REB-BP100BP100S AND BP100E

Chantry BeaconWorks Installation Guide BeaconPoint In this document Unpacking and Mounting the BeaconPoint.... 2 Connecting and Powering the BeaconPoint .. 3 Caution .................................................4 Unpacking and Mounting the BeaconPoint Chantry Networks Inc. BeaconPoint Installation Guide Page 2 Copyright 2003. All rights reserved. Unpacking and Mounting the BeaconPoint Unpack the BeaconPoint from its carton. Also in the carton are the following: • one wall bracket • one allen key (to depress security latch) • one plastic spreading rivet and matching plastic screw (to secure BeaconPoint to bracket 1. Mount the BeaconPoint wall bracket, using 3 screws. For a typical dry wall mounting, use #6 X 1 inch pan head sheet metal screws with # 6 plastic wall anchors. Make sure the top of the bracket is near the LAN ethernet cable plug coming from the wall. 2. Press the back of the BeaconPoint onto the bracket, aligning it with the open notches in the bracket. Then slide it downwards until it click into place. ↑ Channel for allen key to spring clip Security Note #1: A small spring clip on the BeaconPoint case has now snapped into an opening in the bracket. To remove the BeaconPoint from the bracket, insert the allen key (provided) into a small hole at the bottom of the bracket. Use the allen key to depress the spring clip. Then you can slide the case up the bracket and lift off the BeaconPoint. Opening for rivet ↓ ↑ Opening for allen key 3. Insert the plastic spreading rivet through the hole at the bottom of the bracket and into the BeaconPoint case. Then screw in the plastic screw. This spreads the rivet and locks the case to the bracket. Security Note #2: The spreading rivet prevents casual removal of the BeaconPoint. You will need a screwdriver to remove it. Connecting and Powering the BeaconPoint Chantry Networks Inc. BeaconPoint Installation Guide Page 3 Copyright 2003. All rights reserved. Connecting and Powering the BeaconPoint [Optional]. Connect an AC/DC power supply (if PoE is not being used in your network) ↑ ↑ power LAN ethernet connector port connector In the top of the BeaconPoint, connect the LAN ethernet cable to the ethernet port. Power by AC Adaptor If you wish to use an AC power adaptor, the specified adaptor is Ault: PW117RA0503B01 [Input: 120-240 VAC, Output Voltage DC 5 V, max amps 2.00, max watts 10]. The adaptor is not provided with the BeaconPoint. Install the adaptor within six feet of a wall outlet, attach it to the BeaconPoint and then plug the adaptor into a wall outlet. Power Over the Ethernet If your network is already set up with PoE, attach the LAN ethernet cable to RJ45 ethernet connector in the top of the BeaconPoint. Power Over the Ethernet: Adding PoE Injector To provide power for a BeaconPoint us ing the ethernet cable (if this is not set up on your LAN network), you will need a PoE injector (Ault: PW130RA480N01) that provides powe r to the ethernet cable. The PoE injector is not provided with the BeaconPoint. Caution Chantry Networks Inc. BeaconPoint Installation Guide Page 4 Copyright 2003. All rights reserved. Caution This equipment has been tested and found to comply with the limits for a Class B digital devices, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential inst allation. This equipment generates, uses, and can radiate radio frequency e nergy and, if not installed and used in accordance with the instru ction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of more of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. WARNING : Changes or modifications not expressly approved by Chantry Networks could void the user’s authority to operate the equipment WARNING : To satisfy FCC RF exposu re requirements for mobile transmitting devices, a separation distance of 20 cm or more should be maintained between the antenna of this device and persons during device operation. To ensure complianc e, operations at closer than this distance is not recommended. The antenna used for this transmitter must not be co-located in conjunction with any other antenna or transmitter.

