RAD029GSM 850 & GSM 1900 MHz MOBILE PHONE

TCT Mobile Limited

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Apr 06, 2006
Application Purpose: Original Equipment
Date of Application: Apr 06, 2006
Equipment Note: GSM 850 & GSM 1900 MHz MOBILE PHONE
Frequency Range: 1850.20000000 - 1909.80000000
Company: TCT Mobile Limited
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

E5LIQUID_UM_USA_21-03-06 21/03/06 8:47 Page 1 E5LIQUID_UM_USA_21-03-06 21/03/06 8:47 Page 2 Introduction ..........................................................T&A Mobiles phones would like to thank you for your purchasing this mobile.Your handset boasts a wide quality 65k colour display, in a stylish compact design, an embedded VGAcamera, video shooting and playback, java games, IM/Chat (1) (Instant message/Chat), E-mail (1) , Remote Synchronisation (1) , etc. Just 3 clicks and your images and voice messages will be sent to your friends. It’s so simple! Music and lightsWant to see the backlight of your phone dancing to the music? Every time your phone rings, the backlightwill be synchronized aswell. Fantastic!P anorama Have you ever thought that your viewfinder was too narrow to take in everything you wanted to capture?We can help you. Panorama can provide up to 3 pictures in QVGA format. Capture the whole scene.Unbelievable!Video & Video toneDo you want to capture laughter, music and greetings in your video? It’s all in your phone. You can also setany video clip as the incoming melody. We call it Videotone! 1 (1) Depending on your network operator and product. E5LIQUID_UM_USA_21-03-06 21/03/06 8:47 Page 1 Ta b le of contents .................................................. Introduction ................................................................................................................... ...................1 Safety and Use ................................................................................................................. .................5 General Information ............................................................................................................ ............9 1. Your mobile .................................................................................................................. ..........10 1.1 Keys ........................................................................................................................ ..................................................................12 1.2 Main screen icons ........................................................................................................... .......................................................13 2. Getting started .............................................................................................................. ........15 2.1 Set-up ..................................................................................................................... ...................................................................15 2.2 Switching on your telephone ................................................................................................ ..............................................18 2.3 Start-up wizard............................................................................................................ ............................................................19 2.4 Switching off your telephone ................................................................................................ ..............................................19 3. Calls ........................................................................................................................ ................20 3.1 Making a call .............................................................................................................. ..............................................................20 3.2 Calling your voicemail ..................................................................................................... .....................................................21 3.3 Receiving a call ........................................................................................................... .............................................................21 3.4 During the call ............................................................................................................ ............................................................22 3.5 Conference calls ........................................................................................................... .........................................................24 3.6 Double line (ALS) .......................................................................................................... .........................................................24 4. Call log ..................................................................................................................... ...............25 4.1 Call memory ................................................................................................................ ............................................................25 4.2 My Numbers ................................................................................................................. ...........................................................25 4.3 My e-mail address ........................................................................................................... .......................................................26 4.4 Billing .................................................................................................................... ....................................................................26 4.5 Call settings............................................................................................................... ...............................................................27 5. Menu ......................................................................................................................... ...............30 6. Directory .................................................................................................................... ............32 6.1 Consulting your directory ................................................................................................... ............…

Text truncated - open the document above for the full version.

