RAD327HSUPA/HSDPA/UMTS dualband / GSM quadband mobile phone

1 English - CJB32T1ALAAA Quick Start Guide For more information about how to use the cellphone, please go to www.alcatelonetouch.com to download complete user manual. Also on our website you can find helpful FAQs, realize software upgrade, etc. Thank you for buying Alcatel ONE TOUCH 6033A. We hope you will enjoy your high-quality mobile communication experience. Important: Your phone is a unibody device, so the back cover and battery are not removable. If your phone isn’t working normally, try to restart it by pressing and holding the Power key for at least 7 seconds until the startup screen appears. If your phone develops a serious error and can’t be restored by restarting it, you may need to restore factory settings by pressing and holding the Power key and Volume up key until the startup screen appears. Press the Volume up/down key to select “factory reset” in the system recovery menu and finally press the Power key to confirm. Note: Please take care when performing such operations because they will erase personalized settings and data saved in your phone, such as SMS, Contacts, Music, etc. 6033A IP4582_6033A_QG_Eng_USA_03_130423.indd 1IP4582_6033A_QG_Eng_USA_03_130423.indd 12013-4-23  4:39:312013-4-23  4:39:31 23 Table of contents 1 Your mobile ..................................................................... 3 2 Text input ...................................................................... 14 3 Phone call ...................................................................... 15 4 People ............................................................................ 17 5 Messaging....................................................................... 18 6 Email .............................................................................. 19 7 Getting connected ........................................................ 20 8 Locate my location using GPS satellites ...................... 23 9 Data backup .................................................................. 23 10 Factory data reset ....................................................... 24 11 Applications & Internal storage .................................. 24 12 Making the most of your phone .................................. 25 Safety and use ......................................................................... 27 General information .............................................................. 34 Alcatel Mobile Phones Limited Warranty ........................... 35 Troubleshooting...................................................................... 36 1 Your mobile .................. 1.1 Keys and connectors PROTECT YOUR HEARING To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use. micro-USB/headset adapter connector Power key Back key Front camera Home key Recent apps key Touch screen IP4582_6033A_QG_Eng_USA_03_130423.indd 2-3IP4582_6033A_QG_Eng_USA_03_130423.indd 2-32013-4-23  4:39:312013-4-23  4:39:31 45 Volume up SIM card slot Volume down Camera Camera Flash/ Flashlight Recent apps key • Open a list of thumbnail images of apps you've worked with recently. Touch it to open an app. Swipe it left or right to remove a thumbnail from the list. • Touch and hold: As Menu key, touch and hold it to access Wallpaper, Manage applications and Settings. Home key • While on any application or screen, touch to return to the Home screen. Back key • Touch to go back to the previous screen, or to close a dialog box, options menu, the notification panel, etc. These keys are visible when the screen lights up. Power key • Press: Lock the screen/Light up the screen • Press and hold: Show the pop-up menu to select from Ringer mode/Airplane mode/Power off/Quick start/Restart Press and hold: Power on • Press and hold Power key and Volume down key to capture a screenshot. • Press to mute the ringtone when there’s an incoming call. • Press to end the current conversation during a call. • Press for more than 7 seconds to restart the phone when it is dead. Volume keys • Under call mode, adjust the earpiece or headset volume. • In Music/Video/Streaming mode, adjust the media volume. • In general mode, adjust the ring tone volume. • Mute the ringtone of an incoming call. • In Camera mode, using it as the capture key allows you to take a photo and start or stop recording a video. • Press to light up the screen when it dims during a call. IP4582_6033A_QG_Eng_USA_03_130423.indd 4-5IP4582_6033A_QG_Eng_USA_03_130423.indd 4-52013-4-23  4:39:312013-4-23  4:39:31 67 1.2 Getting started 1.2.1 Set-up Inserting or removing the SIM card You must insert your SIM card to make phone calls. Please power off your phone before inserting or removing the SIM card. Insert the SIM card into the slot with the chip facing downwards until it is locked. To remove it, gently push the SIM card until it is unlocked. Installing the SIM Removing the SIM Connecting or removing the headset You must plug the headset adapter into your phone before connecting the headset. To connect the headset, plug the headset adapter into the micro- USB/headset adapter connector of your phone, then plug the headset into the adapter jack. To remove the headset, unplug the headset and the adapter. Charging the battery Connect the battery charger to your phone and outlet respectively. The charging status bar will not float if your battery is extendly consumed. To reduce power consumption and energy waste, when battery is fully charged, disconnect your charger from the plug; switch off Wi-Fi, GPS, Bluetooth or background-running applications when not in use; reduce the backlight time, etc. Removing the headset Connecting the headset IP4582_6033A_QG_Eng_USA_03_130423.indd 6-7IP4582_6033A_QG_Eng_USA_03_130423.indd 6-72013-4-23  4:39:312013-4-23  4:39:31 89 1.2.2 Power on your phone Hold down the Power key until the phone powers on. It will take some secon…

Text truncated - open the document above for the full version.

