RAFXWL-11GUZX802.11 b/g Wireless USB Dongle

User’s guide WLAN 11g USB Dongle Model: XWL-11GUZX Important : Please do not connect your Company USB Wireless LAN Dongle to the USB port of your computer before installing the Company WLAN Utility and Driver. System Requirements – Notebook PC or desktop PC with one free USB port – 32MB memory or greater – 300MHz processor or higher – Microsoft Windows XP / Windows 2000 / Windows Millennium Edition / Windows 98 Second Edition Driver Installation Important: Please do not connect your Company USB Wireless LAN Dongle to the USB port of your computer before installing the Company WLAN Utility and Driver. 1. Insert the Company WLAN Utility and Driver CD in the CD-ROM drive and wait until the following welcome screen appears on your screen. Click [Next]. Note: In case this screen does not appear, in Windows Explorer browse to your CD-ROM and double-click the Setup.exe file. 2. Click [Next] to accept, or [Browse] to change the default destination folder. Note: In some setups of Windows 2000 and Windows XP a Microsoft Digital Signature warning may appear on your screen. Click [Yes] or [Continue anyway] to continue the installation. 3. Now connect your Company USB Wireless LAN Dongle to a USB port of your computer. In the Find New Hardware Wizard that appears on your screen select [No, not this time], and click [Next]. 5. Select [Install the software automatically (Recommended)], and click [Next]. Note: In some setups of Windows 2000 and Windows XP a Microsoft Digital Signature warning may appear on your screen. Click [Yes] or [Continue anyway] to continue the installation. 6. Click [Finish] to finalize the installation. Your Company USB Wireless LAN Dongle is now ready for use. Please refer to the electronic user’s guide on the Company WLAN Utility and Driver CD-ROM for further directions as to the configuration of your dongle. Using the Company WLAN utility Open the Company WLAN utility by double-clicking the Company icon in the system tray, or by clicking [Start] > [Programs] > [Company WLAN Utility]. Note: In Windows XP, please disable the Zero Configuration feature when prompted to do so. A . Click on the Refresh button to see all available SSID networks. B . You can select an SSID network by clicking ot its name in the Available Network field. Details will then be shown in the Current Network Information field. C . The Network Adapter field shows the name of the wireless network adapter. D . The Signal Strength and Link Quality values are shown in block diagrams as well as in percentages. E . At the lower end of this screen you can see the number of transmitted and received frames. F. Click on the More Settings button to bring op the following screen: A . Click on the Change/Apply button to modify the settings in the General Connection Setting field. B . Select the channel in ad-hoc mode from the Channel drop-down menu. C . Select the transmission speed from the Tx Rate drop-down menu. D . Untick the Any box to select another SSID network. E . Select Infrastructure or Ad-hoc mode from the Network Type drop-down menu. F . Select Enable WEP or Disable WEP from the Encryption drop-down menu. G . Select Open System, Shared Key, or Auto from the Authenticication Mode drop-down menu. H . Click on the WEP Encryption Key Setting button to modify the WEP key settings. A new screen will appear (see hereafter). I . Select a previously saved profile from the Profile Name drop-down menu, and click on the Load button to load the profile into memory. Alternatively, key in the profile name and click on the Save Current or Delete button to respectively save or remove the profile. J. For advanced settings or information about the software, click on the Advanced Settings or the Information button. A . Click on the Change/Apply button to modify the WEP key settings. B . Select an encryption key lenght of 64-bit, 128-bit, or 256-bit. C . Select the default key ID. D . Select Hexadecimal or ASCII in the Key Format field. E. Key in the values of the WEP keys in the Key Value field. A . Select English from the Language drop-down menu. B . Select the power saving mode. Power consumption is related to the data throughput. CAM mode (default) gives the highest power consumtion/data throughput ratio, whereas Fast and Maximum offer resp. better and best power savings (but less performance). C . Select World Mode or your region from the User Select drop-down menu in the Country Roaming field, and experiment to get the best results. D . Move the slider in the Fragmentation Threshold bar to adjust the threshold between 256-bytes and 2346-bytes. E. Move the slider in the RTS / CTS Threshold bar to adjust the RTS threshold between 0 and 2347-bytes. Click on the Information button in the More Settings screen to check the driver and utility version, and the MAC address in this screen: Federal Communication Commission Interference Statement Federal Communications Commission (FCC) Requirements, Part 15 This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1. Reorient or relocate the receiving antenna. 2. Increase the separation between the equipment and receiver. 3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 4. Consult the dealer or an experienced …

