RAD139GSM/GPRS quad bands mobile phone

1234567 891011121314 Your cellphone 1 .................. Level of network reception. Voicemail message arrived. Missed calls. Stopwatch is active. Radio is on. WAP alerts (1) . Roaming. Memory card scanning completed. SIM card missing. Line switching (1) : indicates the selected line. GPRS connection status (Activated). GPRS connecting. Music player active. Message receipt in progress. Sending a SMS. Sending a MMS. Silence mode: your cellphone does not ring, beep or vibrate with the exception of the alarm. SMS unread. (In red) Message list is full: your cellphone cannot accept any new messages. You must access the message list and delete at least one message on your SIM card. Flight mode. A2DP connected. Broadcast is on. Status list1.2 Touch status bar and drag it downward to open it; To hide it, tap or drag it upwards. To open an application, tap a menu when a list is open. Desktop1.3 Adding items To add an item from the main menu, press and hold its icon in the main menu list. To add a widget, press from tool bar or long press a blank area on the main screen, tap “Add widgets” to access widget lists and select the item you wish to add. Editing/Removing/Re-organizing items Long press the application on the desktop to edit/remove/re-organize it, touch to edit (only for my favourites), touch to remove. Touch and hold the application until a location frame shows up on the desktop, drag it to the location you desire, and then confirm by tapping “Done”. Wallpaper To personalize your wallpaper, press from tool bar or long press blank area from the main screen, tap “Wallpaper”. You will be directed to “My images” with this option. Toolbar1.4 Tool bar with menu items as a shortcut for quick access. Getting started 2 ................. Set-up2.1 Removing or installing the back cover Inserting or removing the SIM card You must insert your SIM card to make phone calls. Please power off your cellphone before inserting or removing the SIM card. Place the SIM card with the chip facing downwards and slide it into its housing. Make sure that it is correctly inserted. To remove the card, press and slide it out. Installing or removing the battery Insert and click the battery into place, then close the cellphone cover.• Unclip the cover, then remove the battery.• Power on your cellphone2.2 Hold down the key until the cellphone powers on. Power off your cellphone2.3 Hold down the key from the main screen. Using the touchscreen2.4 TapTo access an application, tap it with your finger. DragPlace your finger on the screen to drag the object to the destination. ScrollSlide the screen to scroll up and down the applications, images, web pages... at your convenience. Dialer 3 ......................... Enter the desired number from keypad directly or select a contact from Directory by tapping , then press key or tap to place the call. The number you entered can be saved to Directory by selecting . If you make a mistake, you can delete the incorrect digits by tapping . To hang up the call, press the key. Menu arrange 4 ............ The main menu is designed to vary according to your preference. To access this function, select to enter the main menu, then tap . Change the order Access “Menu arrange”, focus on the main menu item you want to move, and then tap “Options\Move”, it will go to the main menu screen and tick “√” will be shown on the main menu you selected, then release it to your favourite destination. Show/Hide Access “Menu arrange”, tap the left check box of the selected menu once to show/hide, then tap “Options\Save” to save the operation. Restore default From main menu, select “Menu arrange”, then tap “Options\Restore default” to return to the default menu display. Messages 5 .................. Conversational mode and conventional 5.1 mode In conversational view mode, you can view chat history in chronological order. In conventional view mode, you may have access to the following folders: Inbox, Outbox, Sent, Broadcast SMS, Voicemail, Drafts, Empty folder, Templates, Settings. Conversational view mode is set as default. You may switch to conventional view mode by selecting “Options\ Settings\Conversational mode\On(Off)”. Create message5.2 Press from tool bar on the main screen or select “Messages\Write msg” from main menu to create text/multimedia message. An SMS will be converted to MMS automatically when: images, videos, audio, slides or attachments are inserted; Subject, CC/BCC/email address is added; or the message contains more than 8 pages of text. Timer send Schedule a SMS/MMS to be sent out at predefined time (select “Timer send” through ). Email 6 .......................... Your cellphone has an email client with the settings predefined for a few popular email services like – GoogleMail, Windows live, Yahoo, AOL, etc. Besides this, you can set up other POP3 or IMAP4 email accounts that you may be using. Palringo 7 (1) .................... Palringo Instant messaging (IM) allows you to chat with other people using Palringo account. You can also connect to other popular IM services through Palringo, like Yahoo, AIM, GG, ICQ, Google talk, iChat etc. Please note that the services may be upgraded depending on your client version. Directory 8 .................. Consulting your directory8.1 To access the Directory, tap from tool bar on main screen, or select “Directory” from main menu. Birthday reminder8.2 You can set a birthday reminder when editing contact information. This will remind you at regular intervals during the day prior to the set date. Call log 9 ....................... Access9.1 You may access this function from the main menu “Call log” or by pressing . Available options9.2 When you tap , you may have access to Delete, Send message, Save to directory, Edit before call, etc. Billing9.2.1 (1) You can access different items with this option: Last call cost, Total cost, Max cost, Reset cost, Price per unit, Duration, GPRS counter, Beep duration. Call settings 9.2.2 (1) You can access a number …

Text truncated - open the document above for the full version.

No.2966, JinKe Road, Zhangjiang High-Tech Park Shanghai P.R.China 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 2010/8/26 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: RAD139 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhizhou Gong Approval Team Leader TCT Mobile Limited

External Photos:

FCC Label Location

Internal Photos:

No.2010TAR287 Page1 of 18 ©Copyright. All rights reserved by TMC Beijing. TEST REPORT No. 2010TAR287 for TCT Mobile Limited GSM/GPRS quad bands mobile phone Model Name: MINI+ A Marketing Name: OT-710A FCC ID : RAD139 with Hardware Version: PIO Software Version: V421 Issued Date: 2010-07-23 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: DAR accreditation (DIN EN ISO/IEC 17025): No. DGA-PL-114/01-02 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191 Tel:+86(0)10-62304633 , Fax:+86(0)10-62304633 Email:[email protected]. www.emcite.com No.2010TAR287 Page2 of 18 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY .............................................................................................................. 3 1.1. TESTING LOCATION .......................................................................................................... 3 1.2. TESTING ENVIRONMENT .................................................................................................. 3 1.3. PROJECT DATA .................................................................................................................. 3 1.4. SIGNATURE ........................................................................................................................ 3 2. CLIENT INFORMATION .......................................................................................................... 4 2.1. APPLICANT INFORMATION............................................................................................... 4 2.2. MANUFACTURER INFORMATION ..................................................................................... 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 5 3.1. ABOUT EUT ........................................................................................................................ 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 5 4. REFERENCE DOCUMENTS .................................................................................................. 6 4.1. REFERENCE DOCUMENTS FOR TESTING ...................................................................... 6 5. LABORATORY ENVIRONMENT ............................................................................................ 7 6. SUMMARY OF TEST RESULTS ............................................................................................. 8 7. TEST EQUIPMENTS UTILIZED .............................................................................................. 9 ANNEX A: MEASUREMENT RESULTS ...................................................................................... 10 No.2010TAR287 Page3 of 18 ©Copyright. All rights reserved by TMC Beijing. 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: No 52, Huayuan beilu, Haidian District, Beijing,P.R.China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304633 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: July 5,2010 Testing End Date: July 6,2010 1.4. Signature Zi Xiaogang (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.2010TAR287 Page4 of 18 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: TCT Mobile Limited Address /Post: 4/F, South Building,No.2966, Jinke Road, Zhangjiang High-Tech Park, Pudong,Shanghai, 201203, P.R.China City: Shanghai Postal Code: 201203 Country: China Telephone: 0086-21-61460890 Fax: 0086-21-61460602 2.2. Manufacturer Information Company Name: TCT Mobile Limited Address /Post: 4/F, South Building,No.2966, Jinke Road, Zhangjiang High-Tech Park, Pudong,Shanghai, 201203, P.R.China City: Shanghai Postal Code: 201203 Country: China Telephone: 0086-21-61460890 Fax: 0086-21-61460602 No.2010TAR287 Page5 of 18 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description GSM/GPRS quad bands mobile phone Model Name MINI+ A Marketing Name OT-710A FCC ID RAD139 Extreme vol. Limits 3.5VDC to 4.2VDC (nominal: 3.8VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MII of People’s Republic of China. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version N10 012321000122024 PIO V421 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Description SN AE1 Battery / AE2 Travel Adapter / AE3 Travel Adapter / AE4 Headset / AE5 Headset / AE6 Bluetooth Headset / AE7 Data Cable / AE1 Model CAB3120000C1 Manufacturer BYD Capacitance 850mAh Nominal Voltage 3.7V AE2 Model CBA3120AG0C1 Manufacturer BYD Length of DC line 120cm AE3 Model CBA3120AG0C2 Manufacturer Tenpao Length of DC line 120cm AE4 Model CCB3160A10C0 Manufacturer Juwei No.2010TAR287 Page6 of 18 ©Copyright. All rights reserved by TMC Beijing. AE5 Model CCB3160A10C2 Manufacturer Shunda AE6 Model OT-BM82 Manufacturer TCT AE7 Model CDA3122000C0 Manufacturer Juwei/Shenhua *AE ID: is used to identify the test sample in the lab internally. 4. Reference Documents 4.1. Reference Documents for testing The following documents listed in this section are referred for testing. Referen…

Text truncated - open the document above for the full version.

MINI+ A FCC test setup photos 1． Radiated Spurious Emission 2． Conducted Emission 3． Part 15C 4. Part 15B