«Report_Date» FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. Subject: Request for withholding from public disclosure the schematic diagrams and system block diagrams pursuant to an application for certification. Applicant: Chantry Networks Product: BeaconPoint Model: BM100S and BM100E FCC ID: REB-BP100 Dear Sir/Madam, We, Chantry Networks, would like to request that the schematic diagrams, system block diagrams, parts list and operational description, submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This request is made under the provisions of Section 0.457(d) of the Commission's Rules, and Section 552(b)(4) of the Freedom of Information Act. These sections authorize as a withholding from public inspection materials which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. If you have any queries, please do not hesitate to contact us by our phone number: OUR TELEPHONE NO.: (905) 567-6900 Yours truly, Sylvain Louchez VP Engineering

ANNEX 2 - EXTERNAL PHOT OGRAPHS Photo # 1 Bea c onpoin t , Model BP100S (inte r nal antenn a) an d BP100E (e xtern a l ante nna) FCC I D : RE B-BP1 00 IC: 470 2A-BP100 Chan tr y Beaconpoint, BP100E (ex t er nal anten n a) ANNEX 2 - EXTERNAL PHOT OGRAPHS Photo # 2 Bea c onpoin t , Model BP100S (inte r nal antenn a) an d BP100E (e xtern a l ante nna) FCC I D : RE B-BP1 00 IC: 470 2A-BP100 Chan tr y Beaconpoint, BP100E (ex t er nal anten n a) ANNEX 2 - EXTERNAL PHOT OGRAPHS Photo # 3 Bea c onpoin t , Model BP100S (inte r nal antenn a) an d BP100E (e xtern a l ante nna) FCC I D : RE B-BP1 00 IC: 470 2A-BP100 Chan tr y Beaconpoint, BP100S (inter nal anten n a) ANNEX 2 - EXTERNAL PHOT OGRAPHS Photo # 4 Bea c onpoin t , Model BP100S (inte r nal antenn a) an d BP100E (e xtern a l ante nna) FCC I D : RE B-BP1 00 IC: 470 2A-BP100 Chan tr y Beaconpoint, BP100S (inter nal anten n a) \

Chantry NetworksBP100 Bottom Housing Certification Label

BeaconPointChantry Networks Inc.1900 Minnesota CourtMississaugaOntarioCanada Radio Unit 2.4 GHz DSSS 11 MbpsINPUT: +/- 5 V dc 1000 mA P.O.E. +/-48 V dc 250 mA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. BeaconPoint BP100 For Home or Office Use FCC ID: REB-BP100IC: 4702A-BP100

ANNEX 3 - INTERNAL PHOTOGRAPHS Photo # 1 Beaconpoint, Model BP100S (internal antenna) FCC ID: REB-BP100 IC: 4702A-BP100 ANNEX 3 - INTERNAL PHOTOGRAPHS Photo # 2 Beaconpoint, Model BP100S (internal antenna) FCC ID: REB-BP100 IC: 4702A-BP100 ANNEX 3 - INTERNAL PHOTOGRAPHS Photo # 3 Beaconpoint, Model BP100S (internal antenna) FCC ID: REB-BP100 IC: 4702A-BP100

Celestica 1150 Eglinton Avenue East Toronto, Ontario Canada M3C 1H7 August 11, 2003 Mr. Tri Luu Ultratech Engineering Labs Re: Power Calibration Procedure Dear Tri, The following is the procedure for tuning output power on the Chantry BP100 units. The chipset used in the product is provided by Intersil Corp., which also supplies the executable test software used in manufacturing to test and configure the units. One of these tests is called RF-Test, and it is this test which configures the unit’s output power. The procedure is as follows: 1) Set channel to channel 1. 2) Sweep power level across this channel, and determine output power level which corresponds to 30dBc sidelobe specification. 3) Record two values in the unit firmware: #1 The power set level, and #2 The power detector level 4) Repeat for channels 2 to 14 When the units are fully tested, they are deemed completed assemblies. These completed assemblies function in a closed-loop calibrated power mode. The power set and power detector levels programmed into the flash device are used to automatically adjust the power set level to maintain 30dBc sidelobes over all operating conditions. Sincerely, Tomasz Czernecki