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No: 40601006 Date of Issue: June 2, 2004 Page 1 EXTERNAL PHOTOGRPHS OF EUT

Compliance Certification Services Inc. Report No: 40601006 Date of Issue: June 2, 2004 Page 2 INTERNAL PHOTOGRPHS OF EUT Compliance Certification Services Inc. Report No: 40601006 Date of Issue: June 2, 2004 Page 3

Walsin Technology Corporation Introduction of RFANT5220110A0T Series Page 1 of 1 Sep.- 2002 B B r r o o a a d d B B a a n n d d L L T T C C C C M M u u l l t t i i L L a a y y e e r r C C e e r r a a m m i i c c C C h h i i p p A A n n t t e e n n n n a a F F o o r r I I S S M M B B a a n n d d 2 2 . . 4 4 G G H H z z A A p p p p l l i i c c a a t t i i o o n n s s - - R R F F A A N N T T 5 5 2 2 2 2 0 0 1 1 1 1 0 0 A A 0 0 T T S S e e r r i i e e s s FEATURES y Surface Mounted Devices with a small dimension of 5.2 x 2.0 x 1.1 mm 3 meet future miniaturization trend. y Embedded and LTCC (Low Temperature Co-fired Ceramic) technology is able to future integrate with system design as well as beautifying the housing of final product. y High Stability in Temperature / Humidity Change ELECTRICAL CHARACTERISTICS Item Specification Central frequency 2.450 GHz (Note-1) Bandwidth 150MHz (typical) Gain 0 ~ 2 dBi VSWR 2 max. Polarization Linear Azimuth Beamwidth Omni-directional Impedance 50Ω „ Note 1. Central Frequency should be defined after customers’ application approval. APPLICATIONS ƒ Bluetooth/ Wireless LAN/ HormRF ƒ ISM band 2.4GHz applications. DIMENSION 2.0 ±0.2 mm 1.15 ±0.10 mm 5.2 ± 0.2 mm 0.30 ± 0.15 mm 0.30 ± 0.15 mm WTC 2.0 ±0.2 mm 1.15 ±0.10 mm 5.2 ± 0.2 mm 0.30 ± 0.15 mm 0.30 ± 0.15 mm WTC CONSTRUCTION Test Board Test Board Em pty Area Em pty Area 18x9 m m 50ΩF e e d lin e GROUND 30x18 m m 1mm 3.3mm 1.5mm WTC 2.5mm 18mm Em pty Area Em pty Area 18x9 m m 50ΩF e e d lin e GROUND 30x18 m m 1mm 3.3mm 1.5mm WTCWTC 2.5mm 18mm Insertion Loss (S11) Bandwidth >150MHzBandwidth >150MHz CONTACT INFORMATION For more information, please contact with HF Division, Walsin Technology Corporation Tel : 886-3-475-8711 Fax No. : 886-3-475-5197 E mail : [email protected] Patent Pending

Compliance Certification Services Inc. Report No: 40601006-SF FCC ID: RAFXWL-11GUZX Date of Issue: June 2, 2004 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page1 of 22 ANSI/IEEE Std. C95.1-1992 in accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C FCC TEST REPORT For X-Micro Technology Corp. X-Micro WLAN 11g USB Dongle Model: XWL-11GUZX Trade Name: X-Micro Prepared for X-Micro Technology Corp. 12F-3, No. 186, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan 235, R.O.C. Prepared by Compliance Certification Services Inc. No. 81-1, Lane 210, Bade Rd. 2, Luchu Hsiang, Taoyuan Hsien, (338) Taiwan, R.O.C. TEL: 886-3-324-0332 FAX: 886-3-324-5235 Compliance Certification Services Inc. Report No: 40601006-SF Date of Issue: June 2, 2004 Page 3 TABLE OF CONTENTS 1. EUT DESCRIPTION ..................................................................................................... 4 2. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC .... 5 3. DOSIMETRIC ASSESSMENT SYSTEM ................................................................... 5 3.1 MEASUREMENT SYSTEM DIAGRAM .........................................................................6 3.2 SYSTEM COMPONENTS.................................................................................................7 4. EVALUATION PROCEDURES................................................................................... 9 5. MEASUREMENT UNCERTAINTY ......................................................................... 12 6. EXPOSURE LIMIT ..................................................................................................... 13 7. MEASUREMENT RESULTS ..................................................................................... 14 7.1 SYSTEM PERFORMANCE CHECK..............................................................................14 7.2 TEST LIQUID CONFIRMATION ..................................................................................15 7.3 EUT TUNE-UP PROCEDURES......................................................................................16 7.4 SAR MEASUREMENTS RESULTS...............................................................................17 8. EUT PHOTOS .............................................................................................................. 