RFD-CSNGCField Controller Win EC7

Leica CS20 User Manual Version 1.0 English CS20, Introduction 2 Introduction PurchaseCongratulations on the purchase of a Leica CS20. This manual contains important safety directions as well as instructions for setting up the product and operating it. Refer to "1 Safety Directions" for further information. Read carefully through the User Manual before you switch on the product. Product identifica- tion The type and serial number of your product are indicated on the type plate. Always refer to this information when you need to contact your agency or Leica Geosystems authorised service workshop. Trademarks• Windows is a registered trademark of Microsoft Corporation in the United States and other countries • SD Logo is a trademark of SD-3C, LLC. • Bluetooth ® is a registered trademark of Bluetooth SIG, Inc. All other trademarks are the property of their respective owners. Validity of this manual This manual applies to the CS20 field controller and CTR20 expansion pack. Differences between the various models are marked and described. Available documentation Refer to the following resources for all CS20 documentation/software: • the Leica USB documentation card • https://myworld.leica-geosystems.com NameDescription/Format CS20 Quick Guide Provides an overview of the product together with tech- nical data and safety directions. Intended as a quick reference guide. 99 CS20 User Manual All instructions required in order to operate the product to a basic level are contained in the User Manual. Provides an overview of the product together with tech- nical data and safety directions. -9 NameDescription/Format Leica Captivate Technical Reference Manual Overall comprehensive guide to the product and apps. Included are detailed descriptions of special soft- ware/hardware settings and software/hardware func- tions intended for technical specialists. -9 CS20, Introduction 3 myWorld@Leica Geosystems (https://myworld.leica-geosystems.com) offers a wide range of services, information and training material. With direct access to myWorld, you are able to access all relevant services whenever it is convenient for you, 24 hours a day, 7 days per week. This increases your efficiency and keeps you and your equipment instantly updated with the latest information from Leica Geosystems. ServiceDescription myProductsAdd all Leica Geosystems products that you and your company own. View detailed information on your products, buy additional options or Customer Care Packages (CCPs), update your products with the latest software and keep up-to-date with the latest documentation. myServiceView the service history of your products in Leica Geosystems Service Centres and detailed information on the services performed on your products. For your products that are currently in Leica Geosystems Service Centres view the current service status and the expected end date of service. mySupportCreate new support requests for your products that will be answered by your local Leica Geosystems Support Team. View the complete history of your Support and view detailed information on each request in case you want to refer to previous support requests. myTrainingEnhance your product knowledge with the Leica Geosystems Campus - Information, Knowledge, Training. Study the latest online training material or download training material on your products. Keep up- to-date with the latest News on your products and register for Semi- nars or Courses in your country. myTrustedSer- vices Offers increased productivity while at the same time providing maximum security. • myExchange With myExchange you can exchange any files/objects from your computer to any of your Leica Exchange Contacts. • mySecurity If your instrument is ever stolen, a locking mechanism is available to ensure that the instrument is disabled and can no longer be used. CS20, Table of Contents 4 Table of Contents In this manualChapterPage 1Safety Directions 6 1.1General Introduction6 1.2Definition of Use7 1.3Limits of Use7 1.4Responsibilities8 1.5Hazards of Use8 1.6Laser Classification11 1.6.1General11 1.6.2DISTO11 1.7Electromagnetic Compatibility EMC12 1.8FCC Statement, Applicable in U.S.13 2Description of the System 15 2.1Overview15 2.2Terminology15 2.3System Concept16 2.3.1Software Concept16 2.3.2Power Concept17 2.3.3Data Storage Concept17 2.4CS Components18 3User Interface 19 3.1Keyboard19 3.2Operating Principles21 3.3LED Indicators on CS2021 4Operation 22 4.1Equipment Setup22 4.1.1Fixing the CS to a Holder and Pole22 4.1.2Fixing a Hand Strap to the CS23 4.1.3Fixing the Utility Hook to the CS24 4.1.4Replacing the Display Foil on the CS24 4.1.5Inserting and Removing a SIM Card25 4.1.6Setting up for Usage of Long Range Bluetooth Expan- sion Pack CTR2026 4.1.7Connecting to a Personal Computer27 4.1.8Enabling WLAN in Windows EC729 4.2Batteries30 4.2.1Operating Principles30 4.2.2Changing the Battery30 4.2.3Charging the Battery31 4.3Power Functions31 4.4Working with the Memory Device32 4.4.1Working with the SD Card32 4.4.2Working with a USB Memory Stick33 4.5Using the Digital Camera33 4.6Using the Camera Flash Light as Torch34 CS20, Table of Contents 5 5Care and Transport 35 5.1Transport35 5.2Storage35 5.3Cleaning and Drying35 6Technical Data 37 6.1CS20 Technical Data37 6.2CTR20 Technical Data38 6.3Conformity to National Regulations39 6.3.1CS2039 6.3.2CTR2041 7Software Licence Agreement 42 Appendix APin Assignments and Sockets 43 A.1CS2043 CS20, Safety Directions 6 1Safety Directions 1.1General Introduction DescriptionThe following directions enable the person responsible for the product, and the person who actually uses the equipment, to anticipate and avoid operational hazards. The person responsible for the product must ensure that all users understand these directions and adhere to them. About Warning Messages Warning messages are an essential part of the safety concept of the instrument. They appear wherever hazards or hazardous situations can occur. Warning messages... • make the us…

Text truncated - open the document above for the full version.

