RAR30005002DRU 5GHz radio

Page 1 of 13 B5CH114AA B5CH114AA Product Manual DRU 5 GHz WLAN Radio Module Document Date: Nov 10, 2010 Document Number: B5CH114AA Document Version Number: 1 Document Status: Release © Copyright 2010 by BelAir Networks. All rights reserved. B5CH114AA Product Manual DRU 5 GHz WLAN Radio Module Page 2 of 13 Contents About this Document ................................................................... 2 Introduction .................................................................................. 3 Conditions of Use ......................................................................... 4 Module Installation and Service ................................................. 5 Final Product Requirements ........................................................ 6 Regulatory Statements .............................................................. 11 About this Document This document is a product manual for the DRU 5 GHz WLAN Radio Module, including its limitations on use in any product marketed or offered for sale. It is intended as a supplement to training and documentation by BelAir Networks Inc. or its authorized agents. B5CH114AA Product Manual DRU 5 GHz WLAN Radio Module Page 3 of 13 Introduction The B5CH114AA (hereafter referred to as “the module”) is a 5 GHz radio module compatible with the IEEE 802.11 standard for Wireless LAN operation. It is designed to be interoperable with WLAN products which are based on Orthogonal Frequency Division Multiplexing (OFDM) radio technology. The module contains a complete IEEE 802.11a/n radio and Medium Access Control (MAC) protocol engine which allows implementation of an IEEE 802.11a/n access point (AP). The module is not intended for stand-alone operation. It will only be marketed as a complete product, in conjunction with a package, DC power supply and antennas (hereafter referred to as “the product” or the “final product”). The module can be used in the 5 GHz ISM unlicensed bands. Since the module has a BelAir networks proprietary digital interface, it cannot be directly connected to any standard telecommunications or computer devices. It can only be used with final products designed and authorized specifically for that purpose. B5CH114AA Product Manual DRU 5 GHz WLAN Radio Module Page 4 of 13 Conditions of Use General Conditions of Use This manual is intended to supplement training provided by BelAir Networks or authorized parties. The module B5CH114AA is only intended for use in BelAir Networks products and is not for sale to the general public as a stand-alone module. Please read this entire document, including the Regulatory Statements section before attempting to install or operate the module. Warning: Any use of B5CH114AA in any manner which is not expressly specified within this manual or specifically approved by BelAir Networks or its authorized agents will void the user’s right to operate this module, and is expressly forbidden by BelAir Networks. This includes any modification of the module, installation of the module in a configuration or used with antennas which are not expressly listed in this document or approved by BelAir Networks. B5CH114AA Product Manual DRU 5 GHz WLAN Radio Module Page 5 of 13 Country of Use B5CH114AA is certified with limited modular approval for use as an Intentional Radiator in the United States as device: FCC ID: RAR30005002 and in Canada as IC: 4674A-30005002. Please read all regulatory statements at the end of this document before any attempt to install or operate this module. The module is only certified for operation in the United States and Canada. Before attempting to install and operate this module in any other country, contact BelAir Networks for approval. Module Labeling One or more labels are applied to the module during manufacture, including a label which identifies the FCC and Industry Canada identification numbers. Do not attempt to remove any labels from the module. Module Installation and Service Installation into a Product The module shall only be installed by a technician trained by BelAir Networks or its authorized agents. It should only be installed into an approved product (see above) following all manufacturing and service procedures for that product. The module should only be installed into a final product in a manufacturing or service depot site. Caution: B5CH114AA is an electro-static discharge (ESD) sensitive device. All appropriate ESD measures must be taken when handling the module. Failure to employ appropriate ESD protection may damage the module. Module Service The module is not intended as a field-serviceable unit. It contains no field- replaceable or field-serviceable parts, or any external adjustable mechanisms. The module should only be serviced in a manufacturing or service depot site approved by BelAir Networks or its authorized agents. B5CH114AA Product Manual DRU 5 GHz WLAN Radio Module Page 6 of 13 Final Product Requirements The requirements below apply to any final product in which the B5CH114AA module is installed. Antenna Usage and Module Transmit Power The DRU 5GHz radio module supports MIMO 2x2 configuration with two transmit chains and two receive chains. The B5CH114AA module shall only be used at the following output power levels in conjunction with the following antenna types as outlined in the tables that follow. 5725-5850 MHz – Part 15.247 Subpart E For operation in the 5725-5825 MHz UNII band, the B5CH114AA may be set to operate on 20 MHz channel bandwidths. 5725-5850 MHz – Part 15.247 Subpart C For operation in the 5725-5850 MHz ISM band, the B5CH114AA may be set to operate on 20 MHz or 40 MHz channel bandwidths. B5CH114AA Product Manual DRU 5 GHz WLAN Radio Module Page 7 of 13 B5CH114AA Product Manual DRU 5 GHz WLAN Radio Module Page 8 of 13 B5CH114AA Product Manual DRU 5 GHz WLAN Radio Module Page 9 of 13 Certified Antennas: The following antennas are certified for use: In order to comply with the FCC and Industry Canada rules in the USA and Canada, respe…