5F, E building, No. 232, Liang Jing Road Zha ngJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 Da te 2013-2-27 To: Federal Communications Commission, Au thorization & Evaluation Division, 7345 Oakland Mills Road Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: TM C (Telecommunication Metrology Center of MIIT) is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Gong Zhizhou Approval T eam Leader TCT Mobile Limited

5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 2013-04-03 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: RAD327 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhizhou Gong Approval Team Leader TCT Mobile Limited

CBA0003AG0C1 CBA0003AG0C1_label CCB3001A14C1 CCB3001A14C2 CCB3001A15C1 CCB3001A15C2 CDA0000025C1 CDA0000025C2

FCC ID location for RAD327

No. 2013TAR245 Page 1 of 22 ©Copyright. All rights reserved by TMC Beijing. TEST REPORT No. 2013TAR245 for TCT Mobile Limited HSUPA/HSDPA/UMTS dualband / GSM quadband mobile phone Model Name: ONE TOUCH 6033A Marketing Name：Diablo HD US1 FCC ID : RAD327 with Hardware Version: Proto03 Software Version: vAAC-1-US1 Issued Date: 2013-04-15 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: DAkks accreditation (DIN EN ISO/IEC 17025): No. DGA-PL-12123/01-01 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191 Tel:+86(0)10-62304633-2561 , Fax:+86(0)10-62304633-2504 Email:[email protected]. www.emcite.com No. 2013TAR245 Page 2 of 22 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY ............................................................................................................... 3 1.1. TESTING LOCATION ........................................................................................................... 3 1.2. TESTING ENVIRONMENT ................................................................................................... 3 1.3. PROJECT DATA ................................................................................................................... 3 1.4. SIGNATURE .......................................................................................................................... 3 2. CLIENT INFORMATION ........................................................................................................... 4 2.1. APPLICANT INFORMATION ................................................................................................ 4 2.2. MANUFACTURER INFORMATION ...................................................................................... 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 5 3.1. ABOUT EUT .......................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 5 4. REFERENCE DOCUMENTS .................................................................................................... 7 4.1. REFERENCE DOCUMENTS FOR TESTING....................................................................... 7 5. LABORATORY ENVIRONMENT .............................................................................................. 8 6. SUMMARY OF TEST RESULTS .............................................................................................. 9 7. TEST EQUIPMENTS UTILIZED ............................................................................................. 10 ANNEX A: MEASUREMENT RESULTS ....................................................................................... 11 No. 2013TAR245 Page 3 of 22 ©Copyright. All rights reserved by TMC Beijing. 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: No 52, Huayuan beilu, Haidian District, Beijing, P. R. China Postal Code: 100191 Telephone: 0086-10-62304633-2561 Fax: 0086-10-62304633-2504 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: Mar. 22 nd , 2013 Testing End Date: Mar. 29 th , 2013 1.4. Signature Qu Pengfei (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No. 2013TAR245 Page 4 of 22 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: TCT Mobile Limite Address /Post: 5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 City: Shanghai Postal Code: 201203 Country: China Telephone: 0086-21-6146089 Fax: 0086-21-61460602 2.2. Manufacturer Information Company Name: TCT Mobile Limited Address /Post: 5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 City: Shanghai Postal Code: 201203 Country: China Telephone: 0086-21-6146089 Fax: 0086-21-61460602 No. 2013TAR245 Page 5 of 22 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description HSUPA/HSDPA/UMTS dualband / GSM quadband mobile phone Model Name ONE TOUCH 6033A FCC ID RAD327 Extreme vol. Limits 3.5VDC to 4.2VDC (nominal: 3.7VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MIIT of People’s Republic of China. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version EUT1 013485000601268 Proto03 vAAC-1-US1 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Description SN AE1 Battery / AE2 Travel charger / AE3 USB cable / AE4 USB cable / AE1 Model CAC1800001C3 Manufacturer SCUD Capacitance 1800mAh Nominal voltage 3.8V AE2 Model CBA0003AG0C1 Manufacturer BYD Length of cable \ AE3 Model CDA0000025C1 Manufacturer Shenghua Length of cable 100cm AE4 Model CDA0000025C2 Manufacturer Juwei Length of cable 100cm *AE ID: is used to identify the test sample in the lab internally. No. 2013TAR245 Page 6 of 22 ©Copyright. All rights reserved by TMC Beijing. 3.4. EUT set-ups EUT set-up No. Combination of EUT and AE Remarks Set.1 EUT1+ AE1 + AE3 USB Mode Set.2 EUT1+ AE1 + AE2+AE3 Charger No. 2013TAR245 Page 7 of 22 ©Copyr…

Text truncated - open the document above for the full version.

Part22/24 RSE Part22/24 RSE Part15B RE Part15B RE Part15B CE Part15B CE Part15CF RE Part15C CE
