Meru AP832 Installation Guide Copyright © Meru Networks, Inc., 2003–2013. All rights reserved. Other names and brands may be claimed as the property of others. April 2013 Document Number: 882-70013 Rev A Ver 2 AP832 Installation Guide Safety Precautions © 2013 Meru Networks, Inc.Installing AP832e iii Chapter 2 Installing AP832e This chapter describes how to install and configure an AP832e. It contains the following sections: Safety Precautions Unpack the AP832e Installation Requirements Install the AP832e Check AP832e LED Activity Where to Go From Here Safety Precautions IMPORTANT—Read and follow the regulatory instructions in Appendix B before installing and operating this product. If an optional power supply is used, it must be one supplied by Meru Networks. The AP832e is intended only for installation in Environment A as defined in IEEE 802.3af. All intercon- nected equipment must be contained within the same building, including the interconnected equip- ment's associated LAN connection. Unpack the AP832e Confirm that the AP832e shipping package contains these items: Warning! This product is intended to be supplied by a UL Listed power supply marked Class 2 or LPS and rated minimum 12Vdc, 2A. For Power over Ethernet, an 802.3af or 802.3at connection must be used. ivMeru Access Point Installation Guide© 2013 Meru Networks, Inc. Installation Requirements AP832e Wall mount bracket Two ceiling mount brackets (for varying sized ceiling structures) Six antennas Screws for the mounting bracket Installation Requirements An array of holes on the mounting bracket allows the AP832e to be mounted on the wall and over junc- tion boxes or molly bolts. There are holes for passing the PoE Ethernet or external power supply cable through the bracket if the bracket is mounted on a junction box. The AP832e has a security cable slot so you can lock the AP832e with a standard security cable, such as those used to secure laptop computers. The AP832e ships with included ceiling and wall mounting brackets to be used for varying types of lcations, such as on T-bars or over junction boxes. For mounting above ceiling tiles, purchase optional mounting kits: Above Suspended Ceiling Mounting Kit (T-Bar Hanger): MNT-ASCMKIT Above hanging ceiling tiles. Suitable for use in environmental air space in accordance with the Section 832e-22(c) of the National Electric Code and Sections 2- 128.12 - 010 (3) and 12 - 100 of the Canadian Electrical Code. Part 1. C22. 1. Note that in order to comply with these standards, the plastic cover on the AP must be removed. Additional Equipment A power source is needed to power the AP832e. The AP832e requires an 802.3af or 802.3at power source when operating with PoE. If this is not available, 12V DC power (2A rated) must be supplied. Antenna Mappings See Ta b l e 1 to determine which radio is associated with each antenna. Install the AP832e © 2013 Meru Networks, Inc.Installing AP832e v Table 1: Antenna Mappings Install the AP832e Select a Location Attach the Provided Antennas Install the Access Point Select a Location All AP832e interconnected equipment, including the associated LAN connection, must be contained within the same building. In addition, the AP832e location should meet the following conditions: Relatively unobstructed access to the stations the AP serves. Select a location with minimal physical obstructions between the AP and the wireless stations. In an office with cubicles, mounting the APs below a hanging ceiling (plenum is supported) or the wall near the ceiling provides the least obstructed communications path. On