Text truncated - open the document above for the full version.

1 November 10, 2010 Attn: Reviewing Engineer Equipment Authorization Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: RAR30005002 Product Name: DRU 5GHz Radio To Whom It May Concern: This letter is an official request for confidentiality under FCC rule 47 CFR §0.457(d) and §0.459. We requests that the following items with this applications be withheld from public review:  Schematics  Product Block Diagram and Theory of Operation The above materials contain trade secrets and are proprietary to BelAir Networks Inc. Public disclosure of information in these materials may be used in the market place to the disadvantage of BelAir Networks. Dated this 10th of Novemeber 2010 Marcel Chenier Senior Vice President of Engineering BelAir Networks Inc. Telephone (613)‐254 7070 ext.139

1 November 10, 2010 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification FCC: ID RAR30005002 BelAir 5 GHz DRU Radio Module Authority to Act as Agent On our behalf, I appoint Nemko Canada Inc, 303 River Road, Ottawa, Canada, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc., still resides with BelAir Networks, 603 March Road, Kanata, Ontario, Canada, K2K 2M5. Dated this 10th of November 2010 Marcel Chenier Senior Vice President of Engineering BelAir Networks Inc. Telephone (613)‐254 7070 ext.139

1 November 10, 2010 Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 DRU 5GHz radio, tested under part 15. To Whom It May Concern, The module FCC ID: RAR30005002 is submitted for Limited Modular Approval (LMA) by BelAir Networks Inc. In keeping with FCC Public Notice DA 00‐1407, Part 15 Unlicensed Modular Transmitter Approval, this letter affirms that BelAir Networks shall retain complete control over the final installation of the device and ensure compliance of the end‐product to FCC regulations. The module shall only be installed into a final product by technicians trained by BelAir Networks Inc. The module shall not be distributed, marketed or sold to the general public. It will only be available installed in a complete BelAir Networks product. The complete BelAir product shall only be sold by BelAir Networks directly or through a BelAir Networks‐specified sales channel to authorized resellers, and will be installed by professional installers with training by BelAir Networks or authorized representatives. As illustrated by the accompanying documentation, the module FCC ID: RAR30005002 is a module with its own RF shielding, contains the complete radio within the module, provides its own power supply regulation, was tested in a stand‐alone configuration, will be labeled with FCC ID and meets RF exposure regulations. 2 The following is a point‐by‐point response to the items listed in DA 00‐1407: 1. The module has its own RF shielding. It has been tested for radiated emissions with the module on its own, with no external shielding beyond that incorporated into the module to ensure compliance to all radiated emissions requirements at the module level. 2. The input to the module is an Ethernet interface. All modulation and IEEE 802.11a protocol elements reside within the module. There are no modulation or data inputs to the module which could alter the performance or behavior of the modulator or radio which could cause it to exceed FCC limits. 3. The module has its own power supply filtering and regulation for all modulation and radio circuitry in order to avoid any issues with varying power supply inputs. The module is powered by several DC voltage rails. In order to test power line conducted requirements for the module, it was tested with the power supply and package as intended for the complete product which will be manufactured by BelAir Networks. BelAir Networks maintains complete control of the AC‐to‐DC power supply and packaging of the complete product and therefore ensures that compliance will be maintained. 4. The module incorporates MCX RF connectors and does not have an integral antenna on the module. The module was tested in conjunction with the intended antennas (see accompanying documentation). Considering our submission is seeking Limited Modular Approval, BelAir Networks will ensure professional installation of the complete product. In this manner we will ensure that only the approved antenna type is used in conjunction with this module. 5. The module was tested in a stand‐alone configuration for all conducted and radiated emissions, except for conducted power line emissions. Since the module is not AC powered, it was tested with the power supply and package in the configuration with which it will be installed in the product. This configuration is also tested to ensure the complete product will meet all Class B radiated and conducted emissions requirements. 6. The module will be labeled with its own FCC ID number. Since this label will not be visible when the module is installed in the complete product, the manual indicates that the final product shall include a permanent label which uses the 3 wording “Contains FCC ID: RAR30005002”. See the labeling information provided with this submission. 7. The module operates under Part 15.247(b)(3). Since all modulation and IEEE 802.11 protocol elements reside within the module, users will not have access to controls which may cause the module to operate outside its normal mode of operation. All timing and control for RF and modulator sections are inaccessible from outside the module. 8. The module has been evaluated with the intended antenna and complies with RF exposure requirements. The manual states that a distance as per the Table 1 below shall be maintained between any person and the antenna. As BelAir Networks or its authorized agents will retain control of the final installation through the requirement for professional installation, BelAir Networks shall ensure that this distance is maintained in all installations. RF Exposure Table 1: DRU 2.4GHz radioDRU 5GHz radioDRU 2.4GHz radioDRU 5GHz radioDRU 2.4GHz radioDRU 5GHz radio 5 dBi7 dBi≤ 8dBi≤ 15dBi> 8dBi> 15dBi Standard Antennas Minimum Distance 8.1 inches Meduim Gain Antennas Minimum Distance 19.3 inches Minimum Safety Distances High Gain Antennas (up to 22 dBi) Minimum Distance 42.9 inches Sincerely, Marcel Chenier SVP Engineering BelAir Networks Inc.

