RAD551Mobile phone with GSM/GPRS/EDGE 850/1900, WCDMA/HSPA FDD II/V, LTE - Band 4, 7, 17, 802.11b/g/n, Bluetooth.

English - CJB1B16ALAAA Quick Start Guide Thank you for buy ALCATEL ONETOUCH 4045O. We hope you will enjoy your high-quality mobile communication experience. For more information about how to use your cellphone, please visit www.alcatelonetouch.com to download the complete user manual. From the website, you can consult the FAQ, perform software upgrades, etc. PROTECT YOUR HEARING To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use. Table of contents 1 Your phone ����������������������������������������������������������������������1 2 Text input ����������������������������������������������������������������������11 3 Phone call ����������������������������������������������������������������������12 4 Contacts ������������������������������������������������������������������������14 5 Messaging�����������������������������������������������������������������������15 6 Email ������������������������������������������������������������������������������16 7 Getting connected ��������������������������������������������������������17 8 Find my location using GPS satellites ������������������������19 9 Data backup ������������������������������������������������������������������20 10 Factory data reset���������������������������������������������������������20 11 Applications & Internal storage ����������������������������������21 12 Making the most of your phone ����������������������������������22 Safety and use�������������������������������������������������������������������������24 General information ��������������������������������������������������������������31 TCT Mobile (US), Inc�������������������������������������������������������������32 Warranty��Troubleshooting ���������������������������������������������������34 www.sar-tick.com This product meets applicable national SAR limits of 1.6 W/kg. The specific maximum SAR values can be found in RADIO WAVE part of this user guide. When carrying the product or using it while worn on your body, either use an approved accessory such as a holster or otherwise maintain a distance of 1.0 cm from the body to ensure compliance with RF exposure requirements. Note that the product may be transmitting even if you are not making a phone call. 1 1 Your phone ������������������� 1�1 Keys and connectors Micro-USB Connector Front camera Headset connector Home key Touch screen Back key Recent Apps Key Power key 2 Camera Camera Flash/ Flashlight Volume down key Volume up key Recent Apps key • Touch to view or clear recent used applications. • Touch and hold to access Settings options. Home key • From any application or screen, touch to return to the Home screen. • Touch and hold to open Google search. Back key • Touch to go back to the previous screen, or to close a dialog box, options menu, the notification panel, etc. 3 Power key • Press: Lock the screen/Light up the screen. • Press and hold: Show the pop-up menu to select from Power off/Reboot/Airplane mode. • Press the Power key for more than 7s to restart. • Press the Power key and Volume up key to reset. • Press the Power key and Volume down key for 1s to capture a screenshot. Volume Keys • In call mode, adjusts the earpiece or headset volume. • In Music/Video/Streaming mode, adjusts the media volume. • In general mode, adjusts the ringtone volume. • Mutes the ringtone of an incoming call. • In camera preview mode, press Volume up or down key to enter burst shoot. 1�2 Getting started 1�2�1 Set-up Removing or installing the back cover Inserting or removing the SIM card You must insert your SIM card to make phone calls. Please power off your phone before inserting or removing the SIM card. To install SIM card, start by sliding the metal tray to OPEN position, 4 tray will click and release when unlocked. Place the SIM card into the slot with gold contacts facing downward. Once SIM card is placed into slot, close metal tray, then slide tray to LOCK position, tray will click when locked. To remove SIM card, slide the metal SIM card tray to unlock position and gently slide the SIM card out from slot. Your phone only supports micro-SIM cards. Do not attempt to insert other SIM types like mini and nano cards; otherwise this may cause damage to your phone. Installing or removing the microSD card To install microSD card, start by sliding the metal tray right to OPEN position, tray will click and release when unlocked. Place the microSD card into the slot with gold contacts facing downward. Once microSD card is placed into slot, close metal tray, then slide tray to left. To remove microSD card, slide the metal microSD card tray to unlock position and gently slide the microSD card out from slot. To avoid data loss and SD card damage, before removing the SD card, please ensure that the SD card is unmounted (Settings\Storage\Unmount SD card). Charging the battery Connect the battery charger to your phone and wall socket respectively, the LED indicator will light while charging. To reduce power consumption and energy waste, when the battery is fully charged, disconnect your charger; switch off Wi-Fi, GPS, Bluetooth or background-running applications when not in use; reduce the backlight time, etc. 5 1�2�2 Power on your phone Hold down the Power key until the phone powers on. It will take a few seconds before the screen lights up. Set up your phone for the first time The first time you power on the phone, you should set the following options: Input method, Google account, Location, etc. Even if no SIM card is installed, your phone will still power on and you will be able to connect to a Wi-Fi network, sign into your Google account and use some of the phone's features. 1�2�3 Power off your phone Hold down the Power key from the Home screen until the phone options appear, select Power off. 1�3 Home screen You can move all of items (applications, shortcuts, folders and widgets) you u…

Text truncated - open the document above for the full version.

