RAD196GSM/GPRS/EDGE dual band mobile phone

1234567 891011121314 Your cellphone 1 .................. Status bar icons1.1 (1) Battery charge level Vibrate alert: your cellphone vibrates, but does not ring or beep with the exception of the alarm. Bluetooth status (Activated). Bluetooth status (Connected to an audio device). Java status (Activated). Headset connected. Keypad & LCD touch locked. Keypad& LCD touch unlocked. Call forwarding activated: your calls are forwarded. Alarm or appointments programmed. Level of network reception. Wi-Fi connected. Wi-Fi disconnected. Voicemail message arrived. Missed calls. Stopwatch is active. Radio is on. Email unread. WAP alerts (1) . Roaming. Memory card scanning in progress. Memory card scanning completed. SIM card unavailable. Line switching (1) : indicates the selected line. GPRS connection status (Activated). GPRS connecting. EDGE attached. EDGE connecting. Music player active. Message receipt in progress. MMS receipt in progress. Sending a SMS. Sending a MMS. Silence mode: your cellphone does not ring, beep or vibrate with the exception of the alarm. SMS unread. MMS unread. (In red) Message list is full: your cellphone cannot accept any new messages. You must access the message list and delete at least one message on your SIM card. Flight mode. A2DP connected. Broadcast is on. Status list1.2 Tap the status bar and drag down to open, drag up to close. To open an application, tap it from the list. Desktop1.3 Adding items To add an item from the main menu, you can select one of the following ways: Tap and hold an item from the main menu list.• Tap • from the tool bar and select an item. Touch and hold an empty area from the main screen, select “• Add widgets” from the window that opens, then tap the item you want to add to desktop. Removing items Touch and hold the widget you want to remove from the desktop to enter the edit mode, and then tap to remove it, finally tap “Done” to confirm. Re-organizing items Touch and hold the widget you want to move from the desktop editing screen until a location frame shows up, then drag it to the desired location, finally tap “Done” to confirm. Wallpaper To personalize your wallpaper, you can select one of the following two ways: Touch and hold an empty area from the desktop, select “• Wallpaper”, then tap a folder that displayed to select an image as your wallpaper. Tap • from the tool bar, then tap a folder to select an image as your wallpaper. Toolbar1.4 Tool bar with menu items by default as a shortcut for quick access. Scrolling left and right, you can view more items. Getting started 2 ................. Set-up2.1 Removing or installing the back cover Inserting or removing the SIM card You must insert your SIM card to make phone calls. Please power off your cellphone and remove battery before inserting or removing the SIM card. Place the SIM card with the chip facing downwards and slide it into its housing. Make sure that it is correctly inserted. To remove the card, press and slide it out. Installing or removing the battery Insert and click the battery into place, then close the cellphone cover.• Unclip the cover, then remove the battery.• Power on your cellphone2.2 Hold down the key until the cellphone powers on. Power off your cellphone2.3 Hold down the key from the main screen. Using the touchscreen2.4 TapTo access an application, tap it with your finger. DragPlace your finger on the screen to drag the object to the destination. ScrollSlide the screen to scroll up and down the applications, images, web pages... at your convenience. Making a call 3 ...................... Enter the desired number on the on-screen keypad directly or select a contact from Call log or Directory by tapping or respectively, then tap or press key to place the call. The number you entered can be saved to Directory by selecting . If you make a mistake, you can delete the incorrect digits by tapping . To hang up the call, press the key. Menu arrange 4 ............ The main menu is designed to vary according to your preference. To access this function, select to enter the main menu, then tap . Change the order Access “Menu arrange”, focus on the main menu item you want to move, and then tap “Options\Move”, it will go to the main menu screen and tick “√” will be shown on the main menu you selected, then release it to your favourite destination. Show/Hide Access “Menu arrange”, tap the left check box of the selected menu once to show/hide, then tap “Options\Save” to save the operation. Restore default From main menu, select “Menu arrange”, then tap “Options\Restore default settings” to return to the default menu display. Messages 5 .................. Conversational On (Off) mode5.1 In conversational on mode, you can view chat history in chronological order. In conversational off mode, you may have access to the following folders: Inbox, Outbox, Sent, Broadcast SMS, Voicemail, Drafts, etc. You can switch between these two modes by selecting “Settings\Conversational mode\On (Off)”. Conversational mode is set as the default mode and following instructions are based on this mode. Create message5.2 Select “Messages\Write msg” to create text/multimedia message. An SMS will be converted to MMS automatically when: images, videos, audio, slides or attachments are inserted; Subject, CC/BCC/email address is added; or the message contains more than 8 pages of text. Timer send Schedule a SMS/MMS to be sent out at predefined time (“Option\Timer send”). Email 6 .......................... Your cellphone has an email client with the settings predefined for a few popular email services like – GoogleMail, Yahoo, AOL, etc. Besides this, you can set up other POP3 or IMAP4 email accounts that you may be using. Palringo 7 (1) .................... Palringo Instant messaging (IM) allows you to chat with other people using Palringo account. You can also connect to other popular IM services through Palringo, like Yahoo, AIM, GG, ICQ, GTalk, iChat etc. Please note that the services accessible to you wil…

Text truncated - open the document above for the full version.

