1 BH50+ Bluetooth Headset User Guide Oreillette Bluetooth Guide d’utilisation 蓝牙耳机用户指南 Гарнитура Bluetooth Руководство пользователя Auricolare Bluetooth Guida utente Auricular Bluetooth Guía de Usuario CJB227AAL00A 2 English.................................................... 3 Française............................................... 16 简体中文................................................. 31 Русский...................................................41 Italiano.....................................................56 Español.....................................................70 3 BH50+ Bluetooth Headset User Guide Contents Product Specifications -----------------------------------------------------------4 onetouch BH50+ Overview-------------------------------------------------------5 Charging Your Headset----------------------------------------------------------6 Pairing--------------------------------------------------------------------------------6 Using Your Headset---------------------------------------------------------------7 Voice prompt------------------------------------------------------------------------9 Multi-connection--------------------------------------------------------------------9 Factory Setting Reset-------------------------------------------------------------9 Troubleshooting-------------------------------------------------------------------10 Safety Information----------------------------------------------------------------11 Declaration of Conformity------------------------------------------------------12 Guarantee--------------------------------------------------------------------------14 4 Product Specifications Bluetooth Specification V3.0 with V2.1 EDR features, Class 2 Bluetooth Profiles Headset V1.2 and Hands free V1.5 Range of Frequency 2.4GHz spectrum Nominal Charging Time Less than 30minutes Talk Time* Up to 6 hours Standby Time* Up to 220 hours Dimensions 56 x 18 x 9 mm Weight 9.4 grams Operating temperature range -20°C to 55°C Storage temperature range -30°C to 70°C * may vary due to the user’s habit, different modes of operation, and mobile phone settings. 5 BH50+ Overview A. Volume key D. Microphone B. Multi-function button (MFB) • Power on / off • Pair with mobile phone • Answer / End a call • Reject / Transfer a call E. microUSB charging socket 6 C. LED indicator F. Speaker Getting Started To use your onetouch BH50+ Bluetooth headset (“headset”), please follow the steps below: 1, Charging Your Headset Ensure your headset is fully charged and power on. The headset comes with a built-in rechargeable battery. Prior to using the headset for the first time, it is recommended to fully charge the battery. When using a charger, insert the microUSB tip into the headset’s charging socket. While using a charging cable, plug USB tip into a PC or laptop computer which is powered on after the micro USB tip is plugged in the charging socket of the headset. 2, Pairing Pair your charged headset with a Bluetooth-enabled mobile phone. 1) Ensure that headset is off. 2) To activate the pairing mode, press and hold the headset’s MFB without releasing your finger until its status indicator flashes red/blue. 3) Make sure that your mobile device’s Bluetooth is activated. Search Bluetooth devices, select “onetouch BH50+” and enter the passcode “0000”. When pairing is completed, the headset’s status 7 indicator will flash blue light rapidly five times. If pairing cannot be completed within three minutes after the pairing mode activation, the headset’s status indicator will flash purple 5 times and then turns to standby mode. Repeat steps 1 to 3 to pair the devices again. Using your headset Function Button Audio Status indictor POWER ON Press and hold the MFB a short beep Flashing blue light 3 times When you turn on your headset for the first time, the headset enters into pairing mode. The status indicator flashes red and blue alternately, so that you can immediately pair it with your mobile phone. POWER OFF Press and hold the MFB until the LED turns red a long beep Red light for six seconds and then the light goes off Incoming call Ringtone on earphone Quick flashing purple light Answer a call Press the Flashing blue 8 MFB once light End a call Press the MFB once Flashing blue light Adjust Volume Press the volume control button to turn volume up or down Flashing blue light Voice Dialing* Press the MFB once a short beep Flashing blue light To use voice dial, one has to record the voice tag in the mobile device first. Press the MFB once, until you hear a short beep. Simply say the voice tag to dial. Last no. Redial* Double click the MFB Flashing blue light Reject a call* Press and hold the Volume Key for 2 seconds a short beep Flashing blue light Call Transfer (headset to mobile phone)* While speaking, press and hold the a short beep Flashing blue light 9 Call Transfer (mobile phone to headset)* volume Key for 2 seconds * Subject to mobile support Voice Prompt Voice prompt is a very convenient feature, which will guide you operate the headset with voice instruction. Press “volume up and volume down side keys” simultaneously over 6 seconds to enter languages selection mode. onetouch BH50+ offers 3 languages - English, Chinese and Spanish. Press volume up or down side key to select a language and press MFB to confirm the selection. It can be disabled (or enabled again) through pressing “MFB and volume down side key” simultaneously for over 6 seconds. Multi-connection With multi-connection, onetouch BH50+ can connect to up to 2 Bluetooth enabled mobile phones. By default, this function is enabled. It can be disabled or enabled again through pressing “MFB and volume up side key” simultaneously for over 6 seconds. Factory Setting Reset You may restore onetouch BH50+ to its default settings. Resetting will also remove the pairing history of your headset with the mobile phone. 1. Keep onetouch BH50+ in “power on” mode 10 2. Remove the Bluetooth® connection to onetouch BH50+ on your ph…

