RAD509Connected wristband with Bluetooth technology

5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 Date 2014-06-23 To: Federal Communications Commission, Authorization & Evaluation Division, 7345 Oakland Mills Road Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: TMC (Telecommunication Metrology Center of MIIT) is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Gong Zhizhou Product Certification Manager TCT Mobile Limited

5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 2014-07-03 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: RAD509 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhizhou Gong Approval Team Leader TCT Mobile Limited

STATEMENT For end user using, E-Card(EC01) only support battery charging via USB connector, no data connection need to be used. Thanks. Product Certification Manager: Zhizhou.Gong

NFC Anttenna

No.I14Z46902-GPM02 Page 1 of 6 ©Copyright. All rights reserved by TMC Beijing. RF Exposure REPORT No. I14Z46902-GPM02 for TCT Mobile Limited Bluetooth E-Card Model Name: EC01 FCC ID: RAD509 With Hardware Version: PIO Software Version: EC01_V0.14 Issued Date: 2014-07-02 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0)10-62304633, Fax:+86(0)10-62304633 Email:[email protected]. www.emcite.com No.I14Z46902-GPM02 Page 2 of 6 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY ......................................................................................................................... 3 1.1. TESTING LOCATION .................................................................................................................... 3 1.2. TESTING ENVIRONMENT ........................................................................................................... 3 1.3. PROJECT DATA .............................................................................................................................. 3 1.4. SIGNATURE ..................................................................................................................................... 3 2. CLIENT INFORMATION ................................................................................................................... 4 2.1. APPLICANT INFORMATION ....................................................................................................... 4 2.2. MANUFACTURER INFORMATION ............................................................................................ 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................. 5 3.1. ABOUT EUT ..................................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT ..................................................................................... 5 3.3. INTERNAL IDENTIFICATION OF AE ........................................................................................ 5 4. REFERENCE DOCUMENTS ............................................................................................................. 6 4.1. REFERENCE DOCUMENTS FOR TESTING ............................................................................. 6 5. RF EXPOSURE LIMIT ....................................................................................................................... 6 No.I14Z46902-GPM02 Page 3 of 6 ©Copyright. All rights reserved by TMC Beijing. 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: No 52, Huayuan beilu, Haidian District, Beijing,P.R.China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304793 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Project Leader: Xue Zhen Testing Start Date: 2013-02-14 Testing End Date: 2013-03-06 1.4. Signature Xue Zhen (Prepared this test report) Song Chongwen (Reviewed this test report) Lu Bingsong Deputy Director of the laboratory (Approved this test report) No.I14Z46902-GPM02 Page 4 of 6 ©Copyright. All rights reserved by TMC Beijing. 2. Client Information 2.1. Applicant Information Company Name: TCT Mobile Limited Address /Post: 5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 City: Shanghai Postal Code: 201203 Country: China Contact Person: Gong Zhizhou Contact Email [email protected] Telephone: 0086-21-61460890 Fax: 0086-21-61460602 2.2. Manufacturer Information Company Name: TCT Mobile Limited Address /Post: 5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 City: Shanghai Postal Code: 201203 Country: China Contact Person: Gong Zhizhou Contact Email [email protected] Telephone: 0086-21-61460890 Fax: 0086-21-61460602 No.I14Z46902-GPM02 Page 5 of 6 ©Copyright. All rights reserved by TMC Beijing. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description Bluetooth E-Card Model Name EC01 Frequency Band ISM 2400MHz~2483.5MHz Type of Modulation GFSK Number of Channels 79 Extreme Temperature -10/+55°C Normal Voltage 3.8V Peak antenna gain 0dBi Note1: Photographs of EUT are shown in ANNEX A of this test report. 3.2. Internal Identification of EUT EUT ID* IMEI HW Version SW Version UT03A / PIO EC01_V0.14 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE AE ID* Description SN AE1 RF cable --- *AE ID: is used to identify the test sample in the lab internally. No.I14Z46902-GPM02 Page 6 of 6 ©Copyright. All rights reserved by TMC Beijing. 4. Reference Documents 4.1. Reference Documents for testing The following documents listed in this section are referred for testing. Reference Title Version RSS-102 Radio Frequency Exposure Compliance of Radio communication Apparatus (All Frequency Bands) Issue 4 KDB447498 Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies v05r01 5. RF Exposure Limit According to RSS-102 Issue 2, section 2.5 and FCC KDB447498, and the maximum output power listed below, the device is exempt from the routine evaluation and is fulfill RF exposure compliance with FCC and IC requirement. The output power and operating frequency of the device are: mode Maximum Output Power Conducted Radiated 2.4GHz Bluetooth 7.18dBm 7.18dBm ***END OF REPORT***

