RAD001GSM1900 Mobile Phone

English 3DS09782AAAA01 www.alcatel.com English ALCATEL BUSINESS SYSTEMS © 2003. All rights reserved. ALCATEL reserves the right, in customer's interest, to alter material or technical specifications without prior notice. BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:52 Page 1 2 7. Directoriesp. 30 7.1Accessing your directoriesp. 30 7.2Creating a directory file p. 32 7.3Classifying a file in a family p. 33 7.4Available optionsp. 34 7.5Assigning a ring tone to a familyp. 36 7.6Temporary SIM cardp. 36 8. Messagesp. 37 8.1Accessing messagesp. 37 8.2Reading your messages p. 38 8.3Writing a messagep. 43 8.4Data entry system: predictive modep. 45 8.5Sending a messagep. 48 8.6Deleting your messagesp. 49 9. My setupp. 50 9.1Soundsp. 50 9.2Picturesp. 55 9.3Black/White background (Negat.Screen)p. 55 9.4Downloaded data (Downloaded)p. 56 9.5Zoomp. 57 9.6Numbersp. 57 10. Gamesp. 59 1 CONTENTS Safety and precautionsp. 4 Informationp. 9 1.Your telephonep. 11 1.1Keysp. 11 1.2Iconsp. 13 1.3Symbols used in the User Guidep. 14 2. Getting startedp. 15 2.1SIM Card and batteryp. 15 2.2Switching your phone onp. 18 2.3Switching your phone offp. 18 3. Callsp. 19 3.1Making a callp. 19 3.2Calling your voice mailp. 20 3.3Receiving a callp. 20 3.4Options available while callingp. 21 3.5Double line managementp. 24 4. Call memoryp. 25 5. MENUp. 26 6. Eventsp. 29 BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:52 Page 1 4 SAFETY AND PRECAUTIONS We recommend that you read this chapter carefully before use. The manufacturer disclaims any liability for damage which may result as a consequence of improper use or use contrary to the instructions contained herein. •TRAFFIC SAFETY: Given recent studies, which show that using a mobile telephone while driving a vehicle constitutes a real risk, even when the hands-free kit is used (car kit, headset...), drivers are requested to refrain from using their mobile telephone when the vehicle is not parked. Your mobile phone when powered emits radiation which may interfere with the vehicle electronic systems such as anti-lock brakes (ABS, airbag). As a result, you should: -avoid placing the phone on the dashboard or within an airbag deployment area. -connect the phone to an external antenna or switch the phone off. The antenna should be mounted and located away from the driver and passengers or separated from them by a metal screen (e.g. the car roof). -check with the car manufacturer or your car dealer that the dashboard is adequately shielded from mobile phone RF energy. •CONDITIONS OF USE: Switch the phone off before boarding an aircraft to avoid prosecution. Switch the phone offwhen you are in health care facilities, except 3 11. Alarmsp. 63 11.1Wake upp. 63 11.2Appointmentsp. 64 11.3Birthdaysp. 64 11.4Optionsp. 64 12. Calculator/Converterp. 65 12.1Calculator p. 65 12.2Convertp. 66 13. Setupp. 68 13.1Services p. 68 13.2Clockp. 76 13.3Languagesp. 76 13.4Dictionaryp. 76 13.5Input modep. 77 13.6Displayp. 77 13.7Pickupp. 77 13.8Automatic power offp. 78 13.9Double line managementp. 78 13.10 Keypad lockp. 78 14.WAPp. 79 14.1Accessing WAP Servicesp. 79 14.2Available optionsp. 80 14.3Setting up your accessp. 82 14.4Launching WAPp. 84 15. Warrantyp. 85 16. Character setp. 88 17. Accessoriesp. 89 18.Troubleshootingp. 91 BG3 _PCS_AUS_UM_17-07-03 17/07/03 12:52 Page 3 6 • CHARGERS Mains powered chargers mains will operate within the temperature range: 0 to 40°C. The chargers designed for your mobile phone meet with the standard for safety of information technology equipment and office equipment use.They should be used for this purpose only. • RADIO WAVES: THIS MODEL PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. Your mobile phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio-frequency (RF) energy. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The guidelines include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. 