RAD178GSM dual band mobile phone

1 10 2 11 3 12 4 13 5 14 6 15 7 16 89 1817 1 Your cellphone ......... 1.1 Keys Navigation key Confirm an option (press the middle of the key) Activate music player (press and hold the middle of key) Scroll widget bar (press the right or left of the key) Answer Send a call In idle screen: Access call log (Redial) (press) Activate fake call (press and hold) During MP3 Playing: Switch between Headset and speaker (press and hold) Switch on/Switch off the cellphone (press and hold) End call Return to idle screen Left softkey Right softkey Access your voicemail (press and hold) In idle screen: Press and hold/press: Lock/Unlock the keypad In edit mode: Press: input space Press and hold: switch language In idle screen: Press to access shortcuts Fn + P: Access to Profiles Fn + Q: Access to Clock Fn + S: Access to Notes In edit mode: Press once to input top-half character Press twice to lock top-half character inputting mode, then press once to unlock top-half character inputting mode In edit mode: Press: popup symbol page to select special character by navigation key Delete one by one (press) Delete one by one quickly (press and hold) Move cursor to the next line Switch the uppercase and lowercase (in edit screen) 2 Getting started ......... 2.1 Set-up Removing and installing the back cover Removing and installing the battery Inserting and removing the SIM card Place the SIM card with the chip facing downwards and slide it into its housing. Make sure that it is correctly inserted. To remove the card, press it and slide it out. Charging the battery Connect the battery charger to your cellphone and outlet respectively. The charging may take about 20 minutes to start if the • battery is flat. Be careful not to force the plug into the socket.• Make sure the battery is correctly inserted before • connecting the charger. The outlet must be near to the cellphone and easily • accessible (avoid electric extension cables). When using your cellphone for the first time, charge the • battery fully (approximately 3 hours). You are advised to fully charge the battery ( ). To reduce power consumption and energy waste, when • battery is fully charged, disconnect your charger from the plug; switch off Bluetooth when not in use; reduce the backlight time, etc. The charge is complete when the animation stops. 6 Email ................. Your cellphone has an email client with the settings predefined for a few popular email services like – GoogleMail, Windows live, Yahoo, AOL, etc. (1) Besides this, you can set up other POP3 or IMAP4 email accounts that you may be using. 7 Opera Mini .......... Not only does Opera Mini give you the full Web experience where you stay in touch with your friends, obtain information, do your online banking etc., but it is also designed to save time by using compressed web pages. 8 Facebook ............. Facebook is a social utility that connects people with friends and others who work, study and live around them. It provides a number of features with which users interact, such as Wall, Pokes, etc. To open an account online, please go to: http://www.facebook. com/. (1) Depending on your network operator. Quick Start Guide For more information about how to use the cellphone, please go to www.alcatelonetouch.com to download complete user manual (English version only). Moreover, from the website you can also consult FAQ (English version only). Prolonged exposure to music at full volume on the music player may damage the listener's hearing. Set your cellphone volume safely. Use only headphones recommended by TCT Mobile Limited and its affiliates. (1) The icons and illustrations in this guide are provided for information purposes only. English - CJB23F1ALAAA 4 Contacts .............. 4.1 Consulting your contacts To access the contacts from the main screen, press the key and select the icon from the menu. 4.2 Adding a contact Select the directory in which you wish to add contact, press the "Options" softkey, select "Add contact". 5 Messaging ............ 5.1 Create message From the main menu select "Messaging" to create text/ multimedia message. You can type a message and you can also modify a predefined message in Templates or customize your message by adding pictures, photos, sounds, titles, etc (only available while editing a MMS). While writing a message, select "Options" to access all the messaging options. You can save your messages that you send often to Draft or Templates (MMS only). Specific letters (accent) will increase the size of the SMS, this may cause multiple SMS to be sent to your recipient. 3 Calls .......................... 3.1 Making a call Dial the desired number then press the key to place the call. If you make a mistake, you can delete the incorrect digits by pressing the right softkey. To hang up the call, press the key. Making an emergency call If your cellphone is covered by the network, dial emergency number and press the key to make an emergency call. This works even without a SIM card and without typing the PIN code or unlocking the keypad. 3.2 Calling your voicemail (1) To access your voicemail, hold down the key. 3.3 Receiving a call When you receive an incoming call, press the key to talk and then hang up using the key. 3.4 Available functions during the call During a call, you can use your directory, your calendar, short messages, etc. without losing your correspondent. (1) Contact your network operator to check service availability. 1.2 Main screen icons (1) Battery charge level Vibrate alert: your cellphone vibrates, but does not ring or beep. Bluetooth status (Activated). Bluetooth status (Connected to an audio device). Headset connected. Keypad locked. Call forwarding activated: your calls are forwarded. Alarm or appointments programmed. Level of network reception. Voicemail message arrived. Missed calls. Radio is on. (1) Depending on your network operator. 9 mTweet ................ Twitter is a social networking and microblogging service that has gained notab…

Text truncated - open the document above for the full version.

5F, E building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 5/27/2011 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: RAD178 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhizhou Gong Approval Team Leader TCT Mobile Limited

CAB3120000C1 CAB3120000C1 CAB3120000C2 CAB3120000C2 CCB3160A10C2 CCB3160A10C4 CCC22C0A11C1 CCC2270A10C1 CDA3122001C1 CDA3122001C2 CBA3120AG0C2 CBA3120AG0C2 CBA3002AG0C1 CBA3002AG0C1

Lable Location

No.2011TAR356 Page1 of 18 ©Copyright. All rights reserved by TMC Beijing. TEST REPORT No. 2011TAR356 for TCT Mobile Limited GSM dual band mobile phone Model Name: B11Q US Marketing Name: one touch 585A FCC ID : RAD178 with Hardware Version: PIO Software Version: V200 Issued Date: 2011-06-19 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: DAR accreditation (DIN EN ISO/IEC 17025): No. DGA-PL-114/01-02 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191 Tel:+86(0)10-62304633 , Fax:+86(0)10-62304633 Email:[email protected]. www.emcite.com No.2011TAR356 Page2 of 18 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY .............................................................................................................. 3 1.1. TESTING LOCATION .......................................................................................................... 3 1.2. TESTING ENVIRONMENT .................................................................................................. 3 1.3. PROJECT DATA .................................................................................................................. 3 1.4. SIGNATURE ........................................................................................................................ 3 2. CLIENT INFORMATION .......................................................................................................... 4 2.1. APPLICANT INFORMATION............................................................................................... 4 2.2. MANUFACTURER INFORMATION ..................................................................................... 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 5 3.1. ABOUT EUT ........................................................................................................................ 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 5 4. REFERENCE DOCUMENTS .................................................................................................. 6 4.1. REFERENCE DOCUMENTS FOR TESTING ...................................................................... 6 5. LABORATORY ENVIRONMENT ............................................................................................ 7 6. SUMMARY OF TEST RESULTS ............................................................................................. 8 7. TEST EQUIPMENTS UTILIZED .............................................................................................. 9 ANNEX A: MEASUREMENT RESULTS ...................................................................................... 10 No.2011TAR356 Page3 of 18 ©Copyright. All rights reserved by TMC Beijing. 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: No 52, Huayuan beilu, Haidian District, Beijing,P.R.China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304633 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: Jun 01,2011 Testing End Date: Jun 10,2011 1.4. Signature Liu Baodian (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.2011TAR356 Page4 of 18 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: TCT Mobile Limited Address: 5F, E building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area City: Shanghai Postal Code: 201203 Country: P.R.China Telephone: 0086-21-61460890 Fax: 0086-21-61460602 2.2. Manufacturer Information Company Name: TCT Mobile Limited Address: 5F, E building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area City: Shanghai Postal Code: 201203 Country: P.R.China Telephone: 0086-21-61460890 Fax: 0086-21-61460602 No.2011TAR356 Page5 of 18 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description GSM dual band mobile phone Model Name B11Q US Marketing Name one touch 585A FCC ID RAD178 Extreme vol. Limits 3.5VDC to 4.2VDC (nominal: 3.8VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MII of People’s Republic of China. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version EUT1 012697000220193 PIO V200 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Description SN AE1 Travel Adapter / AE2 Travel Adapter / AE3 Battery / AE4 Battery / AE5 USB Cable / AE6 USB Cable / AE1 Model CBA3120AG0C2 Manufacturer TenPao Length of DC line 120cm AE2 Model CBA3002AG0C1 Manufacturer BYD Length of DC line 120cm AE3 Model CAB3120000C1 Manufacturer BYD Capacitance 850mAh Nominal Voltage 3.7V AE4 Model CAB3120000C2 Manufacturer Lishen Capacitance 850mAh No.2011TAR356 Page6 of 18 ©Copyright. All rights reserved by TMC Beijing. Nominal Voltage 3.7V AE5 Model CDA3122001C1 Manufacturer Juwei Length of DC line 150cm AE6 Model CDA3122001C2 Manufacturer Shenghua Length of DC line 150cm *AE ID: is used to identify the test sample in the lab internally. 4. Reference Documents 4.1. Reference Documents for testing The following documents listed in this section are referred for testing. Reference Title Version FCC P…

Text truncated - open the document above for the full version.

! "#$$%#&'(#)*+! ! "#$$%#&'(#)*+"! ! "#$$%#&'(#),+-./0! ! "#$$%#&'(#),+! ! "#$$%#&'(#)123$! ! "#$$%#&'(#)123"! ! "#$$%#&'(#)123&!
