RAD506CDMA 1X BC0/BC1/BC10 MOBILE PHONE

[ALCATEL ONETOUCH 2017B] User Guide [Boost_Alcatel_B3G 1X_UG_EN_20140624_Draft1] TOC i Table of Contents Your Phone at a Glance ...................................................................................................... 1 Set Up Your Phone ............................................................................................................. 2 Activation and Service ........................................................................................................ 4 Create Your Account and Pick Your Plan .................................................................... 4 Activate Your Phone .................................................................................................... 4 Manage Your Account ................................................................................................. 4 Re-Boost ..................................................................................................................... 5 Additional Information .................................................................................................. 5 Set Up Voicemail ................................................................................................................ 5 Your Phone’s Layout ........................................................................................................... 7 Turn Your Phone On and Off .............................................................................................. 9 Navigate Through the Menus .............................................................................................. 9 Select Menu Items .............................................................................................................. 9 Back Up Within a Menu ...................................................................................................... 9 Status Bar ........................................................................................................................... 9 Enter Text ..........................................................................................................................11 Keyboard ....................................................................................................................11 Make Phone Calls ..............................................................................................................13 Call Using the Phone Dialer ........................................................................................13 Call from Recent History .............................................................................................13 Call from Contacts ......................................................................................................14 Call Using a Speed Dial Number ................................................................................14 Call Emergency Numbers ...........................................................................................14 Receive Phone Calls ..........................................................................................................14 Voicemail ...........................................................................................................................15 Voicemail Setup ..........................................................................................................15 Voicemail Notification .................................................................................................15 Retrieve Your Voicemail Messages ............................................................................16 Phone Call Options ............................................................................................................16 In-call Options .............................................................................................................16 TOC ii Caller ID .....................................................................................................................17 Conference Calling .....................................................................................................17 Call Using a Speed Dial Number........................................................................................18 Recent History ...................................................................................................................18 Call Settings ......................................................................................................................19 Personal Contacts Entries– Entries for an individual. ..................................................20 Group Contacts Entries – Entries that contain more than one personal Contacts entry. ...................................................................................................................................20 View Contacts .............................................................................................................20 Contacts List Options ..................................................................................................21 Add a Contact ....................................................................................................................21 Create a Personal Entry..............................................................................................21 Create a Group Entry ..................................................................................................22 Save a Phone Number .......................................................................................................22 Edit a Contact ....................................................................................................................23 Add or Edit Information for a Contact ..........................................................................23 Assign a Ringtone to a Contact...................................................................................23 Delete a Contact .................…

Text truncated - open the document above for the full version.

5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 Date 2014-06-18 To: Federal Communications Commission, Authorization & Evaluation Division, 7345 Oakland Mills Road Columbia, MD 21046 And Timco Engineering, Inc. 849 NW State Road 45 Newberry, Florida 32669 To Whom It May Concern: Song Chongwen from TMC (Telecommunication Metrology Center of MIIT) is authorized to act on our behalf, until otherwise notified, for applications to TIMCO ENGINEERING INC. We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Gong Zhizhou Approval Team Leader TCT Mobile Limited

5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 2014-06-18 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: RAD506 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhizhou Gong Approval Team Leader TCT Mobile Limited

External Photos

Label location justification letter figure 1. Because the majority of the transceiver housing is composed of display, speaker, operating controls, and a removable battery pack, there is extremely limited space available to attach the required label carrying the FCC identifier. Attaching the label to the battery pack is not acceptable because the battery pack is a removable item. For this reason, we propose placing the label carrying the FCC identifier inside the battery compartment as shown in figure 2. The consumer packaging for these models includes the battery pack as a separate item, NOT installed on the radio. As such, the FCC identifier will be readily visible to the user before the battery pack is installed and whenever the battery pack is removed or replaced. In this location, the label will also be protected from physical abuse and remain readable for the anticipated life of the device. The consumer packaging for these models is a "gift box" which does not allow the transceiver to be seen at time of purchase. In order to meet the requirements of 47CFR Part 2.925 (d), We will add the FCC identifier "RAD506" to the outside of the consumer "gift box" packaging. To find the label follow these steps: 1． Remove the cover on the rear side of the product 2． Remove the battery 3． The label is located behind the battery figure 2.