Text truncated - open the document above for the full version.

120313-21a TCT Mobile Multinational Limited Attn: Director of Certification Authority to Act as Agent I appoint ______ East China Institute of Telecommunications ________ to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in Industry Canada’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by American Certification Body, Inc. (ACB), still resides with TCT Mobile Multinational Limited Dated this _______01________day of ______04_____, 20_15___. Agency Agreement Expiration Date: (Typically 8-12 months) By: Guo Lie __________________________ (Signature) ________________________ (Print name) Title: __________________________ On behalf of: ___ TCT Mobile Multinational Limited_______________________ (Company Name) Telephone: __+86-755-3303 5399________________________

THIS MUST BE SIGNED BY THE APPLICANT/AGENT AND SHOULD BE PLACED ON APPROPRIATE LETTERHEAD Request for Confidentiality Date: 2014/3/7 Subject: Confidentiality Request for: RAD485_____ Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ TCT Mobile Limited has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: _______ Zhizhou Gong (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” 2 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

0023 External Photo

0023 cell Cell

Full RF Exposure Evaluation Report No. 2014SAR002302 For Client : TCT Mobile Limited Production : Bluetooth headset Model Name : one touch BH50+ Hardware Version: V1.0 Software Version: onetouch_BH50+_V05_ 20140117_Rel eased_final Issued date: 2014-04-16 FCC ID: RAD485 IC ID: 9238A-0029 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of ECIT Shanghai. Test Laboratory: ECIT Shanghai, East China Institute of Telecommunications Add: 7F, G Area, No.668, Beijing East Road, Huangpu District, Shanghai, P. R. China Tel: (+86)-021-63843300, E-Mail: [email protected] SAR Test Report Report No.: 2014SAR002302 East China Institute of Telecommunications Page Number : 2 of 7 TEL: +86 21 63843300 FAX: +86 21 63843301 Report Issued Date : 16 April 2014 CONTENTS 1 Test Laboratory .......................................................................................................................... 3 1.1 Testing Location .............................................................................................................................. 3 1.2 Testing Environment ....................................................................................................................... 3 1.3 Project Data ..................................................................................................................................... 3 1.4 Signature .......................................................................................................................................... 3 2 Client Information ...................................................................................................................... 4 2.1 Applicant Information for FCC ....................................................................................................... 4 2.2 Manufacturer Information for FCC ................................................................................................ 4 2.3 Applicant Information for IC ........................................................................................................... 4 2.4 Manufacturer Information for IC .................................................................................................... 