No. I14Z46902-GTE01 Page1 of 82 ©Copyright. All rights reserved by TMC Beijing. FCC PART 15C TEST REPORT No. I14Z46902-GTE01 for TCT Mobile Limited Bluetooth E-Card Model Name: EC01 FCC ID: RAD509 with Hardware Version: PIO Software Version: EC01_V0.14 Issued Date: 2014-06-20 DAR accreditation (DIN EN ISO/IEC 17025): No. D-PL-12123-01-01 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629B-1 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology Shouxiang Science Building, No 51, Xueyuan Road, Haidian District, Beijing, P.R.China 100191 Tel:+86(0)10-62304633, Fax:+86(0)10-62304633-2504 Email:[email protected]. www.emcite.com No. I14Z46902-GTE01 Page2 of 82 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY ......................................................................................................................... 3 1.1. TESTING LOCATION ......................................................................................................................... 3 1.2. TESTING ENVIRONMENT .................................................................................................................. 3 1.3. PROJECT DATA ................................................................................................................................. 3 1.4. SIGNATURE ...................................................................................................................................... 3 2. CLIENT INFORMATION ................................................................................................................... 4 2.1. APPLICANT INFORMATION ............................................................................................................... 4 2.2. MANUFACTURER INFORMATION ............................................................................................ 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................. 5 3.1. ABOUT EUT .................................................................................................................................... 5 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .......................................................... 5 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ............................................................. 5 3.4. NORMAL ACCESSORY SETTING ........................................................................................................ 5 3.5. GENERAL DESCRIPTION ................................................................................................................... 5 4. REFERENCE DOCUMENTS ............................................................................................................. 6 4.1. DOCUMENTS SUPPLIED BY APPLICANT............................................................................................. 6 4.2. REFERENCE DOCUMENTS FOR TESTING ........................................................................................... 6 5. LABORATORY ENVIRONMENT ..................................................................................................... 7 6. SUMMARY OF TEST RESULTS ....................................................................................................... 8 6.1. SUMMARY OF TEST RESULTS ........................................................................................................... 8 6.2. STATEMENTS .................................................................................................................................... 8 7. TEST EQUIPMENTS UTILIZED ...................................................................................................... 9 ANNEX A: MEASUREMENT RESULTS ................................................................................................ 10 A.1. MEASUREMENT METHOD .................................................................................................................. 10 A.2. PEAK OUTPUT POWER - CONDUCTED .................................................................................................11 A.3. FREQUENCY BAND EDGES - CONDUCTED .......................................................................................... 12 A.4. CONDUCTED EMISSION ...................................................................................................................... 19 A.5. RADIATED EMISSION .......................................................................................................................... 43 A.6. TIME OF OCCUPANCY (DWELL TIME)................................................................................................. 62 A.7. 20DB BANDWIDTH ............................................................................................................................. 72 A.8. CARRIER FREQUENCY SEPARATION ................................................................................................... 77 A.9. NUMBER OF HOPPING CHANNELS ...................................................................................................... 79 No. I14Z46902-GTE01 Page3 of 82 ©Copyright. All rights reserved by TMC Beijing. 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: Shouxiang Science Building, No 51, Xueyuan Road, Haidian District, Beijing, P.R.China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304633-2504 1.2. Testing Environment Normal Temperature: 15-35°C Extreme Temperature: -20/+55°C Relative Humidity: 20-75% 1.3. Project data Project Leader: Zi Xiaogang Testing Start Date: 2014-06-03 Testing End Date: 2014-06-19 1.4. Signature Zi Xiaogang (Prepared this test report) Sun Xiangqian (Rev…
