RAD260HSUPA/HSDPA/UMTS dual band / GSM quad bands mobile phone

1 English - CJB321GALAAA Quick Start Guide For more information about how to use the phone, please go to www.alcatelonetouch.com to download complete user manual. Moreover, from the website you can also view FAQ, upgrade your phone's software and more. 918S IP4082_918S_QG_BDL_Eng_USA_05_120420.indd 1IP4082_918S_QG_BDL_Eng_USA_05_120420.indd 12012-4-20 Jerry 17:54:002012-4-20 Jerry 17:54:00 23 Your mobile 1 .................. Keys and connectors1.1 Back key Touchscreen Sensor LED light Home key Headset connector Micro-USB connector Volume up Volume down Power key Menu key Search key Prolonged exposure to music at full volume on the music player may damage the listener's hearing. Set your phone volume safely. Use only headphones recommended by TCT Mobile Limited and its affiliates. Table of contents 1 Your mobile ...................................................................................... 3 2 Text input ........................................................................................ 15 3 Phone call ........................................................................................ 16 4 Contacts .......................................................................................... 18 5 Messaging......................................................................................... 19 6 Email ................................................................................................. 20 7 Getting connected ........................................................................ 21 8 Locate my location using GPS satellites .................................. 23 9 Data backup .................................................................................... 24 10 Factory data reset ......................................................................... 25 11 Applications .................................................................................... 25 12 Making the most of your phone ................................................ 26 IP4082_918S_QG_BDL_Eng_USA_05_120420.indd 2-3IP4082_918S_QG_BDL_Eng_USA_05_120420.indd 2-32012-4-20 Jerry 17:54:002012-4-20 Jerry 17:54:00 45 On Home screen, press to quickly access • Settings menu or Notification panel; to launch quick search; to manage applications; to customize your Home screen by adding applications or changing wallpaper. On other screens, press to view options list.• Short press: Light up the screen Return to the Home screen or back to the central Home screen. Long press: Enter the recently used applications list. Go back to the previous menu or screen. Short press: Lock the screen Turn on Display (when in Standby mode) Long press: When phone is off, power on the phone. When phone is on, enter Phone options (Silent mode, Airplane mode, Power off) Press to adjust the Volume (in call/media playing mode) Open Search bar for searching within an application, the phone or web. Getting started1.2 Set-up1.2.1 Removing or installing the back cover Removing or installing front deco Attention: Front deco is a removable and flexible part, please take care of it when removing or installing it. Inserting or removing the SIM card You must insert your SIM card to make phone calls. Please power off your phone and remove battery before inserting or removing the SIM card. Place the SIM card with the chip facing downwards and slide it into its housing. Make sure that it is correctly inserted. To remove the card, press and slide it out. IP4082_918S_QG_BDL_Eng_USA_05_120420.indd 4-5IP4082_918S_QG_BDL_Eng_USA_05_120420.indd 4-52012-4-20 Jerry 17:54:002012-4-20 Jerry 17:54:00 67 Installing or removing the battery Insert and click the battery into place, then close the phone cover.• Unclip the cover, then remove the battery.• Installing and removing the microSD card To release the microSD card holder, slide it in the direction of the arrow and lift it. Then insert the microSD card with the golden contact downward. Finally, turn down the microSD holder and slide it in the opposite direction to lock it. Charging the battery Connect the battery charger to your phone and outlet respectively. To reduce power consumption and energy waste, when battery is fully charged, disconnect your charger from the plug; switch off Wi-Fi, GPS, Bluetooth or background- running applications when not in use; reduce the backlight time, etc. Power on your phone1.2.2 Hold down the Power key until the phone powers on. It will take a few seconds before the screen lights up. Set up your phone for the first time The first time you power on the phone, you are prompted to set up your phone in multiple ways: language, input method, mobile data connection, account setup and synchronization, system update, etc. You are required to sign into your Google account to synchronize email, contacts, calendar and other Google applications (1) . Enter your user name and password, then touch • Sign in. If you forget your password, you can go to http://www.google.com/ to retrieve it. If you don’t own a Google Account, you are prompted to create one by touching Create. Read the setup information on the screen• . Mark/Unmark the check box to choose whether you want to take • advantage of Google's location service, then touch Next. Mark/Unmark the check box to choose whether you want to back • up data with your Google account, then touch Next. Touch • Finish setup. This initial set up can be skipped and enabled via Settings\Accounts & sync. In power on screen without SIM card inserted, you can also connect to a Wi-Fi network to sign into your Google account and to use some features. Power off your phone1.2.3 Hold down the Power key from the Home screen until the phone options appear, select Power off. (1) Application availability depends on country and operator. IP4082_918S_QG_BDL_Eng_USA_05_120420.indd 6-7IP4082_918S_QG_BDL_Eng_USA_05_120420.indd 6-72012-4-20 Jerry 17:54:002012-4-20 Jerry 17:54:00 89 Home screen1.3 You can bring all the items (applications…

Text truncated - open the document above for the full version.

