RFD-CS-BGWin CE filed Controller

Leica CS10/CS15 User Manual Version 3.0 English 2 CS10/CS15, Introduction Introduction PurchaseCongratulations on the purchase of a Leica CS10/CS15. This manual contains important safety directions as well as instructions for setting up the product and operating it. Refer to "5 Safety Directions" for further informa- tion. Read carefully through the User Manual before you switch on the product. Product identifica- tion The type and serial number of your product are indicated on the type plate. Enter the type and serial number in your manual and always refer to this information when you need to contact your agency or Leica Geosystems authorised service work- shop. Type:_______________ Serial No.:_______________ CS10/CS15, Introduction3 SymbolsThe symbols used in this manual have the following meanings: TypeDescription  DangerIndicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.  WarningIndicates a potentially hazardous situation or an unintended use which, if not avoided, could result in death or serious injury.  CautionIndicates a potentially hazardous situation or an unintended use which, if not avoided, may result in minor or moderate injury and/or appreciable material, financial and environmental damage. ) Important paragraphs which must be adhered to in practice as they enable the product to be used in a technically correct and efficient manner. 4 CS10/CS15, Introduction Trademarks•Windows is a registered trademark of Microsoft Corporation in the United States and other countries •CompactFlash and CF are trademarks of SanDisk Corporation •Bluetooth is a registered trademark of Bluetooth SIG, Inc. •SD is a trademark of the SD Card Association All other trademarks are the property of their respective owners. Validity of this manual This manual applies to the CS10 and CS15 field controllers. Differences between the various models are marked and described. Available documentation NameDescription/Format CS10/CS15 User Manual All instructions required in order to operate the product to a basic level are contained in the User Manual. Provides an overview of the product together with tech- nical data and safety directions. 99 NameDescription/Format Viva GNSS Getting Started Guide Describes the general working of the product in standard use. Intended as a quick reference field guide. 99 CS10/CS15, Introduction5 Refer to the following resources for all CS10/CS15 documentation/software: •the Leica Viva Series DVD •https://myworld.leica-geosystems.com myWorld@Leica Geosystems (https://myworld.leica-geosystems.com) offers a wide range of services, information and training material. With direct access to myWorld, you are able to access all relevant services whenever it is convenient for you, 24 hours a day, 7 days per week. This increases your effi- ciency and keeps you and your equipment instantly updated with the latest informa- tion from Leica Geosystems. Viva TPS Getting Started Guide Describes the general working of the product in standard use. Intended as a quick reference field guide. 99 Viva Series Technical Reference Manual Overall comprehensive guide to the product and appli- cation functions. Included are detailed descriptions of special software/hardware settings and software/hard- ware functions intended for technical specialists. 