RAD204GSM/GPRS/EDGE/WCDMA Digital Mobile Phone with Bluetooth

1 10 2 11 3 12 4 13 5 14 6 15 7 16 89 1817 Your cellphone 1 .............. Keys and connectors1.1 Status bar icons1.2.1 (1) Battery charge level Vibrate alert: your cellphone vibrates, but does not ring or beep with the exception of the alarm. Bluetooth status (Activated). Bluetooth status (Connected to an audio device). Java status (Activated). Headset connected. Call forwarding activated: your calls are forwarded. Alarm or appointments programmed. Level of network reception. Voicemail message arrived. Missed calls. Call in progress. Stopwatch is active. Radio is on. Email unread. WAP messages (1) . Roaming. SD card scanning in progress. SD card scanning completed. SIM card unavailable. Line switching (1) : indicates the selected line. GPRS connection status (Activated). GPRS connecting. EDGE connecting. EDGE attached. 2G network available. 3G network available. Music player active. MMS receipt in progress. Sending a SMS. Sending a MMS. Silence mode: your cellphone does not ring, beep or vibrate with the exception of the alarm. SMS unread. MMS unread. (Flickering) Message list is full: your cellphone cannot accept any new messages. You must access the message list and delete at least one message on your SIM card. Flight mode. Status list1.2.2 Touch the status bar and drag down to open, drag up to close. To open an application, touch it from the list. Toolbar1.2.3 Toolbar with 4 fixed shortcuts to access Main menu, Calls, Message, Edit Home screen. Personalize your home screen1.2.4 Adding items To add an item, touch and hold an empty area of the Home screen or select from the toolbar. Add shortcuts• To add a shortcut to the Home screen, such as Alarm, Bookmarks, Contacts, etc. Add widgets• To add a widget to the Home screen, such as the World clock, Music player, etc. Editing/Removing/Re-organizing items Press and hold the application on the Home screen to edit/remove/ re-organize it, touch to edit (only for my favorites), touch to remove. Touch and hold the application and drag it to the location you desire, and then confirm by touching "Done". Customizing wallpaper To personalize your wallpaper, you can select one of the following two ways: Touch and hold an empty area from the Home screen, select • "Wallpaper", then touch a folder to select an image as your wallpaper. Touch • from the tool bar, select "Wallpaper", then touch a folder to select an image as your wallpaper. Getting started 2 ........... Set-up2.1 Removing or installing the back cover Inserting or removing the SIM card You must insert your SIM card to make phone calls. Please power off your cellphone and remove battery before inserting or removing the SIM card. Place the SIM card with the chip facing downwards and slide it into its housing. Make sure that it is correctly inserted. To remove the card, press and slide it out. Installing or removing the battery Insert and click the battery into place, then close the cellphone • cover. Unclip the cover, then remove the battery.• Charging the battery Connect the battery charger to your cellphone and outlet respectively. To reduce power consumption and energy waste, when battery is fully charged, disconnect your charger from the plug; switch off Bluetooth or background-running applications when not in use; reduce the backlight time, etc. Power on your cellphone2.2 Hold down the key until the cellphone powers on. Power off your cellphone2.3 Hold down the key from the Home screen. Using the touchscreen2.4 Touch To access an application, touch it with your finger. Drag Place your finger on the screen to drag the object to the destination. Scroll Slide the screen to scroll up and down the applications, images, web pages... at your convenience. Making a call 3 ................ To place a call, you may touch from tool bar. Enter the desired number on the on-screen keypad directly or select a contact from Call log or Contacts by touching or respectively, then touch or press key to place the call. The number you entered can be saved to Contacts by selecting . If you make a mistake, you can delete the incorrect digits by touching . To hang up the call, press the key. When making, receiving or during a call, press to return to the middle Home screen, and then touch or press to retrieve the call. Muting the ringtone You may mute ringtone of current incoming call by touching . Answer the call by pressing the key. Rejecting a call Press the key once to reject the call, or reject call with SMS by touching . Message 4 ................ Access4.1 You may access this menu using the following options: - Touch to enter the main menu screen, and then select . - Access from tool bar by selecting . Conversational On (Off) mode4.2 In conversational on mode, you can view chat history in chronological order. In conversational off mode, you can access the following folders: Inbox, Outbox, Sent, Broadcast SMS, Voicemail, Drafts, etc. You can switch between these two modes by selecting "Switch view mode" via . Conversational on mode is set as the default mode and the following instructions are based on this mode. Write message4.3 Touch to create text/multimedia messages. Specific letters (accent) will increase the size of the SMS, this may cause multiple SMS to be sent to your recipient. An SMS will be converted to MMS automatically when: images, videos, audio, slides or attachments are inserted; Subject, CC/BCC/email address is added; or the message contains more than 8 pages of text. Timer send Schedule an SMS/MMS to be sent out at predefined time (select "Timer send" via ). Email 5 ...................... Your cellphone has an email client with the settings predefined for a few popular email services like – GoogleMail, Yahoo, AOL, etc. Besides this, you can set up other POP3 or IMAP4 email accounts that you may be using. Palringo 6 (1) ................ Palringo Instant message (IM) allows you to chat with other people using Palringo account. You can also connect to other popular IM services through Palri…