a wall, orient the AP832e horizontally so that you can read the Meru logo without tilting your head at 90 degrees - this orientation provides optimum MIMO performance. Access to wall outlet or a to a Power over Ethernet (PoE) connection to the network switch servicing the controller. We recommend planning for about 256 clients per radio (or per interference region) if you plan to use Virtual Port and plan to have phones as clients. Refer to the Meru Deployment Guides on the support site for more information. AP832e is designed to provide 360 degree omni-directional coverage as illustrated below. Plan place- ment with this pattern in mind. AntennaRadio/Channel 1Radio 1 2Radio 1 3Radio 1 4Radio 2 5Radio 2 6Radio 2 viMeru Access Point Installation Guide© 2013 Meru Networks, Inc. Install the AP832e Figure 1: Coverage Pattern for AP832e When Ceiling Mounted Most installations receive the best coverage using the following guidelines: Install APs toward the center of the building. Place APs about 80 feet apart. Do not install APs near metal objects, such as heating ducts, metal doors, or electric service panels. Attach the Provided Antennas All AP832es have six external antenna ports, labeled 1 - 6. These units operate with six antennas attached, even though some configurations don’t use all six. Instead of attaching an antenna, you can cap unused antenna connectors with 50 ohm Reverse Polarity SMA terminators. (For a list of approved terminators, see http://www.merunetworks.com/merusupport .) To achieve the best performance from your AP832e, position antennas at a 90 degree angle relative to each other. The antennas do not have to be oriented exactly as shown in the figure, but it is important to maintain the relative angles. If for some reason you are unable to maintain those angles, the network still operates, but you may experience up to 20% drop in throughput depending on the antenna orientation. Do not leave any antenna connectors unterminated. All connectors on the AP must be terminated with antennas or with 50 ohm Reverse Polarity SMA terminators. (For a list of approved terminators, see http://www.merunetworks.com/merusupport . The attached antennas must be the same model; if you replace one antenna, replace them all. Install the Access Point AP832e ships several different mounting bracket components to allow for a variety of mounting op…

Text truncated - open the document above for the full version.

1 DO NOT SCALE THIS DRAWING ±.010 ±.05 ±1.5° 3 PLCS 2 PLCS ANG UNLESS OTHERWISE NOTED DIMENSIONS ARE IN INCHES C2/A1R DWG SIZE REV/REL SHEET USE PURSUANT TO COMPANY INSTRUCTIONS THIRD ANGLE PROJECTION P TITLE DESCRIPTION DATE REV DRAWING NUMBER PROE FILE NAME HS 2/25/13 MERU NETWORKS PROPRIETARY 845-00700 3 1 9/19/12 Initial Release 2 11/13/12 Remove incomplete certification information Label, Regulatory 1, AP832e SCALE 1:1 102 mm x 15.5 mm NOTES: UNLESS OTHERWISE SPECIFIED) 1. MUST CONFORM TO UL969 MARKING & LABELING SYSTEM PGDQ2; VAL-THERM-D OR EQUIVALENT. 2. ALL TEXT AND GRAPHICS ARE BLACK.3. CE, GITEKI & KOREAN MARK HAVE MINIMUM HEIGHT OF 5mm.4. The diameter of the C-Tick mark has a minimum requirement of 3mm and the suppliers identification characters have a minimum height requirement of 1mm5. For UAE mark, “TRA” min height 3mm, all other characters min height 2mm6. For So. Africa mark, the ICASA logo min requirement is 3 x 3 mm7. Factory Code: Shanghai = “S”, Shenzhen = “SZ” IC: 6749A-AP832E FCC ID: RE7-AP832E MADE IN CHINA E239453 SZ I.T.E. ACCESSORY 0980 Meru Networks Dual Radio Access PointModel No. AP832e Powered by PoE: -48 V 750 mAPowered by AC Adapter: 12 V 2.0A V 7 V 2 3 2/25/13 Add certs, update product desc, Release to MVT

