RA8-BH003Bluetooth Mono Headset

CRC#: 5278691 Multipoint Bluetooth Mono Headset Instruction Manual Before using this product, read this manual carefully and retain it for future reference. 1. About Bluetooth Technology Bluetooth wireless technology is set to revolutionize the personal connectivity by providing freedom from wired connections-enabling links and connectivity between notebook/laptop, mobile phones, portable handheld devices and other Bluetooth enabled devices within10 meters. Utilizing global sound & digital data 2.4GHz ISM transmission, it makes global communication in the way you’ve never dreamed of! 2.Getting to Know Your Bluetooth Headset To use your Bluetooth Headset, please follow these simple steps: (1) Charge your Headset. Prior to using the Headset, it is recommended to charge the battery fully for the first time. Normal full charge time is 2 hrs. (approx.) (2) Place your Headset and a Bluetooth-enabled mobile phone within 1 meter for pairing. (3) Ensure your Headset and m obile phone is placed within 10 meters Bluetooth sensing distance. (Obstruction could cause shorter sensing distance.) 3. Appearance and Function (1) Speaker (2) Microphone (3) Charging Socket (4) Multi-Function Button (MFB) (5) Volume Increase (V+) (6) Volume Decrease (V-) -01- 4. Charging Your Bluetooth Headset IMPORTANT: (1) Charging indication will b e delayed f or a few minutes if the headset has not been used for a long p er io d time or the batt ery is drained. (2) To prolong durability of batt ery, it is recommended t o charge the headset whenever a low batt ery signal is encounter ed. When batt ery becomes low, the LED will flash red every 3 seconds. Under a low batt ery condition, if headset is continuously used, it will decrease the durability of batt ery as well as the standby time. This causes a longer charge time than the normal 2 hours and the headset will p ower off. (3) The red LED will flash on while charging, and will turn off when charging is completed. The Bluetooth Headset c omes with a built-in r echargeable batt ery. Prior to using the headset, it is recommended t o charge the batt ery fully f or the first time. Normal full charge time is 2 hrs. (approx.) 5. Turning ON/OFF the Headset POWER ON: When the headset is under off mode, press and hold the “MFB” for 3 seconds until you hear a short beep. The r ed LED will flash 3 times, and then the headset will automatically c onnect the last c onnected mobile phone. POWER OFF: When headset is in standby mode, press and hold the “MFB” button for 3 seconds until y ou hear a short beep. The r ed LED will flash 3 times bef ore power off. 6. Pairing Prior to using the headset for the first time, y ou must pair it with a Bluetooth- enabled mobile phone. The steps below describ e pairing instructions f or a typical Bluetooth-enabled mobile phone. (1) Place the headset and mobile phone no more than 1 meter apart. (2) Ensure the headset is in OFF mode. (3) Press and hold the “MFB” button for 6 seconds until the red LED flashes on. I t is now r eady f or pairing. (4) Activate the Bluetooth function on your mobile phone. (R ef er to your mobile phone owner’s manual). (5) Select : ”BT Headset” fr om the list. (6) Enter the pre-programmed c ode “0000” and press “OK” t o pair the headset and the phone. When pairing is completed, the headset is now in standby mode with the red LED flashing every 3 seconds. -02- (7) Press “Return” t o go back to your mobile phone’s main menu. Place the mobile phone and headset within 10 meters f or recommended sensing distance. NOTE: If the pairing is not completed within 2 minutes after pairing mode is activated, the headset will p ower off automatically. You will have t o repair the headset using the steps above. 7. Connection/Link between Headset and Mobile Phone After pairing is completed, headset will r emain in standby mode. Bef ore placeing or answer ing a call, if the headset icon is not shown on phone screen, f ollow the steps below t o activate the Bluetooth c onnection/link through the mobile phone or headset until the headset icon is on the screen. (1) ON PHONE: Select the ”BT Headset” fr om the paired list on your phone screen. (2) ON HEADSET: Press “MFB” and select “Accept” on phone screen to form the connection. 8. Dis connection between Headset and Mobile Phone When you need to connect your headset with another Bluetooth-enabled mobile phone. Follow the steps below to disconnect the headset from the the pre-paired mobile phone. (1) Power off the headset. (2) Select “Disconnect” on the Bluetooth device list of your mobile phone to remove the connection. NOTE: When losing the connection/link, the headset will automatically turn off in 10 minutes. The r ed LED will flash twice e very 3 seconds when the headset is not connected to mobile phone. 9. Using the Headset (1) ANSWERING CALL When receiving a phone call, press the “MFB” button to answer the call. (2) ENDING CALL Press the “MFB” button to end a call. (3) REJECT CALL When you hear the ringing t one, press and hold the “MFB” button for 3 seconds to reject the call. (4) VOICE DIAL If your mobile phone is voice dialing enabled, in standby mode, press the “MFB” button and say the voice tag after you hear a beep. NOTE: Please make sure to record voice tag into the mobile phone bef ore using voice dial function. Functionality v ar ies depending on the mobile phone models. (Ref er t o your mobile phone owner’s manual.) -03- (5) LAST NUMBER RE-DIALING In standby mode, press the “MFB” button twice f or last number redial. (6) ADJUSTING THE VOLUME During a call, press the “V+” or “V-” buttons repeatedly until y ou reach the desired v olume level. (7) MUTE & UN-MUTE a. Mute: During a call, press and hold the “V-” button for 3 seconds to mute the headset. The red LED will flash on during mute mode. b. Un-Mute: press and hold the “V-” button 3 seconds to un-mute the headset. (8) TRANSFERRING CALLS a. Headset to Mobile Phone: During a call, press and hold the “V+” button for 3 seconds. The…

Text truncated - open the document above for the full version.

