RFD-CS-SGWin CE Field Controller

Leica CS10/CS15 User Manual Version 3.0 English 2 CS10/CS15, Introduction Introduction PurchaseCongratulations on the purchase of a Leica CS10/CS15. This manual contains important safety directions as well as instructions for setting up the product and operating it. Refer to "5 Safety Directions" for further informa- tion. Read carefully through the User Manual before you switch on the product. Product identifica- tion The type and serial number of your product are indicated on the type plate. Enter the type and serial number in your manual and always refer to this information when you need to contact your agency or Leica Geosystems authorised service work- shop. Type:_______________ Serial No.:_______________ CS10/CS15, Introduction3 SymbolsThe symbols used in this manual have the following meanings: TypeDescription  DangerIndicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.  WarningIndicates a potentially hazardous situation or an unintended use which, if not avoided, could result in death or serious injury.  CautionIndicates a potentially hazardous situation or an unintended use which, if not avoided, may result in minor or moderate injury and/or appreciable material, financial and environmental damage. ) Important paragraphs which must be adhered to in practice as they enable the product to be used in a technically correct and efficient manner. 4 CS10/CS15, Introduction Trademarks•Windows is a registered trademark of Microsoft Corporation in the United States and other countries •CompactFlash and CF are trademarks of SanDisk Corporation •Bluetooth is a registered trademark of Bluetooth SIG, Inc. •SD is a trademark of the SD Card Association All other trademarks are the property of their respective owners. Validity of this manual This manual applies to the CS10 and CS15 field controllers. Differences between the various models are marked and described. Available documentation NameDescription/Format CS10/CS15 User Manual All instructions required in order to operate the product to a basic level are contained in the User Manual. Provides an overview of the product together with tech- nical data and safety directions. 99 NameDescription/Format Viva GNSS Getting Started Guide Describes the general working of the product in standard use. Intended as a quick reference field guide. 99 CS10/CS15, Introduction5 Refer to the following resources for all CS10/CS15 documentation/software: •the Leica Viva Series DVD •https://myworld.leica-geosystems.com myWorld@Leica Geosystems (https://myworld.leica-geosystems.com) offers a wide range of services, information and training material. With direct access to myWorld, you are able to access all relevant services whenever it is convenient for you, 24 hours a day, 7 days per week. This increases your effi- ciency and keeps you and your equipment instantly updated with the latest informa- tion from Leica Geosystems. Viva TPS Getting Started Guide Describes the general working of the product in standard use. Intended as a quick reference field guide. 99 Viva Series Technical Reference Manual Overall comprehensive guide to the product and appli- cation functions. Included are detailed descriptions of special software/hardware settings and software/hard- ware functions intended for technical specialists. 9 NameDescription/Format 6 CS10/CS15, Introduction ServiceDescription myProductsSimply add all Leica Geosystems products that you and your company own. View detailed information on your products, buy additional options or Customer Care Packages (CCPs), update your products with the latest software and keep up-to-date with the latest documentation. myServiceView the service history of your products in Leica Geosystems Service Centers and detailed information on the services performed on your products. For your products that are currently in Leica Geosystems Service Centers view the current service status and the expected end date of service. mySupportCreate new support requests for your products that will be answered by your local Leica Geosystems Support Team. View the complete history of your Support and view detailed information on each request in case you want to refer to previous support requests. myTrainingEnhance your product knowledge with the Leica Geosystems Campus - Information, Knowledge, Training. Study the latest online training material or download training material on your products. Keep up-to-date with the latest News on your products and register for Seminars or Courses in your country. CS10/CS15, Table of Contents7 Table of Contents In this manualChapterPage 1 Description of the System 11 1.1 Overview11 1.2 Terminology12 1.3 System Concept14 1.3.1Software Concept14 1.3.2Power Concept18 1.3.3Data Storage Concept19 1.4 CS Components21 1.4.1CS10 21 1.4.2CS15 23 1.5 Docking Station Components25 2 User Interface 26 2.1 Keyboard26 2.2 Operating Principles32 3Operation 33 3.1 Equipment Setup33 8 CS10/CS15, Table of Contents 3.1.1Fixing the Display Foil to the CS 33 3.1.2Fixing a Hand Strap to the CS 35 3.1.3Fixing the Slot Cover to the CS 37 3.1.4Inserting and Removing a SIM Card38 3.1.5Setting up as Handheld GNSS 40 3.1.6Setting up the Docking Station42 3.1.7Connecting to a Personal Computer43 3.2 Power Functions49 3.3 Batteries51 3.3.1Operating Principles51 3.3.2Changing the Battery52 3.3.3Charging the Battery55 3.4 Working with the Memory Device57 3.5 LED Indicators on CS10 /CS15 61 3.6 LED Indicators on GS08 /GS12 64 3.7 Using the Digital Camera66 4 Care and Transport 68 4.1 Transport68 4.2 Storage69 4.3 Cleaning and Drying70 CS10/CS15, Table of Contents9 5 Safety Directions 72 5.1 General Introduction72 5.2 Intended Use73 5.3 Limits of Use75 5.4 Responsibilities76 5.5 Hazards of Use78 5.6 Electromagnetic Compatibility EMC84 5.7 FCC Statement, Applicable in U.S.87 6 Technical Data 92 6.1 CS10 /CS15 Technical Data92 6.2 GS05 /GS06 Technical Data97 6.2.1Tracking Characteristics97 6.2.2Accur…

Text truncated - open the document above for the full version.

Label Sample CS10 Page 1/1 Leica Geosystems AG – [email protected] 04.08.2010 06_CS10 LabelSmpl.ppt CS10767866 RFD-CS-SG 767866

Test Report No.: G0M21007-3507-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany EUT intern Page 19 of 126 Test Report No.: G0M21007-3507-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 20 of 126 Test Report No.: G0M21007-3507-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Telit module UC864-G Page 21 of 126 Test Report No.: G0M21007-3507-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 22 of 126

30.07.2010 Page 1 17_CS10 AntSpec.doc [email protected] Antenna Specification for CS10 FCC-ID: RFD-CS-SG Antenna for PAN1310 Bluetooth Module FCC-ID: Q23-31308 2450 MHz AntennaP/N 2450AT18B100 Detail Specification: 06/12/06 Page 1 of 3 General Specifications Part Number2450AT18B100Input Power3W max. Frequency Range2400 - 2500 MhzImpedance50 ! Peak Gain0.5 dBi typ. (XZ-V)Operating Temperature-40 to +85°C Average Gain-0.5 dBi typ. (XZ-V)Reel Quanity3,000 Return Loss9.5 dB min. Terminal Configuration Packaging BulkSuffix = SEg. 2450AT18B100S No. Function P/N Style T & RSuffix = EEg. 2450AT18B100E 1 Feeding Point Suffix Termination 100% TinSuffix = NoneEg. 2450AT18B100(E or S) 2 NC Style Tin / Lead Mechanical Dimensions Inmm L±± W±± T a±± Mounting Considerations Mount these devices with brown mark facing up. Units: mm Line width should be designed to provide 50 ! impedance matching characteristics. a) Without Matching Circuits b) With Matching Circuits Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. www.johansontechnology.com 931 Via Alondra • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 2003 Johanson Technology, Inc. All Rights Reserved 0.051 Please consult Factory 0.0120.020 1.30 0.30 +.004/-.008+0.1/-0.2 "High Frequency Ceramic Solutions" 0.50 0.1260.0083.200.20 0.0630.0081.600.20 12 L W a T ) Matching Component JTI P/Ns: L-14C2N7JV4 L-14C2N2JV4 * 2.6 4.2 1.6 1.9 0.4 2.7nH 1.2pF 3.3nH 2450 MHz AntennaP/N 2450AT18B100 Detail Specification: 06/12/06 Page 2 of 3 Typical Electrical Characteristics (T=25 o C) Test Board: Return Loss a) With Matching Circuita) With Matching Circuit Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. www.johansontechnology.com 931 Via Alondra • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 2003 Johanson Technology, Inc. All Rights Reserved "High Frequency Ceramic Solutions" ) ) ) ) ) ) ) ) ) Ground 13.5mm 6.5mm 39.5mm 6.5mm Matching Circuit No Ground 50! Feed Line Antenna 19mm 2450 MHz AntennaP/N 2450AT18B100 Detail Specification: 06/12/06 Page 3 of 3 Typical Radiation Patterns Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. www.johansontechnology.com 931 Via Alondra • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 2003 Johanson Technology, Inc. All Rights Reserved "High Frequency Ceramic Solutions" ) ) ) ) ) ) ) ) ) Antenna for UC864-G Module FCC-ID: RI7UC864G Datasheet, Part Nr. 766 808, Page 1 GSM / UMTS Quad Band Antenna Part Nr. 766 808 Electrical Characteristics Description Value Comment Frequency Bands 824 - 960 MHz @ 6 dB min. return loss 1720 – 2170 MHz @ 6 dB min. return loss Return Loss See Fig. 1 Impedance 50 ohm Gain total max. low band 2.0 dBi See Table 1 Polarization low band See Fig. 2 Antenna Characteristic Omni directional See Fig. 2 Gain total max. high band 1.0 dBi See Table 2 Polarization high band See Fig. 3 Antenna Characteristic Omni directional See Fig. 3 Power Dissipation 3 W max. Operation Temperature - 40 °C to + 85 °C Surface CuSn6 tin plated ROHS compliant Datasheet, Part Nr. 766 808, Page 2 Dimensions [mm] Fig.1 Return Loss dB 6 4 2 0 -2 -4 -6 -8 -10 -12 -14 CS15 SNr. 1590119 GSM Antenna S11 Start: 500.000000 MHzStop: 2.500000 GHz 27.10.2009 15:38:36HP8510BGSM.spt 1 1 S11 825.000000 MHz -7.8183 dB 2 2 S11 960.000000 MHz -8.6495 dB 3 3 S11 1.720000 GHz -9.5100 dB 4 4 S11 2.170000 GHz -6.7287 dB Datasheet, Part Nr. 766 808, Page 3 Table 1 Gain @ 885 MHz Fig. 2 Characteristic @ 885 MHz Measured @ 885 MHz in CS15 Ground plane = 30° tilted Orientation: Gain vertical max -9.0 dBi Gain vertical avg. -10.5 dBi Gain horizontal max 2.0 dBi Gain horizontal avg. -3.5 dBi Gain total max 2.0 dBi Gain total avg. -3.5 dBi Table 2 Gain @ 1934 MHz Fig. 3 Characteristic @ 1934 MHz Measured @ 1934 MHz in CS15 Ground plane = 30° tilted Orientation: Gain vertical max -1.5 dBi Gain vertical avg. -6.0 dBi Gain horizontal max 0.0 dBi Gain horizontal avg. -4.5 dBi Gain total max 1.0 dBi Gain total avg. -2.5 dBi 0 30 60 90 120 150 180 210 240 270 300 330 20! 18! 16! 14! 12! 10! 8! 6! 4! 2! 0 2 Horizontal Vertical Total 0 30 60 90 120 150 180 210 240 270 300 330 20! 18! 16! 14! 12! 10! 8! 6! 4! 2! 0 2 Horizontal Vertical Total Antenna for ConnectBlue OWLAN211b/g WLAN Module FCC-ID: PVH-090901 Version 1.11 - 2007-10 17 3 Antenna Information There are 2 different antenna options available: • An internal surface mounted (SMD) antenna. • Two U.FL connectors for external antenna. Different types of external antennas are available. See section 4.1 for more information on antenna placement. This chapter gives a quality overview of the different antenna options. 3.1 Surface Mounted Antenna (internal) The unit cannot be mounted in a metal-shielded enclosure with this antenna. Part Number OWLAN211gi Antenna name FR05-01-N Manufacture Fractus Polarization Linear Gain (Typ) 1.1 dBi Antenna Size (LxWxH) 6.7 x 6.7 x 1 mm Comment The antenna gain is dependent of the mounting of the module. See section 4.4 for mounting the module considering the antenna.

EUROFINS PRODUCT SERVICE GMBH Testing Cert #1983.01 TEST - REPORT WLAN FCC RULES PARTS 15.247 IC RADIO STANDARDS RSS-210 Issue 7 FCC ID: RFD-CS-S IC: 3177A-CSS Field controller CS10 Test report no.: G0M20908-2507-C-1 Eurofins Product Service GmbH Storkower Str. 38c, 15526 Reichenwalde, Phone +49-33631-888 0 Germany Fax +49-33631-888 660 Test Report No.: G0M20908-2507-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany TABLE OF CONTENTS 1 General information 3 1.1 Notes 3 1.2 Testing laboratory 4 1.3 Details of approval holder 4 1.4 Application details 5 1.5 Test item 5 1.6 Test standards 7 2 Technical test 7 2.1 Summary of test results 7 2.2 Test environment 7 2.3 Test equipment utilized 8 2.4 General test procedure 9 2.5 Test results 10 3 Transmitter parameters 11 3.1 Occupied bandwidth 11 3.2 Spurious emission radiated 12 4 Receiver parameters 15 4.1 Radiated emission 15 ANNEX 16 Page 2 of 52 Page 3 of 52 Test Report No.: G0M20908-2507-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.2 Testing laboratory 1.2.1 Location EUROFINS PRODUCT SERVICE GMBH Storkower Straße 38c D-15526 Reichenwalde b. Berlin Germany Telephone : +49 33631 888 00 Telefax : +49 33631 888 660 1.2.2 Details of accreditation status DAR ACCREDITED TESTING LABORATORY DAR-R EGISTRATION NUMBER: DAT-P-268/08 R ECOGNIZED NOTIFIED BODY EMC R EGISTRATION NUMBER: BNetzA-bS EMV-07/61 R ECOGNIZED NOTIFIED BODY R&TTE R EGISTRATION NUMBER: BNetzA-bS-02/51-53 FCC FILED TEST LABORATORY R EG.-NO. 96970 A2LA ACCREDITED TESTING LABORATORY C ERTIFICATE NO. 1983.01 B LUETOOTH QUALIFICATION TEST FACILITY (BQTF) A CCREDITED BY BLUETOOTH QUALIFICATION REVIEW BOARD I NDUSTRY CANADA FILED TEST LABORATORY R EG. NO. IC 3470 1.3 Details of approval holder Name : Leica Geosystems AG Street : Heinrich Wild Strasse 1 Town : CH-9435 Heerbrugg Country : Switzerland Telephone : +41 71 727 3764 Contact : Herr Silvan Stucki E-Mail : [email protected] Page 4 of 52 Test Report No.: G0M20908-2507-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.4 Application details Date of receipt of application : 18.08.2009 Date of receipt of test item : 18.08.2009 Date of test : 21.08.2009 - 24.08.2009 1.5 Test item Description of test item : Field controller Type identification : CS10 Serial number : without Photos : See annex A. Technical data Frequency band : 2.4 GHz – 2.4835 GHz Frequency (ch A) : 2412 MHz Frequency (ch B) : 2437 MHz Frequency (ch C) : 2462 MHz Number of Channels : 11 Operating Modes : duplex Type of modulation : DSSS, OFDM Data Rate (Mbps) Modulation Support 1 DSSS 6 OFDM Fixed point-to-point operation: Yes / No Power supply : 7.4VDC (battery) Antenna : internal antenna Antenna gain : 1.1idBi Host device : none Page 5 of 52 Test Report No.: G0M20908-2507-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Classification : Fixed Device Mobile Device (Human Body distance > 20 cm) Portable Device (Human Body distance < 20 cm) Manufacturer: (if applicable) Name : Leica Geosystems AG Street : Heinrich Wild Strasse 1 Town : CH-9435 Heerbrugg Country : Switzerland Additional information: The sample is using WLAN technology according IEEE 802.11 b/g. The scheme for frequency generation, spectrum spreading, receiver parameters, synchronization procedure, and other parameters are determined by the mentioned standard above. The test item has three radios with three antennas inside. All radios were tested separatly with one radio active and the other radios deactived. The manufacturer declares that the device Field controller CS10 uses the Bluetooth wireless module model PAN1310 of the company Panasonic, the frequency hopping transceiver module WIT2450 of the company Cirronet and the OWLAN211g module from connectBlue AB. Therefore a shortened test plan was created in confirmation with the manufacturer. The test results for the Bluetooth are given in the test report G0M20908-2507-P-15 and for the WIT2450 in the test report report G0M20908-2507-C-2. Page 6 of 52 Test Report No.: G0M20908-2507-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.6 Test standards Technical standard: FCC Parts: 15.247 IC Standards: RSS 210 Issue 7 2 Technical test 2.1 Summary of test results No deviations from the technical specification(s) were ascertained in the course : of the tests performed. or The deviations as specified in 2.5 were ascertained in the course of the tests … performed. 2.2 Test environment Temperature : 24°C Relative humidity content : 20 ... 75 % Air pressure : 86 ... 103 kPa Details of power supply : 7.4VDC(battery) Normal test position: 30° to horizontal Page 7 of 52 Test Report No.: G0M20908-2507-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 2.3 Test equipment utilized No. Test equipment Type Manufacturer ETS 0012 Biconical Antenna HK 116 R & S ETS 0013 LPD Antenna HL 223 R & S ETS 0015 Log Periodical Antenna HL 025 R & S ETS 0018 Horn antenna BBHA 9120 D Schwarzbeck ETS 0253 Spectrum Analyzer FSIQ 26 R & S ETS 0271 Spectrum Analyzer FSEK 30 R & S ETS 0288 Artificial mains ESH2-Z5 R & S ETS 0086 Anechoic chamber AC 1 Frankonia ETS 0474 EMI Test Receiver ESCS 30 R&S Page 8 of 52 Test Report No.: G0M20908-2507-C-1 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 2.4 General test procedure POWER LINE CONDUCTED INTERFERENCE: The procedure used was ANSI STANDARD C63.4-2003 5.2 using a 50 μH LISN (if necessary). Both lines were observed. The bandwidth of the spectrum analyzer was 10 kHz with an appropriate sweep speed. RADIATION INTERFERENCE: The test procedure used was ANSI STANDARD C63.4-2003 6.4 using a spectrum analyzer. The resolution bandwidth of the spectrum analyzer was 100 kHz for measurements below 1 GHz and RBW 1 MHz was used above 1 GHz. The analyzer was calibrated in dB above a microvolt at the ou…

Text truncated - open the document above for the full version.

Königswinkel 10 32825 Blomberg Germany Phone+49 5235 9500-0 Fax+49 5235 9500-10 TEST REPORT Test Report Reference:R70284_AEdition 1 Equipment under Test:802.11b/g Wireless LAN module cB-OWLAN211gi-02/ cB-OWLAN211gx-02 FCC ID: PVH090901 IC: 5325A-090901 Applicant: connectBlue AB Manufacturer:connectBlue AB Test Laboratory (CAB) accredited by DATech GmbH in compliance with DIN EN ISO/IEC 17025 under the Reg. No. DAT-P-105/99-21, FCC Test site registration number 90877 and Industry Canada Test site registration IC3469 TEST REPORT REFERENCE: R70284_A Edition 1 Examiner: Dieter SÜTTHOFFDate of issue: 12 July 2007Page2 of109 Contents:Page 1 IDENTIFICATION.....................................................................................................................................4 1.1 APPLICANT.....................................................................................................................................4 1.2 MANUFACTURER..........................................................................................................................4 1.3 DATES.............................................................................................................................................4 1.4 TEST LABORATORY......................................................................................................................5 1.5 RESERVATION...............................................................................................................................5 1.6 NORMATIVE REFERENCES..........................................................................................................5 1.7 TEST RESULTS..............................................................................................................................5 2 TECHNICAL DATA OF EQUIPMENT......................................................................................................6 2.1 DEVICE UNDER TEST...................................................................................................................6 2.2 PERIPHERY