ANTENNA Product overview This aesthetically pleasing antenna features six integrated 2.4 and 5 GHz dual- band, omni-directional antennas, ideal for demanding 802.11n applications. | MeruNetworKS.coM | ANteNNA ANt-6ABGN-24 DuAl-bAND miNi mimO cEiliNg- mOuNT OmNi-DirEcTiONAl ANTENNA ANT-6AbgN-24 An aesthetically pleasing antenna to support demanding 802.11n applications For more information about Meru antennas, visit | www.merunetworks.com | Or email your questions to: [email protected] corporate Headquarters 894 ross drive Sunnyvale, cA 94089 t +1 (408) 215-5300 F +1 (408) 215-5301 e [email protected] Meru Networks | Copyright © 2012 Meru Networks, Inc. All rights reserved worldwide. Meru Networks is a registered trademark of Meru Networks, Inc. All other trademarks, trade names, or service marks mentioned in this document are the property of their respective owners. 03.12 DS1025 ANTENNA eNviroNMeNtAL & MecHANicAL coNSiderAtioNS Temperature -22° F to +158° F (-30° C to +70° C) Weight 0.68 lbs (0.31 kgs) Dimensions 7.1” x 5.1” x 1.9” (18 cm x 13 cm x 5 cm) cable 36” (91.5 cm) plenum mounting Style Ceiling connector Type RP SMA plug eLectricAL SPeciFicAtioNS Frequency range 2.4–2.483 GHz 5.15–5.85 GHz gain 2.5 dBi 4 dBi VPbW/Vertical 55° 60° HPbW/Horizontal 360° VSWr 2.0 max 2.5 max Polarization Vertical impedance 50 Ohms PArt NuMBerS ANT-6ABGN-24 Dual-band Mini MIMO Ceiling-mount Omni-directional Antenna for 2.4/5.0/5.2/5.6/5.8 GHz meru delivers an all-wireless network that fully supports the enterprise, delivering a consistent, interactive experience for all users. No matter what applications they are running. No matter how many other users are on the network. SPEciFicATiONS

Ceiling Mount Omnidirectional Antenna for Indoor Use External Ceiling Mount Indoor Antenna For more information about the Meru Antennas, visit www.merunetworks.com ANT-I3ABGN-0304-O The ANT-I3ABGN-0304-O is a dual-band, ceiling-mount omnidirectional antenna, designed to operate indoors. The dual-band frequency coverage means that a single type of antenna can be deployed with any radio in the 2.4–2.5 GHz or 5.1–5.850 GHz bands. The 18” plenum pigtails have dual-band leads that support both 2.4 and 5 GHz with RPSMA connectors. E-Plane Pattern E-Plane Pattern H-Plane Pattern H-Plane Pattern 2.4 GHz 5 GHz Frequency Range 2.4–2.5 GHz and 5.1–5.850 GHz Gain 3 dBi for 2.4–2.5 GHz 4 dBi for 5.1–5.850 GHz VSWR ≤2.0 Vertical Beamwidth 90°/160° Horizontal Beamwidth 360° Polarization Vertical Number of Leads 3 Maximum Input Power 2 watts Lightning Protection DC grounded Mechanical Size 5.9” x 2.9” x 1.0” (15 cm x 7.37 cm x 2.54 cm) Weight 1.55 lbs (0.703 Kg) Operating Temperature Range -40 °F to 158 °F / -40 °C to 70 °C Antenna Connection RPSMA plug Mount Style Ceiling mount Cable Length 18” plenum pigtails Standard Warranty 1 year Part Numbers ANT-I3ABGN-0304-O Dual-band, Omnidirectional External Antenna for 2.4/5.0/5.2/5.6/5.8 GHz Meru delivers an all-wireless network that fully supports the enterprise, delivering a consistent, interactive experience for all users. No matter what applications they are running. No matter how many other users are on the network. Corporate Headquarters 894 Ross Drive, Sunnyvale, CA 94089 T +1.408.215.5300 F +1.408.215.5301 E [email protected] For more information about Meru antennas, visit www.merunetworks.com or email your questions to: [email protected] Meru Networks | Copyright © 2012 Meru Networks, Inc. All rights reserved worldwide. Meru Networks is a registered trademark of Meru Networks, Inc. All other trademarks, trade names, or service marks mentioned in this document are the property of their respective owners. 04.12 DS1052.1 ANT-I3ABGN-0304-O TECHNICAL SPECIFICATIONS Ceiling Mounting Images