4 3 Equipment Under Test (EUT) and Ancillary Equipment (AE) ................................................. 5 3.1 About EUT ........................................................................................................................................ 5 4.2 Internal Identification of EUT used during the test ...................................................................... 5 4.3 Internal Identification of AE used during the test ........................................................................ 5 5 TEST METHODOLOGY .............................................................................................................. 6 5.1 Applicable Limit Regulations ......................................................................................................... 6 6 SAR Test Result ......................................................................................................................... 7 SAR Test Report Report No.: 2014SAR002302 East China Institute of Telecommunications Page Number : 3 of 7 TEL: +86 21 63843300 FAX: +86 21 63843301 Report Issued Date : 16 April 2014 1 Test Laboratory 1.1 Testing Location Company Name: ECIT Shanghai, East China Institute of Telecommunications Address: 7-8F, G Area, No. 668, Beijing East Road, Huangpu District, Shanghai, P. R. China Postal Code: 200001 Telephone: (+86)-021-63843300 Fax: (+86)-021-63843301 1.2 Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% Ambient noise & Reflection: < 0.012 W/kg 1.3 Project Data Project Leader: Wang Yaqiong Testing Start Date: 2013-03-05 Testing End Date: 2013-03-05 1.4 Signature Hu Jiajing (Prepared this test report) Yu Naiping (Reviewed this test report) Zheng Zhongbin Director of the laboratory (Approved this test report) SAR Test Report Report No.: 2014SAR002302 East China Institute of Telecommunications Page Number : 4 of 7 TEL: +86 21 63843300 FAX: +86 21 63843301 Report Issued Date : 16 April 2014 2 Client Information 2.1 Applicant Information for FCC Company Name: TCT Mobile Limited Address: 5F, E building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 Telephone: +86-755-3303 5399 Postcode: 518057 2.2 Manufacturer Information for FCC Company Name: TCL COMMUNICATION TECHNOLOGY HOLDINGS LIMITED Address: 70 Huifeng 4rd, ZhongKai Hi-tech Development District , Huizhou, Guangdong 516006 P.R.China Telephone: +86-755-3303 5399 Postcode: 518057 2.3 Applicant Information for IC Company Name: TCT Mobile Multinational Limited Address: Room 1910-12A, Tower 3, China HK City 33 Canton Road Tsimshatsui Kowloon Hong Kong Telephone: +86-755-3303 5399 Postcode: -- 2.4 Manufacturer Information for IC Company Name: TCT Mobile Multinational Limited Address: Room 1910-12A, Tower 3, China HK City 33 Canton Road Tsimshatsui Kowloon Hong Kong Telephone: +86-755-3303 5399 Postcode: -- SAR Test Report Report No.: 2014SAR002302 East China Institute of Telecommunications Page Number : 5 of 7 TEL: +86 21 63843300 FAX: +86 21 63843301 Report Issued Date : 16 April 2014 3 Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1 About EUT Description: Premium BT headset with black chrome NCVM Model name: one touch BH50+ Operation Model(s): Bluetooth Tx Frequency: 2402 ~ 2480 MHz (BT) Test device Production information: Production unit Device type: Portable device UE category: 3 Antenna type: Inner antenna 4.2 Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version N01 N/A V1.0 onetouch_BH50+_V05_20140 117_Released_final *EUT ID: is used to identify the test sample in the lab internally. 4.3 Internal Identificati…

Text truncated - open the document above for the full version.