5 in designated areas. As with many other types of equipment now in regular use, mobile telephones can interfere with other electrical or electronic devices, or equipment using radio frequency. When the phone is switched on, avoid placing it near a medical aid device, if you carry one, such as a pacemaker, one hearing aid or insulin pump. When using the phone you should hold it against the ear on the opposite side to the device, if any. Switch the phone off when you are near gas or flammable liquids. Strictly obey all signs and instructions posted in a fuel depot, gas station, or chemical plant, or in any potentially explosive atmosphere. Do not let small children use the phone without supervision. Do not attempt to open or repair it yourself. Use only Alcatel batteries, battery chargers, and accessories that are compatible with your phone model. (See Accessories List, chapter 17). Alcatel will not be held responsible if this is not respected. Do not allow your phone to be exposed to unfavourable environmental conditions (humidity, rain, infiltration of liquids, dust, sea air, etc). The manufacturer’s recommended operating temperature range is -10°C to + 55°C. Over 55°C the legibility of the phone’s display may be impaired, though this is temporary and not serious. •BATTERY: Before removing the battery from your phone, please make sure that the phone is switched off. Take precautions with the battery and do not attempt to open the battery (chemical substances may cause burns). Do not pierce, disassemble nor cause a short-circuit in a battery. Do not burn or dispose of a used battery in household waste or store it at temperatures above 60 °C. Batteries must be disposed of in accordance with locally applicable environm…

Text truncated - open the document above for the full version.

32, avenue Kléber 92707 Colombes Cedex France Tél. : + 33 (0)1 55 66 70 00 One Touch 331P User's manual Alcatel declares that the following sentence is added on page 8 of the manual: "For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines when used with an accessory that contains no metal and that positions the handset a minimum of 1.5 cm from the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines." Colombes, August 12 th , 2003 Marielle Taureau Mobile Phone Division Approvals Domain

CETECOM ICT Services GmbH Test report no.: 2-3250-01-01/03Issue Date: 2003-07-04Page 136 (151) Photographs of the equipment CETECOM ICT Services GmbH Test report no.: 2-3250-01-01/03Issue Date: 2003-07-04Page 137 (151) Photographs of the equipment CETECOM ICT Services GmbH Test report no.: 2-3250-01-01/03Issue Date: 2003-07-04Page 138 (151) Photographs of the equipment CETECOM ICT Services GmbH Test report no.: 2-3250-01-01/03Issue Date: 2003-07-04Page 139 (151) Photographs of the equipment

TTI-P-G 158 Appendix for DASY Test-Report, Alcatel_6575_325 : Calibration Data Appendix for the Report Dosimetric Assessment of the Alcatel One Touch 331P (FCC ID: RAD001) According to the FCC Requirements Calibration Data July 08, 2003 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer Alcatel Business Systems 32, Avenue Kléber F-92707 Colombes Cedex France This report shall not be reproduced except in full without the written approval of the testing laboratory.

TTI-P-G 158 DASY Test-Report, Alcatel_ 6575_325 Page 1 of 38 Report Dosimetric Assessment of the Portable Device Alcatel One Touch 331P (FCC ID: RAD001) According to the FCC Requirements July 08 2003 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer Alcatel Business Systems 32, avenue KlÈber F-92707 Colombes Cedex The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. dasy_report_fcc_supplement_c _3.2.doc/16.06.2003/CH DASY Test-Report, Alcatel_ 6575_325 Page 2 of 38 dasy_report_fcc_supplement_c _3.2.doc/16.06.2003/CH H Executive Summary The One Touch 331P is a new mobile phone (Portable Device) from Alcatel operating in the 1900 MHz frequency range. The device has an integrated antenna. The system concepts used is the PCS 1900 standard. The objective of the measurements done by IMST was the dosimetric assessment of one device in the PCS 1900 standard. The examinations have been carried out with the dosimetric assessment system ÑDASY4ì. The measurements were made according to the Supplement C to OET Bulletin 65 of the Federal Communications Commission (FCC) Guidelines [FCC 2001] for