ANTENNA H Plane 2.5 GHzH Plane 5.47 GHz E Plane 2.5 GHzE Plane 5.47 GHz Product ovErviEw The ANT-ABGN-23 is a dual-band, three-element omni-directional antenna for use in 802.11n MIMO applications. Housed in a compact, low-profile PVC/acrylic radome, the antenna can be mounted to a variety of drop ceiling grids using the integrated spring clips. It can also be mounted to a flush surface via the four mounting holes. Each of the three MIMO antenna elements is connected to the Meru AP300 Access Point via a low-loss, plenum-rated, coax pigtail. The radiation patterns are uniform and symmetrical, providing high levels of signal density into defined coverage zones. This antenna will greatly enhance the performance of 802.11n systems. The dual-band frequency coverage means that a single type of antenna can be deployed with any MIMO radio in the 2.4–2.5 GHz or 4.9–5.9 GHz bands. | MEruNEtworKS.coM | ANtENNA ANt-ABGN-23 ExTErNAl MIMO ANTENNA ANT-ABGN-23 Wall/Ceiling Grid Mounted, Low Profile, and Omni-directional For more information about Meru antennas, visit | www.merunetworks.com | Or email your questions to: [email protected] corporate Headquarters 894 ross drive Sunnyvale, cA 94089 t +1 (408) 215-5300 F +1 (408) 215-5301 E [email protected] Meru Networks | Copyright © 2012 Meru Networks, Inc. All rights reserved worldwide. Meru Networks is a registered trademark of Meru Networks, Inc. All other trademarks, trade names, or service marks mentioned in this document are the property of their respective owners. 03.12 DS1026 ANTENNA 89.0 22.0 308.2 89.0 93.2 Mechanical Size 12 1/8” x 7/8” x 3 11/16” (30.8 cm x 2.2 cm x 9.4 cm) Weight 0.86 lb (0.39 kg) Antenna Connection Reverse SMA (3x) radome PVC/Acrylic Mount Style Ceiling grid/suspended tile Cable length 5 ft Frequency range 2.4–2.5 GHz and 4.9–5.9 GHz Gain 3.0 dBi for 2.4–2.5 GHz 4.0 dBi for 4.9–5.9 GHz Maximum VSWr 2.0:1 3dB Beamwidth Elevation 60º 3dB Beamwidth Azimuth Omni-directional Polarization Linear, vertical Maximum Input Power 2 watts Meru delivers an all-wireless network that fully supports the enterprise, delivering a consistent, interactive experience for all users. No matter what applications they are running. No matter how many other users are on the network. SPECIFICATIONS

ANTENNA Product overview This compact antenna ships by default with the Meru AP300, AP433, AP1010e, and AP1020e Access Points. The antenna is designed for indoor applications and can also be ordered for use with other Meru access points. The antenna is white and has a low profile. It supports both the 2.4 GHz and the 5.0 GHz spectrums. | MeruNetworKS.coM | ANteNNA ANt-ABGN23o-w DUAL-BAND, OMNI- DIRECTIONAL ANTENNA ANT-ABGN23O-W Compact, white, low-profile antenna designed for indoor applications For more information about Meru antennas, visit | www.merunetworks.com | Or email your questions to: [email protected] corporate Headquarters 894 ross drive Sunnyvale, cA 94089 t +1 (408) 215-5300 F +1 (408) 215-5301 e [email protected] Meru Networks | Copyright © 2012 Meru Networks, Inc. All rights reserved worldwide. Meru Networks is a registered trademark of Meru Networks, Inc. All other trademarks, trade names, or service marks mentioned in this document are the property of their respective owners. 03.12 DS1027 ANTENNA eNviroNMeNtAL & MecHANicAL coNSiderAtioNS Temperature -10° C to + 55° C (14° F to 131° F) Humidity 95% at 25° C (77° F) Radome Color Off-white Dimensions 5.15” x 0.7” (13.1 cm x 1.8 cm) Connector Type RP SMA plug Frequency Range 2.4–2.5 GHz 4.9–5.875 GHz Gain 2 dBi HPBW/Horizontal 360° VSWR 1.5:1 max Polarization Linear, vertical Impedance 50 Ohms PArt NuMBer ANT-ABGN23O-W Dual-band, Omni-directional Antenna for 2.4/5.0/5.2/5.6/5.8 GHz Meru delivers an all-wireless network that fully supports the enterprise, delivering a consistent, interactive experience for all users. No matter what applications they are running. No matter how many other users are on the network. SPECIFICATIONS

Dual-band, Omnidirectional, High-gain Antenna For more information, visit www.merunetworks.com ANT-ABGN47O Compact antenna for indoor use This is a compact, cosmetically attractive, dual-band, 1/4-wave antenna covering the 2.45 GHz and 5.8 GHz bands. The antenna features a tilt-and-swivel joint that allows it to be oriented at straight or right angles to the access point or to be conveniently folded for storage. The antenna offers higher gain compared to the default antennas on Meru access points. The antenna is ideal for indoor usage and helps increase the coverage and range of the wireless signal. H-Plane 2.45 GHz E-Plane 2.45 GHz H-Plane 5.8 GHz E-Plane 5.8 GHz Part Numbers ANT-ABGN47O Dual-band, Omnidirectional Antenna for 2.4 and 5.8 GHz Meru delivers an all-wireless network that fully supports the enterprise, delivering a consistent, interactive experience for all users. No matter what applications they are running. No matter how many other users are on the network. Corporate Headquarters 894 Ross Drive, Sunnyvale, CA 94089 T +1.408.215.5300 F +1.408.215.5301 E [email protected] ANT-ABGN47O TECHNICAL SPECIFICATIONS ENVIRONMENTAL & MECHANICAL CONSIDERATIONS Fully weatherized Radome color Black Radome material ABS Dimensions 4” x 0.5” (10.2 cm x 1.3 cm) Connector type RP SMA plug ELECTRICAL SPECIFICATIONS Frequency Range 2.4–2.5 GHz 5.500-5.825 GHz Gain 4.7 dBi HPBW/Horizontal 360° VSWR 1.9:1 max Polarization Linear, vertical Impedance 50 Ohms For more information, visit www.merunetworks.com or email your questions to: [email protected] Meru Networks | Copyright © 2012 Meru Networks, Inc. All rights reserved worldwide. Meru Networks is a registered trademark of Meru Networks, Inc. All other trademarks, trade names, or service marks mentioned in this document are the property of their respective owners. Meru Networks assumes no responsibility for any inaccuracies in this document. Meru Networks reserves the right to change, modify, transfer, or otherwise revise this publication without notice. 11.12 DS1028.1

Ceiling Mount Omnidirectional Antenna for Indoor Use External Ceiling Mount Indoor Antenna For more information about the Meru Antennas, visit www.merunetworks.com ANT-I2ABGN-0304-O H Plane 2.4 GHzE Plane 2.4 GHz E Plane 5 GHzH Plane 5 GHz The ANT-I2ABGN-0304-O is a dual-band, ceiling-mount omnidirectional antenna, designed to operate indoors. The dual-band frequency coverage means that a single type of antenna can be deployed with any radio in the 2.4–2.5 GHz or 5.1–5.850 GHz bands. The 36” cables have dual-band leads that support both 2.4 and 5 GHz with RPSMA connectors. Frequency Range 2.4–2.5 GHz and 5.1–5.850 GHz Gain 3 dBi for 2.4–2.5 GHz 4 dBi for 5.1–5.850 GHz VSWR ≤2.0 Vertical Beamwidth 100°/100° Horizontal Beamwidth 360° Polarization Vertical Number of Leads 2 Maximum Input Power 2 watts Lightning Protection DC grounded Mechanical Size 2.9” x 5.41” x 1” (7.37 cm x 13.7 