November 16, 2010 Re: FCC IDs for 2.4 GHz and 5 GHz Radios To whom it may concern: BelAir Networks DRU (double radio unit) contains two radios – a 2.4 GHz radio and a 5 GHz radio. BelAir will use FCC ID RAR30002002 for the DRU 2.4 GHz radio and RAR30005002 for the DRU 5 GHz Radio. This is a device consisting of two radio sections assembled in a common enclosure. The radios are constructed on separate shielded areas of a circuit board and have independent frequency controlling circuits for each radio. BelAir often updates the FCC filings of our radios as new market requirements emerge. Separate FCC IDs allow BelAir to independently update the 2.4 GHz and 5 GHz filings. For example, BelAir may update the 2.4 GHz filing if a new antenna is required; and the 5 GHz radio FCC filing may be updated to include additional UNI bands. Sincerely, Roland A. Smith Director Systems Design BelAir Networks Inc. 613‐254‐7070 x 120 [email protected] BelAir Networks Inc. 603 March Road Kanata, Ontario Canada K2K 2M5 613-254-7070 [email protected] www.belairnetworks.com

B5CH114AA Primary Side with Shields B5CH114AA Primary Side no Shields B5CH114AA Secondary Side

BelAir Networks DRU 5 GHz Radio November 10, 2010 1 Module Labeling: DRU 5 GHz Radio The following label shall be permanently affixed to the radio module as follows: Raw Label Detail: Size: 1 inches x ¼ inch Material: Polyimide, White Finish: Gloss Backing: High Temperature Permanent Acrylic Adhesive Approvals: CSA and UL. Printing Detail: FCC, IC label: Text to be Arial Bold 6 point and is to be centrally located. All printed data is to have excellent solvent and smudge resistance. BelAir Networks model number label on radio module FCC ID: RAR30005002 B5CH114AA FCC ID: RAR30005002 IC: 4674A‐30005002 BelAir Networks DRU 5 GHz Radio November 10, 2010 2 Label Location: BelAir Networks DRU 5 GHz Radio November 10, 2010 3 Product Labeling The following permanent label, or one containing equivalent information, must be affixed in a conspicuous location on the exterior of any product containing this module. In addition the label contents shall appear prominently in the final product user manual. This device contains the following: FCC ID: RAR30005002 IC : 4674A‐30005002

B5CH114AA Primary Side with Shields B5CH114AA Primary Side no Shields B5CH114AA Secondary Side

November 10, 2010 RAR30005002 MPE Engineering Analysis 1 Engineering Analysis MPE for 5GHz DRU Transceiver FCC ID: RAR30005002 BelAir Networks This analysis was performed as part of the FCC certification requirements for spread spectrum devices, according to the requirements of: FCC part 15, and FCC OET Bulletin 65 “Evaluating Compliance with FCC Guidelines for Human Exposure to Radio frequency Electromagnetic Fields”.  Module RAR30005002 will be mounted in BelAir Networks host units and will be professionally installed (Fixed) to provide a minimum separation distance from all persons as detailed in co‐location compliance tables below.  This device will only be operated according to the exposure conditions described in this application.  End users and installers will be provided with antenna installation and transmitter operating conditions for satisfying RF exposure compliance. The measured worst‐case transmit power yielding the worst‐case EIRP were used for the MPE calculations. Calculations were performed based on FCC OET Bulletin 65. The calculations are performed based on the following formula provided in OET 65: S = EIRP / (4R 2 ). Co‐location compliance for multiple frequency exposure criteria to the power density exposure limit is detailed in the table below. This calculation is a worst‐case analysis since it assumes all devices are continuously transmitting. The device utilizes the IEEE 802.11 WLAN protocol which operates in time‐division duplex (TDD) mode, so the transmit duty cycle can never be 100% in normal operation. It is also assumed that all directional antennas are aligned to point in the same direction so that power from all radios adds together. November 10, 2010 RAR30005002 MPE Engineering Analysis 2 The following tables outlines the MPE analysis for various combinations of radios and antennas the RAR30005001 can be used with: Case 1: 1 X RAR30002002 (DRU 2.4GHz radio) with 16dBi Antennas and 1 X RAR30005002 (DRU 5GHz radio) wtih 22dBi Antennas Co‐location Compliance for Integrated DRU 2.4GHz IEEE 802.11b/g/n & DRU 5GHz IEEE 802.11a/n Radios Safety Distance:109 cm( 42.9 inches ) Worst‐case Total EIRP Max Power Density Maximum Number of Radios Worst‐case Total EIRP Max Power Density Maximum Number of Radios Total Density for co ‐ located radios Limit: General Population / Uncontrolled ExposureResult [dBm][mW/cm^2][dBm][mW/cm^2][mW/cm^2][mW/cm^2] 42.280.113151.140.87110.9841Complies Case 2: 1 X RAR30002002 (DRU 2.4GHz radio) with 5dBi Antennas and 1 X RAR30005002 (DRU 5GHz radio) wtih 7 dBi Antennas Co‐location Compliance for Integrated DRU 2.4GHz IEEE 802.11b/g/n & DRU 5GHz IEEE 802.11a/n Radios Safety Distance:20.5 cm( 8.1 inches ) Worst‐case Total EIRP Max Power Density Maximum Number of Radios Worst‐case Total EIRP Max Power Density Maximum Number of Radios Total Density for co ‐ located radios Limit: General Population / Uncontrolled ExposureResult [dBm][mW/cm^2][dBm][mW/cm^2][mW/cm^2][mW/cm^2] 33.270.402133.430.41710.8191Complies Case 3: 1 X RAR30002002 (DRU 2.4GHz radio) with 8dBi Antennas and 1 X RAR30005002 (DRU 5GHz radio) wtih 15 dBi Antennas Co‐location Compliance for Integrated DRU 2.4GHz IEEE 802.11b/g/n & DRU 5GHz IEEE 802.11a/n Radios Safety Distance:49 cm( 19.3 inches ) Worst‐case Total EIRP Max Power Density Maximum Number of Radios Worst‐case Total EIRP Max Power Density Maximum Number of Radios Total Density for co ‐ located radios Limit: General Population / Uncontrolled ExposureResult [dBm][mW/cm^2][dBm][mW/cm^2][mW/cm^2][mW/cm^2] 35.610.121144.140.86010.9801Complies Case 4: 1 X RAR30002002 (DRU 2.4GHz radio) with 5dBi Antennas and 1 X RAR30005002 (DRU 5GHz radio) wtih 15 dBi Antennas Co‐location Compliance for Integrated DRU 2.4GHz IEEE 802.11b/g/n & DRU 5GHz IEEE 802.11a/n Radios Safety Distance:48 cm( 18.9 inches ) Worst‐case Total EIRP Max Power Density Maximum Number of Radios Worst‐case Total EIRP Max Power Density Maximum Number of Radios Total Density for co ‐ located radios Limit: General Population / Uncontrolled ExposureResult [dBm][mW/cm^2][dBm][mW/cm^2][mW/cm^2][mW/cm^2] 33.270.073144.140.89610.9691Complies RAR30002002 (DRU 2.4GHz radio)RAR30005002 (DRU 5GHz radio) RAR30002002 (DRU 2.4GHz radio)RAR30005002 (DRU 5GHz radio) RAR30002002 (DRU 2.4GHz radio)RAR30005002 (DRU 5GHz radio) RAR30002002 (DRU 2.4GHz radio)RAR30005002 (DRU 5GHz radio) The equipment therefore fulfills the requirements on power density for general population/uncontrolled exposure and therefore complies with the requirements of FCC Bulletin 65. November 10, 2010 RAR30005002 MPE Engineering Analysis 3 The following worst case summary table will be incorporated in BelAir Networks installation procedures. DRU 2.4GHz radio DRU 5GHz radio DRU 2.4GHz radio DRU 5GHz radio DRU 2.4GHz radio DRU 5GHz radio 5 dBi7 dBi≤ 8dBi≤ 15dBi> 8dBi> 15dBi Standard Antennas Minimum Distance 8.1 inches Meduim Gain Antennas Minimum Distance 19.3 inches Minimum Safety Distances High Gain Antennas (up to 22 dBi) Minimum Distance 42.9 inches

