RFD-BTWCOBT/WLAN module

TIWI Transceiver Module / User’s Guide Version: 1.0 Author: Path: Christian Gerber Date Page Date of version: 24.04.2015 15_TIWI UserMan.docx 09.04.2015 1 of 7 TIWI Transceiver Module User’s Guide Internal Use only Last Update 24.04.2015 TIWI Transceiver Module / User’s Guide Version: 1.0 Author: Path: Christian Gerber Date Page Date of version: 24.04.2015 15_TIWI UserMan.docx 09.04.2015 2 of 7 Contents TIWI Transceiver Module .........................................................................................................................1 1 Introduction ......................................................................................................................................3 1.1 Purpose & Scope ......................................................................................................................3 1.2 Audience ...................................................................................................................................3 1.3 Revision History ........................................................................................................................3 2 Description .......................................................................................................................................3 2.1 Features ....................................................................................................................................3 2.2 Integration of the TIWI Module ...............................................................................................4 3 EMC Compliance Application Guide .................................................................................................4 3.1 Introduction ..............................................................................................................................4 3.2 Module Integration Considerations – Antenna Systems ..........................................................4 3.3 Module Integration Considerations – Firmware ......................................................................4 3.4 Testing Requirements for End-Product ....................................................................................5 3.5 Marking Requirements for End-Product and Compliance Statements. ...................................5 3.5.1 Federal Communication Commission Interference Statement ....................................... 5 3.5.2 Industry Canada Statement ............................................................................................. 5 3.5.3 Responsibilities to comply with FCC and Industry Canada Regulations .......................... 6 3.5.4 End Product Labeling ....................................................................................................... 7 TIWI Transceiver Module / User’s Guide Version: 1.0 Author: Path: Christian Gerber Date Page Date of version: 24.04.2015 15_TIWI UserMan.docx 09.04.2015 3 of 7 1 Introduction 1.1 Purpose & Scope The purpose of this document is to provide details regarding the setup and use of the TIWI transceiver module in Leica Geosystems AG and Hexagon AB. This document will also present application guidance such that the module’s EMC compliance will not be degraded. This Document is for Internal use only. 1.2 Audience This document is intended to be read by engineers and technical management. A general knowledge of common engineering practices is assumed. 1.3 Revision History Version Document Changes Date of Release 1.0 First version 24.04.2015 2 Description The TIWI is a Bluetooth WLAN Module. The module HW is based on the TiWi-BLE module from LSR. The differences between the TiWi-BLE Module and the module from Leica is only the RF-parameters and the antenna that are used. 2.1 Features  IEEE 802.11b,g,n,d,e,i compliant  Typical WLAN Transmit Power: o 20.0dBm, 11 Mbps,CCK (b) o 14.5dBm, 54 Mbps,OFDM (g) o 12.5dBm, 65 Mbps,OFDM (n)  Typical WLAN Sensitivity: o -89dBm, 8% PER, 11 Mbps o -76dBm, 10% PER, 54 Mbps o -73dBm, 10% PER, 65 Mbps  Bluetooth 2.1+EDR, Power Class 1.5  Full support for BLE 4.0 and ANT  Miniature footprint: 18 mm x 13 mm  Low height profile: 1.9 mm  U.FL connector for external antenna  Terminal for PCB/Chip antenna feeds  Integrated band-pass filter  Modular certification allows reuse of LSR  SDIO Host data path interfaces  Bluetooth Advanced Audio Interfaces  Low power operation mode  RoHS compliant Installation TIWI Transceiver Module / User’s Guide Version: 1.0 Author: Path: Christian Gerber Date Page Date of version: 24.04.2015 15_TIWI UserMan.docx 09.04.2015 4 of 7 2.2 Integration of the TIWI Module Please look in to the datasheet from LSR. --> www.lsr.com (TiWi-BLE Module) Document Nr: 330-0087 3 EMC Compliance Application Guide 3.1 Introduction The TiWi module has been tested as Modular Radio in accordance with the FCC .The device has been tested to relevant FCC parts and the results of the testing may be found in the module’s test report. Since this module and its associated set of approved antenna has been certified as a Modular Radio, this allows to integrate this module into an end-product and only be responsible for the Unintentional Emissions levels produced by the product. The manufacturer of the module is the responsible for the compliance of the Intentional Emissions produced by the module, as long as, the recommendations presented in this application guide. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 3.2 Module Integration Considerations – Antenna Systems The module must be used with one of the approved antennas: Name Technology Frequency Peak Gain Connector BTFA-2450 Inverted-F 2.4 – 2.5GHz 2 dBi U.FL The antennas should place such that they are minimally disturbed by the product’s packaging mater…