DEVICES...................................................................................................................8 3 OPERATIONAL STATES AND PHYSICAL BOUNDARIES.....................................................................8 4 APPLICATION OVERVIEW.....................................................................................................................9 5 TEST RESULTS.......................................................................................................................................10 5.1 CONDUCTED EMISSIONS ON POWER SUPPLY LINES (150 kHz to 30 MHz)...........................10 5.1.1 METHOD OF MEASUREMENT..........................................................................................10 5.1.2TEST RESULTS (CONDUCTED EMISSIONS ON POWER SUPPLY LINES) ..................11 5.2 6 dB BANDWIDTH..........................................................................................................................13 5.2.1METHOD OF MEASUREMENT (6 dBBANDWIDTH)........................................................13 5.2.2TEST RESULTS (6 dBBANDWIDTH)................................................................................14 5.3 MAXIMUM PEAK OUTPUT POWER..............................................................................................18 5.3.1 METHOD OF MEASUREMENT (MAXIMUM PEAK OUTPUT POWER)............................18 5.3.2 TEST RESULTS (MAXIMUM PEAK OUTPUT POWER)...................................................19 5.4 POWER SPECTRAL DENSITY......................................................................................................20 5.4.1 METHOD OF MEASUREMENT (POWER SPECTRAL DENSITY).................................... 20 5.4.2 TEST RESULTS (POWER SPECTRAL DENSITY)............................................................21 5.5 BAND-EDGE COMPLIANCE...........................................................................................................25 5.5.1 METHOD OF MEASUREMENT (BAND-EDGE COMPLIANCE)........................................25 5.5.2 TEST RESULT (BAND-EDGE COMPLIANCE (RADIATED)) b-mode...............................26 5.5.3 TEST RESULT (BAND-EDGE COMPLIANCE (RADIATED)) g-mode...............................28 CONTINUED NEXT PAGE TEST REPORT REFERENCE: R70284_A Edition 1 Examiner: Dieter SÜTTHOFFDate of issue: 12 July 2007Page3 of109 Contents (continued):Page 5.6 RADIATED EMISSIONS..................................................................................................................30 5.6.1 METHOD OF MEASUREMENT (RADIATED EMISSIONS)...............................................30 5.6.2TEST RESULTS (TRANSMITTER RADIATED EMISSIONS)............................................36 5.6.2.1 PRELIMINARY MEASUREMENT INTERNAL ANTENNA (30 kHz to 1 GHz).......36 5.6.2.2FINALMEASUREMENT INTERNAL ANTENNA (9 kHz to 30 MHz).....................40 5.6.2.3 FINAL MEASUREMENT INTERNAL ANTENNA (30 MHz to 1 GHz)....................41 5.6.2.4 PRELIMINARY MEASUREMENT INTERNAL ANTENNA (1 GHz to 25 GHz) b-mode................................................................................................45 5.6.2.5 FINAL MEASUREMENT INTERNAL ANTENNA (1 GHz to 25 GHz) b mode.......52 5.6.2.6 PRELIMINARY MEASUREMENT INTERNAL ANTENNA (1 GHz to 25 GHz) g-mode................................................................................................55 5.6.2.7 FINAL MEASUREMENT INTERNAL ANTENNA (1GHz to 25 GHz) g- mode......62 5.6.2.8 PRELIMINARY MEASUREMENT EXTERNAL PATCH ANTENNA (1 GHz to 25 GHz) b-mode................................................................................................65 5.6.2.9 FINAL MEASUREMENT EXTERNAL PATCH ANTENNA (1 GHz to 25 GHz) b-mode................................................................................................72 5.6.2.10 PRELIMINARY MEASUREMENT EXTERNAL PATCH ANTENNA (1 GHz to 25 GHz) g-mode............................…

Text truncated - open the document above for the full version.