Text truncated - open the document above for the full version.

Authorization Letter FCC ID: RAD204 Date: 28 th June, 2010 To whom it may concern: We, the undersigned, hereby authorize The State Radio_monitoring_center Testing Center (SRTC) to act on our behalf, as our agent, in the following matters related to the FCC approval of our product: Product Name: GSM/GPRS/EDGE/WCDMA Digital Mobile Phone with Bluetooth Marketing Name: one touch 905M Product Model: MINI3G M Report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by The State Radio_monitoring_center Testing Center (SRTC) within the scope of this authorization shall have the same effects as our own. This authorization shall expire 2 months from original date. If you have any question regarding the authorization, please don’t hesitate to contact with me. Thank you. Sincerely, Gong Zhizhou TCT Mobile Limited. 5F, E building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, 201203, P.R. China Tel: +86-021-61460890 Fax: +86-021-61460602

Request of Confidentiality Federal Communications Commission Authorization and Evaluation Division Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying of following product: Product Name: GSM/GPRS/EDGE/WCDMA Digital Mobile Phone with Bluetooth Marketing Name: one touch 905M Product Model: MINI3G M FCC ID: RAD204 The following information should be held confidential: All Schematics/block diagrams All Parts list for the above schematic diagram Tune-Up Procedure Operational description and technical overview of product The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Gong Zhizhou TCT Mobile Limited. 5F, E building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, 201203, P.R. China Tel: +86-021-61460890 Fax: +86-021-61460602