Text truncated - open the document above for the full version.

Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Direct Phone: +41 71 727 3098 Phone +41 71 727 31 31 E-Mail: [email protected] www.leica-geosystems.com FCC Heerbrugg, 22 December 2015 Federal Communications Commission Equipment Approval Services Post Office Box 358315 Pittsburg, PA 15262-0001 Request for Confidentiality Leica Geosystems AG - FCC-ID: RFD-BTWCO, FCC Part 15 Certification Gentlemen, In accordance with 0.459 of CFR 47, Leica Geosystems AG hereby requests confidentiality of -Operational Description (11_TIWI OpDes.pdf) -Block Diagrams (12_TIWI BlkDia.pdf) -Schematics (13_TIWI Schem.pdf) -Parts List (16_TIWI PartsLst.pdf) attachments for the subject application. These documents contain detailed system and equipment description and related information about the product which Leica Geosystems AG considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. There are special tools necessary to open the products and the internal design is not publicly accessible. Since the design is a basis from which future technological products will evolve, Leica Geosystems AG considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Hannes Juen Christian Gerber Manager Quality Engineering R&D Electronics Design Leica Geosystems AG Leica Geosystems AG

Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Direct Phone: +41 71 727 3098 Phone +41 71 727 31 31 E-Mail: [email protected] www.leica-geosystems.com FCC Heerbrugg, 22 December 2015 Federal Communications Commission Equipment Approval Services Post Office Box 358315 Pittsburg, PA 15262-0001 Short Term Confidentiality Request for the mobile device "TIWI" FCC ID: RFD-BTWCO Gentlemen In accordance with 0.457 and 0.459 of CFR 47, Leica Geosystems AG hereby requests for ‘Short Term Confidentiality’ of all -External Photos (08_TIWI ExtPho.pdf) -Internal Photo (09_TIWI IntPho.pdf) -Test set-up photos (10_TIWI TSup.pdf) -User manual (15_TIWI_UserMan.pdf) attachments for the subject application. These documents contain detailed system and equipment description and related information about the product which Leica Geosystems AG considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, Leica Geosystems AG considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Please contact us if you have any additional questions. Best regards Hannes Juen Christian Gerber Manager Quality Engineering R&D Electronics Design Leica Geosystems AG Leica Geosystems AG

Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Direct Phone: +41 71 727 3098 Phone +41 71 727 31 31 E-Mail: [email protected] www.leica-geosystems.com Modular Approval Request Letter Date: 2015-05-12 FCC ID: RFD-BTWCO Type of Equipment: Modular Transmitter The following requirements according to FCC Part 15.212 are met: i RF shielding The radio portion has his own shielding (see external photos). ii Buffered modulation/data inputs, has been integrated in the chipset iii Power supply regulation, is integrated iv Antenna requirements section 15.203, 15.204 b and 15.204 c The module comes with one permanently attached antenna. The spurious emission requirements are fulfilled (see attached test report). v Stand alone test configuration Please referring to test set up configuration photo vi Labelling The module has its own label. The instruction for labelling rules for the host device has been stated in the users manual vii Compliance on specific rule or operating requirements The required FCC rules has been fulfilled and all instructions for maintaining compliance has been clearly stated in the users manual viii RF Exposure, RF exposure requirements are fulfilled for mobile configuration. The installation of the module is restricted to mobile host devices what is clearly stated in the installation instruction of the user manual. For portable applications OEM integrators need SAR evaluation and an own FCC ID. Christian Gerber R&D Electronics Design Leica Geosystems AG

