  1. Home/
  2. Black Diamond Equipment/
  3. REMVECTOR01

REMVECTOR01Avalanche Beacon VECTOR

Black Diamond Equipment
Avalanche Beacon VECTOR - FCC ID REMVECTOR01 - Black Diamond Equipment
Click to zoom

Application Details

Equipment Class
DCD - Part 15 Low Power Transmitter Below 1705 kHz
Date of Grant
Dec 19, 2011
Application Purpose
Original Equipment
Date of Application
Dec 19, 2011
Equipment Note
Avalanche Beacon VECTOR
Frequency Range
0.45700000 - 0.45700000
Company
Black Diamond Equipment
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

EN DE TEchNical DaTa Certification: Warning: Any changes or modifications not expressly approved by the manufacturer, responsible for compliance, could void the user’s authority to operate this device. Europe: Manufacturer: PIEPS GmbH Country of manufacture: Austria; Model: VECTOR; Canada: IC: 7262A-VECTOR01; USA: FCC ID: REMVECTOR01; This device complies with Part 15 of the FCC Rules and IC RSS-210. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Conformity: PIEPS GmbH declares hereby, that the product PIEPS VECTOR fulfils all requirements and regulations of directive 1999/5/EC! The declaration of conformity can be downloaded at the following source: http://www.pieps.com/certification; Manufacturer, Sales & Service: PIEPS GmbH, Parkring 4, 8403 Lebring, Austria, office@ pieps.com, www.pieps.com Warranty Conditions: The device is guaranteed by the manufacturer against defects in material and workmanship for a period of 2 years from the date of purchase. • This warranty does not apply to damage caused by incorrect use, dropping or dismantling of the device by unauthorized persons. • Any further warranty or liability for consequential damage is expressly excluded. • Warranty claims should be addressed - enclosing the receipt of purchase - to the relevant sales outlet. PIEPS warranty extension free of charge: Extend the warranty of your PIEPS VECTOR from 2 to 5 years: With the PIEPS warranty extension you have the possibility to extend the standard warranty of your PIEPS Vector free of charge. Simply register online at www.pieps.com and get your warranty certificate for 5 years valid from the date of purchase. You can save on repair costs and valuable time. The warranty can be extended within 3 months from the date of purchase. Device designationPIEPS VECTOR SystemMaintenance free, fully digital 4 antenna system with GPS support GPSUltra Low Power with -160 dB SuperSense® Technology Transmission frequency457 kHz (EN 300718) Power supplyLithium-ion battery + alkaline-battery-adapter InterfaceUSB for charging Digital rangeapprox. 80 m, circular Temperature range-20°C to +45°C Weight200 g Dimensions (LxWxH)132 x 75 x 26 mm 08/11 |33

External Photos

ANNEX BEXTERNAL PICTURES Test engineer:Raimund BLASKReport Number:F113539E1 Date of issue:30November2011Order Number:11-113539page1 of 2 113539eut1.JPG: EUT, front-view ANNEX BEXTERNAL PICTURES Test engineer:Raimund BLASKReport Number:F113539E1 Date of issue:30November2011Order Number:11-113539page2 of 2 113539eut2.JPG: EUT, rear-view

Internal Photos

ANNEX CINTERNAL PICTURES Test engineer:Raimund BLASKReport Number:F113539E1 Date of issue:30November 2011Order Number:11-113539page1 of 2 113539eut3.JPG: EUT, PCB front-view ANNEX CINTERNAL PICTURES Test engineer:Raimund BLASKReport Number:F113539E1 Date of issue:30November 2011Order Number:11-113539page2 of 2 113539eut4.JPG: EUT, PCB rear-view