9 NameDescription/Format 6 CS10/CS15, Introduction ServiceDescription myProductsSimply add all Leica Geosystems products that you and your company own. View detailed information on your products, buy additional options or Customer Care Packages (CCPs), update your products with the latest software and keep up-to-date with the latest documentation. myServiceView the service history of your products in Leica Geosystems Service Centers and detailed information on the services performed on your products. For your products that are currently in Leica Geosystems Service Centers view the current service status and the expected end date of service. mySupportCreate new support requests for your products that will be answered by your local Leica Geosystems Support Team. View the complete history of your Support and view detailed information on each request in case you want to refer to previous support requests. myTrainingEnhance your product knowledge with the Leica Geosystems Campus - Information, Knowledge, Training. Study the latest online training material or download training material on your products. Keep up-to-date with the latest News on your products and register for Seminars or Courses in your country. CS10/CS15, Table of Contents7 Table of Contents In this manualChapterPage 1 Description of the System 11 1.1 Overview11 1.2 Terminology12 1.3 System Concept14 1.3.1Software Concept14 1.3.2Power Concept18 1.3.3Data Storage Concept19 1.4 CS Components21 1.4.1CS10 21 1.4.2CS15 23 1.5 Docking Station Components25 2 User Interface 26 2.1 Keyboard26 2.2 Operating Principles32 3Operation 33 3.1 Equipment Setup33 8 CS10/CS15, Table of Contents 3.1.1Fixing the Display Foil to the CS 33 3.1.2Fixing a Hand Strap to the CS 35 3.1.3Fixing the Slot Cover to the CS 37 3.1.4Inserting and Removing a SIM Card38 3.1.5Setting up as Handheld GNSS 40 3.1.6Setting up the Docking Station42 3.1.7Connecting to a Personal Computer43 3.2 Power Functions49 3.3 Batteries51 3.3.1Operating Principles51 3.3.2Changing the Battery52 3.3.3Charging the Battery55 3.4 Working with the Memory Device57 3.5 LED Indicators on CS10 /CS15 61 3.6 LED Indicators on GS08 /GS12 64 3.7 Using the Digital Camera66 4 Care and Transport 68 4.1 Transport68 4.2 Storage69 4.3 Cleaning and Drying70 CS10/CS15, Table of Contents9 5 Safety Directions 72 5.1 General Introduction72 5.2 Intended Use73 5.3 Limits of Use75 5.4 Responsibilities76 5.5 Hazards of Use78 5.6 Electromagnetic Compatibility EMC84 5.7 FCC Statement, Applicable in U.S.87 6 Technical Data 92 6.1 CS10 /CS15 Technical Data92 6.2 GS05 /GS06 Technical Data97 6.2.1Tracking Characteristics97 6.2.2Accur…

Text truncated - open the document above for the full version.

30.07.2010 Page 1 17_CS15 AntSpec.doc [email protected] Antenna Specification for CS15 FCC-ID: RFD-CS-BG Antenna for PAN1310 Bluetooth Module FCC-ID: Q23-31308 2450 MHz AntennaP/N 2450AT18B100 Detail Specification: 06/12/06 Page 1 of 3 General Specifications Part Number2450AT18B100Input Power3W max. Frequency Range2400 - 2500 MhzImpedance50 ! Peak Gain0.5 dBi typ. (XZ-V)Operating Temperature-40 to +85°C Average Gain-0.5 dBi typ. (XZ-V)Reel Quanity3,000 Return Loss9.5 dB min. Terminal Configuration Packaging BulkSuffix = SEg. 2450AT18B100S No. Function P/N Style T & RSuffix = EEg. 2450AT18B100E 1 Feeding Point Suffix Termination 100% TinSuffix = NoneEg. 2450AT18B100(E or S) 2 NC Style Tin / Lead Mechanical Dimensions Inmm L±± W±± T a±± Mounting Considerations Mount these devices with brown mark facing up. Units: mm Line width should be designed to provide 50 ! impedance matching characteristics. a) Without Matching Circuits b) With Matching Circuits Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. www.johansontechnology.com 931 Via Alondra • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 2003 Johanson Technology, Inc. All Rights Reserved 0.051 Please consult Factory 0.0120.020 1.30 0.30 +.004/-.008+0.1/-0.2 "High Frequency Ceramic Solutions" 0.50 0.1260.0083.200.20 0.0630.0081.600.20 12 L W a T ) Matching Component JTI P/Ns: L-14C2N7JV4 L-14C2N2JV4 * 2.6 4.2 1.6 1.9 0.4 2.7nH 1.2pF 3.3nH 2450 MHz AntennaP/N 2450AT18B100 Detail Specification: 06/12/06 Page 2 of 3 Typical Electrical Characteristics (T=25 o C) Test Board: Return Loss a) With Matching Circuita) With Matching Circuit Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. www.johansontechnology.com 931 Via Alondra • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 2003 Johanson Technology, Inc. All Rights Reserved "High Frequency Ceramic Solutions" ) ) ) ) ) ) ) ) ) Ground 13.5mm 6.5mm 39.5mm 6.5mm Matching Circuit No Ground 50! Feed Line Antenna 19mm 2450 MHz AntennaP/N 2450AT18B100 Detail Specification: 06/12/06 Page 3 of 3 Typical Radiation Patterns Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. www.johansontechnology.com 931 Via Alondra • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 2003 Johanson Technology, Inc. All Rights Reserved "High Frequency Ceramic Solutions" ) ) ) ) ) ) ) ) ) Antenna for UC864-G Module FCC-ID: RI7UC864G Datasheet, Part Nr. 766 808, Page 1 GSM / UMTS Quad Band Antenna Part Nr. 766 808 Electrical Characteristics Description Value Comment Frequency Bands 824 - 960 MHz @ 6 dB min. return loss 1720 – 2170 MHz @ 6 dB min. return loss Return Loss See Fig. 1 Impedance 50 ohm Gain total max. low band 2.0 dBi See Table 1 Polarization low band See Fig. 2 Antenna Characteristic Omni directional See Fig. 2 Gain total max. high band 1.0 dBi See Table 2 Polarization high band See Fig. 3 Antenna Characteristic Omni directional See Fig. 3 Power Dissipation 3 W max. Operation Temperature - 40 °C to + 85 °C Surface CuSn6 tin plated ROHS compliant Datasheet, Part Nr. 766 808, Page 2 Dimensions [mm] Fig.1 Return Loss dB 6 4 2 0 -2 -4 -6 -8 -10 -12 -14 CS15 SNr. 1590119 GSM Antenna S11 Start: 500.000000 MHzStop: 2.500000 GHz 27.10.2009 15:38:36HP8510BGSM.spt 1 1 S11 825.000000 MHz -7.8183 dB 2 2 S11 960.000000 MHz -8.6495 dB 3 3 S11 1.720000 GHz -9.5100 dB 4 4 S11 2.170000 GHz -6.7287 dB Datasheet, Part Nr. 766 808, Page 3 Table 1 Gain @ 885 MHz Fig. 2 Characteristic @ 885 MHz Measured @ 885 MHz in CS15 Ground plane = 30° tilted Orientation: Gain vertical max -9.0 dBi Gain vertical avg. -10.5 dBi Gain horizontal max 2.0 dBi Gain horizontal avg. -3.5 dBi Gain total max 2.0 dBi Gain total avg. -3.5 dBi Table 2 Gain @ 1934 MHz Fig. 3 Characteristic @ 1934 MHz Measured @ 1934 MHz in CS15 Ground plane = 30° tilted Orientation: Gain vertical max -1.5 dBi Gain vertical avg. -6.0 dBi Gain horizontal max 0.0 dBi Gain horizontal avg. -4.5 dBi Gain total max 1.0 dBi Gain total avg. -2.5 dBi 0 30 60 90 120 150 180 210 240 270 300 330 20! 18! 16! 14! 12! 10! 8! 6! 4! 2! 0 2 Horizontal Vertical Total 0 30 60 90 120 150 180 210 240 270 300 330 20! 18! 16! 14! 12! 10! 8! 6! 4! 2! 0 2 Horizontal Vertical Total Antenna for ConnectBlue OWLAN211b/g WLAN Module FCC-ID: PVH-090901 Version 1.11 - 2007-10 17 3 Antenna Information There are 2 different antenna options available: • An internal surface mounted (SMD) antenna. • Two U.FL connectors for external antenna. Different types of external antennas are available. See section 4.1 for more information on antenna placement. This chapter gives a quality overview of the different antenna options. 3.1 Surface Mounted Antenna (internal) The unit cannot be mounted in a metal-shielded enclosure with this antenna. Part Number OWLAN211gi Antenna name FR05-01-N Manufacture Fractus Polarization Linear Gain (Typ) 1.1 dBi Antenna Size (LxWxH) 6.7 x 6.7 x 1 mm Comment The antenna gain is dependent of the mounting of the module. See section 4.4 for mounting the module considering the antenna.

Test Report No.: G0M21007-3512-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Annex A Photos of the EUT EUT Front EUT Back Page 17 of 81 Test Report No.: G0M21007-3512-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany EUT Top EUT Bottom Page 18 of 81

Label Sample CS15 Page 1/1 Leica Geosystems AG – [email protected] 04.09.2010 06_CS15 LabelSmpl.ppt CS15 767871 RFD-CS-BG

Test Report No.: G0M21007-3512-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany EUT PCB 1 EUT PCB Page 19 of 81 Test Report No.: G0M21007-3512-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany EUT PCB 2 EUT PCB 2 Page 20 of 81 Test Report No.: G0M21007-3512-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany EUT Module FRONT with shielding EUT PCB 2 without shielding Page 21 of 81

EUROFINS PRODUCT SERVICE GMBH SAR TEST - REPORT SAR Compliance Test Report Test report no.: G0M21007-3512-S-1 Field Controller CS15 FCC-ID: RFD-CS-S-BG Eurofins Product Service GmbH Storkower Str. 38c, 15526 Reichenwalde, Phone +49-33631-888 0 Germany Fax +49-33631-888 660 Test Report No.: G0M21007-3512-S-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany TABLE OF CONTENTS 1 General information 3 1.1 Notes 3 1.2 Testing laboratory 4 1.3 Details of approval holder 4 1.4 Manufacturer 5 1.5 Application details 5 1.6 Test item 5 1.7 Test results 6 1.8 Test standards 6 2 Technical test 7 2.1 Summary of test results 7 2.2 Test environment 7 2.3 Test equipment utilized 8 2.4 Definitions 9 2.5 Measurement system description 10 2.6 Test system specification 15 2.7 Measurement procedure 16 2.8 Reference points 17 2.9 Test positions 19 2.10 Measurement uncertainty 23 3 Tissue and system verification 24 3.1 Tissue verification 24 3.2 System verification 25 4 Test Results 26 5 Transmitter co-location performance evaluation 29 6 References 32 7 Annex 33 Page 2 of 115 Test Report No.: G0M21007-3512-S-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.2 Testing laboratory 1.2.1 Location EUROFINS PRODUCT SERVICE GMBH Storkower Straße 38c D-15526 Reichenwalde b. Berlin Germany Telephone : +49 33631 888 00 Fax : +49 33631 888 660 1.2.2 Details of accreditation status DAR ACCREDITED TESTING LABORATORY DAR-R EGISTRATION NUMBER: DAT-P-268/08 R ECOGNIZED NOTIFIED BODY EMC R EGISTRATION NUMBER: BNetzA-bS EMV-07/61 R ECOGNIZED NOTIFIED BODY R&TTE R EGISTRATION NUMBER: BNetzA-bS-02/51-53 FCC FILED TEST LABORATORY R EG.-NO. 96970 A2LA ACCREDITED TESTING LABORATORY C ERTIFICATE NO. 1983.01 B LUETOOTH QUALIFICATION TEST FACILITY (BQTF) A CCREDITED BY BLUETOOTH QUALIFICATION REVIEW BOARD I NDUSTRY CANADA FILED TEST LABORATORY R EG. NO. IC 3470 Statement: The tests documented within this report are carried out in accordance with the scope of accreditation of test laboratory Eurofins Product Service GmbH. 1.3 Details of approval holder Name : Leica Geosystems AG Street : Heinrich Wild Strasse 1 Town : CH-9435 Heerbrugg Country : Switzerland Telephone : +41 71 727 3098 Fax : +41 71 726 5098 Contact : Herr Hannes Juen E-Mail : [email protected] Page 4 of 115 Test Report No.: G0M21007-3512-S-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.4 Manufacturer: (if applicable) Name : Street : Town : Country : 1.5 Application details Date of receipt of application : 26.07.2010 Date of receipt of test item : 26.07.2010 Date of test : 17.08.2010 - 25.08.2010 1.6 Test item FCC ID : RFD-CS-S-BG Description of test item : Field Controller Type identification : CS15 Serial number : without; Identical prototype Device category : PCT (Licensed Portable Transmitter Worn On Body) Technical data UMTS Frequency range : Operation Band V Operation Band II TX Frequency range : 824 - 849MHz 1850 - 1910 MHz RX Frequency range : 869 - 894MHz 1930 - 1990 MHz Max. rad. RF output power : 23.93 (0.25 W) 23.48 (0.22 W) GSM / PCS / EGPRS Frequency range : GSM 850 / EGPRS PCS 1900 / EGPRS TX Frequency range : 824.2 - 848.8 MHz 1850.2 - 1909.9 MHz RX Frequency range : 869.2 - 893.8 MHz 1930.2 - 1989.8 MHz Max. rad. RF output power : 33.07 dBm (2.03 W) 29.28 dBm (0.85 W) WLAN TX / RX Frequency range : 2400,0 - 2483,5 MHz Tested Frequency : Ch.6 2437,0 MHz Max.rad. RF output power : 20.60 dBm (0.11 W) Page 5 of 115 Test Report No.: G0M21007-3512-S-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Power supply : 7.4VDC rechargeable battery Antenna Tx : integral Antenna RX : integral Additional information : Tx and Rx. antenna are the same. This test sample was tested according FCC OET Bulletin 65, Supplement C, Edition 01-01 on the used Frequency band.. 1.7 Test Results Max. SAR Measurement UMTS Band V (Body) : 0.248mW/g (averaged over 1 gram) Max. SAR Measurement UMTS Band II (Body) : 0.416 mW/g (averaged over 1 gram) Max. SAR Measurement GPRS/EGPRS 850 (Body) : 0.800 mW/g (averaged over 1 gram) Max. SAR Measurement GPRS/EGPRS 1900 (Body) : 0.248 mW/g (averaged over 1 gram) Max. SAR Measurement WLAN (Body) : 0.162 mW/g (averaged over 1 gram) This EUT has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-2003, December 2003. 1.8 Test standards Standards : - IEEE Std. 1528-2003, December 2003 FCC Rule Part(s) : - FCC OET Bulletin 65, Supplement C, Edition 01-01 Page 6 of 115 Test Report No.: G0M21007-3512-S-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 2 Technical test 2.1 Summary of test results Applicable Configuration Handset (Head) Handset (Body) Headset (Head) Body Worn Equipment X EUT complies with the RF radiation exposure limits of the FCC as shown by the SAR measurement results. These measurements are taken to simulate the RF effects exposure under worst-case conditions. The EUT complies with the requirements in respect to all parameters subject to the test. The test results and statements relate only to the item(s) tested. Please note that the absorption and distribution of electromagnetic energy in the body are very complex phenomena that depend on the mass, shape, and size of the body, the orientation of the body with respect to the field vectors, and the electrical properties of both the body and the environment. Other variables that may play a substantial role in possible biological effects are those that characterize the environment (e.g. ambient temperature, air velocity, relative humidity, and body insulation) and those that characterize the individual (e.g. age, gender, activity level, debili…

Text truncated - open the document above for the full version.

EUROFINS PRODUCT SERVICE GMBH Testing Cert 1983.01 TEST - REPORT FCC RULES PARTS 22H and 24E and 27C IC RADIO STANDARDS RSS 132, RSS 133 and RSS-139 for UMTS FCC ID: RFD-CS-BG Field Controller CS15 Test report no.: G0M21007-3512-C-1 Eurofins Product Service GmbH Storkower Str. 38c, 15526 Reichenwalde, Phone +49-33631-888 0 Germany Fax +49-33631-888 660 Test Report No.: G0M21007-3512-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany TABLE OF CONTENTS 1 General information 3 1.1 Notes 3 1.2 Testing laboratory 4 1.3 Details of approval holder 4 1.4 Application details 5 1.5 Test item 5 1.6 Test standards 6 2 Technical test 6 2.1 Summary of test results 6 2.2 Test environment 6 2.3 Test equipment utilized 7 2.4 General test procedure 8 2.5 Test results 9 3 Transmitter parameters 10 3.1 RF power output radiated (ERP, EIRP) 11 3.2 Spurious emission radiated 13 4 Receiver parameters 15 4.1 Spurious emission radiated 15 Annex A Pictures 17 Annex B RF power output radiated 23 Annex C Transmitter spurious emission radiated 36 Annex D Receiver spurious emission radiated 73 Page 2 of 81 Page 3 of 81 Test Report No.: G0M21007-3512-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.2 Testing laboratory 1.2.1 Location EUROFINS PRODUCT SERVICE GMBH Storkower Strasse 38c D-15526 Reichenwalde b. Berlin Germany Telephone : +49 33631 888 00 Telefax : +49 33631 888 660 1.2.2 Details of accreditation status DAR ACCREDITED TESTING LABORATORY DAR-R EGISTRATION NUMBER: DAT-P-268/08 R ECOGNIZED NOTIFIED BODY EMC R EGISTRATION NUMBER: BNetzA-bS EMV-07/61 R ECOGNIZED NOTIFIED BODY R&TTE R EGISTRATION NUMBER: BNetzA-bS-02/51-53 FCC FILED TEST LABORATORY R EG.-NO. 96970 A2LA ACCREDITED TESTING LABORATORY C ERTIFICATE NO. 1983.01 B LUETOOTH QUALIFICATION TEST FACILITY (BQTF) A CCREDITED BY BLUETOOTH QUALIFICATION REVIEW BOARD I NDUSTRY CANADA FILED TEST LABORATORY R EG. NO. IC 3470 1.3 Details of approval holder Name : Leica Geosystems AG Street : Heinrich Wild Strasse 1 Town : CH-9435 Heerbrugg Country : Switzerland Telephone : +41 71 727 3098 Fax : +41 71 726 5098 Contact : Herr Hannes Juen E-Mail : +41 71 727 3098 Page 4 of 81 Test Report No.: G0M21007-3512-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.4 Application details Date of receipt of application : 26.07.2010 Date of receipt of test item : 26.07.2010 Date of test : 24.08.2010 - 27.08.2010 1.5 Test item Description of test item : Field Controller Type identification : CS15 Serial number : without Photos : See annex A. Technical data FDDII Frequency range Tx – : 1852.4 - 1907.6 MHz Frequency range Rx – : 1932.4 - 1987.6 MHz FDDV Frequency range Tx – : 826.4 - 846.6 MHz Frequency range Rx - : 871.4 - 891.6 MHz Antenna Type : internal antenna (FDDV) (FDDII) Antenna Gain : 2.0dBi 1.0dBi Power supply : 7.4VDC Operating mode : duplex Type of modulation : WCDMA (UTRA-FDD) Used module : UC864-G (manufacturer: Telit Communications S.p.A) FCC I D module : RI7UC864G Emission : F9W Manufacturer: (if applicable) Name : Street : Town : Country : Page 5 of 81 Test Report No.: G0M21007-3512-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.6 Test standards Technical standard : FCC Parts: 22H, 24E, 27C, 2, 15 IC Standards: RSS-132 Issue 2 RSS-133 Issue 5 RSS-139 Issue 2 RSS-Gen Issue 2 Additional information : Because of using the UMTS 850 as an alternative technology in 850 MHz band, not all test cases of FCC Part 22 are required. This test report covers the test which are related to UMTS radio technology in operating bands II and V only. Operation in others bands or with other radio technologies are subject of other independent test reports. The manufacturer declares that the device Field Controller CS15 uses the module UC864-G of the company Telit. Therefore a shortened test plan was created in confirmation with the manufacturer. 2 Technical test 2.1 Summary of test results No deviations from the technical specification(s) were ascertained in the course : of the tests performed. or The deviations as specified in 2.5 were ascertained in the course of the tests … performed. 2.2 Test environment Temperature : 25°C Voltage : U nom : 7.4VDC Relative humidity content : 20 ... 75% Air pressure : 86 ... 103kPa Page 6 of 81 Test Report No.: G0M21007-3512-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 2.3 Test equipment utilized No. Test equipment Type Manufacturer ETS 0014 Log Periodical Antenna HL 025 R & S ETS 0059 Kikusui amplifier PCR 2000L Keytek/ EMC ETS 0085 Shielded room SR 1 Frankonia ETS 0251 Climatic chamber VT 4004 Vötsch ETS 0281 Spectrum Analyzer FSM R & S ETS 0288 Artificial mains ESH2-Z5 R & S ETS 0294 Biconical antenna HK 116 R & S ETS 0295 LPD antenna HL 223 R & S ETS 0310 Anechoic chamber AC 3 Frankonia ETS 0375 Vector Signal Gener. SMIQ03B R & S ETS 0376 Signal Generator SMP22 R & S ETS 0378 Advanced Signal Conditioning UnitASCU190 R & S ETS 0379 Advanced Signal Conditioning UnitASCU180 R & S ETS 0380 Advanced Signal Conditioning UnitASCU900 R & S ETS 0382 Vector Signal Gener. SMIQ03B R & S ETS 0383 Spectrum Analyzer FSU26 R & S ETS 0384 Main Frame Signal and Conditioning Unit SSCU-GW R & S ETS 0385 Protocol Slave CRTU-RU (CRTU-G) R & S ETS 0386 Power meter NRVD R & S ETS 0390 System PC PC3600 TS-PC36 R & S ETS 0394 Advanced Signal Conditioning UnitASCUFDD- WCDMA R & S ETS 0413 Signal Analyzer FSIQ 26 R & S ETS 0416 Power Supply EX752M TTi ETS 0473 GSM / UMTS System Simulator TS 8950 R&S ETS 0476 EMI Test receiver ESCS 30 R&S ETS 0484 Radio Communication Tester CMU 200 R&S Page 7 of 81 Test Report No.: G0M21007-3512-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 2.4 General test procedure POWER LINE CONDUCTED INTERFERENCE: The procedure used was ANSI STANDARD C63.4-2003 5.2 using a 50 μH LISN (if necessary). Both lines were observed. The bandwidt…

Text truncated - open the document above for the full version.

Test Report No.: NK08R101 Telit Communications S.p.A. FCC ID :RI7UC864G Page 1 of 86 Nemko Korea CO., Ltd. 300-2, Osan-Ri, Mohyeon-Myeon, Cheoin-Gu, Yongin-City, Gyeonggi-Do, KOREA TEL:+82 31 322 2333 FAX:+82 31 322 2332 FCC EVALUATION REPORT FOR CERTIFICATION Applicant : Telit Communications S.p.A. Dates of Issue : May 6, 2008 Via Stazione di Prosecco, 5/B 34010 Sgonico Test Report No. : NK08R101 Trieste, Italy Test Site : Nemko Korea Co., Ltd. FCC ID Brand Name CONTACT PERSON Applied Standard: FCC 47 Part 2 & 22H & 24E Classification: PCS Licensed Transmitter (PCB) EUT Type: GSM850/1900(GPRS/EGPRS)/UMTS850/1900(HSDPA) Module The device bearing the brand name and FCC ID specified above has been shown to comply with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4-2003. I attest to the accuracy of data and all measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Tested By : Minchul Shin Reviewed By : H.H. Kim Engineer Manager & Chief Engineer RI7UC864G Telit Telit Communications S.p.A. Via Stazione di Prosdcco, 5/B 34010 Sqonico Trieste, Italy Mr. Andrea Fragiacomo Telephone No. : +39 040 4192111 Test Report No.: NK08R101 Telit Communications S.p.A. FCC ID :RI7UC864G Page 2 of 86 TABLE OF CONTENTS 1. Scope 4 2. Introduction (Site Description) 5 3. Test Conditions & EUT Information 6 4. Measuring Instrument Calibration 7 5. Summary of Test Results 8 6. Recommendation / Conclusion 8 7. Sample Calculation 9 8. Test Equipment 10 9. Description of Test 20 9.1 Effective Radiated Power (ERP/EIRP) 20 9.2 Conducted Output Power 24 9.3 Occupied Bandwidth / 26dB Emission Bandwidth 26 9.4 Radiated Spurious & Harmonic Emission (GSM 850_GPRS) 27 9.5 Radiated Spurious & Harmonic Emission (PCS 1900_GPRS) 29 9.6 Radiated Spurious & Harmonic Emission (WCDMA Band V_HSDPA) 31 9.7 Radiated Spurious & Harmonic Emission (WCDMA Band II_HSDPA) 33 9.8 Frequency Stability / Temperature Variation (GSM 850_GPRS) 35 9.9 Frequency Stability / Temperature Variation (PCS 1900_GPRS) 36 9.10 Frequency Stability / Temperature Variation (GSM 850_EDGE) 37 9.11 Frequency Stability / Temperature Variation (PCS 1900_EDGE) 38 9.12 Frequency Stability / Temperature Variation (WCDMA Band V_HSDPA) 39 9.13 Frequency Stability / Temperature Variation (WCDMA Band II_HSDPA) 40 10. Emission Designator 41 11. Test Plots (GSM 850_GPRS) 42 12. Test Plots (PCS 1900_GPRS) 48 13. Test Plots (GSM 850_EDGE) 54 14. Test Plots (PCS 1900_EDGE) 60 15. Test Plots (WCDMA Band V_HSDPA) 66 Test Report No.: NK08R101 Telit Communications S.p.A. FCC ID :RI7UC864G Page 3 of 86 16. Test Plots (WCDMA Band II_HSDPA 72 17. Maximum Permissible Exposure 78 Appendix A: Labelling Requirement 81 Appendix B: Photographs of Test Set-up 82 Appendix C: EUT Photographs 83 Test Report No.: NK08R101 Telit Communications S.p.A. FCC ID :RI7UC864G Page 4 of 86 1. Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission under FCC Part 2 & Part 22 & 24. Responsible Party : Contact Person : Manufacturer : Telit Communications S.p.A. Mr. Andrea Fragiacomo Tel No. : +39 040 4192111 Telit Communications S.p.A. Via Stazione di Prosdcco, 5/B 34010 Sqonico, Trieste, Italy z FCC ID: RI7UC864G z Model: UC864-G z Brand Name: Telit z EUT Type: GSM850/1900(GPRS/EGPRS)/UMTS850/1900(HSDPA) Module z Electric Rating: +3.8 Vdc z Equipment Class: z Applied Standard: z Dates of Test: z Place of Tests: PCS Licensed Transmitter (PCB) FCC 47 CFR 2 FCC 47 CFR Part 22H &24E April 21, 2008 to April 30, 2008 Nemko Korea Co., Ltd. Test Report No.: NK08R101 Telit Communications S.p.A. FCC ID :RI7UC864G Page 5 of 86 2. Introduction (Site Description) The measurement procedure described in American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C63.4-2003) was used in determining radiated and conducted emissions emanating from Telit Communications S.p.A. FCC ID : RI7UC864G These measurement tests were conducted at Nemko Korea Co., Ltd. The site address is 300-2, Osan-Ri, Mohyeon-Myeon, Cheoin-Gu, Yongin-Si, Gyeonggi-Do, KOREA The area of Nemko Korea Corporation Ltd. Test site is located in a mountain area at 80 kilometers (48 miles) southeast and Incheon International Airport (Incheon Airport), 30 kilometers (18miles) south-southeast from central Seoul. It is located in the valley surrounded by mountains in all directions where ambient radio signal conditions are quiet and a favorable area to measure the radio frequency interference on open field test site for the computing and ISM devices manufactures. The detailed description of the measurement facility was found to be in compliance with the requirements of §2.948 according to ANSI C63.4 2003. Fig. 1. The map above shows the Seoul in Korea vicinity area. The map also shows Nemko Korea Corporation Ltd. and Incheon Airport. Nemko Korea Co., Ltd. 300-2,Osan-Ri,Mohyeon-Myeon, Cheoin-Gu, Yongin-Si, Gyunggi-Do, KOREA 449-852 Tel) +82-31-322-2333 Fax) +82-31-322-2332 Test Report No.: NK08R101 Telit Communications S.p.A. FCC ID :RI7UC864G Page 6 of 86 3. Test Conditions & EUT Information Operating During Test The EUT was tested at the lowest channel, middle channel and the h…

Text truncated - open the document above for the full version.