External Photos page 1 Model No.: TiWi-BLE FCC ID: RFD-BTWCO IC: 3177A-BTWCO Project No.: G0M-1410-4214 TiWi-BLE module mounted on evaluation board Module External Photos page 2 Model No.: TiWi-BLE FCC ID: RFD-BTWCO IC: 3177A-BTWCO Project No.: G0M-1410-4214 TiWi-BLE module mounted on evaluation board, power su pply and antenna Module Antenna

Label Sample / Location page 1 Model No.: TiWi-BLE FCC ID: RFD-BTWCO IC: 3177A-BTWCO Project No.: G0M-1410-4214 TiWi-BLE module mounted on evaluation board

Internal Photos page 1 Model No.: TiWi-BLE FCC ID: RFD-BTWCO IC: 3177A-BTWCO Project No.: G0M-1410-4214

Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Direct Phone: +41 71 727 4116 Phone +41 71 727 31 31 E-Mail: [email protected] www.leica-geosystems.com Declaration concerning Antenna Specification It is hereby declared that the product Model No.: TIWI FCC ID: RFD-BTWCO fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type described below: Model No. of antenna: BTFA-2450 Type of antenna: inverted-F Peak Gain of the antenna: 2 dBi Frequency range: 2400 - 2500 MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Leica Geosystems AG Address: Heinrich-Wild-Strasse City: Heerbrugg ZIP / Postal code: 8408 Country: Switzerland Place: Heerbrugg Date: 12.05.2015 Signature:

Test Report No.: G0M-1410-4214-TFC091ME-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 15 RF-EXPOSURE ASSESSMENT REPORT FCC 47 CFR Part 2.1091 Industry Canada RSS-102 RF-Exposure evaluation of mobile equipment Report Reference No. ..................... : G0M-1410-4214-TFC091ME-V01 Testing Laboratory ......................... : Eurofins Product Service GmbH Address............................................. : Storkower Str. 38c 15526 Reichenwalde Germany Accreditation ..................................... : A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Filed Test Laboratory, Reg.-No.: 96970 IC OATS Filing assigned code: 3470A Applicant’s name ............................ : Leica Geosystems AG Address............................................. : Heinrich Wild Strasse 9435 Heerbrugg SWITZERLAND Test specification: Standard ........................................... : 47 CFR 1.1310 / 47 CFR 2.1091 / 47 CFR 2.1093 OET Bulletin 65:1997 RSS-102, Issue 5:2015-03 Safety Code 6:2015-03 Equipment under test (EUT): Product description Bluetooth, WLAN and BLE Modul Model No. TiWi-BLE Additional Model(s) None Brand Name(s) Leica Geosystems Hardware version None Firmware / Software version None FCC-ID: RFD-BTWCO IC: 3177A-BTWCO Test result Passed Test Report No.: G0M-1410-4214-TFC091ME-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 15 Version History Version Issue Date Remarks Revised by 01 2015-05-12 Initial Release Test Report No.: G0M-1410-4214-TFC091ME-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 15 REPORT INDEX 1 EQUIPMENT (TEST ITEM) DESCRIPTION 5 1.1 Reference Documents 6 1.2 Standalone Radiation Sources 7 1.3 Multi-transmitter Modes 8 2 RESULT SUMMARY 9 3 RF-EXPOSURE CLASSIFICATIONS 10 4 ASSESSMENT 11 4.1 MPE Assessment – 47 CFR 2.1091 / RSS-102 11 Test Report No.: G0M-1410-4214-TFC091ME-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 15 1 Equipment (Test item) Description Description Bluetooth, WLAN and BLE Modul Model TiWi-BLE Additional Model(s) None Brand Name(s) Leica Geosystems Serial number None Hardware version None Software / Firmware version None FCC-ID RFD-BTWCO IC 3177A-BTWCO Equipment type Radio module Test Report No.: G0M-1410-4214-TFC091ME-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 15 1.1 Reference Documents Document type Document No. Issued by Date FCC 15.247 Bluetooth LE Test Report G0M-1410-4214-TFC247BL-V01 Eurofins Product Service GmbH 2015-05-12 FCC 15.247 Bluetooth Test Report G0M-1410-4214-TFC247BT-V01 Eurofins Product Service GmbH 2015-05-12 FCC 15.247 WLAN Report G0M-1410-4214-TFC247WF-V01 Eurofins Product Service GmbH 2015-05-12 Test Report No.: G0M-1410-4214-TFC091ME-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 15 1.2 Standalone Radiation Sources Mode # Description Bluetooth LE Frequency range [MHz] 2402 – 2480 Channels 40 Transmission modes GFSK Modulations GFSK Maximum radiated power [dBm] 11.5 Maximum transmission duty cycle [%] 100% (worst case assessment) Antenna gain [dBi] 2.0 Antenna diameter [cm] 3.5 Bluetooth Frequency range [MHz] 2402 – 2480 Channels 79 Transmission modes DH5, 2-DH5, 3-DH5 Modulations GFSK, PI/4-DQPSK, 8-DPSK Maximum radiated power [dBm] 10.2 Maximum transmission duty cycle [%] 78 Antenna gain [dBi] 2.0 Antenna diameter [cm] 3.5 WLAN 2.4 GHz Frequency range [MHz] 2412 – 2462 Channels 11 Transmission modes DSSS, OFDM, HT-20, HT-40 Modulations BPSK, QPSK, 16-QAM, 64-QAM Maximum radiated power [dBm] 27.5 Maximum transmission duty cycle [%] 100 Antenna gain [dBi] 2.0 Antenna diameter [cm] 3.5 Test Report No.: G0M-1410-4214-TFC091ME-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 8 of 15 1.3 Multi-transmitter Modes None Test Report No.: G0M-1410-4214-TFC091ME-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 9 of 15 2 Result Summary FCC 47 CFR Part 2.1091, IC RSS-102 Product Specific Standard Section Requirement Result Remarks 47 CFR 2.1091 Maximum permissible exposure @ 20cm below limit PASS RSS-102 2.5.2 Maximum permissible exposure @ 20cm below limit PASS Remarks: Test Report No.: G0M-1410-4214-TFC091ME-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 10 of 15 3 RF-Exposure Classifications Device Types Fixed A fixed device is defined as a device physically secured at one fixed location and cannot be easily re-located. Mobile A mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating structure(s) and the body of the user or nearby persons. (47 CFR 2.1091) Portable A portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. (47 CFR 2.1093) Exposure Categories Occupational / Controlled Limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when an individual is transient through a location where occupational/controlled limits apply provided he or she is made aware of the potential for exposure. General population / uncontrolled Exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or cannot exercise control over their exposure. Test Report No.: G0M-1410-…

Text truncated - open the document above for the full version.