evaluating compliance of mobile and portable devices with FCC limits for human exposure (general population) to radiofrequency emissions. All measurements have been performed in accordance to the recommendations given by SPEAG (Fig. 13). The Alcatel One Touch 331P mobile phone (FCC ID: RAD001) is in compliance with the Federal Communications Commission (FCC) Guidelines [FCC 2001] for uncontrolled exposure. The phone was tested in the Body Worn configuration with the following accessories and combinations: • Belt clip and headset prepared by: ........................................... reviewed by: .............................................. AndrÈ van den Bosch Dipl.-Ing. Christoph Hennes test engineer quality assurance engineer IMST GmbH Carl-Friedrich-Gaufl-Strafle 2 D-47475 Kamp-Lintfort Tel. +49- 2842-981 373 Fax +49- 2842-981 399 email: [email protected] DASY Test-Report, Alcatel_ 6575_325 Page 3 of 38 dasy_report_fcc_supplement_c _3.2.doc/16.06.2003/CH H Table of Contents 1 SUBJECT OF INVESTIGATION ................................................................................................................... 4 2 THE IEEE STANDARD C95.1 AND THE FCC EXPOSURE CRITERIA................................................. 4 2.1 DISTINCTION BETWEEN EXPOSED POPULATION, DURATION OF EXPOSURE AND FREQUENCIES...................... 4 2.2 DISTINCTION BETWEEN MAXIMUM PERMISSIBLE EXPOSURE AND SAR LIMITS................................................ 5 2.3 SAR LIMIT................................................................................................................................................... 5 3 THE FCC MEASUREMENT PROCEDURE ................................................................................................ 6 3.1 GENERAL REQUIREMENTS............................................................................................................................ 6 3.2 DEVICE OPERATING NEXT TO A PERSON’S EAR............................................................................................. 6 3.3 BODY-WORN AND OTHER CONFIGURATIONS................................................................................................. 9 4 THE MEASUREMENT SYSTEM ................................................................................................................ 10 4.1 PHANTOM.................................................................................................................................................. 12 4.2 PROBE....................................................................................................................................................... 12 4.3 MEASUREMENT PROCEDURE...................................................................................................................... 13 4.4 UNCERTAINTY ASSESSMENT........................................................................................................................ 14 5 SAR RESULTS ................................................................................................................................................ 15 6 EVALUATION ................................................................................................................................................ 16 7 APPENDIX ...................................................................................................................................................... 18 7.1 ADMINISTRATIVE DATA.............................................................................................................................. 18 7.2 DEVICE UNDER TEST AND TEST CONDITIONS.............................................................................................. 18 7.3 TISSUE RECIPES......................................................................................................................................... 19 7.4 MATERIAL PARAMETERS............................................................................................................................. 19 7.5 SIMPLIFIED PERFORMANCE CHECKING...................................................................................................... 20 7.6 ENVIRONMENT........................................................................................................................................... 24 7.7 TEST EQUIPMENT....................................................................................................................................... 24 7.8 CERTIFICATES OF CONFORMITY.................................................................................................................. 25 7.9 PICTURES OF THE DEVICE UNDER TEST................................................................................................…

Text truncated - open the document above for the full version.

TTI-P-G 158 DASY Test-Report, Alcatel_6575_325_SAR Distribution Plots Page 1 of 12 Appendix for the Report Dosimetric Assessment of the Alcatel One Touch 331P (FCC ID: RAD001) According to the FCC Requirements SAR Distribution Plots July 08, 2003 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer Alcatel Business Systems 32, avenue KlÈber F-92707 Colombes Cedex The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. dasy_report_fcc_supplement_c _2.0.doc/25.09.2001/CH DASY Test-Report, Alcatel_6575_325_SAR Distribution Plots Page 2 of 12 dasy_report_fcc_supplement_c _2.0.doc/25.09.2001/CH Table of Contents 1 SAR DISTRIBUTION PLOTS, PCS 1900 HEAD..........................................................................................3 2 SAR DISTRIBUTION PLOTS, PCS 1900 BODY..........................................................................................7 3 SAR Z-AXIS SCANS (VALIDATION) ........................................................................................................... 9 4 SAR Z-AXIS SCANS (MEASUREMENTS) .................................................................................................11 DASY Test-Report, Alcatel_6575_325_SAR Distribution Plots Page 3 of 12 dasy_report_fcc_supplement_c _2.0.doc/25.09.2001/CH 1 SAR Distribution Plots, PCS 1900 Head Test Laboratory: IMST DUT: Alcatel ; Type: ONE TOUCH 331 P; Serial: 330587533874290 Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8 Medium: Head 1900 MHz (σ = 1.38 mho/m, ε r = 39.3, ρ = 1000 kg/m 3 ) Phantom section: Left Section DASY4 Configuration: - Probe: ET3DV6 - SN1669; ConvF(5.2, 5.2, 5.2); Calibrated: 21.03.2003 - Sensor-Surface: 4mm (Mechanical And Optical Surface Detection) - Electronics: DAE3 Sn335; Calibrated: 05.05.2003 - Phantom: SAM TP:1176; Type: SAM 4.0; Serial: 1176 - Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.6 Build 115 cheek left/Area Scan (6x10x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 9.79 V/m Power Drift = -0.04 dB Maximum value of SAR = 0.223 mW/g cheek left/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Peak SAR (extrapolated) = 0.409 W/kg SAR(1 g) = 0.236 mW/g; SAR(10 g) = 0.122 mW/g Reference Value = 9.79 V/m Power Drift = -0.04 dB Maximum value of SAR = 0.261 mW/g Fig. 1: SAR distribution for PCS 1900, channel 661, cheek position, left side of head. (25.06.2003; Ambient Temperature: 21.5∞ C; Liquid Temperature: 20.1∞ C). DASY Test-Report, Alcatel_6575_325_SAR Distribution Plots Page 4 of 12 dasy_report_fcc_supplement_c _2.0.doc/25.09.2001/CH Test Laboratory: IMST File Name: 331plm_2.da4 DUT: Alcatel ; Type: ONE TOUCH 331 P; Serial: 330587533874290 Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8 Medium: Head 1900 MHz (σ = 1.38 mho/m, ε r = 39.3, ρ = 1000 kg/m 3 ) Phantom section: Left Section DASY4 Configuration: - Probe: ET3DV6 - SN1669; ConvF(5.2, 5.2, 5.2); Calibrated: 21.03.2003 - Sensor-Surface: 4mm (Mechanical And Optical Surface Detection) - Electronics: DAE3 Sn335; Calibrated: 05.05.2003 - Phantom: SAM TP:1176; Type: SAM 4.0; Serial: 1176 - Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.6 Build 115 tilted left/Area Scan (6x10x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 10.8 V/m Power Drift = 0.01 dB Maximum value of SAR = 0.208 mW/g tilted left/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Peak SAR (extrapolated) = 0.337 W/kg SAR(1 g) = 0.206 mW/g; SAR(10 g) = 0.109 mW/g Reference Value = 10.8 V/m Power Drift = 0.01 dB Maximum value