RAD421GSM dual band mobile phone

www.sar-tick.com This product meets applicable national SAR limits of 1.6W/kg. The specific maximum SAR values can be found in the RADIOWAVES section of this user guide. When carrying the product or using it while worn on your body, either use an approved accessory such as a holster or otherwise maintain a distance of 10 mm from the body to ensure compliance with RF exposure requirements. Note that the product may be transmitting even if you are not making a phone call. 1 9 2 10 3 11 4 12 5 13 6 14 7 15 8 16 1 Your mobile .............. 1.1 Keys Navigation key Confirm an option (press the middle of the key) Answer Send a call In idle screen: Access call log (Redial) (press) Switch on/Switch off the telephone (press and hold) End call Return to idle screen Left softkey Right softkey Access your voicemail (press and hold) In Edit mode: - Press: access the symbols table - Press and hold: enter zero In Edit mode: - Press: change input methods In idle screen: - Press: # - Press and hold: activate/deactivate vibrate mode In Edit mode: - Press: (space) From Idle screen - Press: dial ‘5’ - Press and hold: switch the LED Flashlight on/off ALCATEL 1041A 2 Getting started ......... 2.1 Set-up Removing and installing the back cover Removing and installing the battery Inserting and removing the SIM card Place the SIM card with the chip facing downwards and slide it into its housing. Make sure that it is correctly inserted. To remove the card, press it and slide it out. 4 Contacts ............. 4.1 Consulting your contacts To access the Contacts from the main screen, press the key and select the icon from the menu. 4.2 Adding a contact You can add a new contact to phone or SIM card by selecting “Add contact”. 5 Messages ............ 5.1 Create message From the main menu select “Messages” to create text. You can type a message and you can also modify a predefined message in Templates. While writing a message, select “Options” to access all of the messaging options. You can save your messages that you send often to Drafts. Specific letters (accent) will increase the size of the SMS, this may cause multiple SMS to be sent to your recipient. Quick Start Guide For more information about how to use the phone, please go to www.alcatelonetouch.com to download complete user manual (English version only). Also on our website you can find helpful FAQs (English version only). (1) The icons and illustrations in this guide are provided for information purposes only. 3 Calls .......................... 3.1 Making a call Dial the desired number then press the key to place the call. If you make a mistake, you can delete the incorrect digits by pressing the right softkey. To hang up the call, press the key. Making an emergency call If your phone is covered by the network, dial emergency number and press the key to make an emergency call. This works even without a SIM card and without typing the PIN code. 3.2 Calling your voicemail (1) To access your voicemail, hold down the key. 3.3 Receiving a call When you receive an incoming call, press the key to talk and then hang up using the key. 3.4 Available functions during the call During a call, you can use your directory, your calendar, text messages, etc. without hanging up or dropping the call. (1) Contact your network operator to check service availability. Charging the battery Connect the battery charger to your phone and outlet respectively. Charging may take about 20 minutes to start if the battery is • flat. Be careful not to force the plug into the socket.• Make sure the battery is correctly inserted before connecting • the charger. The outlet must be near to the phone and easily accessible • (avoid electric extension cables). When using your telephone for the first time, charge the • battery fully (approximately 3 hours). You are advised to fully charge the battery ( ). To reduce power consumption and energy waste, when • battery is fully charged, disconnect your charger from the plug; reduce the backlight time, etc. The charge is complete when the animation stops. 2.2 Power on your phone Hold down the key until the phone powers on. 2.3 Power off your phone Hold down the key from the main screen. 6 Call log ................ 6.1 Access You can access the function using the following options: Select • from main menu Press the send key from Home screen• 6.2 Available options When you press “Options”, you can have access to View, Send SMS, Save to Contacts, Edit before call, Add to blacklist, Add to whitelist, Delete etc. 7 Camera ............... Your mobile phone is fitted with a camera for taking photos that you can use in different ways: Store them in your “• My files\Images”. Customise your main screen.• Make sure that microSD card is well inserted before taking photos. 8 Settings .............. From the main menu, select the menu icon and select the function of your choice in order to customize your telephone: Profiles, Phone settings, Call settings, Network, Connectivity, Security, Regulatory & Safety, Restore default. 9 Tools ..................... 9.1 Alarm Your mobile phone has a built-in alarm clock with a snooze feature. 9.2 Calculator Enter a number, select the type of operation to be performed, and enter the second number, then press “=” to display the result. 9.3 Calendar Once you enter this menu from the main menu, there is a monthly-view calendar for you to query date. 9.4 Notes You can create a note in text format by accessing “Tools\ Notes” from the main menu. 9.5 Bluetooth Access this feature by pressing to enter the main menu, then selecting “Tools\Bluetooth”. 9.6 Converter Weight converter and Length converter. 9.7 Voice Alarm With this menu, you may create the voice file and set it as the alarm. 9.8 Fake call This program enables you to call yourself by simulating a caller number/name, ringtone at a scheduled time. It helps you to politely escape from social situations at any time you wish. This call can be rejected by key. 9.9 Call filter Enable b…

Text truncated - open the document above for the full version.