TEST REPORT No. 2014RFB002302 For Client : TCT Mobile Limited Production: Bluetooth headset Bluetooth headset Model Name : one touch BH50+ Hardware Version: V1.0 Software Version: onetouch_BH50+_V05_20140117_ Released_final FCC ID: RAD485 IC ID: 9238A-0029 Issued date: 2014-04-17 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of ECIT Shanghai. Test Laboratory: ECIT Shanghai, East China Institute of Telecommunications Add: 7F, G Area, No.668, Beijing East Road, Huangpu District, Shanghai, P. R. China Tel: (+86)-021-63843300, E-Mail: [email protected]. Report No.: 2014RFB002302 Page 2 of 73 CONTENTS 1. GENERAL INFORMATION .................................................................................... 3 1.1 NOTES ..................................................................................................................... 3 1.2 STATEMENTS ............................................................................................................ 3 1.3 TESTING LABORATORY INFORMATION ........................................................................ 4 1.3.1. Testing Location ............................................................................................... 4 1.3.2. Testing Environment ........................................................................................ 4 1.3.3. Project data ....................................................................................................... 4 1.3.4. Signature ........................................................................................................... 4 1.4 DETAILS OF APPLICANT OR MANUFACTURER .............................................................. 5 1.4.1. Applicant Information ....................................................................................... 5 1.4.2. Manufacturer Information ................................................................................ 5 2. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ........... 6 2.1. ABOUT EUT .......................................................................................................... 6 2.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ...................... 6 2.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ........................ 6 3. REFERENCE DOCUMENTS ................................................................................. 7 3.1. REFERENCE DOCUMENTS FOR TESTING ........................................................ 7 4. SUMMARY OF TEST RESULTS ........................................................................... 8 5. TEST RESULT ..................................................................................................... 10 5.1. PEAK OUTPUT POWER-CONDUCTED ............................................................. 10 5.2. FREQUENCY BAND EDGES-CONDUCTED ...................................................... 15 5.3. CONDUCTED EMISSION .................................................................................... 22 5.4. RADIATED EMISSION ......................................................................................... 32 5.5. TIME OF OCCUPANCY (DWELL TIME) ............................................................. 45 5.6. 20DB BANDWIDTH ............................................................................................. 55 5.7. CARRIER FREQUENCY SEPARATION .............................................................. 60 5.8. NUMBER OF HOPPING CHANNELS ................................................................. 62 5.9. AC POWERLINE CONDUCTED EMISSION ....................................................... 66 6. TEST EQUIPMENTS AND ANCILLARIES USED FOR TESTS .......................... 69 7. TEST ENVIRONMENT ......................................................................................... 71 ANNEX A DEVIATIONS FROM PRESCRIBED TEST METHODS ................................. 73 Report No.: 2014RFB002302 Page 3 of 73 1. General Information 1.1 Notes All reported tests were carried out on a sample equipment to demonstrate limited compliance with the section 3. The test results of this test report relate exclusively to the item(s) tested as specified in section 5. The following deviation from, additions to, or exclusions from the test specifications have been made. See section 3. 1.2 Statements The product Bluetooth headset , supporting BT, manufactured by TCL COMMUNICATION TECHNOLOGY HOLDINGS LIMITED is a new product for testing. ECIT has verified that the compliance of the tested device specified in section 5 of this test report is successfully evaluated according to the procedure and test methods as defined in type certification requirement listed in section 5 of this test report. Report No.: 2014RFB002302 Page 4 of 73 1.3 Testing Laboratory information 1.3.1. Testing Location Company Name: ECIT Shanghai, East China Institute of Telecommunications Address: 7F, G Area,No. 668, Beijing East Road, Huangpu District, Shanghai, P. R. China Postal Code: 200001 Telephone: 86-21-63843300 Fax: 86-21-63843301 FCC Registration NO.: 489729 1.3.2. Testing Environment Normal Temperature: 15-35°C Extreme Temperature: N/A Relative Humidity: 20-75% 1.3.3. Project data Project Leader: Wangyaqiong Testing Start Date: 2014-02-21 Testing End Date: 2014-02-24 1.3.4. Signature Wang Daming (Prepared this test report) Liu Jianquan (Reviewed this test report) Zheng Zhongbin Director of the laboratory (Approved this test report) Report No.: 2014RFB002302 Page 5 of 73 1.4 Details of applicant or manufacturer 1.4.1. Applicant Information for FCC Company Name: TCT Mobile Limited Address /Post: 5F, E building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 Country: China 1.4.2. Manufacturer Information for FCC Company Name: TCL COMMUNICATION TECHNOLOGY HOLDINGS LIMITED Address /…

Text truncated - open the document above for the full version.

Test setup photo RE: CE:
