RAD155GSM/GPRS Dual-band mobile phone

1 9 2 10 3 11 4 12 5 13 6 14 7 15 8 16 1 Your cellphone ......... 1.1 Keys Navigation key Confirm an option (press the middle of the key) Activate music player (press and hold the middle of key) Scroll widget bar (press the right or left of the key) Answer Send a call In idle screen: Access call log (Redial) (short keypress) Activate fake call (press and hold) During MP3 Playing: Switch between Headset and speaker (press and hold) Switch on/Switch off the cellphone (press and hold) End call Return to idle screen Left softkey Right softkey Access your voicemail (press and hold) In Edit mode: - Short keypress: access the language list - Press and hold: enter zero In Edit mode: - Short keypress: change input methods - Press and hold: access the Symbols table In idle screen: - Short keypress: # - Press and hold: activate/deactivate the vibrate mode In Edit mode: - Short keypress: (space) Camera key: access "Camera" (short keypress) 1.2 Main screen icons (1) Battery charge level Vibrate alert: your cellphone vibrates, but does not ring or beep. Bluetooth status (Activated). Bluetooth status (Connected to an audio device). Headset connected. Call forwarding activated: your calls are forwarded. Alarm or appointments programmed. 2 Getting started ......... 2.1 Set-up Removing and installing the back cover Removing and installing the battery Inserting and removing the SIM card Place the SIM card with the chip facing downwards and slide it into its housing. Make sure that it is correctly inserted. To remove the card, press it and slide it out. Charging the battery Connect the battery charger to your cellphone and mains socket respectively. The charging may take about 20 minutes to start if the • battery is flat. Be careful not to force the plug into the socket.• Make sure the battery is correctly inserted before • connecting the charger. The mains socket must be near to the cellphone and easily • accessible (avoid electric extension cables). When using your cellphone for the first time, charge the • battery fully (approximately 3 hours). You are advised to fully charge the battery ( ). To reduce power consumption and energy waste, when • battery is fully charged, disconnect your charger from the plug; switch off Bluetooth when not in use; reduce the backlight time, etc. The charge is complete when the animation stops. 2.2 Power on your cellphone Hold down the key until the cellphone powers on. 2.3 Power off your cellphone Hold down the key from the main screen. 6 Email .................... Your cellphone has an email client with the settings predefined for a few popular email services like – GoogleMail, Windows live, Yahoo, AOL, etc. Besides this, you can set up other POP3 or IMAP4 email accounts that you may be using. 7 Opera Mini .......... Not only does Opera Mini give you the full Web experience where you stay in touch with your friends, obtain information, do your online banking etc., but it is also designed to save time by using compressed web pages. 8 Facebook ............. Facebook is a social utility that connects people with friends and others who work, study and live around them. It provides a number of features with which users interact, such as Wall, Pokes, etc. To open an account online, please go to: http://www.facebook. com/. Quick Start Guide For more information about how to use the cellphone, please go to www.alcatelonetouch.com to download complete user manual (English version only). Also on our website you can find helpful FAQs. (English version only). Prolonged exposure to music at full volume on the music player may damage the listener's hearing. Set your cellphone volume safely. Use only headphones recommended by TCT Mobile Limited and its affiliates. (1) Depending on your network operator. (1) The icons and illustrations in this guide are provided for information purposes only. 4 Contacts ............. 4.1 Consulting your contacts To access the contacts from the main screen, press the key and select the icon from the menu. 4.2 Adding a contact Select the directory in which you wish to add contact, press the "Options" softkey, select "Add contact". 5 Messaging ........... 5.1 Create message From the main menu select "Messaging" to create text/ multimedia message. You can type a message and you can also modify a predefined message in Templates or customize your message by adding pictures, photos, sounds, titles, etc (only available while editing a MMS). While writing a message, select "Options" to access all the messaging options. You can save your messages that you send often to Draft or Templates (MMS only). Specific letters (accent) will increase the size of the SMS, this may cause multiple SMS to be sent to your recipient. 3 Calls .......................... 3.1 Making a call Dial the desired number then press the key to place the call. If you make a mistake, you can delete the incorrect digits by pressing the right softkey. To hang up the call, press the key. Making an emergency call If your cellphone is covered by the network, dial emergency number and press the key to make an emergency call. This works even without a SIM card and without typing the PIN code. 3.2 Calling your voicemail (1) To access your voicemail, hold down the key. 3.3 Receiving a call When you receive an incoming call, press the key to talk and then hang up using the key. 3.4 Available functions during the call During a call, you can use your directory, your calendar, text messages, etc. without hanging up or dropping the call. (1) Contact your network operator to check service availability. Level of network reception. Voicemail message arrived. Missed calls. Radio is on. WAP alerts (1) . Roaming. SIM card missing. GPRS connection status (Activated). GPRS connecting. Sending a MMS. MMS receiving. Silence mode: your cellphone does not ring, beep or vibrate with the exception of the alarm. SMS unread. MMS unread. Flight mode. (1) Depending on your network operator. 9 mTweet ................ Twitter is …

Text truncated - open the document above for the full version.