Sunitec Enterprise Co., Ltd. 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County 23581, Taiwan FCC Confidentiality Request Number: CF303 Version: V01 Date: 2012-4-18 To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name Sunitec Enterprise Co., Ltd. Addresss 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County23581, Taiwan City Jhonghe Country Taiwan request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: RA8 - BH003 of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) x Operational Description x Block Diagrams x Schematics Diagrams Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Jhonghe，Taiwan April 18, 2012 Tom Chien General Manager

Report No: SZ120412B10-RP Page 1 / 4 Report No: SZ120412B10-RP Page 2 / 4 Report No: SZ120412B10-RP Page 3 / 4 Report No: SZ120412B10-RP Page 4 / 4

20.0 mm 14.0 mm Sunitec Enterp rise CO., Lt d. Bluetooth Headset Model No.: BH805 Made in Chi na Input DC: 5V 300mA IC : 8486A-BH805 FCC ID:RA8 - BH003 Sunitec Enterp rise CO., Lt d. Bluetooth Headset Model No.: BH805 Made in Chi na Input DC: 5V 300mA IC : 8486A-BH805 FCC ID:RA8 - BH003

Report No: SZ120412B10-RP Page 1 / 3 Internal Photos of EUT Report No: SZ120412B10-RP Page 2 / 3 Report No: SZ120412B10-RP Page 3 / 3

Report No: SZ120412B10-RP Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NVLAP, NIST or any government agencies. The test result of this report relate only to the tested sample identified in this report. FCC ID: RA8-BH003 Page 1 of 60 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. FCC 47 CFR PART 15 SUBPART C TEST REPORT For Bluetooth Mono Headset Model: BH805 Brand: N/A Test Report Number: SZ120410B10-RP Prepared for Sunitec Enterprise Co., Ltd 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County, 23581, Taiw an Prepared by COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. No.10-1, Mingkeda Logistics Park, No.18, Huanguan South Rd., Guan Lan Town, Baoan District, Shenzhen, China TEL: 86-755-28055000 FAX: 86-755-28055221 Issued Date: April 30,2012 Report No: SZ120412B10-RP FCC ID: RA8-BH003 Page 2 of 60 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue No. Revisions Effect Page Revised By 00 SZ120412B10-RP Initial Issue ALL Anna Liu Report No: SZ120412B10-RP FCC ID: RA8-BH003 Page 3 of 60 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION .....................................................................................4 2. EUT DESCRIPTION..........................................................................................................5 3. TEST METHODOLOGY....................................................................................................6 3.1 DESCRIPTION OF TEST MODES ............................................................................................ 6 4. FACILITIES AND ACCREDITATIONS .............................................................................7 4.1 FACILITIES................................................................................................................................. 7 4.2 ACCREDITATIONS ................................................................................................................... 7 4.3 MEASUREMENT UNCERTAINTY .......................................................................................... 7 5. SETUP OF EQUIPMENT UNDER TEST ..........................................................................8 5.1 SETUP CONFIGURATION OF EUT ......................................................................................... 8 5.2 SUPPORT EQUIPMENT ..........................................................................................................8 6. FCC PART 15.247 REQUIREMENTS ..............................................................................9 6.1 20DB BANDWIDTH................................................................................................................... 9 6.2 PEAK POWER .......................................................................................................................... 14 6.3 PEAK POWER SPECTRAL DENSITY.................................................................................... 16 6.4 BAND EDGES MEASUREMENT ........................................................................................... 17 6.5 FREQUENCY SEPARATION .................................................................................................. 27 6.6 NUMBER OF HOPPING FREQUENCY.................................................................................. 30 6.7 TIME OF OCCUPANCY (DWELL TIME) .............................................................................. 33 6.8 SPURIOUS EMISSIONS........................................................................................................... 40 6.9 POWERLINE CONDUCTED EMISSIONS ............................................................................. 48 Report No: SZ120412B10-RP FCC ID: RA8-BH003 Page 4 of 60 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1. TEST RESULT CERTIFICATION Product: Bluetooth Mono Headset Model: BH805 Brand: N/A Tested: April 12~29,2012 Applicant: Sunitec Enterprise Co., Ltd 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County, 23581, Taiwan Manufacturer: Sunitec Enterprise Co., Ltd No.2,Qilin Road 2, RunTang Ind, Dan-Keng Village Fu Ming Community, Guan-Lan Town, BaoAn District, Shenzhen Guangdong China APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4:2009 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.207, 15.209 and 15.247. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Tom Gan Supervisor of EMC Dept. Compliance Certification Service Inc. Aven Zhou Supervisor of Report Dept. Compliance Certification Service Inc. Report No: SZ120412B10-RP FCC ID: RA8-BH003 Page 5 of 60 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 2. EUT DESCRIPTION Product Bluetooth Mono Headset Model Number BH805 Brand N/A Model Discrepancy N/A Identify Number SZ120412B10-RP Power Supply DC5V supplied by the notebook or DC3.7V supplied by the battery Received D…

Text truncated - open the document above for the full version.

Report No.: SZ120412B10-RP FCC ID: RA8-BH003 Page 1 / 2 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Report No.: SZ111208B03-RP FCC ID: RA8-BH003 Page 2 / 2 . RADIATED EMISSION TEST Below 1GHz Above 1GHz