19 9. EQUIPMENT LIST & CALIBRATION STATUS ................................................... 20 10. FACILITIES ................................................................................................................. 21 11. REFERENCES ............................................................................................................. 21 12. ATTACHMENTS ......................................................................................................... 22 Compliance Certification Services Inc. Report No: 40601006-SF Date of Issue: June 2, 2004 Page 4 1. EUT DESCRIPTION Applicant: X-Micro Technology Corp. 12F-3, No. 186, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan 235, R.O.C. Model Number / Trade Name: XWL-11GUZX / X-Micro Device Category: PORTABLE DEVICES Exposure Category: GENERAL POPULATION/UNCONTROLLED EXPOSURE Test Sample is a: Production unit Modulation type: 802.11b Direct Sequence Spread Spectrum 802.11g Orthogonal Frequency Division Multiplexing (OFDM) Tx Frequency: 2412 ~ 2462 MHz Max. O/P Power: (Conducted/Peak) 18.93dBm Max. SAR (1g): 0.099W/kg Application Type: Certification FCC Rule Part(s): 15C Antennas: Chip Ant. Test Host: IBM P/N: 2659-HT2 S/N: AK-VNCW6 Compliance Certification Services Inc. Report No: 40601006-SF Date of Issue: June 2, 2004 Page 5 2. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC The US Federal Communications Commission has released the report and order “Guidelines for Evaluating the Environmental Effects of RF Radiation", ET Docket No. 93-62 in August 1996 [1]. The order requires routine SAR evaluation prior to equipment authorization of portable transmitter devices, including portable telephones. For consumer products, the applicable limit is 1.6 mW/g for an uncontrolled environment and 8.0 mW/g for an occupational/controlled environment as recommended by the ANSI/IEEE standard C95.1-1992 [6]. According to the Supplement C of OET Bulletin 65 “Evaluating Compliance with FCC Guide-lines for Human Exposure to Radio frequency Electromagnetic Fields", released on Jun 29, 2001 by the FCC, the device should be evaluated at maximum output power (radiated from the antenna) under “worst-case” conditions for normal or intended use, incorporating normal antenna operating positions, device peak performance frequencies and positions for maximum RF energy coupling. 3. DOSIMETRIC ASSESSMENT SYSTEM These measurements were performed with the automated near-field scanning system DASY4 from Schmid & Partner Engineering AG (SPEAG). The system is based on a high precision robot (working range greater than 0.9 m) which positions the probes with a positional repeatability of better than ± 0.02 mm. Special E- and H-field probes have been developed for measurements close to material discontinuity, the sensors of which are directly loaded with a Schottky diode and connected via highly resistive lines to the data acquisition unit. The SAR measurements were conducted with the dosimetric probe ES3DV2-SN: 3023 (manufactured by SPEAG), designed in the classical triangular configuration and optimized for dosimetric evaluation. The probe has been calibrated according to the procedure with accuracy of better than ±10%. The spherical isotropy was evaluated with the procedure and found to be better than ±0.25 dB. The phantom used was the SAM Twin Phantom as described in FCC supplement C, IEEE P1528 and…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No: 40601006-RP FCC ID: RAFXWL-11GUZX Date of Issue: June 2, 2004 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 of 62 FCC 47 CFR PART 15 SUBPART C TEST REPORT For X-Micro Technology Corp. X-Micro WLAN 11g USB Dongle Model: XWL-11GUZX Trade Name: X-Micro Prepared for X-Micro Technology Corp. 12F-3, No. 186, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan 235, R.O.C. Prepared by Compliance Certification Services Inc. No. 81-1, Lane 210, Bade Rd. 2, Luchu Hsiang, Taoyuan Hsien, (338) Taiwan, R.O.C. TEL: 886-3-324-0332 FAX: 886-3-324-5235 Compliance Certification Services Inc. Report No: 40601006-RP FCC ID: RAFXWL-11GUZX Date of Issue: June 2, 2004 Page 2 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION........................................................................................................3 2. EUT DESCRIPTION..............................................................................................................................4 3. TEST METHODOLOGY.......................................................................................................................5 3.1 EUT CONFIGURATION........................................................................................................................5 3.2 EUT EXERCISE....................................................................................................................................5 3.3 GENERAL TEST PROCEDURES.............................