RAD055GSM 850/1900 mobile phone with BT

English - T5000830AAAA 02 C7_UM_USA_29-08-07 29/08/07 8:23 Page 1 Table of contents ........................Safety and use ......................................................................5General information..........................................................101. Your mobile ..................................................................12 1.1 Keys ......................................................................................................14 1.2 Main screen icons ..............................................................................16 1.3 External screen icons........................................................................17 2. Getting started ............................................................18 2.1 Set-up....................................................................................................18 2.2 Power on your phone ......................................................................21 2.3 Power off your phone ......................................................................21 3. Calls ..............................................................................22 3.1 Making a call........................................................................................22 3.2 Calling your voicemail ......................................................................22 3.3 Receiving a call ..................................................................................23 3.4 During the call ....................................................................................24 3.5 Conference calls ................................................................................25 3.6 Line switching (ALS)..........................................................................26 4. Menu..............................................................................275. Call logs / settings ........................................................29 5.1 Call memory ......................................................................................29 5.2 My numbers ........................................................................................29 5.3 Billing ....................................................................................................30 5.4 Call settings ........................................................................................30 6. Directory ......................................................................33 6.1 Consulting your directory ..............................................................33 6.2 Creating a file......................................................................................35 6.3 Available options................................................................................35 2 Introduction ................................T&A Mobile Phones would like to thank you for purchasing this mobilephone.Power music player/video player• With playlist, lyrics display and equalizer• Full screen video playback• Watch the show on 1.8” TFT screenUnlimited video recording• Shoot video clips as long as you want (1) USB mass storageSimply a USB key.WebcamThe best companion for PC Messenger.Bluetooth• Bluetooth 2.0• A2DP profile (Bluetooth stereo) 1 (1) Depending on battery and free memory. C7_UM_USA_29-08-07 29/08/07 8:23 Page 1 11.3 Recent pages ......................................................................................5811.4 Go to URL ..........................................................................................5811.5 Profiles..................................................................................................58 12. Media album ................................................................60 12.1 My audio ..............................................................................................6012.2 My images ............................................................................................6112.3 My videos ............................................................................................6112.4 My creations........................................................................................6112.5 Unknown files ....................................................................................6112.6 Memory card ......................................................................................6212.7 Managing audio, images, videos and creations ............................6312.8 Formats and compatibility ..............................................................6412.9 Memory status....................................................................................64 13. Camera & Video ..........................................................65 13.1 Access ..................................................................................................6513.2 Camera ................................................................................................6513.3 Video ....................................................................................................68 14. Music ............................................................................72 14.1 Music ....................................................................................................7214.2 Settings ................................................................................................7314.3 Playing with lyrics ..............................................................................73 15. Games & Applications ................................................74 15.1 Launch an application........................................................................7415.2 Java settings ........................................................................................7415.3 Java downloading................................................................................74 16. Making the most of your mobile................................76 16.1 PC suite..................................…

Text truncated - open the document above for the full version.