External Photos

Report No.: ER/2006/20013 FCC ID:RAD029 Issue Date: Mar. 6, 2006 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test re- port cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw APPENDIX 2 PHOTOGRPHS OF EUT Report No.: ER/2006/20013 FCC ID:RAD029 Issue Date: Mar. 6, 2006 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test re- port cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw All of EUT Adaptor-3DS09371AGAA Supplier: Leader Electronics Report No.: ER/2006/20013 FCC ID:RAD029 Issue Date: Mar. 6, 2006 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test re- port cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Adaptor-3DS09371AGAA Supplier: Astec Adaptor-3DS09371AAAA Supplier: Astec Report No.: ER/2006/20013 FCC ID:RAD029 Issue Date: Mar. 6, 2006 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test re- port cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Adaptor-3DS09371AAAA Supplier: Leader Electronics Adaptor-3DS07848AAAA Supplier :Primax Report No.: ER/2006/20013 FCC ID:RAD029 Issue Date: Mar. 6, 2006 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test re- port cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Front View of EUT Back View of EUT Report No.: ER/2006/20013 FCC ID:RAD029 Issue Date: Mar. 6, 2006 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test re- port cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Left View of EUT Right View of EUT Report No.: ER/2006/20013 FCC ID:RAD029 Issue Date: Mar. 6, 2006 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test re- port cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Top View of EUT Bottom View of EUT Report No.: ER/2006/20013 FCC ID:RAD029 Issue Date: Mar. 6, 2006 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test re- port cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Open View of EUT – 1 Open View of EUT - 2 Report No.: ER/2006/20013 FCC ID:RAD029 Issue Date: Mar. 6, 2006 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test re- port cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Internal of EUT --- 1 Internal of EUT --- 2 Report No.: ER/2006/20013 FCC ID:RAD029 Issue Date: Mar. 6, 2006 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test re- port cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Internal of EUT --- 3 Internal of EUT --- 4 Report No.: ER/2006/20013 FCC ID:RAD029 Issue Date: Mar. 6, 2006 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test re- port cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw Internal of EUT --- 5

Internal Photos

Operational Description

Antenna

RF Exposure Info

Order No: SHGLO060200019GSM Date: Mar. 28, 2006 Page: 1 of 105 SAR TEST REPORT Eequipment Under Test : GSM 850&GSM1900MHz MOBILE PHONE Model No. : E5La Market name: OT-C750a FCC ID : RAD029 Applicant : T&A Mobile Phones Address of Applicant : 5/F, No.2966, Jinke Rd, Zhangjiang High-Teck Park, Pudong, Shanghai 201203. P. R. China Date of Receipt : 2006.03.17 Date of Test : 2006.03.17 – 2006.03.21 Date of Issue : 2006.03.28 Standards: FCC OET Bulletin 65 supplement C, ANSI/IEEE C95.1, C95.3, IEEE 1528-2002 In the configuration tested, the EUT complied with the standards specified above. Remarks: This report details the results of the testing carried out on one sample, the results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS-CSTC Shanghai GSM Lab or testing done by SGS-CSTC Shanghai GSM Lab must approve SGS Shanghai GSM Lab in connection with distribution or use of the product described in this report in writing. Tested by : Date : 2006.03.28 Approved by : Date : 2006.03.28 Order No: SHGLO060200019GSM Date: Mar. 28, 2006 Page: 2 of 105 Contents 1. General Information.............................................................................5 1.1 Test Laboratory..........................................................................................................5 1.2 Details of Applicant...................................................................................................5 1.3 Description of EUT(s)................................................................................................5 1.4 Test Environment......................................................................................................6 1.5 Operation Configuration...........................................................................................6 1.6 The SAR Measurement System................................................................................6 1.7 SAR System Verification...........................................................................................8 1.8 Tissue Simulant Fluid for the Frequency Band 850MHz and 1900MHZ................9 1.9 Test Standards and Limits......................................................................................10 2. Summary of Results..........................................................................11 3. Instruments List.................................................................................13 4. Measurements....................................................................................14 850MHz GSM Mode........................................................................................................14 4.1 FCC-OET65-LeftHandSide-Cheek-GSM850-Low...................................................14 FCC-OET65-LeftHandSide-GSM850--Cheek-Low.................................................................14 4.2 FCC-OET65-LeftHandSide-Cheek-GSM850-Mid....................................................15 FCC-OET65-LeftHandSide-GSM850-Cheek-Mid..................................................................15 4.3 FCC-OET65-LeftHandSide-Cheek-GSM850-High..................................................17 FCC-OET65-LeftHandSide-GSM850-Cheek-High.................................................................17 4.4 FCC-OET65-LeftHandSide-Tilt-GSM850-Low........................................................19 FCC-OET65-LeftHandSide-GSM850-Tilt-Low......................................................................19 4.5 FCC-OET65-LeftHandSide-Tilt-GSM850-Mid.........................................................21 FCC-OET65-LeftHandSide-GSM850-Tilt-Mid.......................................................................21 4.6 FCC-OET65-LeftHandSide-Tilt-GSM850-High........................................................23 FCC-OET65-LeftHandSide-GSM850-Tilt-High......................................................................23 LeftHandSide-Cheek-GSM850-High (Interpolated SAR, Maximum Value)................25 FCC-OET65-LeftHandSide-GSM850-Cheek-High (Traditional).............................................25 4.7 FCC-OET65-RightHandSide-Cheek-GSM850-Low................................................28 FCC-OET65-RightHandSide-GSM850-Cheek-Low................................................................28 4.8 FCC-OET65-RightHandSide-Cheek-GSM850-Mid.................................................29 FCC-OET65-RightHandSide-GSM850-Cheek-Mid................................................................29 4.9 FCC-OET65-RightHandSide-Cheek-GSM850-High...............................................31 Order No: SHGLO060200019GSM Date: Mar. 28, 2006 Page: 3 of 105 FCC-OET65-RightHandSide-GSM850-Cheek-High...............................................................31 4.10 FCC-OET65-RightHandSide-Tilt-GSM850-Low....................................................33 FCC-OET65-RightHandSide-GSM850-Tilt-Low....................................................................33 4.11 FCC-OET65-RightHandSide-Tilt-GSM850-Mid.....................................................35 FCC-OET65-RightHandSide-GSM850-Tilt-Mid.....................................................................35 4.12 FCC-OET65-RightHandSide-Tilt-GSM850-High....................................................37 FCC-OET65-RightHandSide-GSM850-Tilt-High...................................................................37 RightHandSide-Cheek-GSM850-High (Interpolated SAR, Maximum Value).............39 FCC-OET65-RightHandSide-GSM850-Cheek-High...............................................................39…