Report No.: 24838RET.101 Date: 2006-12-13 Page: 2 of 8 FDT08_04 INDEX 1. COMPETENCE AND GUARANTEES..........................................................................................3 2. GENERAL CONDITIONS..............................................................................................................3 3. CHARACTERISTICS OF THE TEST............................................................................................3 3.1 TEST REQUESTED.................................................................................................................3 3.2 REQUIREMENTS AND METHOD........................................................................................4 4. IDENTIFICATION DATA SUPPLIED BY THE APPLICANT.....................................................4 4.1 APPLICANT.............................................................................................................................5 4.2 REPRESENTATIVE................................................................................................................5 4.3 TEST SAMPLES SUPPLIER...................................................................................................5 4.4 IDENTIFICATION OF ITEM/ITEMS TESTED.....................................................................5 5. USAGE OF SAMPLES, PERIOD OF TESTING AND ENVIRONMENTAL CONDITIONS.....5 5.1 USAGE OF SAMPLES............................................................................................................5 5.2 PERIOD OF TESTING............................................................................................................6 5.3 ENVIROMENTAL CONDITIONS..........................................................................................7 6. TEST RESULTS..............................................................................................................................8 7. REMARKS AND COMMENTS......................................................................................................8 8. SUMMARY......................................................................................................................................8 ANNEXES ANNEX A. TEST RESULTS ANNEX B. MEASURING RESULTS FOR ELECTROMAGNETIC EMISSION ANNEX B. PHOTOGRAPHS Report No.: 24838RET.101 Date: 2006-12-13 Page: 3 of 8 FDT08_04 1. COMPETENCE AND GUARANTEES Centro de Tecnología de las Comunicaciones (AT4 WIRELESS), S.A. is a laboratory with a measurement facility in compliance with the requirements of Section 2.948 of the FCC rules and has been added to the list of facilities whose measurements data will be accepted in conjuction with applications for Certification under Parts 15 or 18 of the Commission's Rules. Registration Number: 905266. Centro de Tecnología de las Comunicaciones (AT4 WIRELESS), S.A. is a laboratory with a measurement site in compliance with the requirements of RSS 212, Issue 1 (Provisional) and has been added to the list of filed sites of the Canadian Certification and Engineering Bureau. Reference File Number: IC 4621. In order to assure the traceability to other national and international laboratories, AT4 WIRELESS has a calibration and maintenance programme for its measuring equipment. AT4 WIRELESS guarantees the reliability of the data presented in this report, which is the result of measurements and tests performed to the item under test on the date and under the conditions stated on the report and is based on the knowledge and technical facilities available at AT4 WIRELESS at the time of execution of the test. AT4 WIRELESS is liable to the client for the maintenance by its personnel of the confidentiality of all information related to the item under test and the results of the test. 2. GENERAL CONDITIONS 1. This report only refers to the item that has undergone the test. 2. This report does not constitute or imply by its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without written approval of AT4 WIRELESS. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of AT4 WIRELESS and the Accreditation Bodies. 3. CHARACTERISTICS OF THE TEST 3.1 TEST REQUESTED 1. Measurements for frequency hopping spread spectrum equipment (Bluetooth) operating in the 2400 MHz -2483.5 MHz band and using, according to FCC Part 15.247. 2. Continuous conducted emission, power leads: Standard: FCC Rules and Regulations 47 CFR Part 15 Limit: Class B Method: FCC Rules and Regulations 47 CFR Part 15, Subpart C Report No.: 24838RET.101 Date: 2006-12-13 Page: 4 of 8 FDT08_04 3.2 REQUIREMENTS AND METHOD 1. FCC parts 15.33, 15.35, 15.247, 15.207, 15.205, 15.209, 15.109 and the document DA 00- 705:"Filing and Measurement Guidelines for Frequency Hopping Spread Spectrum Systems". The testing was performed according to the procedure in ANSI C63.4: 2003. Radiated testing was performed in AT4 WIRELESS' semi-anechoic chamber. This site has been fully described in a report submitted to the FCC and was accepted in a letter dated July 25, 2002. 2. FCC Rules and Regulations 47 CFR Part 15, Subpart C: Limits and methods of measurements for radio frequency devices. Intentional radiators. The instrumentation used to perform the testing is listed below: 1. Semianechoic Absorber Lined Chamber IR 11. BS. 2. Control Chamber IR 12.BC. 3. Antenna mast EM 1072 NMT. 4. Rotating table EM 1084-4. ON. 5. Multi device controller ETS 2090. 6. Bilog antenna CHASE CBL6111. 7. Antenna tripod EMCO 11968C. 8. Double-ridge Guide Horn antenna 1-18 GHz HP 11966E. 9. Double-ridge Guide Horn antenna 18-40 GHz Agilent 119665J. 10. RF pre-amplifier Miteq JS4-12002600-30-5A. 11. Semianechoic Absorber Lined Chamber IR 11. BS. 12. RF pre-amplifier Miteq AFS5-04001300-15-10P-6. 13. RF pre-amplifier Schaffner CPA 9231. 14. Spectrum analyzer …

Text truncated - open the document above for the full version.