Chantry BeaconWorks Installation Guide BeaconPoint In this document Unpacking and Mounting the BeaconPoint ....................... Error! Bookmark not defined. Connecting and Powering the BeaconPoint ....................... Error! Bookmark not defined. Caution .................................................4 Caution Chantry Networks Inc. BeaconPoint Installation Guide Page 2 Copyright 2003. All rights reserved. Caution This equipment has been tested and found to comply with the limits for a Class B digital devices, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential inst allation. This equipment generates, uses, and can radiate radio frequency e nergy and, if not installed and used in accordance with the instru ction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of more of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. WARNING : Changes or modifications not expressly approved by Chantry Networks could void the user’s authority to operate the equipment WARNING : To satisfy FCC RF exposu re requirements for mobile transmitting devices, a separation distance of 20 cm or more should be maintained between the antenna of this device and persons during device operation. To ensure complianc e, operations at closer than this distance is not recommended. The antenna used for this transmitter must not be co-located in conjunction with any other antenna or transmitter.

Aug. 11, 2003 TIMCO ENGINEERING INC. P O BOX 370 849 N.W. STATE ROAD 45 NEWBERRY, FLORIDA USA 32669 Subject: FCC Certification Authorization Application under FCC Part 15, Subpart C, Sec. 15.247 - Digital Modulation Transmitters operating in the frequency band 2400 - 2483.5 MHz. Product: Beaconpoint Model No.: BP100S (internal antenna) and BP100E (external antenna) FCC ID: REB-BP100 Dear Sir/Madam As appointed agent for Chantry Networks, we would like to submit the application to FCC for certification of the above product. Please review all necessary files uploaded to TIMCO UPLOAD SITE for detailed information. • The Models BP100S and BP100E are exactly identical except for there antennas’ type and mounting mechanism. • Compliance with RF Exposure Requirements: The transmitter complies with FCC 2.1091 with the minimum RF safety distance of 20 cm. Please refer to Users Manual for details of RF Exposure Information. If you have any queries, please do not hesitate to contact us. Yours truly, Tri Minh Luu, P. Eng., V.P., Engineering Encl 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] UltraTech Group of Labs 31040/SIT C-1376 46390-2049 200093-0 2 00-034 SL2-IN-E-1119R Aug. 11, 2003 Chantry Networks 125 - 1900 Minnesota Court Mississauga, Ontario Canada, L5N 3C9 Attn.: Mr. Fai Siew Subject: FCC Certification Application Testing under FCC Part 15, Subpart C, Sec. 15.247 - Digital Modulation Transmitters operating in the frequency band 2400 - 2483.5 MHz. Product: Beaconpoint Model No.: BP100S (internal antenna) and BP100E (external antenna) FCC ID: REB-BP100 Dear Mr. Siew, The product sample, as provided by you, has been tested and found to comply with FCC Part 15, Subpart C, Sec. 15.247 - Digital Modulation Transmitters operating in the frequency band 2400 - 2483.5 MHz. • The Models BP100S and BP100E are exactly identical except for there antennas’ type and mounting mechanism. • Compliance with RF Exposure Requirements: The transmitter complies with FCC 2.1091 with the minimum RF safety distance of 20 cm. Please refer to Users Manual for details of RF Exposure Information. Enclosed you will find copies of the engineering report. If you have any queries, please do not hesitate to contact us. Yours truly, Tri Minh Luu, P. Eng., V.P., Engineering Encl. 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] UltraTech Group of Labs 31040/SIT C-1376 46390-2049 200093-0 2 00-034 SL2-IN-E-1119R ENGINEERING TEST REPORT Beaconpoint Model No.: BP100S (internal antenna) And BP100E (external antenna) FCC ID: REB-BP100 Applicant: Chantry Networks 125 - 1900 Minnesota Court Mississauga, Ontario Canada, L5N 3C9 In Accordance With FEDERAL COMMUNICATIONS COMMISSION (FCC) PART 15, SUBPART C, SEC. 15.247 Digital Modulation Transmitters operating in the frequency band 2400 - 2483.5 MHz UltraTech's File No.: CLS-109FCC15C This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: Aug. 11, 2003 Report Prepared by: Tri Luu, P.Eng. Tested by: Hung Trinh, RFI Technician Issued Date: Aug. 11, 2003 Test Dates: July 28-Aug. 10, 2003 ƒ The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected. ƒ This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected], Email: [email protected] 2 31040/SIT C-1376 46390-2049 200093-0 SL2-IN-E-1119R 00-034 FCC PART 15, SUBPART C, SEC. 15.247 - DIGITAL MODULATION TRANSMITTERS Page 2 Beaconpoint, Model BP100S (internal antenna) and BP100E (external antenna) FCC ID: REB-BP100 ULTRATECH GROUP OF LABS File #: CLS-109FCC15C 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Aug. 11, 2003 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com • All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. SUBMITTAL CHECK LIST .............................................................................................................. 4 EXHIBIT 1. INTRODUCTION ................................................................................................................................ 5 1.1. SCOPE ............................................................................................................................................................... 5 1.2. RELATED SUBMITAL(S)/GRANT(S)........................................................................................................................ 5 1.3. NORMATIVE REFERENCES .......................................................................................................................... 5 EXHIBIT 2. PERFORMANCE ASSESSMENT ..................................................................................................... 6 2.1. CLIENT INFORMATION .................................................................................................................................... 6 2.2. EQUIPMENT UNDER TEST (EUT) INFORMATION ............................................................................................ 6 2.3. EUT’S TECHNICAL SPECIFICATIONS ........................................................................................................ 7 2.4. LIST OF EUT’S PORTS......................................................................................................................................... 8 2.5. ANCILLARY EQUIPMENT.......................................................…

Text truncated - open the document above for the full version.

ANNEX 1 - PHOTOGRAPHS OF TEST SETUP Photo # 1 Bea c onpoin t , Model BP100S (inte r nal antenn a) an d BP100E (e xtern a l ante nna) FCC I D : RE B-BP1 00 IC: 470 2A-BP100 Plot # 1 - AC Pow e rlin e Conducted Emissions ANNEX 1 - PHOTOGRAPHS OF TEST SETUP Photo # 2 Bea c onpoin t , Model BP100S (inte r nal antenn a) an d BP100E (e xtern a l ante nna) FCC I D : RE B-BP1 00 IC: 470 2A-BP100 Plot # 2 - AC Pow e rlin e Conducted Emissions ANNEX 1 - PHOTOGRAPHS OF TEST SETUP Photo # 3 Bea c onpoin t , Model BP100S (inte r nal antenn a) an d BP100E (e xtern a l ante nna) FCC I D : RE B-BP1 00 IC: 470 2A-BP100 Plot # 3 – Radiated Em issions at 3 Meters O FTS for Model B P 100E ANNEX 1 - PHOTOGRAPHS OF TEST SETUP Photo # 4 Bea c onpoin t , Model BP100S (inte r nal antenn a) an d BP100E (e xtern a l ante nna) FCC I D : RE B-BP1 00 IC: 470 2A-BP100 Plot # 4 – Radiated Em issions at 3 Meters O FTS for Model B P 100E ANNEX 1 - PHOTOGRAPHS OF TEST SETUP Photo # 5 Bea c onpoin t , Model BP100S (inte r nal antenn a) an d BP100E (e xtern a l ante nna) FCC I D : RE B-BP1 00 IC: 470 2A-BP100 Plot # 5 – Radiated Em issions at 3 Meters O FTS for Model B P 100S ANNEX 1 - PHOTOGRAPHS OF TEST SETUP Photo # 6 Bea c onpoin t , Model BP100S (inte r nal antenn a) an d BP100E (e xtern a l ante nna) FCC I D : RE B-BP1 00 IC: 470 2A-BP100 Plot # 6 – Radiated Em issions at 3 Meters OFTS for Model B P 100SE