of SAR = 0.233 mW/g Fig. 2: SAR distribution for PCS 1900, channel 661, tilted position, left side of head. (25.06.2003; Ambient Temperature: 21.7∞ C; Liquid Temperature : 19.9∞ C). DASY Test-Report, Alcatel_6575_325_SAR Distribution Plots Page 5 of 12 dasy_report_fcc_supplement_c _2.0.doc/25.09.2001/CH Test Laboratory: IMST File Name: 331prm_1.da4 DUT: Alcatel ; Type: ONE TOUCH 331 P; Serial: 330587533874290 Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8 Medium: Head 1900 MHz (σ = 1.38 mho/m, ε r = 39.3, ρ = 1000 kg/m 3 ) Phantom section: Right Section DASY4 Configuration: - Probe: ET3DV6 - SN1669; ConvF(5.2, 5.2, 5.2); Calibrated: 21.03.2003 - Sensor-Surface: 4mm (Mechanical And Optical Surface Detection) - Electronics: DAE3 Sn335; Calibrated: 05.05.2003 - Phantom: SAM TP:1176; Type: SAM 4.0; Serial: 1176 - Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.6 Build 115 cheek right/Area Scan (6x10x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 11.2 V/m Power Drift = 0.04 dB Maximum value of SAR = 0.147 mW/g cheek right/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Peak SAR (extrapolated) = 0.259 W/kg SAR(1 g) = 0.16 mW/g; SAR(10 g) = 0.0881 mW/g Reference Value = 11.2 V/m Power Drift = 0.04 dB Maximum value of SAR = 0.176 mW/g cheek right/Zoom Scan (7x7x7)/Cube 1: Measurement grid: dx=5mm, dy=5mm, dz=5mm Peak SAR (extrapolated) = 0.205 W/kg SAR(1 g) = 0.146 mW/g; SAR(10 g) = 0.0891 mW/g Reference Value = 11.2 V/m Power Drift = 0.04 dB Maximum value of SAR = 0.157 mW/g Fig. 3: SAR distribution for PCS 1900, channel 661, cheek position, right side of head ( 25.06.2003; Ambient Temperature: 21.7∞ C; Liquid Temperature : 19.9∞ C). 0 1 DASY Test-Report, Alcatel_6575_325_SAR Distribution Plots Page 6 of 12 dasy_report_fcc_supplement_c _2.0.doc/25.09.2001/CH Test Laboratory: IMST File Name: 331prm_2.da4 DUT: Alcatel ; Type: ONE TOUCH 331 P; Serial: 330587533874290 Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8 Medium: Head 1900 MHz (σ = 1.38 mho/m, ε r = 39.3, ρ = 1000 kg/m 3 ) Phantom section: Right Section DASY4 Configuration: - Probe: ET3DV6 - SN1669; ConvF(5.2, 5.2, 5.2); Calibrated: 21.03.2003 - Sensor-Surface: 4mm (Mechanical And Optical Surface Detection) - Electronics: DAE3 Sn…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Radio Satellite Communication Untertürkheimer Straße 6-10 . D-66117 SaarbrückenTelephone: +49 (0)681 598-9100Telefax: -9075 RSC11issue test report consist of 151 PagesPage 1 (151) BLUETOOTH TM is a trademark owned by Bluetooth SIG, Inc. and licensed to CETECOM Recognized by the Federal Communications Commission FCC–Identification Number: 90462 TCB ID: DE 0001 Accredited by the German Accreditation Council DAR–Registration Number TTI–P–G 166/98 Independent ETSI compliance test house ETSI Accredited Bluetooth™ Test Facility (BQTF) Test report no.: 2-3250-01-01/03 FCC Part 24/15 One Touch 331P FCC ID: RAD001 CETECOM – ICT Services GmbH Untertürkheimerstr. 6-10 66117 Saarbrücken, Germany Telephone: + 49 (0) 681 / 598-0 Fax: + 49 (0) 681 / 598-9075 CETECOM ICT Services GmbH Test report no.: 2-3250-01-01/03Issue Date: 2003-07-04Page 2 (151) Table of Contents 1 General information 1.1 Notes 1.2 Testing laboratory 1.3 Details of applicant 1.3 Application details 1.5 Test item 1.6 Test specifications 2 Technical test 2.1 Summary of test results 2.2 Test report CETECOM ICT Services GmbH Test report no.: 2-3250-01-01/03Issue Date: 2003-07-04Page 3 (151) 1 General information 1.1 Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. Technical responsibility for area of testing : 2003-07-23RSC 8411 Ames H. DateSectionNameSignature Technical responsibility for area of testing : 2003-07-23RSC8412Hausknecht D. DateSectionNameSignature CETECOM ICT Services GmbH Test report no.: 2-3250-01-01/03Issue Date: 2003-07-04Page 4 (151) 1.2 Testing laboratory CETECOM ICT Services GmbH Untertürkheimer Straße 6 - 10 66117 Saarbrücken Germany Telephone: + 49 681 598 - 9100 Telefax : + 49 681 598 - 9075 E-mail: [email protected] Internet: www.cetecom-ict.de Accredited testing laboratory The Test laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025. DAR registration