Text truncated - open the document above for the full version.

Test Report

SGS-CSTC Standards Technical Services Co., Ltd. 1/F, 7/F, 9/F, 10/F, the 3rd Building No. 889, Yishan Road, Xuhui District, Shanghai, China Telephone: +86 (0) 21 6495 1616 Fax: +86 (0) 21 5450 0954 [email protected] Report No.: SHEMO060200119IT Page 1 of 52 Authorized Signature: Tino Pan Chester Zhao E&E Section Head E&E Project Engineer SGS-CSTC Co., Ltd. SGS-CSTC Co., Ltd This report refers to the General Conditions for Inspection and Testing Services, printed overleaf This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the SGS PRODUCT CERTIFICATION MARK.. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. All test results in this report can be traceable to National or International Standards. Member of the SGS Group (SGS SA) FCC TEST REPORT(DOC) Application No.: SHEMO060200119IT Applicant: TCL&Alcatel Mobile Phones. Equipment Under Test (EUT): NOTE: The following sample(s) submitted was/were identified on behalf of the client as EUT Name: GSM Mobile Phone Type.: E5La Marketing Name: OT-C750a Item No.: Not supplied by client Serial No.: Not supplied by client Standards: CFR 47 part 2: 2004, CFR 47 Part 15: 2005, ANSI C63.4: 2003 Date of Receipt: 23 February 2006 Date of Test: 23 February 2006 to 7 March 2006 Date of Issue: 8 March 2006 Test Result : PASS SGS-CSTC Standards Technical Services Co., Ltd. 1/F, 7/F, 9/F, 10/F, the 3rd Building No. 889, Yishan Road, Xuhui District, Shanghai, China Telephone: +86 (0) 21 6495 1616 Fax: +86 (0) 21 5450 0954 [email protected] Report No.: SHEMO060200119IT Page 2 of 52 2 Test Summary Test Test Requirement Test Method Class / Severity Result Radiated Emission 30MHz-1000MHz CFR 47 Part 15 ANSI C63.4: 2003 Class B PASS Conducted Emission 150KHz-30MHz CFR 47 Part 15 ANSI C63.4: 2003 Class B PASS Note: OT-C750a has five power adapters (ASTEC: 3DS09371AGAA, 3DS09371AAAA , LEADER: 3DS09371AGAA, 3DS09371AAAA , 3DS09371AAHA) and one earphone. And all sample have been tested, So we just have five sets test data show in report. SGS-CSTC Standards Technical Services Co., Ltd. 1/F, 7/F, 9/F, 10/F, the 3rd Building No. 889, Yishan Road, Xuhui District, Shanghai, China Telephone: +86 (0) 21 6495 1616 Fax: +86 (0) 21 5450 0954 [email protected] Report No.: SHEMO060200119IT Page 3 of 52 3 Contents Page 1 COVER PAGE..........................................................................................................................................................1 2 TEST SUMMARY....................................................................................................................................................2 3 CONTENTS ..............................................................................................................................................................3 4 GENERAL INFORMATION..................................................................................................................................4 4.1 CLIENT INFORMATION............................................................................................................................................4 4.2 GENERAL DESCRIPTION OF E.U.T...........................................................................................................................4 4.3 DETAILS OF E.U.T. .................................................................................................................................................4 4.4 DESCRIPTION OF SUPPORT UNITS...........................................................................................................................5 4.5 STANDARDS APPLICABLE FOR TESTING..................................................................................................................5 4.6 TEST LOCATION......................................................................................................................................................5 4.6 DEVIATION FROM STANDARDS...............................................................................................................................6 4.7 ABNORMALITIES FROM STANDARD CONDITIONS....................................................................................................6 4.8 MONITORING OF EUT FOR ALL IMMUNITY TEST....................................................................................................6 4.9 TEST CONFIDENT LEVEL.........................................................................................................................................6 5 EQUIPMENTS USED DURING TEST .................................................................................................................7 6 EMISSION TEST RESULTS..................................................................................................................................8 6.1 RADIATED EMISSIONS, 30MHZ TO 1GHZ...............................................................................................................8 6.1.1 E.U.T. Operation..........................................................................................................................................8 6.1.2 Test setup: ..........................................................................................................................................…

