1 English - CJB33K001AAA Quick Start Guide For more information about how to use the phone, please go to www.alcatelonetouch.com to download complete user manual. Moreover, from the website you can also consult FAQ. ALCATEL ONETOUCH SIDEKICK 2 Table of contents 1 Your BP60/66 ...................................................3 2 Getting started ................................................5 3 Bluetooth switch .............................................6 4 Messaging ..........................................................7 5 Contacts ............................................................8 6 Call log ...............................................................8 7 Profiles ...............................................................9 8 Settings...............................................................9 9 Music player controller ................................10 10 Find phone ......................................................11 11 Alert .................................................................11 3 1 Your BP60/66 .... 1.1 Key and connectors BP60 BP66 1 2 3 4 5 6 7 8 1 2 3 4 5 6 4  Left softkey  Send key  Navigation key/OK key  Right softkey  End key  Space key  Reset hole  micro-USB connector • Press to go up/down/left/right • Press to confirm • Pick up/Send a call • Press: End a call Return to Home screen Light on/off the screen • Press and hold: Power on/off • Press: Input # • Press and hold: Switch between general and silent mode • Press: Input * • Press and hold: Lock the screen 1.2 Change wallpaper You can set wallpaper by pressing Settings\ Phone settings\Wallpaper. 5 2 Getting started 2.1 Charging the battery Connect the battery charger to your phone and outlet respectively. To reduce power consumption and energy waste when battery charger is fully charged, disconnect your charger from the plug. 2.2 Power on your phone Hold down the key until the phone powers on. 2.3 Power off your phone Hold down the key from the Home screen. 6 3 Bluetooth switch ....../ You can activate Bluetooth paring in host. Host activate connection: You can also turn Bluetooth on and select Bluetooth to see the list of available Bluetooth devices. You need to input your password (0000) in host once you touch ALCATEL ONE TOUCH BP60/66 to pair in host. When pairing is successful, host name on BP60/66 will be visible. You only need to pair BP60/66 once. It automatically reconnects to your host once you turn on the BP60/66 and host Bluetooth. 7 4 Messaging .... You can access this menu by selecting "Messaging" in main menu. BP60/66 can synchronize new messages from host. You can view and compose new messages in BP60/66. You can also reply to messages via BP60/66. Sent messages will be synchronised to host sent box. Once the host receives an MMS, there will be a prompt dialog box in BP60/66 to remind you to read the MMS in the host. 8 5 Contacts ...... "Contacts" enables quick and easy access to the people you want to reach. You can access this function by selecting “Contacts” from the main menu. You can review contacts which are synchronized from host. By pressing the BP60/66 navigation up/ down/left/right key, you can go to last/next/last page/next page contacts. Select the contact you wish to call and press to make the call. You can also send message to the contact by select Options\Send text message. 6 Call log ......... You can access the function using the following options. • Select from main menu • Select key from phone keyboard Answered calls/Rejected calls Outgoing calls (Redial) Missed calls BP60/66 can interpret all missed calls, outgoing and incoming calls from host but you will not be able to delete this information from BP60/66. You can select an contact in call log list, then select Options to give a call or send text message. 9 7 Profiles ......... With this menu, you can personalize ringtones for different events and environments. 8 Settings ........ From the main menu, select "Settings" to select various functions which will enable you to customize your BP60/66. 8.1 Audio settings Allows you to have settings of ringtone, volume, alert type, ring type and extra ringtone. 8.2 Phone settings You can customize time and date, language, input method, wallpaper and LCD backlight of ALCATEL ONE TOUCH BP60/66. 8.3 Security (1) You can turn on or turn off Password on boot and Auto keypad lock. You can also change phone password. 8.4 Factory data reset (1) You can input password to restore factory settings. (1) The factory data reset password and first boot password are 1234. 10 8.5 Bluetooth settings Turn on Visibility so that other Bluetooth device can find your ALCATEL ONE TOUCH BP60/66. 9 Music player controller ..... BP60/66 does not have a function to install music directly. It can however control a music player via host by Remote Control function. Select Music player controller from the main menu to play last song, next song or stop. 11 10 Find phone..... You can select Find phone and the host will ring which will help you to find your host when you cannot locate your host. 11 Alert ...... You can read calendar events and alarm events on BP60/66, but you cannot edit or set these events on BP60/66 directly. In addition, the event icon will appear on BP60/66 screen when the reminder time arrives. 12 Safety and use ......... We recommend that you read this chapter carefully before using your mobile phone. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use or use contrary to the instructions contained herein. • TRAFFIC SAFETY: Given that studies show that using a mobile phone while driving a vehicle constitutes a real risk, even when the hands-free kit is used (car kit, headset...), drivers are requested to refrain from using their mobile phone when the vehicle is not parked. Check the laws and regulations on the use of wireless mobile phones and their accessories in the areas where you drive. Always obey them…

Text truncated - open the document above for the full version.

5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 Date 2013-12-10 To: Federal Communications Commission, Authorization & Evaluation Division, 7345 Oakland Mills Road Columbia, MD 21046 And American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: TMC (Telecommunication Metrology Center of MIIT) is authorized to act on our behalf, until otherwise notified, for applications to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Gong Zhizhou Approval Team Leader TCT Mobile Limited

5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 TEL: +86(0)21 61460666 FAX: +86(0)21 61460602 2013-12-16 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: RAD908 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhizhou Gong Approval Team Leader TCT Mobile Limited

FCC ID : RAD908

FCC ID: RAD908 label location

FCC ID: RAD908

No. 2013TAR773 Page1 of 90 ©Copyright. All rights reserved by TMC Beijing. FCC PART 15C TEST REPORT No. 2013TAR773 for TCT Mobile Limited Bluetooth phone Model Name: Ashley+ Marketing Name: ONE TOUCH BP66 FCC ID: RAD908 with Hardware Version: PIO Software Version: V33 Issued Date: 2013-12-16 DAR accreditation (DIN EN ISO/IEC 17025): No. D-PL-12123-01-01 FCC 2.948 Listed: No.733176 IC O.A.T.S listed: No.6629B-1 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of TMC Beijing. Test Laboratory: TMC Beijing, Telecommunication Metrology Center of Ministry of Industry and Information Technology Shouxiang Science Building, No 51, Xueyuan Road, Haidian District, Beijing, P.R.China 100191 Tel:+86(0)10-62304633-2054, Fax:+86(0)10-62304633 Email:[email protected]. www.emcite.com No. 2013TAR773 Page2 of 90 ©Copyright. All rights reserved by TMC Beijing. CONTENTS 1. TEST LABORATORY ......................................................................................................................... 3 1.1. T ESTING LOCATION ......................................................................................................................... 3 1.2. T ESTING ENVIRONMENT .................................................................................................................. 3 1.3. P ROJECT DATA ................................................................................................................................. 3 1.4. S IGNATURE ...................................................................................................................................... 3 2. CLIENT INFORMATION ................................................................................................................... 4 2.1. A PPLICANT INFORMATION ............................................................................................................... 4 2.2. MANUFACTURER INFORMATION ............................................................................................ 4 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................. 5 3.1. A BOUT EUT .................................................................................................................................... 5 3.2. I NTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .......................................................... 5 3.3. I NTERNAL IDENTIFICATION OF AE USED DURING THE TEST ............................................................. 5 3.4. N ORMAL ACCESSORY SETTING ........................................................................................................ 6 3.5. G ENERAL DESCRIPTION ................................................................................................................... 6 4. REFERENCE DOCUMENTS ............................................................................................................. 7 4.1. D OCUMENTS SUPPLIED BY APPLICANT ............................................................................................ 7 4.2. R EFERENCE DOCUMENTS FOR TESTING ........................................................................................... 7 5. LABORATORY ENVIRONMENT ..................................................................................................... 8 6. SUMMARY OF TEST RESULTS ....................................................................................................... 9 6.1. S UMMARY OF TEST RESULTS ........................................................................................................... 9 6.2. S TATE MEN TS .................................................................................................................................... 9 7. TEST EQUIPMENTS UTILIZED .................................................................................................... 10 ANNEX A: MEASUREMENT RESULTS ................................................................................................. 11 A.1. MEASUREMENT METHOD ................................................................................................................... 11 A.2. PEAK OUTPUT POWER - CONDUCTED ................................................................................................ 13 A.3. FREQUENCY BAND EDGES - CONDUCTED .......................................................................................... 14 A.4. CONDUCTED EMISSION ...................................................................................................................... 21 A.5. RADIATED EMISSION .......................................................................................................................... 45 A.6. TIME OF OCCUPANCY (DWELL TIME) ................................................................................................ 67 A.7. 20DB BANDWIDTH ............................................................................................................................. 77 A.8. CARRIER FREQUENCY SEPARATION ................................................................................................... 82 A.9. NUMBER OF HOPPING CHANNELS ...................................................................................................... 84 A.10. AC POWERLINE CONDUCTED EMISSION .......................................................................................... 88 No. 2013TAR773 Page3 of 90 ©Copyright. All rights reserved by TMC Beijing. 1. Test Laboratory 1.1. Testing Location Company Name: TMC Beijing, Telecommunication Metrology Center of MIIT Address: Shouxiang Science Building, No 51, Xueyuan Road, Haidian District, Beijing, P.R.China Postal Code: 100191 Telephone: 00861062304633 Fax: 00861062304633 1.2. Testing Environment Normal Temperature: 15-35°C Extreme Temperature: -20/+55°C Relative Humidity: 20-75% 1.3. Project data Project Lea…