cm x 2.5 cm) Weight 0.39 lbs (0.177 kgs) Operating Temperature Range -40 °F to 158 °F / -40 °C to 70 °C Antenna Connection RPSMA plug with 3 ft cable Mount Style Ceiling mount Cable Length 3 ft Standard Warranty 1 year Part Numbers ANT-I2ABGN-0304-O Dual-band, Omnidirectional External Antenna for 2.4/5.0/5.2/5.6/5.8 GHz Meru delivers an all-wireless network that fully supports the enterprise, delivering a consistent, interactive experience for all users. No matter what applications they are running. No matter how many other users are on the network. Corporate Headquarters 894 Ross Drive, Sunnyvale, CA 94089 T +1.408.215.5300 F +1.408.215.5301 E [email protected] For more information about Meru antennas, visit www.merunetworks.com or email your questions to: [email protected] Meru Networks | Copyright © 2012 Meru Networks, Inc. All rights reserved worldwide. Meru Networks is a registered trademark of Meru Networks, Inc. All other trademarks, trade names, or service marks mentioned in this document are the property of their respective owners. 04.12 DS1052 ANT-I2ABGN-0304-O TECHNICAL SPECIFICATIONS Ceiling mounting images

External Patch Antenna Flexible Wall/Mast Mount Installation, Low Profile, and Directional For more information about the Meru Antennas, visit www.merunetworks.com ANT-O4ABGN-0607-PT The ANT-O4ABGN-0607-PT is a dual-band, dual-diversity patch antenna. It features two integrated 2.4 GHz, 6 dBi elements and two 5.1–5.85 GHz, 7 dBi elements arranged in one enclosure. The antenna can be mounted to a wall or mast, indoors or outdoors. Each of the two diversity antenna elements is connected to the access points via RPSMA plug connectors. The radiation patterns are uniform and symmetrical, providing high levels of signal density into defined coverage zones. The dual-band frequency coverage means that a single type of antenna can be deployed with any radio in the 2.4–2.5 GHz or 5.1–5.850 GHz bands. E Plane 5 GHzE Plane 2.4 GHz H Plane 2.4 GHzH Plane 5 GHz Frequency Range 2.4–2.5 GHz and 5.1–5.850 GHz Gain 6 dBi for 2.4–2.5 GHz 7 dBi for 5.1–5.850 GHz VSWR ≤1.5/≤2.0 Nominal Impedance 50 Ohms Beamwidth Elevation 72º at 2.4 GHz, 60º at 5 GHz Beamwidth Azimuth 82º at 2.4 GHz, 75º at 5 GHz Polarization Vertical Number of Leads 4 Maximum Input Power 50 watts Mechanical Size 12.6” x 6.1” x 1” (32 cm x 15.5 cm x 2.5 cm) Weight 1.4 lbs (0.64 kgs) Operating Temperature Range -22 °F to 158 °F / -30 °C to 70 °C Antenna Connection RPSMA plug with 3 ft cable Mount Style Articulating for wall/mast Cable Length 3 ft Standard Warranty 1 year Part Numbers ANT-O4ABGN-0607-PT Dual-band, Dual-diversity Patch Antenna for 2.4/5.0/5.2/5.6/5.8 GHz Meru delivers an all-wireless network that fully supports the enterprise, delivering a consistent, interactive experience for all users. No matter what applications they are running. No matter how many other users are on the network. Corporate Headquarters 894 Ross Drive, Sunnyvale, CA 94089 T +1.408.215.5300 F +1.408.215.5301 E [email protected] For more information about Meru antennas, visit www.merunetworks.com or email your questions to: [email protected] Meru Networks | Copyright © 2012 Meru Networks, Inc. All rights reserved worldwide. Meru Networks is a registered trademark of Meru Networks, Inc. All other trademarks, trade names, or service marks mentioned in this document are the property of their respective owners. 04.12 DS1051 ANT-O4ABGN-0607-PT TECHNICAL SPECIFICATIONS

ANTENNA Product overview The ANT-O6ABGN-0606-O is an outdoor dual-band, six-element omni- directional antenna for use in 802.11n MIMO applications. Housed in a ruggedized fiberglass enclosure, the antenna can be mounted to a wall, beam, or mast. Each of the six MIMO antenna elements is connected to the Meru AP300 or OAP433 Access Point via a low-loss, plenum-rated, coax pigtail. The radiation patterns are uniform and symmetrical, providing high levels of signal density into wide spaces such as warehouses or manufacturing facilities. This antenna will greatly enhance the performance of 802.11n systems. The dual-band frequency coverage means that a single type of antenna can be deployed with any MIMO radio in the 2.4–2.5 GHz or 5.150–5.850 GHz bands. | MeruNetworKS.coM | ANteNNA ANt-o6ABGN-0606-o EXTERNAL MIMO OMNI-DIRECTIONAL ANTENNA ANT-O6ABGN-0606-O Flexible wall/beam/mast mount installation, ruggedized, and omni-directional e Plane 2.4 GHz e Plane 5 GHz H Plane 5 GHzH Plane 2.4 GHz For more information about Meru antennas, visit | www.merunetworks.com | Or email your questions to: [email protected] corporate Headquarters 894 ross drive Sunnyvale, cA 94089 t +1 (408) 215-5300 F +1 (408) 215-5301 e [email protected] Meru Networks | Copyright © 2012 Meru Networks, Inc. All rights reserved worldwide. Meru Networks is a registered trademark of Meru Networks, Inc. All other trademarks, trade names, or service marks mentioned in this document are the property of their respective owners. 03.12 DS1029 ANTENNA Maximum Input Power 20 watts Mechanical Size 6” x 7 1/64” (152.4 mm x 180.4 mm) Weight 3.74 lb (1.70 kg) Antenna Connection RPSMA Radome Fiberglass Mount Style Attaches to wall/beam/mast with included hardware Cable Length 3 ft Frequency Range 2.4–2.5 GHz and 5.150–5.850 GHz Gain 6 dBi for 2.4–2.5 GHz 6 dBi for 5.150–5.850 GHz Maximum VSWR 1.5:1 for 2.4 GHz; 2.0:1 for 5 GHz Beamwidth Elevation 40º @ 2.4 GHz, 40º @ 5 GHz Beamwidth Azimuth 360º @ 2.4 GHz, 360º @ 5 GHz Polarization Vertical Number of Leads 6 certiFicAtioNS Certified in U.S. and Canada. For other regions, contact your local Meru representative. Meru delivers an all-wireless network that fully supports the enterprise, delivering a consistent, interactive experience for all users. No matter what applications they are running. No matter how many other users are on the network. SPECIFICATIONS

ANTENNA Product overview The ANT-O6ABGN-0607-PT is a dual-band, three-patch antenna for use in 802.11n MIMO applications. Housed in a low-profile radome, the antenna can be mounted to a wall or mast, indoors or outdoors. Each of the three MIMO antenna elements is connected to the Meru AP300, AP433e, AP1010e/AP1020e Access Points via a low-loss, plenum-rated, coax pigtail. The radiation patterns are uniform and symmetrical, providing high levels of signal density into defined coverage zones. This antenna will greatly enhance the performance of 802.11n systems. The dual-band frequency coverage means that a single type of antenna can be deployed with any MIMO radio in the 2.4–2.5 GHz or 5.1–5.850 GHz bands. | MeruNetworKS.coM | ANteNNA ANt-o6ABGN-0607-Pt ExTErNAl MIMO PATch ANTENNA ANT-O6ABGN-0607-PT Flexible Wall/Mast Mount Installation, Low Profile, and Directional H Plane 2.4 GHzH Plane 5 GHz e Plane 2.4 GHz e Plane 5 GHz For more information about Meru antennas, visit | www.merunetworks.com | Or email your questions to: [email protected] corporate Headquarters 894 ross drive Sunnyvale, cA 94089 t +1 (408) 215-5300 F +1 (408) 215-5301 e [email protected] Meru Networks | Copyright © 2012 Meru Networks, Inc. All rights reserved worldwide. Meru Networks is a registered trademark of Meru Networks, Inc. All other trademarks, trade names, or service marks mentioned in this document are the property of their respective owners. 