5F, E building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 Date 2011-4-11 To: Federal Communications Commission, Authorization & Evaluation Division, 7345 Oakland Mills Road Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: TMC (Telecommunication Metrology Center of MIIT) is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Gong Zhizhou Approval Team Leader TCT Mobile Limited

5F, E building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 4/11/2011 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: RAD155 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhizhou Gong Approval Team Leader TCT Mobile Limited

EUT photograph

EUT Label Location

EUT Interior photograph

No.2011TAR133 Page 1 of 19 ©Copyright. All rights reserved by TMC Beijing. TEST REPORT No. 2011TAR133 for TCT Mobile Limited GSM/GPRS Dual bands mobile phone Model Name: B11C US Marketing Name: one touch 665A FCC ID : RAD 155 with Hardware Version: PIO Software Version: V721 Issued Date: 2011-04-20 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: DAR accreditation (DIN EN ISO/IEC 17025): No. DGA-PL-114/01-02 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191 Tel:+86(0)10-62304633 , Fax:+86(0)10-62304633 Email:[email protected]. www.emcite.com No.2011TAR133 Page 2 of 19 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY .............................................................................................................. 3 1.1. TESTING LOCATION .......................................................................................................... 3 1.2. TESTING ENVIRONMENT .................................................................................................. 3 1.3. PROJECT DATA .................................................................................................................. 3 1.4. SIGNATURE ........................................................................................................................ 3 2. CLIENT INFORMATION .......................................................................................................... 4 2.1. APPLICANT INFORMATION............................................................................................... 4 2.2. MANUFACTURER INFORMATION ..................................................................................... 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 5 3.1. ABOUT EUT ........................................................................................................................ 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 5 4. REFERENCE DOCUMENTS .................................................................................................. 7 4.1. REFERENCE DOCUMENTS FOR TESTING ...................................................................... 7 5. LABORATORY ENVIRONMENT ............................................................................................ 8 6. SUMMARY OF TEST RESULTS ............................................................................................. 9 7. TEST EQUIPMENTS UTILIZED ............................................................................................ 10 ANNEX A: MEASUREMENT RESULTS ...................................................................................... 11 No.2011TAR133 Page 3 of 19 ©Copyright. All rights reserved by TMC Beijing. 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: No 52, Huayuan beilu, Haidian District, Beijing, P. R. China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304633 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: Mar 11, 2011 Testing End Date: Mar 15, 2011 1.4. Signature Liu Baodian (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.2011TAR133 Page 4 of 19 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: TCT Mobile Limited Address /Post: 5F, E building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. City: Shanghai Postal Code: 201203 Country: China Telephone: +86-21-61460890 Fax: +86-21-61460602 2.2. Manufacturer Information Company Name: TCT Mobile Limited Address /Post: 5F, E building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. City: Shanghai Postal Code: 201203 Country: China Telephone: +86-21-61460890 Fax: +86-21-61460602 No.2011TAR133 Page 5 of 19 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description GSM/GPRS Dual bands mobile phone Model Name one touch 665A FCC ID RAD155 Extreme vol. Limits 3.5VDC to 4.2VDC (nominal: 3.7VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MII of People’s Republic of China. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version EUT1 012584000002088 PIO V721 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Description SN AE1 Travel Adapter / AE2 Travel Adapter / AE3 Battery / AE4 Battery / AE5 Battery / AE6 USB Cable / AE1 Model CBA3120AG0C1 Manufacturer BYD Length of DC line 120cm AE2 Model CBA3120AG0C2 Manufacturer Tenbao Length of DC line 120cm AE3 Model CAB22D0000C1 Manufacturer BYD Capacitance 650mAh Nominal Voltage 3.7V AE4 Model CAB22B0000C1 Manufacturer BYD Capacitance 750mAh Nominal Voltage 3.7V No.2011TAR133 Page 6 of 19 ©Copyright. All rights reserved by TMC Beijing. AE5 Model CAB22B0010C1 Manufacturer BYD Capacitance 850mAh Nominal Voltage 3.7V AE6 Model CDA3122001C01 Manufacturer Juwei Length of DC line 150cm *AE ID: is used to identify the test sample in the lab internally. EUT set-ups EUT set-up No. Combination of EUT and AE Remarks Set.1 EUT1+ AE1+AE3/4/5 -- Set.2 EUT1+ AE2+AE3/4/5…

Text truncated - open the document above for the full version.

EUT Set-up photos CE: RSE: Part 15C RE Part 15B RE