5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 Date 2015-01-19 To: Federal Communications Commission, Authorization & Evaluation Division, 7345 Oakland Mills Road Columbia, MD 21046 And American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: CTTL-Terminals Test Lab of China Academy of Telecommunication Research of MIIT is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Zhizhou GONG Product Certification Manager TCT Mobile Limited

5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 2015-01-30 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 S ubject: Confidentiality request or FCC ID: RAD551 To W hom It May Concern: Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, (TCT Mobile Limited) hereby requests permanent confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure also hereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of (up to 180) days: - External Photos - Internal Photos - Test Setup Photos - User Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Zhizhou GONG P roduct Certification Manager TCT Mobile Limited

TLi020F1 TLi020F1 TLi020F2 TLi020F2 CCB0005A11C1 CCB0005A11C6 CCB3160A11C1 CCB3160A11C6 CCB0005A10C6 CCB0005A10C1 CBA3007AG0C1 CBA3007AG0C1 CBA3007AG0C1 CBA3007AG0C4 CBA3007AG0C4 CBA3007AG0C4 CDA3122002C2 CDA3122002C1 CDA3122005C1 CDA3122005C2

©Copyright. All rights reserved by CTTL. TEST REPORT No. I15Z40876-EMC01 for TCT Mobile Limited HSDPA/HSUPA/HSPA+/UMTS quad band / GSM quad band/LTE 5 band Moblie phone Model Name: 4045O FCC ID: RAD551 with Hardware Version: PIO Software Version: v5L38 Issued Date: 2015-04-28 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. This project is only tested using FCC standards and not an application of FCC, so the project does not have a FCC ID. Test Laboratory: FCC 2.948 Listed: No. 525429 CTTL, Telecommunication Technology Labs, Academy of Telecommunication Research, MIIT No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191. Tel: +86(0)10-62304633-2512, Fax: +86(0)10-62304633-2504 Email: [email protected], website: www.chinattl.com No.I15Z40876-EMC01 Page 2 of 21 ©Copyright. All rights reserved by CTTL. REPORT HISTORY Report Number Revision Description Issue Date I15Z40876-EMC01 Rev.0 1st edition 2015-04-22 I15Z40876-EMC01 Rev.1 2st edition 2015-04-28 No.I15Z40876-EMC01 Page 3 of 21 ©Copyright. All rights reserved by CTTL. CONTENTS 1. TEST LABORATORY ............................................................................................................... 4 1.1. TESTING LOCATION ........................................................................................................... 4 1.2. TESTING ENVIRONMENT ................................................................................................... 4 1.3. PROJECT DATA ................................................................................................................... 4 1.4. SIGNATURE .......................................................................................................................... 4 2. CLIENT INFORMATION ........................................................................................................... 5 2.1. APPLICANT INFORMATION ................................................................................................ 5 2.2. MANUFACTURER INFORMATION ...................................................................................... 5 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 6 3.1. ABOUT EUT .......................................................................................................................... 6 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 6 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 6 3.4. EUT SET-UPS ....................................................................................................................... 7 4. REFERENCE DOCUMENTS .................................................................................................... 8 4.1. REFERENCE DOCUMENTS FOR TESTING....................................................................... 8 5. LABORATORY ENVIRONMENT .............................................................................................. 9 6. SUMMARY OF TEST RESULTS ............................................................................................ 10 7. TEST EQUIPMENTS UTILIZED ............................................................................................. 11 ANNEX A: MEASUREMENT RESULTS ....................................................................................... 12 No.I15Z40876-EMC01 Page 4 of 21 ©Copyright. All rights reserved by CTTL. 1. Test Laboratory 1.1. Testing Location Location 1: CTTL(huayuan North Road) Address: No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: 2015-04-16 Testing End Date: 2015-04-18 1.4. Signature Qu Pengfei (Prepared this test report) Sun Xiangqian (Reviewed this test report) Lu Bingsong Director of the laboratory (Approved this test report) No.I15Z40876-EMC01 Page 5 of 21 ©Copyright. All rights reserved by CTTL. 2. Client Information 2.1. Applicant Information Company Name: TCT Mobile Limited Address /Post: 5F, C building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Area, Shanghai, P.R. China. 201203 City: Shanghai Postal Code: 201203 Country: China Contact Person: Zhizhou Gong Contact Email / Telephone: +86 21 51798260 Fax: +86 21 61460602 2.2. Manufacturer Information Company Name: TCT Mobile Limited Address /Post: 5F, C building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Area, Shanghai, P.R. China. 201203 City: Shanghai Postal Code: 201203 Country: China Telephone: +86 21 51798260 Fax: +86 21 61460602 No.I15Z40876-EMC01 Page 6 of 21 ©Copyright. All rights reserved by CTTL. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description HSDPA/HSUPA/HSPA+/UMTS quad band / GSM quad band/LTE 5 band Moblie phone Model Name 4045O FCC ID RAD551 Extreme vol. Limits 3.55VDC to 4.35VDC (nominal: 3.8VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MIIT of People’s Republic of China. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version EUT3 865948020100321 PIO v5L38 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Description SN Remarks AE1 battery B2000010C1100J9S 14TCT-BA-0070 AE2 battery B2000013C2Y0S8L1 14TCT-BA-2145 AE3 battery B2000010C1100MKL 14TCT-BA-0425 AE4 battery B2000013C2Y0S9VG 14TCT-BA-2150 AE5 Travel Charger / 14TCT-CH-2129 AE6 Travel Charger / 14TCT-CH-1517 AE7 Travel Charger / 14TCT-CH-2430 AE8 Travel Charger / 14TCT-CH-2422 AE9 USB Cable / 14TCT-DC-0777 AE10 USB Cable / 14TCT-DC-0163 AE1, AE3 Commercial name …