number: TTI-P-G-166/98 Listed by: Federal Communications Commission (FCC) Identification/Registration No : 90462 Accredited Bluetooth TM Test Facility (BQTF) BLUETOOTH TM is a trademark owned by Bluetooth SIG, Inc. and licensed to CETECOM 1.3Details of applicant Name : ALCATEL BUSINESS SYSTEMS Street : 32 avenue Kleber City : 92707 Colombes Country : France Telephone : +33 1 55 66 32 20 Telefax : + 33 1 55 66 64 02 Contact : Mr. Jean Fleuriot Telephone : +33 1 55 66 32 20 E-mail: [email protected] 1.4 Application details Date of receipt of application : 2003-05-20 Date of receipt of test item : 2003-07-02 Date of test : 2003-07-02 - 2003-07-03 CETECOM ICT Services GmbH Test report no.: 2-3250-01-01/03Issue Date: 2003-07-04Page 5 (151) 1.5 Test item: Type of equipment : Mobile Phone Type designation:One Touch 331P Manufacturer: Street: City: Country: Serial number:S/N: Additional information : Frequency:1850.2 – 1909.8 MHz Type of modulation:300KGXW / 300KG7W Number of channels :300 (PCS1900) Antenna:Integral antenna Power supply:3,7V DC NiMH Battery Output power GSM 1900 :cond : 30.1 dBm Peak , ERP: 28.3 dBm (Burst); EIRP: 30.4 dBm (Burst) Temperature range:-30°C - +60°C FCC – ID:RAD001 IC :- / - IMEI:350946.56.660137.2 Hardware Status:01 Software Status:01 Additional Accessories: 1) headset, reference 3DS 07855 AAAA (Supplier Merry) 2) headset, reference 3DS 07855 ABAA (Supplier Leemax) 3) battery, reference 3DS 09352 AAAA (Supplier BYD) 4) battery, reference 3DS 06641 AAAA (Supplier Sony) 5) single range charger, reference 3DS 09371 AGAA, 100-127V (Supplier Leader Electronics) 6) SMS keyboard, reference 3DS 07237 AAAA (Supplier Thong Fook Precision Industries) 7) Cigar lighter charger, reference 3DS 07848 AAAA (Supplier Primax) 8) Easy to install hands-free car kit, reference MP82 (Supplier Primax) 1.6Test specifications: FCC Part 24 FCC Part 15 CETECOM ICT Services GmbH Test report no.: 2-3250-01-01/03Issue Date: 2003-07-04Page 6 (151) 2 Technical test For Part 24/22 we use the substitution method ( TIA/EIA 603). 2.1 Summary of test results No deviations from the technical specification(s) were ascertained in the course of the tests performed. FINAL VERDICT: PASS CETECOM ICT Services GmbH Test report no.: 2-3250-01-01/03Issue Date: 2003-07-04Page 7 (151) 2.2Test report TEST REPORT Test report no. : 2-3250-01-01/03 CETECOM ICT Services GmbH Test report no.: 2-3250-01-01/03Issue Date: 2003-07-04Page 8 (151) TEST REPORT REFERENCE LIST OF MEASUREMENTS PARAMETER TO BE MEASURED PAGE Part PCS 1900 POWER OUTPUT SUBCLAUSE § 24.2329 FREQUENCY STABILITY SUBCLAUSE § 24.23511 AFC FREQ ERROR vs. VOLTAGE12 AFC FREQ ERROR vs. TEMPERATURE12 EMISSIONS LIMITS §24.23814 CONDUCTED SPURIOUS EMISSIONS72 BLOCK EDGE COMPLIAMNCE FOR BLOCK A, B, C, D, E AND F81 OCCUPIED BANDWIDTH §2.98993 CONDUCTED EMISSIONS § 15.107/207100 ADDITIONAL MEASUREMENTS FOR THE ANCILLARY EQUIPMENT PART 15.109 103 TEST EQUIPMENT AND ANCILLARIES USED FOR TESTS129 TEST SITE131 PHOTOGRAPHS OF THE EQUIPMENT136 CETECOM ICT Services GmbH Test report no.: 2-3250-01-01/03Issue Date: 2003-07-04Page 9 (151) REFERENCE NUMBER(S) OF TEST EQUIPMENT USED (for reference numbers see test equipment listing) 64 POWER OUTPUT SUBCLAUSE § 24.232 Summery: This paragraph contains both average , peak output powers and EIRP measurements for the mobile station. In all cases, the peak output power is within the required mask (this mask is specified in the JTC standards, TIA PN3389 Vol. 1 Chap 7, and is no FCC requirement). Method of Measurements: The mobile was set up for the max. output power with pseudo random data modul…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Test report no.: 2-3250-01-01/03Issue Date: 2003-07-04Page 131 (151) Test site CETECOM ICT Services GmbH Test report no.: 2-3250-01-01/03Issue Date: 2003-07-04Page 132 (151) Test site CETECOM ICT Services GmbH Test report no.: 2-3250-01-01/03Issue Date: 2003-07-04Page 133 (151) Test site CETECOM ICT Services GmbH Test report no.: 2-3250-01-01/03Issue Date: 2003-07-04Page 134 (151) Test site CETECOM ICT Services GmbH Test report no.: 2-3250-01-01/03Issue Date: 2003-07-04Page 135 (151) Test site