Test Report

Königswinkel 10 32825 Blomberg Germany Phone:+49 (0) 52 35 95 00-0 Fax:+49 (0) 52 35 95 00-10 Test Report Report Number: F113539E1 Applicant: PIEPS GmbH Manufacturer: PIEPS GmbH Equipment under Test (EUT): Avalanche Beacon “VECTOR” Laboratory (CAB) accredited by Deutsche Gesellschaft für Akkreditierung mbH in compliancewith DIN EN ISO/IEC 17025 under the Reg. No. DGA-PL-105/99-22, FCC Test site registration number 90877and Industry Canada Test site registration IC3469A-1 Testengineer:Raimund BLASKReport Number:F113539E1 Date of issue:30 November2011Order Number:11 -113539page2 of 22 REFERENCES [1]ANSI C63.4-2009American National Standard for Methods of Measuring of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. [2]FCC CFR 47 Part 15 (August 2011)Radio Frequency Devices [3]RSS-210 Issue 8 (December2010)Low-power Licence-exempt Radiocommunication Devices (All Frequency Bands): Category I Equipment [4]RSS-GenIssue 3 (December 2010)General Requirements and Information for the Certification of Radiocommunication Equipment TEST RESULT The complete test results are presented in the following. RESERVATION T h i s t e s t r e p o r t i s o n l y v a l i d i n i t s o r i g i n a l f o r m . Any reproduction of its contents in extracts without written permission of the accredited test laboratory PHOENIX TESTLAB GmbH isprohibited. The test results herein refer only to the tested sample. PHOENIX TESTLAB GmbH is not responsible for any generalizations or conclusions drawn from these test results concerning further samples. Any modification of the tested samples is prohibited and leads to the invalidity of this test report. Each page necessarily contains the PHOENIX TESTLAB Logo and the TEST REPORT NUMBER. Testengineer:Raimund BLASKReport Number:F113539E1 Date of issue:30 November2011Order Number:11-113539page3 of22 Contents:Page 1IDENTIFICATION.....................................................................................................................................4 1.1APPLICANT.......................................................................................................................4 1.2MANUFACTURER.............................................................................................................4 1.3TEST LABORATORY........................................................................................................4 1.4EUT (EQUIPMENT UNDER TEST)...................................................................................5 1.5TECHNICAL DATA OF EQUIPMENT................................................................................5 1.6DATES..............................................................................................................................5 2OPERATIONAL STATES.........................................................................................................................6 3ADDITIONAL INFORMATION (as declared by the applicant):................................................................6 4OVERVIEW..............................................................................................................................................7 5METHODS OF MEASUREMENT............................................................................................................8 5.1RADIATED EMISSIONS....................................................................................................8 5.2RADIATED EMISSIONS.................................................................................................. 15 5.2.1TEST RESULTS (RADIATED EMISSIONS) ..........................................................................15 5.2.1.1PRELIMINARY RADIATED EMISSION MEASUREMENT (9 kHz to 30 MHz).................15 5.2.1.2FINAL RADIATED EMISSION MEASUREMENT (9 kHz to 30 MHz)...............................17 5.2.1.3PRELIMINARY MEASUREMENT (30 MHz to 1 GHz)......................................................18 6TEST EQUIPMENT AND ANCILLARIES USED FOR TESTS..............................................................20 7REPORT HISTORY...............................................................................................................................21 8LIST OF ANNEXES................................................................................................................................22 Testengineer:Raimund BLASKReport Number:F113539E1 Date of issue:30 November2011Order Number:11-113539page4 of22 1IDENTIFICATION 1.1APPLICANT Name:PIEPS GmbH Address:Parkring 4 8403 Lebring Country:Austria Name for contact purposes:Mr. DI Wolfgang Platzer Tel:+43-3182-52556-12 Fax:+43-3182-52556-19 e-mail address:[email protected] 1.2MANUFACTURER Name:PIEPS GmbH Address:Parkring 4 8403 Lebring Country:Austria Name for contact purposes:Mr. Rudolf Sackl Tel:+43-3182-52556-12 Fax:+43-3182-52556-19 e-mail address:[email protected] 1.3TEST LABORATORY The tests were carried out at:PHOENIX TESTLAB GmbH Königswinkel 10 32825 Blomberg Germany accredited byDGA Deutsche Gesellschaft für Akkreditierung mbHin compliance with DIN EN ISO/IEC 17025 under Reg. No.DGA-PL-105/99-22,FCC Test site registration number 90877andIndustry Canada Test site registration IC3469A-1. Testengineer:Raimund BLASKReport Number:F113539E1 Date of issue:30 November2011Order Number:11-113539page5 of22 1.4EUT (EQUIPMENTUNDER TEST) Test object: *Avalanche Beacon Type: *Vector Antenna type: *Integral H-Field-Antenna Hardware version: *Rev. 6 Software version: *Version 1.0 1.5TECHNICAL DATA OF EQUIPMENT Duty cycle class: *Up to 100% Rated transmitter fieldstrength: *7 dBμA/m @ 10 m distance (declared by the applicant) Channel spacing: *- ITU classification: *1K50A1A Alignment range: *457 kHz Switching range: *457 kHz Modulation:*A1ADouble Sideband Amplitude Modulation Bit rate of transmitter:*No Data transfer Supply Voltage:*U Nom =3.7 VU Min =2.9VU Max =4.2V Power Supply:*3.7 V Lithium-Ion-Batte…

Text truncated - open the document above for the full version.

Test Setup Photos

ANNEX APHOTOGRAPHS Test engineer:Raimund BLASKReport Number:F113539E1 Date of issue:30November 2011Order Number:11-113539page1 of 3 113539emi1.JPG:Test set-uppreliminaryradiated emission (H-Field) ANNEX APHOTOGRAPHS Test engineer:Raimund BLASKReport Number:F113539E1 Date of issue:30November 2011Order Number:11-113539page2 of 3 113539emi2.JPG: Test set-up radiated emission (E-Field) ANNEX APHOTOGRAPHS Test engineer:Raimund BLASKReport Number:F113539E1 Date of issue:30November 2011Order Number:11-113539page3 of 3 113539emi3.JPG: Test set-up finalradiated emission (H-Field)

Contact Information

Applicant

Robin -- Rocco(Quality Engineering Manager)
[email protected]801-993-1323Fax: 800-775-7625

Test Firm

PHOENIX TESTLAB GmbHHolger Bentje
[email protected]49-5235-9500-24Fax: 49-5235-9500-28

Technical Specifications

#Rule PartsFrequency RangePower Output
115C0.457 MHz - 0.457 MHz-
Confidentiality
Long Term