RAD204 External Photo Headset CCB3160A10C2 Headset CCB3160A10C3

RAD204 Internal Photo

D-PL-12111-01-01 CNAS L0447 Registration No.910917 CONFORMANCE TEST REPORT FOR HUMAN EXPOSURE TO ELECTROMAGNETIC FIELDS Report No.: SRTC2011-H024-E0054 Product Name: GSM/GPRS/EDGE/WCDMA Digital Mobile Phone with Bluetooth Marketing Name: one touch 905M Product Model: MINI3G M Applicant: TCT Mobile Limited Manufacture: TCT Mobile Limited Specification: FCC OET Bulletin 65 (Edition 97-01) Supplement C (Edition 01-01) 47CFR 2.1093 FCC ID: RAD204 The State Radio_monitoring_center Testing Center (SRTC) No.80 Beilishi Road Xicheng District Beijing, China Tel: 86-10-68009202 Fax: 86-10-68009205 No.: SRTC2011-H024-E0054 FCC ID: RAD204 The State Radio_monitoring_center Testing Center (SRTC) Page number: 1 of 120 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright ©SRTC Executive summary Test report no.: SRTC2011-H024-E0054 Product Model: MINI3G M Date of test: 2011.07.01 Date of report: 2011.07.04 Laboratory: The State Radio_monitoring_center Testing Center (SRTC) Test has been Carried out in accordance with: 47CFR §2.1093 Radiofrequency Radiation Exposure Evaluation: Portable Devices FCC OET Bulletin 65 (Edition 97-01), Supplement C (Edition 01-01) Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields RSS-102 Evaluation Procedure for Mobile and Portable Radio Transmitters with Respect to Health Canada’s Safety Code 6 for Exposure of Humans to Radio Frequency Fields IEEE 1528 - 2003 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Technique Documentation:The documentation of the testing performed on the tested devices is archived for 5 years at SRTC Result summary: This Test Report Is Issued by: Mr. Song Qizhu Director of the test lab Checked by: Mr. Wang Junfeng Deputy director of the test lab Tested by: Ms. Liu Jia Test engineer Issued date: 2011.07.04 Mode CH/f(MHz) Power (dBm) Position Sar Limit (1g avg) (mW/g) Measured value (1g avg)(mW/g) Result GSM850 128/824.2 189/836.4 32.50 32.43 Right cheek 1.6 1.1 PASS No.: SRTC2011-H024-E0054 FCC ID: RAD204 The State Radio_monitoring_center Testing Center (SRTC) Page number: 2 of 120 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright ©SRTC Tables of contents 1. GENERAL INFORMATION ...................................................................................................... 3 1.1 Notes of the test report ........................................................................................................ 3 1.2 Information about the testing laboratory ............................................................................. 3 1.3 Applicant’s details ............................................................................................................... 3 1.4 Manufacturer’s details ......................................................................................................... 3 1.5 Test Details ......................................................................................................................... 4 1.6 Maximum Results ............................................................................................................... 4 1.6.1 GSM ......................................................................................................................... 4 1.6.2 WCDMA .................................................................................................................. 5 2. DESCRIPTION OF THE DEVICE UNDER TEST ................................................................. 6 2.1 Description of the Antenna ................................................................................................. 6 2.2 Picture of the EUT .............................................................................................................. 6 2.3 Test Positions for the Device under test .............................................................................. 7 2.4 Picture to demonstrate the required liquid depth ................................................................. 8 3. TEST CONDITIONS .................................................................................................................. 8 3.1 Temperature and Humidity ................................................................................................. 8 3.2 Test Signal, Frequencies and Output Power ....................................................................... 8 3.3 SAR Measurement Set-up ................................................................................................... 8 4. DESCRIPTION OF THE TEST EQUIPMENT ....................................................................... 9 4.1 Measurement System and Components .............................................................................. 9 4.2 Phantoms ........................................................................................................................... 10 4.3 Tissue Simulants ............................................................................................................... 10 4.3.1 Tissue Simulant Recipes ........................................................................................ 11 4.3.2 System Checking .................................................................................................... 11 4.3.3 Tissue Simulants used in the Measurements .......................................................... 12 5. DESCRIPTION OF THE TEST PROCEDURE ................................................................... 13 5.1 Device Holder ................................................................................................................... 13 5.2 Test positions .................................................................................................................... 14 5.2.1 Against Phantom Head ..........................................................…

Text truncated - open the document above for the full version.