Internal Photos

No.I14Z45961-EMC01 Page 1 of 18 ©Copyright. All rights reserved by TMC Beijing. TEST REPORT No. I14Z45961-EMC01 for TCT Mobile Limited CDMA 1X BC0/BC1/BC10 mobile phone Model Name: B3G 1X Marketing Name: 2017B&2017P FCC ID: RAD506 with Hardware Version: Revision 1.1 Software Version: 2017BVB2 Issued Date: Jun.13 th , 2014 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629A-1 TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191 Tel: +86(0)10-62304633-2561, Fax: +86(0)10-62304633-2504 Email:[email protected]. www.emcite.com No.I14Z45961-EMC01 Page 2 of 18 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY .............................................................................................................. 3 1.1. TESTING LOCATION .......................................................................................................... 3 1.2. TESTING ENVIRONMENT .................................................................................................. 3 1.3. PROJECT DATA .................................................................................................................. 3 1.4. SIGNATURE ........................................................................................................................ 3 2. CLIENT INFORMATION .......................................................................................................... 4 2.1. APPLICANT INFORMATION............................................................................................... 4 2.2. MANUFACTURER INFORMATION ..................................................................................... 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 5 3.1. ABOUT EUT ........................................................................................................................ 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 5 3.4. EUT SET-UPS ..................................................................................................................... 6 4. REFERENCE DOCUMENTS .................................................................................................. 7 4.1. REFERENCE DOCUMENTS FOR TESTING ...................................................................... 7 5. LABORATORY ENVIRONMENT ............................................................................................ 8 6. SUMMARY OF TEST RESULTS ............................................................................................. 9 7. TEST EQUIPMENTS UTILIZED ............................................................................................ 10 ANNEX A: MEASUREMENT RESULTS ...................................................................................... 11 No.I14Z45961-EMC01 Page 3 of 18 ©Copyright. All rights reserved by TMC Beijing. 1. Test Laboratory 1.1. Testing Location Location A Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: No 52, Huayuan Bei Road, Haidian District, Beijing, P.R. China Postal Code: 100191 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: May 19 th , 2014 Testing End Date: Jun. 13 th , 2014 1.4. Signature Qu Pengfei (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.I14Z45961-EMC01 Page 4 of 18 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: TCT Mobile Limited Address /Post: 5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. City: Shanghai Postal Code: 201203 Country: China Contact Person: Gong Zhizhou Contact Email [email protected] Telephone: 0086-21-61460890 Fax: 0086-21-61460602 2.2. Manufacturer Information Company Name: TCT Mobile Limited Address /Post: 5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. City: Shanghai Postal Code: 201203 Country: China Telephone: 0086-21-61460890 Fax: 0086-21-61460602 No.I14Z45961-EMC01 Page 5 of 18 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description CDMA 1X BC0/BC1/BC10 mobile phone Model Name B3G 1X Marketing Name 2017B&2017P FCC ID RAD506 Extreme vol. Limits 3.5VDC to 4.35VDC (nominal: 3.8VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MIIT of People’s Republic of China. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version EUT2 A100003BBACED7 Revision 1.1 2017BVB2 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Description SN Remarks AE1 Battery / 1445961BA007 AE2 Battery / 1445961BA009 AE3 Battery / 1445961BA006 AE4 Travel charger / 1445961CH002 AE5 Travel charger / 1445961CH010 AE6 USB / TCT-DC-0325 AE7 USB / / AE1, AE2, AE3 Model CAB3120000C1 Manufacturer BYD Capacitance 850 mAh Nominal voltage 3.7V AE4, AE5 Model CBA3002AG0C2 Manufacturer Tenpao Length of cable 119.5cm AE6 Model USB Cable Manufacturer Juwei Length of cable 100cm No.I14Z45961-EMC01 Page 6 of 18 ©Copyright. All rights reserved by TMC Beijing. AE7 Model USB Cable Manufacturer Shenhua Length of cable 100cm *AE ID: is used to ident…

Text truncated - open the document above for the full version.

EUT Set-up photos