5F, E building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 Date 2011-4-11 To: Federal Communications Commission, Authorization & Evaluation Division, 7345 Oakland Mills Road Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: TMC (Telecommunication Metrology Center of MIIT) is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Gong Zhizhou Approval Team Leader TCT Mobile Limited

No.2966, JinKe Road, Zhangjiang High-Tech Park Shanghai P.R.China 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 2011/4/23 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: RAD196 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhizhou Gong Approval Team Leader TCT Mobile Limited

External Photos:

FCC label placement

Internal Photos:

No.2011TAR176 Page1 of 20 ©Copyright. All rights reserved by TMC Beijing. TEST REPORT No. 2011TAR176 for TCT Mobile Limited GSM/GPRS/EDGE dual band mobile phone Model Name: Agate lifestyle Marketing Name: TCL-8107 FCC ID: RAD196 with Hardware Version: PIO Software Version: SW27i Issued Date: 2011-04-26 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: DAR accreditation (DIN EN ISO/IEC 17025): No. DGA-PL-114/01-02 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191 Tel:+86(0)10-62304633, Fax:+86(0)10-62304633 Email:[email protected]. www.emcite.com No.2011TAR176 Page2 of 20 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY .............................................................................................................. 3 1.1. TESTING LOCATION .......................................................................................................... 3 1.2. TESTING ENVIRONMENT .................................................................................................. 3 1.3. PROJECT DATA .................................................................................................................. 3 1.4. SIGNATURE ........................................................................................................................ 3 2. CLIENT INFORMATION .......................................................................................................... 4 2.1. APPLICANT INFORMATION............................................................................................... 4 2.2. MANUFACTURER INFORMATION ..................................................................................... 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 5 3.1. ABOUT EUT ........................................................................................................................ 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 5 4. REFERENCE DOCUMENTS .................................................................................................. 6 4.1. REFERENCE DOCUMENTS FOR TESTING ...................................................................... 6 5. LABORATORY ENVIRONMENT ............................................................................................ 7 6. SUMMARY OF TEST RESULTS ............................................................................................. 8 7. TEST EQUIPMENTS UTILIZED .............................................................................................. 9 ANNEX A: MEASUREMENT RESULTS ...................................................................................... 10 No.2011TAR176 Page3 of 20 ©Copyright. All rights reserved by TMC Beijing. 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: No 52, Huayuan beilu, Haidian District, Beijing,P.R.China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304633 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: Apr 13,2011 Testing End Date: Apr 20,2011 1.4. Signature Liu Baodian (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.2011TAR176 Page4 of 20 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: TCT Mobile Limited Address /Post: 4F, South Building, No.2966, JinKe Road, Zhangjiang High-Tech Park Shanghai 201203, P.R.China City: Shanghai Postal Code: 201203 Country: P.R.China Telephone: 0086 21 61460883 Fax: 0086 2161460602 2.2. Manufacturer Information Company Name: TCT Mobile Limited Address /Post: 4F, South Building, No.2966, JinKe Road, Zhangjiang High-Tech Park Shanghai 201203, P.R.China City: Shanghai Postal Code: 201203 Country: P.R.China Telephone: 0086 2161460890 Fax: 0086 2161460602 No.2011TAR176 Page5 of 20 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description GSM/GPRS/EDGE dual band mobile phone Model Name Agate lifestyle Marketing Name TCL-8107 FCC ID RAD196 Frequency GSM 850MHz; PCS 1900MHz Antenna Internal Power supply Battery or Charger (AC Adaptor) Extreme vol. Limits 3.5VDC to 4.2VDC (nominal: 3.8VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MII of People’s Republic of China. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version EUT1 012742000000441 PIO SW27i *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Description SN AE1 Battery / AE2 Charger / AE3 Charger / AE4 Headset / AE5 Headset / AE6 Bluetooth Headset / AE7 Charger / AE1 Model CAB3120000C1 Manufacturer BYD Capacitance 850mAh Nominal Voltage 3.7V AE2 Model CBA3120AG0C1 Manufacturer BYD Length of DC line 120cm AE3 Model CBA3120AG0C2 Manufacturer TENPAO Length of DC line 120cm No.2011TAR176 Page6 of 20 ©Copyright. All rights reserved by TMC Beijing. AE4 Model CCB3160A10C0 Manufacturer Juwei Length of DC line 150cm AE5 Model CCB3160A10C2 Manufacturer Shunda Length of DC line 150cm AE6 Model OT-BM82 Manufacturer TCT Mobile AE7 Model CBA31DDAH0C1 Manufacturer BYD Length of DC line 120cm *AE ID: is used to identify the test sample i…

Text truncated - open the document above for the full version.

TCL-8107 FCC test setup photo 1． Radiated Spurious Emission 2． Conducted Emission(Charging) 3． Conducted Emission(USB) 4． Radiated Emission(Charging) 5． Radiated Emission(USB) 6. part15C
