RA8-BH004Bluetooth Mono Headset

4. Charging Your Bluetooth Headset IMPORTANT: (1) Charging indication will b e delayed f or a few minutes if the headset has not been used for a long p er io d time or the batt ery is drained. (2) To prolong durability of batt ery, it is recommended t o charge the headset whenever a low batt ery signal is encounter ed. When batt ery becomes low, the LED will flash red every 3 seconds. Under a low batt ery condition, if headset is continuously used, it will decrease the durability of batt ery as well as the standby time. This causes a longer charge time than the normal 2 hours and the headset will p ower off. (3) The red LED will flash on while charging, and blue LED will flash on when charging is completed. The Bluetooth Headset comes with a built-in r echa rgeable batt ery. Prior to using the headset, it is recommended t o charge the batt ery fully f or the first time. Normal full charge time is 2 hrs. (approx.) 5. Turning ON/OFF the Headset POWER ON: When the headset is in off mode, press and hold the “MFB” f or 3 seconds until you hear a short beep. Theblue LED willflash 5 times, and then the headset will automatically r e-connect t o the last c onnected mobile phone. POWER OFF: When headset is in standby mode, press and hold the “MFB” button for 3 seconds until y ou hear a short beep. The r ed LED will flash 5times bef ore turning off. 6. Pairing Prior to using the headset for the first time, y ou must pair it with a Bluetooth- enabled mobile phone. The steps below describ e pairing instructions f or a typical Bluetooth-enabled mobile phone. (1) Place the headset and mobile phone no more than 1 meter apart. (2) Ensure the headset is in OFF mode. (3) Press and hold the “MFB” button for 6 seconds until the red and blue LED flashes. It is now r eady f or pairing. (4) Activate the Bluetooth function on your mobile phone. (R ef er to your mobile phone owner’s manual). (5) Select : ”BT Headset” fr om the list. (6) Enter the pre-programmed c ode “0000” and press “OK” t o pair the headset and the phone. When pairing is completed, the red LED will st op flashing and the headset is now in standby mode with the blue LED flashing every 3 seconds. -02- CRC#: 5279036 Instruction Manual Before using this product, read this manual carefully and retain it for future reference. 1. About Bluetooth Technology Bluetooth wireless technology is set to revolutionize the personal connectivity by providing freedom from wired connections-enabling links and connectivity between notebook/laptop, mobile phones, portable handheld devices and other Bluetooth enabled devices within10 meters. Utilizing global sound & digital data 2.4GHz ISM transmission, it makes global communication in the way you’ve never dreamed of! 2.Getting to Know Your Bluetooth Headset To use your Bluetooth Headset, please follow these simple steps: (1) Charge your Headset. Prior to using the Headset, it is recommended to charge the battery fully for the first time. Normal full charge time is 2 hrs. (approx.) (2) Place your Headset and a Bluetooth-enabled mobile phone within 1 meter for pairing. (3) Ensure your Headset and m obile phone is placed within 10 meters Bluetooth sensing distance. (Obstruction could cause shorter sensing distance.) 3. Appearance and Function (1) Speaker (2) Microphone (3) Charging Socket (4) Multi-Function Button (MFB) (5) Volume Increase (V+) (6) Volume Decrease (V-) -01- (3) (1) (5) (6) (2) (2) (4) (7) Press “Return” t o go back to your mobile phone’s main menu. Place the mobile phone and headset within 10 meters f or recommended sensing distance. NOTE: If the pairing is not completed within 2 minutes after pairing mode is activated, the headset will p ower off automatically. You will have t o repair the headset using the steps above. 9. Using the Headset (1) ANSWERING CALL When receiving a phone call, press the “MFB” button to answer the call. (2) ENDING CALL Press the “MFB” button to end a call. (3) REJECT CALL When you hear the ringing t one, press and hold the “MFB” button for 3 seconds to reject the call. (4) VOICE DIAL If your mobile phone is voice dialing enabled, in standby mode, press the “MFB” button and say the voice tag after you hear a beep. NOTE: Please make sure to record voice tag into the mobile phone bef ore using voice dial function. Functionality v ar ies depending on the mobile phone models. (Ref er t o your mobile phone owner’s manual.) -03- 7. Connection/Link between Headset and Mobile Phone After pairi ng is completed, head set is always under st andby mode. Before you place or answer a call, if the headset ic on is not sh own on ph one screen, please fol low the steps below to activate the Bluetooth connection/ link thr ough your mobile phone or headset until the headset icon is on the screen. (1) On phone: Select the “B T Headset” fr om the paired list on your phone screen. (2) On headset: Short pr ess “MFB” and select “Ac cept” on phone screen to ac cept connection. 8. Disconnection between Headset and Mobile Phone When you need to connect your headset with an other Bluetooth-enabled mobile phone, please fol low the steps below to disconnect the headset wi th the pre-paired mobile phone. (1) Power off the Headset. (2) Select “Disconnecting” on the Bluetooth device list of your mobile phone to remove the connection. Note: When losing the connection/ link, the he adset will be aut omatic ally po wer off in 10 minutes . The blue LED will flash twic e in every 3 se conds when the headset is not connected with mobile phone. Manufactured for your Military Exchanges ©2012 Exchange P.O.BOX 660202 Dallas, TX 75266-0202 Printed in China www.shop my exchange.com -07- 14. Product Specifications Bluetooth C ompliance: Bluetooth V2.1 + EDR specifications Oper ating F requency Band: 2.4 GHz ~ 2.48 GHz unlicensed ISM band Output Power : Class 2 Power Output, up to 10 meters Support P rofiles: HSP and HFP1.5 profiles Support Multiple P aired Device: Up to 8 Bluetooth Phone can be paired Stand-by Time: Up …

Text truncated - open the document above for the full version.

Sunitec Enterprise Co., Ltd. 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County 23581, Ta i w a n FCC Authorization Letter Number: CF304 Version: V01 Date: 2012-4-18 We, (the approval holder) Company name Sunitec Enterprise Co., Ltd. Addresss 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County23581, Taiwan City Jhonghe Country Ta i w a n declare that the following representative (agent): Name (person) Aven zhou Function Supervisor Company name Compliance Certification Services (Shenzhen) Inc. Addresss No10-1, Mingkeda Logistics Park, No.18 Huanguan South RD. Guan lan Town, Baoan District, Shenzhen China City Shenzhen Country China is hereby authorized to apply the following equipment for certification on our behalf: Product Description Bluetooth Mono Headset Type or Model(s) BH600N Tradename or Brand(s) N/A We also authorize Teleconformity, Mr. M. Koop, (address: Rietven 31, 7534NH Enschede, Netherlands) to process this application. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Jhonghe，Ta i w a n April 18, 2012 Tom Chien General Manager

Sunitec Enterprise Co., Ltd. 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County 23581, Taiwan FCC Confidentiality Request Number: CF303 Version: V01 Date: 2012-4-18 To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name Sunitec Enterprise Co., Ltd. Addresss 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County23581, Taiwan City Jhonghe Country Taiwan request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: RA8 - BH004 of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) x Operational Description x Block Diagrams x Schematics Diagrams Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Jhonghe，Taiwan April 18, 2012 Tom Chien General Manager

Report No: SZ120412B12-RP Page 1 / 4 Report No: SZ120412B12-RP Page 2 / 4 Report No: SZ120412B12-RP Page 3 / 4 Report No: SZ120412B12-RP Page 4 / 4

20.0 mm 14.0 mm Sunitec Enterp rise CO., Lt d. Bluetooth Headset Model No.: BH600N Made in Chi na Input DC: 5V 300mA IC : 8486A-BH600N FCC ID:RA8 - BH004 Sunitec Enterp rise CO., Lt d. Bluetooth Headset Model No.: BH600N Made in Chi na Input DC: 5V 300mA IC : 8486A-BH600N FCC ID:RA8 - BH004

Report No: SZ120412B12-RP Page 1 / 3 Internal Photos of EUT Report No: SZ120412B12-RP Page 2 / 3 Report No: SZ120412B12-RP Page 3 / 3

Report No: SZ120412B12-RP FCC ID: RA8-BH004 Page 1 of 60 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. FCC 47 CFR PART 15 SUBPART C TEST REPORT For Bluetooth Mono Headset Model: BH600N Brand: N/A Test Report Number: SZ120412B12-RP Prepared for Sunitec Enterprise Co.,Ltd 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County, 23581, Taiwan Prepared by COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. No.10-1, Mingkeda Logistics Park, No.18, Huanguan South Rd., Guan Lan Town, Baoan District, Shenzhen, China TEL: 86-755-28055000 FAX: 86-755-28055221 Issued Date: April 30, 2012 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NVLAP, NIST or any government agencies. The test result of this report relate only to the tested sample identified in this report. Report No: SZ120412B12-RP FCC ID: RA8-BH004 Page 2 of 60 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue No. Revisions Effect Page Revised By 00 SZ120412B12-RP Initial Issue ALL Nancy Fu Report No: SZ120412B12-RP FCC ID: RA8-BH004 Page 3 of 60 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION .....................................................................................4 2. EUT DESCRIPTION..........................................................................................................5 3. TEST METHODOLOGY ....................................................................................................6 3.1. DESCRIPTION OF TEST MODES ...............................................................................6 4. FACILITIES AND ACCREDITATIONS .............................................................................7 4.1. FACILITIES...................................................................................................................7 4.2. ACCREDITATIONS ......................................................................................................7 4.3. MEASUREMENT UNCERTAINTY ...............................................................................7 5. SETUP OF EQUIPMENT UNDER TEST ..........................................................................8 5.1. SETUP CONFIGURATION OF EUT ............................................................................8 5.2. SUPPORT EQUIPMENT ............................................................................................8 6. FCC PART 15.247 REQUIREMENTS ..............................................................................9 6.1. 20DB BANDWIDTH ......................................................................................................9 6.2. PEAK POWER............................................................................................................14 6.3. PEAK POWER SPECTRAL DENSITY .......................................................................16 6.4. BAND EDGES MEASUREMENT ...............................................................................17 6.5. FREQUENCY SEPARATION .....................................................................................27 6.6. NUMBER OF HOPPING FREQUENCY .....................................................................30 6.7. TIME OF OCCUPANCY (DWELL TIME) ....................................................................33 6.8. SPURIOUS EMISSIONS ............................................................................................40 6.9. POWERLINE CONDUCTED EMISSIONS .................................................................58 Report No: SZ120412B12-RP FCC ID: RA8-BH004 Page 4 of 60 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1. TEST RESULT CERTIFICATION Product: Bluetooth Mono Headset Model: BH600N Brand: N/A Tested: April 12~ April 29, 2012 Applicant: Sunitec Enterprise Co.,Ltd 10F.-1, No.200, Jingping Rd., Jhonghe City, Taipei County, 23581, Taiwan Manufacturer: Sunitec Enterprise Co.,Ltd No.2, Qilin Road 2, RunTang Ind, Dan-Keng Village Fu Ming Community, Guan-Lan Town, BaoAn District, Shenzhen Guangdong China APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4:2009 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.207, 15.209 and 15.247. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Tom Gan Supervisor of EMC Dept. Compliance Certification Service Inc. Aven Zhou Supervisor of Report Dept. Compliance Certification Service Inc. Report No: SZ120412B12-RP FCC ID: RA8-BH004 Page 5 of 60 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 2. EUT DESCRIPTION Product Bluetooth Mono Headset Model Number BH600N Brand N/A Model Discrepancy N/A Identify Number SZ120412B12-RP Power Supply DC 5V supplied by the notebook or DC3.7V supplied by the battery Received Date April 12, 2012 Frequency Range 2402 ~ 2480 MHz Transmit Power GFSK: 6.75dBm 8DPSK: 5.75dBm Modulation Technique FHSS (GFSK for 1Mbps, π/4-DQPSK for 2Mbps, 8DPSK for 3Mbps) Nu…

Text truncated - open the document above for the full version.

Report No.: SZ120412B12-RP Page 1 / 2 FCC ID: RA8-BH004 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Report No.: SZ120412B12-RP FCC ID: RA8-BH004 Page 2 . RADIATED EMISSION TEST Below 1GHz Above 1GHz