Text truncated - open the document above for the full version.

Test Report

Report No.: ER/2006/20013 FCC ID:RAD029 Issue Date: Mar. 6, 2006 Page: 1 of 75 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test re- port cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 22 SUBPART H and PART 24 SUBPART E REQUIREMENT OF Product Name: GSM 850/1900 mobile phone Brand Name: Alcatel Model Name: E5La Market Name: OT-C750a FCC ID: RAD029 Report No.: ER/2006/20013 Issue Date: Mar. 06, 2006 FCC Rule Part: 2 & 22H & 24E Prepared for T&A Mobile Phones 5/F, No.2966, Jinke Rd, Zhangjiang High-Teck Park, Pudong Shanghai 201203. P. R. China Prepared by SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei County, Taiwan. Note: This report shall not be reproduced except in full, without the written approval of SGS Taiwan Ltd. This document may be altered or revised by SGS Taiwan Ltd. personnel only, and shall be noted in the revision section of the document. Report No.: ER/2006/20013 FCC ID:RAD029 Issue Date: Mar. 6, 2006 Page: 2 The…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Zhizhou Gong

[email protected]+86(0)2151798260Fax: +86(0)2161460600

Test Firm

SGS-CSTC Standards Technical Services Co.,Ltd.June Zhang

[email protected]8675525328598Fax: 86075526710594

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
2	24E	1.85 GHz - 1.91 GHz	598.00 mW	242KGXW	63 Hz

Confidentiality

Long Term

Grant Notes

Power Output is ERP for Part 22 and EIRP for Part 24. Body-worn operations are restricted to approved belt-clips, holsters or similar accessories tested for this filing and to belt-clips, holsters or similar accessories that have no metallic component in the assembly and which provide at least 2.0 cm separation between the device and the users body. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. The highest reported SAR values are: Part 22 Head: 0.794 W/kg; Body-worn 1.09 W/kg; PCS Band Head: 0.547 W/kg; Body-worn 0.489 W/kg.