Test Report No.: G0M-1410-4214-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 92 FCC TEST REPORT FCC 47 CFR Part 15C Industry Canada RSS-210 Digital transmission systems operating within the 2400 – 2483.5 MHz band Report Reference No. ..................... : G0M-1410-4214-TFC247BL-V01 Testing Laboratory ......................... : Eurofins Product Service GmbH Address............................................. : Storkower Str. 38c 15526 Reichenwalde Germany Accreditation ..................................... : A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Filed Test Laboratory, Reg.-No.: 96970 IC OATS Filing assigned code: 3470A Applicant’s name ............................ : Leica Geosystems AG Address............................................. : Heinrich Wild Strasse 9435 Heerbrugg SWITZERLAND Test specification: Standard ........................................... : 47 CFR Part 15C KDB Publication No. 558074 RSS-210, Issue 8, 2010-12 RSS-Gen, Issue 4, 2014-11 ANSI C63.4:2009 Test scope.............. ........................ : complete Radio compliance test Equipment under test (EUT): Product description Bluetooth, WLAN and BLE Modul Model No. TiWi-BLE Additional Model(s) None Brand Name(s) Leica Geosystems Hardware version 1.0 Firmware / Software version 4.0 FCC-ID: RFD-BTWCO IC: 3177A-BTWCO Test result Passed Test Report No.: G0M-1410-4214-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 92 Version History Version Issue Date Remarks Revised by 01 2015-05-12 Initial Release Test Report No.: G0M-1410-4214-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 92 REPORT INDEX 1 EQUIPMENT (TEST ITEM) DESCRIPTION 5 1.1 Photos – Equipment External 6 1.2 Photos – Equipment internal 8 1.3 Photos – Test setup 10 1.4 Supporting Equipment Used During Testing 12 1.5 Test Modes 13 1.6 Test Equipment Used During Testing 14 1.7 Sample emission level calculation 16 2 RESULT SUMMARY 17 3 TEST CONDITIONS AND RESULTS 18 3.1 Test Conditions and Results – Occupied Bandwidth 18 3.2 Test Conditions and Results – 6 dB Bandwidth 22 3.3 Test Conditions and Results – Maximum peak conducted power 26 3.4 Test Conditions and Results – Power spectral density 27 3.5 Test Conditions and Results – AC power line conducted emissions 28 3.6 Test Conditions and Results – Band edge compliance 31 3.7 Test Conditions and Results – Conducted spurious emissions 34 3.8 Test Conditions and Results – Transmitter radiated emissions 38 3.9 Test Conditions and Results – Receiver radiated emissions 41 ANNEX A Transmitter radiated spurious emissions 43 ANNEX B Receiver radiated spurious emissions 85 Test Report No.: G0M-1410-4214-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 92 1 Equipment (Test item) Description Description Bluetooth, WLAN and BLE Modul Model TiWi-BLE Additional Model(s) None Brand Name(s) Leica Geosystems Serial number None Hardware version 1.0 Software / Firmware version 4.0 FCC-ID RFD-BTWCO IC 3177A-BTWCO Equipment type Radio module Radio type Transceiver Radio technology Bluetooth 4.0 Low Energy Operating frequency range 2402 - 2480 MHz Assigned frequency band 2400 - 2483.5 MHz Main test frequencies F LOW 2402 MHz F MID 2440 MHz F HIGH 2480 MHz Spreading Frequency Hopping Modulations GFSK Number of channels 40 Channel spacing 2MHz Number of antennas 1 Antenna Type Inverted - F antenna Model BTFA-2450 Manufacturer INWAVE Gain 2.0 dBi (customer declaration) Manufacturer Leica Geosystems AG Heinrich Wild Strasse 9435 Heerbrugg SWITZERLAND Power supply V NOM 3.6 VDC AC/DC-Adaptor Model MW 3R15GS Vendor Stabi-Net Input 100-240 V / 50-60 Hz / 0.35A Output 6 VDC Test Report No.: G0M-1410-4214-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 12 of 92 1.4 Supporting Equipment Used During Testing Product Type* Device Manufacturer Model No. Comments AE Laptop Lenovo T540p Test mode software *Note: Use the following abbreviations: AE : Auxiliary/Associated Equipment, or SIM : Simulator (Not Subjected to Test) CABL : Connecting cables Test Report No.: G0M-1410-4214-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 13 of 92 1.5 Test Modes Mode # Description Transmit General conditions: EUT powered by laboratory power supply. Radio conditions: Mode = standalone transmit Spreading = Hopping stopped (single hopping channel) Modulation = GFSK Data rate = 1 Mbps Bandwidth = 2 MHz Duty cycle = 100 % Power level = 15 (Test mode setting) Receive General conditions: EUT powered by laboratory power supply. Radio conditions: Mode = standalone receive (scan mode) Spreading = On Modulation = GFSK AC-Powerline General conditions: EUT powered by commercial AC/DC-adaptor Radio conditions: Mode = Transmit Spreading = On Test Report No.: G0M-1410-4214-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 14 of 92 1.6 Test Equipment Used During Testing Measurement Software Description Manufacturer Name Version EMC Test Software Dare Instruments Radimation 2014.1.15 Occupied Bandwidth Description Manufacturer Model Identifier Cal. Date Cal. Due Spectrum Analyzer R&S FSP 30 EF00312 2014-02 2015-02 6dB Bandwidth Description Manufacturer Model Identifier Cal. Date Cal. Due Spectrum Analyzer R&S FSP 30 EF00312 2014-02 2015-02 Maximum peak conducted power Description Manufacturer Model Identifier Cal. Date Cal. Due Spectrum Analyzer R&S FSP 30 EF00312 2014-02 2015-02 Power spectral density Description Manufacturer Model Identifier Cal. Date Cal. Due Spectrum Analyzer R&S FSP 30 EF00312 2014-02 2015-02 Band edge compliance Description Manufacturer Model Identifier Cal. Date Cal. Due Spectrum Analyzer R&S FSP 30 EF00312 2014-02 2015-02 Conducted spurious emissions Description Manu…

Text truncated - open the document above for the full version.

Test Report No.: G0M-1410-4214-TFC247WF-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 133 FCC TEST REPORT FCC 47 CFR Part 15C Industry Canada RSS-210 Digital transmission systems operating within the 2400 – 2483.5 MHz band Report Reference No. ..................... : G0M-1410-4214-TFC247WF-V01 Testing Laboratory ......................... : Eurofins Product Service GmbH Address............................................. : Storkower Str. 38c 15526 Reichenwalde Germany Accreditation ..................................... : A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Filed Test Laboratory, Reg.-No.: 96970 IC OATS Filing assigned code: 3470A Applicant’s name ............................ : Leica Geosystems AG Address............................................. : Heinrich Wild Strasse 9435 Heerbrugg SWITZERLAND Test specification: Standard ........................................... : 47 CFR Part 15C KDB Publication No. 558074 D01 v03r02 RSS-210, Issue 8, 2010-12 RSS-Gen, Issue 4, 2014-11 ANSI C63.4:2009 Test scope.............. ........................ : complete Radio compliance test Equipment under test (EUT): Product description Bluetooth, WLAN and BLE Modul Model No. TiWi-BLE Additional Model(s) None Brand Name(s) Leica Geosystems Hardware version 1.0 Firmware / Software version 4.0 FCC-ID: RFD-BTWCO IC: 3177A-BTWCO Test result Passed Test Report No.: G0M-1410-4214-TFC247WF-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 133 Version History Version Issue Date Remarks Revised by 01 2015-05-12 Initial Release Test Report No.: G0M-1410-4214-TFC247WF-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 133 REPORT INDEX 1 EQUIPMENT (TEST ITEM) DESCRIPTION 5 1.1 Photos – Equipment External 6 1.2 Photos – Equipment internal 8 1.3 Photos – Test setup 10 1.4 Supporting Equipment Used During Testing 12 1.5 Test Modes 13 1.6 Test Equipment Used During Testing 14 1.7 Sample emission level calculation 16 2 RESULT SUMMARY 17 3 TEST CONDITIONS AND RESULTS 18 3.1 Test Conditions and Results – Occupied Bandwidth 18 3.2 Test Conditions and Results – 6 dB Bandwidth 28 3.3 Test Conditions and Results – Maximum peak conducted power 38 3.4 Test Conditions and Results – Power spectral density 40 3.5 Test Conditions and Results – AC power line conducted emissions 41 3.6 Test Conditions and Results – Band edge compliance 44 3.7 Test Conditions and Results – Conducted spurious emissions 51 3.8 Test Conditions and Results – Transmitter radiated emissions 62 3.9 Test Conditions and Results – Receiver radiated emissions 64 ANNEX A Transmitter radiated spurious emissions 66 ANNEX B Receiver radiated spurious emissions 126 Test Report No.: G0M-1410-4214-TFC247WF-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 133 1 Equipment (Test item) Description Description Bluetooth, WLAN and BLE Modul Model TiWi-BLE Additional Model(s) None Brand Name(s) Leica Geosystems Serial number None Hardware version 1.0 Software / Firmware version 4.0 FCC-ID RFD-BTWCO IC 3177A-BTWCO Equipment type Radio module Radio type Transceiver Radio technology IEEE 802.11 b/g/n Operating frequency range 2412 - 2462 MHz Assigned frequency band 2400 - 2483.5 MHz Main test frequencies F LOW 2412 MHz F MID 2437 MHz F HIGH 2462 MHz Spreading CCK, DSSS, OFDM Modulations BPSK, QPSK, 16-QAM, 64-QAM Number of channels 11 Channel spacing 5MHz Number of antennas 1 Antenna Type inverted - F antenna Model BTFA-2450 Manufacturer INWAVE Gain 2.0 dBi (manufacturer declaration) Manufacturer Leica Geosystems AG Heinrich Wild Strasse 9435 Heerbrugg SWITZERLAND Power supply V NOM 3.6 VDC V MIN N/R V MAX N/R AC/DC-Adaptor Model MW 3R15GS Vendor Stabi-Net Input 100-240 V / 50-60 Hz / 0.35A Output 6 VDC Test Report No.: G0M-1410-4214-TFC247WF-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 12 of 133 1.4 Supporting Equipment Used During Testing Product Type* Device Manufacturer Model No. Comments AE Laptop Lenovo T540p Test mode software *Note: Use the following abbreviations: AE : Auxiliary/Associated Equipment, or SIM : Simulator (Not Subjected to Test) CABL : Connecting cables Test Report No.: G0M-1410-4214-TFC247WF-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 13 of 133 1.5 Test Modes Mode # Description DSSS General conditions: EUT powered by AC/DC adaptor Radio conditions: Mode = standalone transmit Spreading = DSSS Modulation = BPSK Data rate = 1 Mbps Bandwidth = 20 MHz Duty cycle = 99 % Power level = 17dBm OFDM General conditions: EUT powered by AC/DC adaptor Radio conditions: Mode = standalone transmit Spreading = OFDM Modulation = BPSK Data rate = 6 Mbps Bandwidth = 20 MHz Duty cycle = 99 % Power level = 15dBm HT20 General conditions: EUT powered by AC/DC adaptor Radio conditions: Mode = standalone transmit Spreading = OFDM Modulation = BPSK Data rate = 7.2 Mbps Bandwidth = 20 MHz Duty cycle = 99 % Power level = 15dBm Receive General conditions: EUT powered by AC/DC adaptor Radio conditions: Mode = standalone receive AC-Powerline General conditions: EUT powered by AC/DC adaptor Radio conditions: Mode = standalone transmit Spreading = DSSS Power level = 17dBm Test Report No.: G0M-1410-4214-TFC247WF-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 14 of 133 1.6 Test Equipment Used During Testing Measurement Software Description Manufacturer Name Version EMC Test Software Dare Instruments Radimation 2014.1.15 Occupied Bandwidth Description Manufacturer Model Identifier Cal. Date Cal. Due Spectrum Analyzer R&S FSP 30 EF00312 2014-02 2015-02 6dB Bandwidth Description Manufacturer Model Identifier Cal. Date Cal. Due Spectrum Analyzer R&S FSP 30 EF00312 2014-02 2015-02 Maximum peak conducted power Description Manufacturer Model Identifier Cal. Date Cal…

Text truncated - open the document above for the full version.

TSup Photos page 1 Model …