8.8.4 Power On/Off (1) You can customize your welcome animation or image that appears whenyou switch on your phone.You can also customize your OFF screen with an image or animation.8.8.5 Menu display Board • All the main menu icons displayed on one screen. Image • One full-screen icon displayed at a time. List • Main menus displayed line by line. 8.9 Clock Set the time and date in your phone. 12/24h format. You may also editdaylight savings time settings.8.10 Keys 8.10.1 Softkeys These keys have predefined functions, which vary from one model toanother (operator services, games access, or Games & Applications, ...).Youcan customize (2) them, assigning the functions you wish to each key. 48 (1) Depending on the model. (2) Depending on your network operator. 8.8 Display 8.8.1 Main screen The main screen is displayed when you switch on your telephone.You can access the main functions from the main screen either with thenavigation key or by pressing and by selecting the icons displayed on the screen (1) . By selecting “ Main screen ” you can customize it by replacing the default image or animation displayed on your telephone. When you receive an event (incoming call, SMS/MMS,notifications, etc.) the icon, type and number of events will bedisplayed on your main screen allowing you to consult themdirectly. 8.8.2 Sub-display (2) The external display of your phone alerts you of any events. You canpersonalize the external phone display by setting.8.8.3 Screen saver If you activate this option, the screen saver will be displayed a little whileafter the main screen. You can choose a picture, an animation or a videoas your screen saver. 47 (1) Depending on the operator. (2) OT-C701A and OT-C707A only. C7_UM_USA_29-08-07 29/08/07 8:24 Page 47 8.11.2 Backlight It allows you to reduce brightness for better performance of batteries andsave power during periods of expected inactivity.You may also customizeits duration, Immediate, 10s, 30s and 1min.8.11.3 Languages (1) Display language for messages (select using ).The “ Automatic ” option selects the language according to the home network (if available).8.11.4 Dictionary Your phone has a dictionary for words typed which are predicted and areautomatically called if you choose the Predictive Mode (T9). When youconsult your dictionary, you can add, modify or erase words by using the“ Options ” softkey. 8.11.5 Input mode (2) Please see chapter “Latin input mode”, page 77. In addition to the specificcharacters table for for Cyrillic, Chinese, or English, other data inputmodes are also available in your telephone. This feature allows you towrite short messages and add names with special characters to yourdirectory.8.11.6 Security Activate PIN • The SIM card protection code is requested eachtime as the phone is powered on if this code isactivated. Change PIN • Change PIN code. 50 (1) Contact your network operator to check service availability. (2) Depending on the language. 8.10.2 Keypad By customizing your keys, you can call someone or access a functiondirectly from the main screen.To program a key on your keypad, select “ Keypad ” and choose the key that you wish to program.-“ Speed dial ”: activate this option to program numbers with contacts. In Idle mode, keep pressing number to dial directly. -“ Keys ”: activate this option to program the functions. 8.11 More settings... 8.11.1 Auto lock Lock the keypadKeypad will be automatically locked when phone is in the closed position (1) . Three music keys on the front cover will be automatically locked after youclose the phone (2) . Unlock the keypadOpen the slider (1) /flip (2) . The keypad will be unlocked automatically on receiving a call or pluggingin the charger (1) . 49 (1) OT-C717A only. (2) OT-C701A and OT-C707A only. C7_UM_USA_29-08-07 29/08/07 8:24 Page 49 52 9 Tools ................................ 9.1 Bluetooth™ (1) Access this feature by selecting “ Tools ” from the main menu, then “ Bluetooth ”. To use your phone with a Bluetooth device, you need to proceed in twosteps:- Pair and register the device to your phone,- Select it to use hands-free communication. Only one Bluetooth audio device (your Bluetooth headset or your Bluetooth car kit) can beconnected during the communication. Pair and register your Bluetooth deviceActivate the Bluetooth feature by selecting the “ Tools\Bluetooth\ Activation\On ” option.Then enter the “ Device list ” menu to search for connectable Bluetooth devices and select the device you want to bepaired with in the list. If the bluetooth device has no keyboard, enter itsdefault password to register it with your phone. If the Bluetooth devicehas keyboard/keypad, enter the same set of password on both handset andthe device to get it registered.From the list, press the “ Options ” softkey to connect/disconnect, rename, search for new devices or delete an unconnected one from the list. Don’t forget to turn on your Bluetooth device and activate thepairing mode while pairing it with your phone. (1) It is recommended that you use Alcatel Bluetooth headsets. See yourretailer for compatible devices. Change PIN2 • A protection code for certain SIM card features(Billing/Cost/FDN, etc.) will be requested if youattempt to access it, if the code is activated. Selectto update it with a new one (between 4 and 8digits). Activate phone • It is requested each time as the phone is powered code on if this code is activated. Change phone • Change phone password, its initial one is 1234. codeFixed dialed • It allows the phone to be "locked" so that it can only num. dial certain numbers, or numbers with certainprefixes. To activate this function, PIN2 code ismandatory. 8.11.7 Networks Network sel. • Depending on the option selected, the networksearch mode will be: • Automatic • The first network searched for is the network youused last. • Manual • The choice of the network connection is left up tothe user. Pref. networks • List of networks to which you wish to be connectedin order of priority (update …

Text truncated - open the document above for the full version.

Label Declaration for C7SA The FCC ID label of C7SA is placed in the battery compartment of the phone. So the phone is packaged separate from the battery during the shipment and thus the label is visible at the time of purchase.

Telecommunication Metrology Center of Ministry of Information Industry No. 2007TAR013 Page 49 of 57 ANNEX B PHOTOGRAPHS OF EUT External Photo Mobile Phone Mobile Phone Telecommunication Metrology Center of Ministry of Information Industry No. 2007TAR013 Page 50 of 57 Mobile Phone Charger (AC/DC Adapter) Telecommunication Metrology Center of Ministry of Information Industry No. 2007TAR013 Page 51 of 57 Label of Charger (AC/DC Adapter) USB Cable Telecommunication Metrology Center of Ministry of Information Industry No. 2007TAR013 Page 52 of 57 Headset

Telecommunication Metrology Center of Ministry of Information Industry No. 2007TAR013 Page 53 of 57 Internal Photo Mobile phone Disassembly Mobile phone Disassembly Telecommunication Metrology Center of Ministry of Information Industry No. 2007TAR013 Page 54 of 57 Mobile phone Disassembly Mobile phone Disassembly Telecommunication Metrology Center of Ministry of Information Industry No. 2007TAR013 Page 55 of 57 Mobile phone Disassembly Mobile phone Disassembly Telecommunication Metrology Center of Ministry of Information Industry No. 2007TAR013 Page 56 of 57 Mobile phone Disassembly