www.nemko.com Report Reference ID: 155793-5TRFWL Test specification: Title 47 - Telecommunication Chapter I - Federal Communications Commission Subchapter A - General Part 15 - Radio Frequency Devices Subpart E – Unlicensed National Information Infrastructure Devised Applicant: BelAir Networks Inc. 603 March Road, Ottawa, ON, Canada K2K 2M5 Apparatus: DRU 5 GHz radio Model number: B5CH114AAA FCC ID: RAR30005002 Testing laboratory: Nemko Canada Inc. 303 River Road Ottawa, ON, Canada K1V 1H2 Telephone: (613) 737-9680 Facsimile: (613) 737-9691 Name and title Date Tested by: David Duchesne, Wireless/EMC Specialist Reviewed by: Richard Brazeau, Laboratory Manager December 13, 2010 Nemko Canada Inc., a testing laboratory, is accredited by the Standards Council of Canada. The tests included in this report are within the scope of this accreditation. 15.407.doc - Date: August 18, 2010 Product: DRU 5 GHz radio Nemko Canada Inc., 303 River Rd, Ottawa, ON, Canada, K1V 1H2 Report reference ID: 155793-5TRFWL Page 2 of 28 Table of contents Section 1: Report summary.........................................................................................................................................................3 1.1 Test specification.........................................................................................................................................................3 1.2 Statement of compliance.............................................................................................................................................3 1.3 Exclusions....................................................................................................................................................................3 1.4 Registration number....................................................................................................................................................3 1.5 Test report revision history...........................................................................................................................................3 1.6 Limits of responsibility..................................................................................................................................................3 Section 2: Summary of test results.............................................................................................................................................4 2.1 FCC Part 15 Subpart E – Intentional Radiators, test results........................................................................................4 Section 3: Equipment under test (EUT) and application details...............................................................................................5 3.1 Product details.............................................................................................................................................................5 3.2 Sample information......................................................................................................................................................5 3.3 EUT technical specifications........................................................................................................................................5 3.4 EUT description...........................................................................................................................................................5 3.5 Operation of the EUT during testing............................................................................................................................5 3.6 EUT setup diagram......................................................................................................................................................5 Section 4: Engineering considerations.......................................................................................................................................6 4.1 Modifications incorporated in the EUT.........................................................................................................................6 4.2 Technical judgment......................................................................................................................................................6 4.3 Deviations from laboratory tests procedures................................................................................................................6 Section 5: Test conditions...........................................................................................................................................................7 5.1 Power source and ambient temperatures....................................................................................................................7 Section 6: Measurement uncertainty..........................................................................................................................................8 Section 7: Test equipment...........................................................................................................................................................9 7.1 Test equipment list.......................................................................................................................................................9 Section 8: Testing data...............................................................................................................................................................10 8.1 Clause 15.403(i) Emission bandwidth........................................................................................................................10 8.2 Clause 15.407(a)(3) 5.725–5.825 GHz band output power and spectral density limits..............................................11 8.3 Clause 15.407(a)(6) Peak excursion..........................................................................................................................14 8.4 Clause 15.4…

Text truncated - open the document above for the full version.

AC Power Line Conducted Emissions Radiated Emissions