5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 Date 2013-9-20 To: Federal Communications Commission, Authorization & Evaluation Division, 7345 Oakland Mills Road Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: TMC (Telecommunication Metrology Center of MIIT) is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Gong Zhizhou Approval Team Leader TCT Mobile Limited

5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 2013-09-20 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: RAD421 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhizhou Gong Approval Team Leader TCT Mobile Limited

5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 Declaration of USB Port ALCATEL 1041A, use a micro-USB port in handset. This USB port support charging only, but don’t support data transmission. Signature: Print name: Zhizhou Gong Date: 2013-9-29 Company: TCT Mobile Limited

EUT photograph Mobile Phone Mobile Phone Mobile Phone Mobile Phone Mobile Phone Mobile Phone Mobile Phone Battery AE1 Battery AE1 Battery AE2 Battery AE2 Battery AE3 Battery AE3 Battery AE4 Battery AE4 Charger AE5 Label of Charger AE5 Charger AE6 Label of Charger AE6 Headset AE7 Headset AE8 Headset AE9 Headset AE10 Data Cable AE11 Data Cable AE12 Data Cable AE13 Data Cable AE14

EUT Interior photograph Mobile Phone Mobile Phone Disassembly Mobile Phone Disassembly Mobile Phone Disassembly

No.2013TAR630 Page1 of 97 ©Copyright. All rights reserved by TMC Beijing. FCC PART 15C TEST REPORT No. 2013TAR630 for TCT Mobile Limited GSM dual band mobile phone Model Name: Tiger L US 1SIM VGA Marketing Name: ALCATEL 1041A FCC ID : RAD421 with Hardware Version: Proto Software Version: vA13 Issued Date: 2013-09-24 DAR accreditation (DIN EN ISO/IEC 17025): No. D-PL-12123-01-01 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629B Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology Shouxiang Science Building, No 51, Xueyuan Road, Haidian District, Beijing, P.R.China 100191 Tel:+86(0)10-62304633-2678, Fax:+86(0)10-62304633 Email:[email protected]. www.emcite.com No.2013TAR630 Page2 of 97 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY ......................................................................................................................... 3 1.1. T ESTING LOCATION ......................................................................................................................... 3 1.2. T ESTING ENVIRONMENT .................................................................................................................. 3 1.3. P ROJECT DATA ................................................................................................................................. 3 1.4. S IGNATURE ...................................................................................................................................... 3 2. CLIENT INFORMATION ................................................................................................................... 4 2.1. A PPLICANT INFORMATION ............................................................................................................... 4 2.2. MANUFACTURER INFORMATION ............................................................................................ 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................. 5 3.1. A BOUT EUT .................................................................................................................................... 5 3.2. I NTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .......................................................... 5 3.3. I NTERNAL IDENTIFICATION OF AE USED DURING THE TEST ............................................................. 5 3.4. N ORMAL ACCESSORY SETTING ........................................................................................................ 6 3.5. G ENERAL DESCRIPTION ................................................................................................................... 6 4. REFERENCE DOCUMENTS ............................................................................................................. 7 4.1. D OCUMENTS SUPPLIED BY APPLICANT ............................................................................................ 7 4.2. R EFERENCE DOCUMENTS FOR TESTING ........................................................................................... 7 5. LABORATORY ENVIRONMENT ..................................................................................................... 8 6. SUMMARY OF TEST RESULTS ....................................................................................................... 9 6.1. S UMMARY OF TEST RESULTS ........................................................................................................... 9 6.2. S TATE MEN TS .................................................................................................................................... 9 7. TEST EQUIPMENTS UTILIZED .................................................................................................... 10 ANNEX A: MEASUREMENT RESULTS ................................................................................................. 11 A.1. MEASUREMENT METHOD ................................................................................................................... 11 A.2. PEAK OUTPUT POWER - CONDUCTED ................................................................................................ 13 A.3. FREQUENCY BAND EDGES - CONDUCTED .......................................................................................... 14 A.4. CONDUCTED EMISSION ...................................................................................................................... 21 A.5. RADIATED EMISSION .......................................................................................................................... 45 A.6. TIME OF OCCUPANCY (DWELL TIME) ................................................................................................ 72 A.7. 20DB BANDWIDTH ............................................................................................................................. 82 A.8. CARRIER FREQUENCY SEPARATION ................................................................................................... 87 A.9. NUMBER OF HOPPING CHANNELS ...................................................................................................... 89 A.10. AC POWERLINE CONDUCTED EMISSION .......................................................................................... 93 No.2013TAR630 Page3 of 97 ©Copyright. All rights reserved by TMC Beijing. 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: Shouxiang Science Building, No 51, Xueyuan Road, Haidian District, Beijing, P.R.China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304633 1.2. Testing Environment Normal Temperature: 15-35°C Extreme Temperature: -20/+55°C Relative Humidity: 20-75% 1.3. Pro…

Text truncated - open the document above for the full version.

FDD ID RAD421 Conducted emission RE Radiated Spurious Emission