03.12 DS1030 ANTENNA Maximum Input Power 50 watts Mechanical Size 17 1/2” x 6 1/64” x 1” (44.5 cm x 15.3 cm x 2.5 cm) Weight 1.9 lbs (0.86 kgs) Antenna connection RPSMA Mount Style Articulating for wall/mast cable length 3 ft Frequency range 2.4–2.5 GHz and 5.1–5.850 GHz Gain 6 dBi for 2.4–2.5 GHz 7 dBi for 4.9–5.850 GHz Maximum VSWr 1.5:1 for 2.4 GHz; 2.0:1 for 5 GHz 3 dB Beamwidth Elevation 72º @ 2.4 GHz, 60º @ 5 GHz 3 dB Beamwidth Azimuth 82º @ 2.4 GHz, 75º @ 5 GHz Polarization Vertical Number of leads 6 certiFicAtioNS Certified in U.S. and Canada. For other regions, contact your local Meru representative. Meru delivers an all-wireless network that fully supports the enterprise, delivering a consistent, interactive experience for all users. No matter what applications they are running. No matter how many other users are on the network. SPEcIFIcATIONS

§ 15.247(i) Maximum Permissible Exposure RF Exposure Requirements: §1.1307(b)(1) and §1.1307(b)(2): Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. RF Radiation Exposure Limit: §1.1310: As specified in this section, the Maximum Permissible Exposure (MPE) Limit shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in Sec. 1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of Sec. 2.1093 of this chapter. MPE Limit Calculation: EUT’s operating frequencies @ 2400-2483.5 MHz & 5745-5825MHz; Limit for Uncontrolled exposure: 1 mW/cm 2 or 10 W/m 2 2.4 GHz highest power density: EUT antenna gain = (3dBi x3) 7.77 dBi; power = 638.3 mW Equation from page 18 of OET 65, Edition 97-01 S = PG / 4R 2 or R = √PG / 4S where, S = Power Density P = Power Input to antenna G = Antenna Gain (5.98 numeric) R = 20 cm S = (638.3*5.98/ 4*3.14*400) = 0.759 mW/cm2 5.8 GHz highest power density: EUT antenna gain = (7dBi x3) 11.77 dBi; power = 227 mW Equation from page 18 of OET 65, Edition 97-01 S = PG / 4R 2 or R = √PG / 4S where, S = Power Density P = Power Input to antenna G = Antenna Gain (15.03 numeric) R = 20 cm S = (227*15.03/ 4*3.14*400) = 0.679 mW/cm2

§ 15.247(b) Peak Power Output and RF Exposure RF Exposure Requirements: §1.1307(b)(1) and §1.1307(b)(2): Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. RF Radiation Exposure Limit: §1.1310: As specified in this section, the Maximum Permissible Exposure (MPE) Limit shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in Sec. 1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of Sec. 2.1093 of this chapter. Test Results: The EUT was compliant with the requirements of this section. Radios are capable of simultaneous operation. The worst case power densities for all bands for a single radio are listed below (non –simultaneous operation). DTS band Unii 1 band Unii 3 band 2.4 GHz 5.8 GHz Antenna Gain (dBi) 7.77 11.77 11.77 8.77 Power (dBm) 28.05 23.56 11.21 20.31 Power density (mW/cm2) 0.759 0.679 0.39 0.16 When both radios operate at the same time, Meru Networks will lower the power of each radio by 3dB. The Power densities for this case are listed below: DTS band Unii 1 band Unii 3 band 2.4 GHz 5.8 GHz Antenna Gain (dBi) 7.77 11.77 11.77 8.77 Power (dBm) 25.05 20.56 8.21 17.31 Power density (mW/cm2) 0.38 0.34 0.02 0.08 As can be seen from the second table above, the power densities do not exceed 100 % per OET 65 requirements when the spectral power density is calculated at least 20cm away from the unit when two bands may operate simultaneously. Therefore, the EUTs meet the Uncontrolled Exposure limit. Test Engineer(s): Jonathan Chao
