5V supplied by the PC Received Date June 28,2012 Frequency Range 2402 ~ 2480 MHz Transmit Power GFSK :7.39dBm 8DPSK :5.34dBm Modulation Technique FHSS (GFSK for 1Mbps, π/4-DQPSK for 2Mbps, 8DPSK for 3Mbps) Number of Channels 79 Channels Ante…
