RAD166GSM/GPRS dual bands mobile phone

1234567 891011121314 1 Your cellphone ............... Voicemail Sym key Vibration alert Del key Memory card Power on/off End call Answer/Send call Navigation key (1) : Main menu,confirm an option Profiles Calendar New Messages FM Radio Shift key Left softkey Space key Fn key Enter key Right softkey Prolonged exposure to music at full volume on the music player may damage the listener's hearing. Set your cellphone volume safely. Use only headphones recommended by TCT Mobile Limited and its affiliates. 1.1 Keys Navigation key Confirm an option (press the middle of the key) Access to menu (short keypress) Show/hide shortlist menu(long keypress) Answer Send a call Access call memory (short keypress) Access to Fake call (long keypress) Switch on/Switch off the cellphone (long keypress) End call Return to the idle screen Left softkey Right softkey Access your voicemail (long keypress) Input the "#" in Idle In idle screen: Long/short keypress: Lock/Unlock the keypad In edit mode: Short keypress: input space Long keypress: switch language Fn key + Space: switch input mode In idle screen: Press to access shortcuts Fn + P: access to Profiles Fn + Q: access to Clock Fn + S: access to Notes In edit mode: Press once to input top-half character. Press twice to lock top-half inputting mode, then press once to unlock top-half inputting mode. Long keypress: access to Dictionary. In edit mode: Short press: popup symbol page to select special character by navigation key Long press & Fn+SYM: popup smileys page to select special smileys by navigation key Delete one by one (short keypress) Delete one by one quickly (long keypress) Switch the uppercase and minuscule (in edit screen) Return a cursor to the next line. 1.2 Main screen icons (1) Battery charge level Vibrate alert: Your cellphone vibrates, but does not ring or beep with the exception of the alarm. Headset connected. Keypad locked. Call forwarding activated: your calls are forwarded. Alarm clock. Level of network reception. Voicemail message arrived. Missed calls. Radio is on. Stopwatch is active. WAP alerts (1) . Roaming. Memory card scanning in progress. Memory card scanning completed. Line switching (2) : indicates the selected line. GPRS connection status (Blue - Activated). GPRS connecting. Message receipt in progress. Sending a message. Silence mode: your cellphone neither rings, beeps nor vibrates except for the alarms. Message unread. Message list is full: your terminal cannot accept any new messages. You must access the message list and delete at least one message on your SIM card. Flight mode. (1) Depending on your network operator. (2) Contact your network operator to check service availability. Installing or removing the battery 2 Getting started .............. 2.1 Set-up Removing or installing the back cover Inserting or removing the SIM card Place the SIM card with the chip facing downwards and slide it into its housing. Make sure that it is correctly inserted. To remove the card, press the bottom and slide it out. Please power off your cellphone before you remove the SIM card. Charging the battery Connect the battery charger to your phone and mains socket respectively • The charging may take about 20 minutes to start if the battery is flat. • Be careful not to force the plug into the socket. • Make sure the battery is correctly inserted before connecting the charger. • The mains socket must be near to the phone and easily accessible (avoid electric extension cables). • When using your telephone for the first time, charge the battery fully (approximately 3 hours).You are advised to fully charge the battery ( ). • To reduce power consumption and energy waste, when battery is fully charged, disconnect your charger from the plug; reduce the backlight time, etc. The charge is complete when the animation stops. 2.2 Power on your cellphone Hold down the key until the cellphone powers on. 2.3 Power off your cellphone Hold down the key until the cellphone power off. 3 Calls ........................... 3.1 Making a call Dial the desired number then press the key to place the call. If you make a mistake, you can delete the incorrect digits by pressing the right softkey or key. To hang up the call, press the key. Making an emergency call If your cellphone has network coverage, dial emergency number and press the key to make an emergency call. This works even without a SIM card and without typing the PIN code or unlocking the keypad. 3.2 Call memory You can access your call memory by pressing the key from the idle screen. Check "Outgoing calls", "Missed calls", "Answered calls". 4 Menu arrange ........... Main Menu is designed to vary according to your preference. Change the order From main menu, press left softkey and select "Move" or long keypress key till tick "√" is shown, then move the cursor to your favorite destination and confirm with key. Show/Hide Access "Menu arrange", press key till tick ("√") show or off, it will show/hide some main menu. (1) The icons and illustrations in this guide are provided for informational purposes only. (1) Depending on your network operator. (1) The quality of the radio depends on the coverage of the radio station in that particular area. 5 Messages .................. 5.1 Messages: Text/Multimedia message 5.1.1 Create message From the main menu select "Messages" to create text/multimedia message. You can type a message and you can also modify a predefined message in Templates or customize your message by adding pictures, photos, sounds, titles, etc (only available while editing a MMS). While writing a message, select "Options" to access all the messaging options.You can save your messages that you send often to Drafts or Templates (MMS only). 5.1.2 Inbox All received messages (read and unread) are stored in the same Inbox. Group by sender/Group by receiver (1) Messages can be grouped by sender/receiver ("Options\Group by sender"/"Options\Group by receiver"). And you are enabled to quick search the messages b…