5F, E building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 Date 2011-12-13 To: Federal Communications Commission, Authorization & Evaluation Division, 7345 Oakland Mills Road Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: TMC (Telecommunication Metrology Center of MIIT) is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Gong Zhizhou Approval Team Leader TCT Mobile Limited

5F, E building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 2012-3-19 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: RAD260 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhizhou Gong Approval Team Leader TCT Mobile Limited

Label

No.2012TAR044 Page 1 of 17 ©Copyright. All rights reserved by TMC Beijing. TEST REPORT No. 2012TAR044 for TCT Mobile Limited HSUPA/HSDPA/UMTS dual band / GSM quad bands mobile phone Model Name: GIN S Marketing Name: one touch 918S FCC ID: RAD260 IC No.: 9238A-0008 with Hardware Version: PIO Software Version: SW31H_AWS Issued Date: 2012-02-20 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: DAR accreditation (DIN EN ISO/IEC 17025): No. DGA-PL-114/01-02 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191 Tel:+86(0)10-62304633-2678 , Fax:+86(0)10-62304633-2504 Email:[email protected]. www.emcite.com No.2012TAR044 Page 2 of 17 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY ............................................................................................................... 3 1.1. TESTING LOCATION ........................................................................................................... 3 1.2. TESTING ENVIRONMENT ................................................................................................... 3 1.3. PROJECT DATA ................................................................................................................... 3 1.4. SIGNATURE .......................................................................................................................... 3 2. CLIENT INFORMATION ........................................................................................................... 4 2.1. APPLICANT INFORMATION ................................................................................................ 4 2.2. MANUFACTURER INFORMATION ...................................................................................... 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 5 3.1. ABOUT EUT .......................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 5 3.4. EUT SET-UPS ....................................................................................................................... 6 4. REFERENCE DOCUMENTS .................................................................................................... 7 4.1. REFERENCE DOCUMENTS FOR TESTING....................................................................... 7 5. LABORATORY ENVIRONMENT .............................................................................................. 8 6. SUMMARY OF TEST RESULTS .............................................................................................. 9 7. TEST EQUIPMENTS UTILIZED ............................................................................................. 10 ANNEX A: MEASUREMENT RESULTS ....................................................................................... 11 No.2012TAR044 Page 3 of 17 ©Copyright. All rights reserved by TMC Beijing. 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: No 52, Huayuan beilu, Haidian District, Beijing, P. R. China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304633 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: Jan. 21 st , 2012 Testing End Date: Jan. 30 th , 2012 1.4. Signature Qu Pengfei (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.2012TAR044 Page 4 of 17 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: TCT Mobile Limited Address /Post: 5F, E building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. City: Shanghai Postal Code: 201203 Country: China Contact Person: Gong Zhizhou Contact Email [email protected] Telephone: 0086-21-61460890 Fax: 0086 21 61460602 2.2. Manufacturer Information Company Name: TCT Mobile Limited Address /Post: 5F, E building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. City: Shanghai Postal Code: 201203 Country: China Telephone: 0086-21-61460890 Fax: 0086 21 61460602 No.2012TAR044 Page 5 of 17 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description HSUPA/HSDPA/UMTS dual band / GSM quad bands mobile phone Model Name GIN S Marketing Name one touch 918S FCC ID RAD260 IC Number 9238A-0008 Extreme vol. Limits 3.5VDC to 4.2VDC (nominal: 3.7VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MIIT of People’s Republic of China. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version EUT1 013122000000775 PIO SW31H_AWS *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Description SN AE1 Battery B2641105B9A AE2 Battery BAK2011060100318 AE3 Travel charger / AE4 USB cable / AE5 USB cable / AE6 USB cable / AE7 USB cable / AE1 Model CAB31P0000C1 Manufacturer BYD Capacitance 1300mAh Nominal voltage 3.7V AE2 Model CAB31P0000C2 Manufacturer BAK Capacitance 1300mAh Nominal voltage 3.7V AE3 Model CBA3002AG0C1 Manufacturer BYD Length of cable 123cm No.2012TAR044 Page 6 of 17 ©Copyright. All rights reserved by TMC…