No. DAT-P-114/01-01 TEST REPORT No. 2007TAR016 Product OT-C717A Model C7SA Client T&A Mobile Phones Telecommunication Metrology Center of Ministry of Information Industry Telecommunication Metrology Center of Ministry of Information Industry No. 2007TAR016 Page 2 of 20 Notice 1. The test report shall be invalid if there is no “specified stamp for the test report” or the stamp of the test organization on it. 2. Copies of the test report shall be invalid if there is no “specified stamp for the test report” or the stamp of the test organization on it. 3. The test report shall be invalid if there are no signatures of the testing person, reviewing person and approving person on it. 4. The test report shall be invalid if it is altered. 5. Any demurral about the test shall be put forward to the testing organization within 15 days after the receiving of the test report. 6. This test report standalone dose not constitute or imply by its own an approval of the product by any Certification Authorities or Competent Bodies. 7. This report is only valid if complete, and test report shall not be reproduced except in full, without written approval of the laboratory. 8. This report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of Telecommunication Metrology Center of MII and the Accreditation Bodies, if it applies. Address: No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China (Telecommunication Metrology Center of MII) Post code: 100083 Telephone: +86 10 62302041 Fax: +86 10 62304793 Web site: http://www.emcite.com E-mail: [email protected] Telecommunication Metrology Center of Ministry of Information Industry No. 2007TAR016 Page 3 of 20 TABLE OF CONTENT 1. COMPETENCE AND WARRANTIES .....................................................................5 2. Testing Laboratory ................................................................................................5 2.1 Testing Location .................................................................................................5 2.2 Testing Environment...........................................................................................5 2.3 Testing Period .....................................................................................................6 3. Applicant Information ...........................................................................................6 3.1 Client Information................................................................................................6 3.2 Manufacture Information ....................................................................................7 4. Equipment Under Test (EUT) and Ancillary Equipment (AE).............................7 4.1 About EUT ...........................................................................................................7 4.2 Internal Identification of EUT used during the test...........................................7 4.3 Photographs of EUT............................................................................................7 5. SUMMARY OF TEST RESULTS ............................................................................7 6. MAIN TEST INSTRUMENTS ..................................................................................8 ANNEX A MEASUREMENT RESULTS ......................................................................9 ANNEX B PHOTOGRAPH OF EUT..........................................................................12 ANNEX C TEST LAYOUT.........................................................................................20 Telecommunication Metrology Center of Ministry of Information Industry No. 2007TAR016 Page 5 of 20 1. COMPETENCE AND WARRANTIES Telecommunication Metrology Center of Ministry of Information Industry(hereinafter TMC) is a test laboratory accredited by DAR (DATech) – Deutschen Akkreditierungs Rat (Deutsche Akkreditierungsstelle Technik), for the tests indicated in the Certificate No. DAT-P-114/01-01. TMC is a test laboratory accredited by CNAL – Accreditation Certificate of China National Accreditation Board for Laboratories, for the tests indicated in the Certificate No. L0442. TMC is FCC listed lab. FCC listed number is 733176. The test site in TMC is registered in Industry Canada. The IC registration number is 6629 . TMC is a testing laboratory competent to carry out the tests described in this report. TMC guarantees the reliability of the data presented in this report, which is the result of measurements and tests performed to the item under test on the date and under the conditions stated on the report and is based on the knowledge and technical facilities available at TMC at the time of execution of the test. TMC is liable to the client for the maintenance by its personnel of the confidentiality of all information related to the item under test and the results of the test. 2. Testing Laboratory 2.1 Testing Location Company Name: Telecommunication Metrology Center of Ministry of Information Industry Address: No 52, Huayuan beilu, Haidian District, Beijing,P.R.China Postal Code: 100083 Telephone: 00861062303288 Fax: 00861062304793 2.2 Testing Environment Semi-anechoic chamber (23 meters×17meters×10meters) did not exceed following limits along the EMC testing: Temperature Min. = 15 °C, Max. = 30 °C Relative humidity Min. = 30 %, Max. = 60 % Shielding effectiveness > 110 dB Electrical insulation > 10 kΩ Ground system resistance < 0.5 Ω Normalised site attenuation (NSA) < ±3.2 dB, 10 m distance, from 30 to 1000 MHz Uniformity of field strength Between 0 and 6 dB, from 26 to 1000 MHz Telecommunication Metrology Center of Ministry of Information Industry No. 2007TAR016 Page 6 of 20 Control room did not exceed following limits along the EMC testing: Temperature Min. = 15 °C, Max. = 35 °C Relative humidity Min. =30 %, Max. = 60 % Shielding effectiveness > 110 dB Electrical insulation > 10 kΩ Ground system resistance < 0.5 Ω Conducted…

Text truncated - open the document above for the full version.

Telecommunication Metrology Center of Ministry of Information Industry No. 2007TAR016 Page 20 of 20 ANNEX C TEST LAYOUT Pic C.1 Radiated Emission Pic C.2 Conducted Emission ***END OF REPORT BODY***