D-PL-12111-01-01 CNAS L0447 Registration No.910917 TEST REPORT Report No.: SRTC2011-H024-E0055 Product Name: GSM/GPRS/EDGE/WCDMA Digital Mobile Phone with Bluetooth Marketing Name: one touch 905M Product Model: MINI3G M Applicant: TCT Mobile Limited Manufacture: TCT Mobile Limited Specification: 47CFR Part 15 July 10, 2008, Subpart C FCC ID: RAD204 The State Radio_monitoring_center Testing Center (SRTC) No.80 Beilishi Road Xicheng District Beijing, China Tel: 86-10-68009202 Fax: 86-10-68009205 No.: SRTC2011-H024-E0055 FCC ID: RAD204 The State Radio_monitoring_center Testing Center (SRTC) Page number: 2 of 75 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC CONTENTS 1．General information ................................................................................. 3 1.1 Notes of the test report ................................................................................................... 3 1.2 Information about the testing laboratory ....................................................................... 3 1.3 Applicant’s details ............................................................................................................ 3 1.4 Manufacturer’s details ..................................................................................................... 3 1.5 Application details ............................................................................................................ 4 1.6 Reference specification ................................................................................................... 4 1.7 Information of EUT .......................................................................................................... 4 1.7.1 General information .............................................................................................. 4 1.7.2 EUT details ............................................................................................................ 4 1.7.3 Auxiliary equipment details .................................................................................. 5 2. Test information ........................................................................................ 6 2.1 Summary of the test results............................................................................................ 6 2.2 Test result .......................................................................................................................... 7 2.2.1 Occupied Bandwidth-§15.247(a) (1) .................................................................. 7 2.2.2 Peak power output-§15.247(a) (1) ................................................................... 13 2.2.3 Spurious RF conducted emissions-§15.247(d) .............................................. 20 2.2.4 Spurious radiated emissions-§15.247(d),§15.35(b),§15.209 ...................... 38 2.2.5 Band edge compliance-§15.247(d) .................................................................. 45 2.2.6 Dwell time-§15.247(a) (1)(iii) ......................................................................... 62 2.2.7 Channel separation-§15.247(a) (1) .................................................................. 69 2.2.8 Number of hopping frequencies-§15.247(a) (iii) ......................................... 71 2.2.9 AC Powerline Conducted Emission-§15.107, §15.207 ................................. 73 2.3. List of test equipment ................................................................................................... 75 No.: SRTC2011-H024-E0055 FCC ID: RAD204 The State Radio_monitoring_center Testing Center (SRTC) Page number: 3 of 75 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC 1．General information 1.1 Notes of the test report The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written permission of The State Radio_monitoring_center Testing Center (SRTC). The test results relate only to individual items of the samples which have been tested. 1.2 Information about the testing laboratory Company: The State Radio_monitoring_center Testing Center (SRTC) Address: No.80 Beilishi Road, Xicheng District, Beijing China City: Beijing Country or Region: China Contacted person: Wang Junfeng Tel: +86 10 68009181 +86 10 68009202 Fax: +86 10 68009195 +86 10 68009205 Email: [email protected] / [email protected] 1.3 Applicant’s details Company: TCT Mobile Limited Address: 5F, E building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area City: Shanghai Country or Region: P.R.China Grantee Code: RAD Contacted Person: Gong Zhizhou Tel: +86-21-61460890 Fax: +86-21-61460602 Email: [email protected] 1.4 Manufacturer’s details Company: TCT Mobile Limited Address: 5F, E building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area City: Shanghai Country or Region: P.R.China Contacted Person: Gong Zhizhou Tel: +86-21-61460890 Fax: +86-21-61460602 Email: [email protected] No.: SRTC2011-H024-E0055 FCC ID: RAD204 The State Radio_monitoring_center Testing Center (SRTC) Page number: 4 of 75 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC 1.5 Application details Date of reception of test sample: 9 th Jun 2011 Date of test: 10 th Jun 2011 to 23 rd Jun 2011 1.6 Reference specification 47CFR Part 15, July 10, 2008, Subpart C 1.7 Information of EUT 1.7.1 General information Name of EUT GSM/GPRS/EDGE/WCDMA Digital Mobile Phone with Bluetooth FCC ID RAD204 Frequency range 2.4000~2.4835GHz Number of channel 79 Modulation type GFSK, π/4DQPSK,8DPSK Duplex mode TDD Channel spacing 1MHz Data rate 1Mbps,2 Mbps,3 Mbps Antenna type Integral Power Supply Battery or charger Rated Power Supply Voltage 3.8V HW Version PIO3 SW Version sw160 1.7.2 EUT details Product Name Marketing Name Product Model IMEI GSM/GPRS/EDGE/WCDMA Digital Mobile Phone with Bluetooth one touch 905M MINI3G M 012835000000070 No.: SRTC20…

Text truncated - open the document above for the full version.

D-PL-12111-01-01 CNAS L0447 Registration No.910917 Appendix1 TEST SETUP Report No.: SRTC2011-H024-E0055 Product Name: GSM/GPRS/EDGE/WCDMA Digital Mobile Phone with Bluetooth Marketing Name: one touch 905M Product Model: MINI3G M Applicant: TCT Mobile Limited Manufacture: TCT Mobile Limited Specification: 47CFR Part 15 July 10, 2008, Subpart C FCC ID: RAD204 The State Radio_monitoring_center Testing Center (SRTC) No.80 Beilishi Road Xicheng District Beijing, China Tel: 86-10-68009202 Fax: 86-10-68009205 No.: SRTC2011-H024-E0055 FCC ID: RAD204 The State Radio_monitoring_center Testing Center (SRTC) Page number: 2 of 3 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC Appendix1 Test Setup Conducted Spurious Emissions Test setup Spurious Radiated Emissions Test setup No.: SRTC2011-H024-E0055 FCC ID: RAD204 The State Radio_monitoring_center Testing Center (SRTC) Page number: 3 of 3 Tel: 86-10-68009202 68009203 Fax: 86-10-68009195 68009205 Copyright © SRTC AC Power Line Conducted Emission Test setup