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS........................................................6 3.5 DESCRIPTION OF TEST MODES...........................................................................................................6 4. INSTRUMENT CALIBRATION...........................................................................................................7 5. FACILITIES AND ACCREDITATIONS ..............................................................................................8 5.1 FACILITIES....................................................................................................................................... 8 5.2 EQUIPMENT........................................................................................................................................8 5.3 LABORATORY ACCREDITATIONS AND LISTING..................................................................................8 5.4 TABLE OF ACCREDITATIONS AND LISTINGS.......................................................................................9 6. SETUP OF EQUIPMENT UNDER TEST...........................................................................................10 6.1 SETUP CONFIGURATION OF EUT.......................................................................................................10 6.2 SUPPORT EQUIPMENT ...............................................................................................................10 7. FCC PART 15.247 REQUIREMENTS ................................................................................................11 7.1 6DB BANDWIDTH.............................................................................................................................11 7.2 PEAK POWER....................................................................................................................................16 7.3 BAND EDGES MEASUREMENT ................................................................................................21 7.4 PEAK POWER SPECTRAL DENSITY....................................................................................................22 7.5 RADIO FREQUENCY EXPOSURE........................................................................................................32 7.6 SPURIOUS EMISSIONS ................................................................................................................36 7.7 POWERLINE CONDUCTED EMISSIONS...............................................................................................58 APPENDIX 1 PHOTOGRPHS OF TEST SETUP......................................................................................61 Compliance Certification Services Inc. Report No: 40601006-RP FCC ID: RAFXWL-11GUZX Date of Issue: June 2, 2004 Page 4 2. EUT DESCRIPTION Product X-Micro WLAN 11g USB Dongle Trade Name X-Micro Model Number XWL-11GUZX Model Discrepancy N/A Power Supply Powered from host device Frequency Range 2412 ~ 2462 MHz Transmit Power 802.11b mode: 18.83 dBm 802.11g mode: 17.22 dBm Modulation Technique 802.11b: DSSS (CCK; DQPSK; DBPSK) 802.11g: OFDM Transmit Data Rate 802.11b: 11Mbps(CCK) with fall back rates of 5.5, 2, and 1Mbps 802.11g: 54Mbps with fall back rates of 48/36/24/18/12/9/6 Mbps (OFDM) Number of Channels 11 Channels Antenna Specification Chip Antenna Gain: 2 dBi (Max) Note: This submittal(s) (test report) is intended for FCC ID: RAFXWL-11GUZX filing to comply with Section 15.207, 15.209 and 15.247 of the FCC Part 15, Subpart C Rules. Compliance Certification Services Inc. Report No: 40601006-RP FCC ID: RAFXWL-11GUZX Date of Issue: June 2, 2004 Page 5 3. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4 and FCC CFR 47 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057, 15.207, 15.209 and 15.247. 3.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner that intends to maximize its emission characteristics in a continuous normal application. 3.2 EUT EXERCISE The EUT was operated in the engineering mode to fix the TX fre…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No: 40601006-RP FCC ID: RAFXWL-11GUZX Date of Issue: June 2, 2004 Page 61 APPENDIX 1 PHOTOGRPHS OF TEST SETUP Radiated Emission Set up Photos Compliance Certification Services Inc. Report No: 40601006-RP FCC ID: RAFXWL-11GUZX Date of Issue: June 2, 2004 Page 62 Conducted Emission Set Up Photos