FCC Heerbrugg, 25 November 2014 Federal Communications Commission Equipment Approval Services Post Office Box 358315 Pittsburg, PA 15262-0001 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: RFD-CSNGC including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Please contact us if you have any additional questions. Best regards Hannes Juen Christian Gerber Manager Quality Engineering R&D Electronics Design Leica Geosystems AG Leica Geosystems AG Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Direct Phone: +41 71 727 3098 Phone +41 71 727 31 31 E-Mail: [email protected] www.leica-geosystems.com

FCC Heerbrugg, 15 November 2014 Federal Communications Commission Equipment Approval Services Post Office Box 358315 Pittsburg, PA 15262-0001 Request for Confidentiality Leica Geosystems AG - FCC-ID: RFD-CSNGC , FCC Part 15 Certification Gentlemen, In accordance with 0.459 of CFR 47, Leica Geosystems AG hereby requests confidentiality of -Operational Description (11_CS20NGC OpDes.pdf) -Block Diagrams (12_CS20NGC BlkDia.pdf) -Schematics (13_CS20NGC Schem.pdf) -Parts List (16_CS20NGC PartsLst.pdf) attachments for the subject application. These documents contain detailed system and equipment description and related information about the product which Leica Geosystems AG considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. There are special tools necessary to open the products and the internal design is not publicly accessible. Since the design is a basis from which future technological products will evolve, Leica Geosystems AG considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Hannes Juen Christian Gerber Manager Quality Engineering R&D Electronics Design Leica Geosystems AG Leica Geosystems AG Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Direct Phone: +41 71 727 3098 Phone +41 71 727 31 31 E-Mail: [email protected] www.leica-geosystems.com

External Photos page 1 Model No.: CS20 CDMA Disto FCC ID: RFD-CSNGC IC: 3177A- CSNGC Project No.: G0M-1406-3915

Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrug Switzerland Phone +41 71 727 31 31 www.leica-geosystems.com 1 Label 1 Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrug Switzerland Phone +41 71 727 31 31 www.leica-geosystems.com 2 Label 2

Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Phone +41 71 727 31 31 07_CS20NGC LabelLoc.docx Label 1 Label 2

Internal Photos page 1 Model No.: CS20 CDMA Disto FCC ID: RFD-CSNGC IC: 3177A- CSNGC Project No.: G0M-1406-3915 Internal Photos page 2 Model No.: CS20 CDMA Disto FCC ID: RFD-CSNGC IC: 3177A- CSNGC Project No.: G0M-1406-3915

Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Direct Phone: +41 71 727 3098 Phone +41 71 727 31 31 E-Mail: [email protected] www.leica-geosystems.com Declaration concerning Antenna Specification It is hereby declared that the product Model No.: CS20 CDMA Disto FCC ID: RFD-CSNGC fulfills the requirement in FCC test relating to the antenna type. 1 BT/WLAN The device specified above confirms to the FCC recommendations for internal antenna type described below: Model No. of antenna: Pulse / W3008C Type of antenna: ceramic chip soldered into the PCB Peak Gain of the antenna: 2.2 dBi Frequency range: 2400-2483.5 MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. 2 GSM / UMTS / CDMA The device specified above confirms to the FCC recommendations for internal antenna type described below: Model No. of antenna: Ethertronics / P522303 Type of antenna: Isolated Magnetic Dipole permanently attached (soldered into the PCB) Peak Gain of the antenna: 2.8 dBi Frequency range: 824-2170 MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Direct Phone: +41 71 727 3894 E-Mail: [email protected] 2/2 3 LR-BT The device specified above confirms to the FCC recommendations for internal antenna type described below: Model No. of antenna: Leica Geosystems / 805684 Type of antenna: inverted-F permanently attached (built into the housing) Peak Gain of the antenna: 1 dBi Frequency range: 2400-2480 MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Leica Geosystems Address: Heinrich-Wild-Strasse City: Heerbrugg ZIP / Postal code: 9435 Country: Switzerland Place: Heerbrugg Date: 02.02.2015 Signature:

Test Report No.: G0M-1406-3915-TFC093SR-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany SAR TEST REPORT FCC 47 CFR Part 2.1093 Industry Canada RSS-102 RF-Exposure evaluation of portable equipment Report Reference No. .................... : G0M-1406-3915-TFC093SR-V01 Testing Laboratory ........................ : Eurofins Product Service GmbH Address ............................................ : Storkower Str. 38c 15526 Reichenwalde Germany Accreditation .................................... : A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Filed Test Laboratory, Reg.-No.: 96970 IC OATS Filing assigned code: 3470A Applicant’s name ........................... : Leica Geosystems AG Address ............................................ : Heinrich Wild Strasse 9435Heerbrugg SWITZERLAND Test specification: Standard ........................................... : FCC 47 CFR Part 2 §2.1093 FCC OET Bulletin 65 Supplement C 01-01 IEEE Std. 1528-2003 IEEE Std. 1528 - 2013 IC RSS-102 Issue 5 Safety Code 6 (2015) Non-standard test method..............: None Test scope.............. ....................... : complete Radio compliance test Equipment under test (EUT): Product description Field Controller Win EC7 Model No. CS20 CDMA Disto Additional Model(s) None Brand Name(s) Leica Geosystems Hardware version V5.0 Firmware / Software version 1.0 Contains FCC-ID: RFD-CSNGC IC: 3177A-CSNGC Test result Passed Page 1 of 112 Page 2 of 112 Test Report No.: G0M-1406-3915-TFC093SR-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Version History Version Issue Date Remarks Revisedby 01 2015-04-28 Initial Release Page 3 of 112 Test Report No.: G0M-1406-3915-TFC093SR-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany REPORT INDEX 1 EQUIPMENT (TEST ITEM) DESCRIPTION 6 1.1 Equipment photos 8 1.2 Equipment setup photos 11 1.3 Reference Documents 14 1.4 Supporting Equipment Used During Testing 15 1.5 Supported standalone operating modes 16 1.6 Conducted Power Values 17 1.7 Standalone Operational Mode Test Exclusion 21 1.8 Supported concurrent (multi-transmitter) operating modes 22 1.9 Supported use cases 23 1.10 Radio Test Modes 24 1.11 Test Positions 26 1.12 Test Equipment Used During Testing 27 2 RESULT SUMMARY 28 3 DEFINITIONS 29 3.1 Controlled Exposure 29 3.2 Uncontrolled Exposure 29 3.3 Localized SAR 29 4 LOCALIZED SAR MEASUREMENT EQUIPMENT 30 4.1 Complete SAR DASY5 Measurement System 30 4.2 Robot Arm 32 4.3 Data Acquisition Electronics 32 4.4 Isotropic E -Field Probe ≤ 3 GHz 33 4.5 Isotropic E-Field Probe ≤ 6 GHz 34 4.6 Test phantom and positioner 35 4.7 System Validation Dipoles 36 5 SINGLE-BAND SAR MEASUREMENT 37 5.1 General measurement description 37 5.2 SAR measurement description 37 5.3 Reference lines and points for Handsets 38 5.4 Test positions relative to the Head 39 5.5 Test positions relative to the human body 40 5.6 Measurement Uncertainty 41 Page 4 of 112 Test Report No.: G0M-1406-3915-TFC093SR-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 6 TEST CONDITIONS AND RESULTS 42 6.1 Recipes for Tissue Simulating Liquids 42 6.2 Test Conditions and Results – Tissue Validation 43 6.3 Test Conditions and Results – System Validation 46 6.4 Test Conditions and Results – Standalone SAR Measurement 48 6.5 Test Conditions and Results – Multi -transmitter SAR Result 50 Calibration Documents 52 ANNEX A System Validation Reports 93 ANNEX B SAR Measurement Reports 103 Page 5 of 112 Test Report No.: G0M-1406-3915-TFC093SR-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1 Equipment (Test item) Description Description Field Controller Win EC7 Model CS20 CDMA Disto Additional Model(s) None Brand Name(s) Leica Geosystems Serial number None Hardware version V5.0 Software / Firmware version 1.0 FCC-ID RFD-CSNGC IC 3177A-CSNGC Equipment type End product Prototype or production unit Identical Prototype Device category Handset Environment General public Radio technologies GSM, UMTS, WLAN, Bluetooth Operating frequency ranges GSM 850: 824 MHz - 849 MHz PCS 1900: 1850 MHz - 1910 MHz CDMA 1xRTT BC 0: 824 MHz – 849 MHz CDMA 1xRTT BC 1: 1850 MHz – 1909 MHz CDMA 1xRTT BC 10: 817 MHz – 824 MHz CDMA EV-DO BC 0: 824 MHz – 849 MHz CDMA EV-DO BC 1: 1850 MHz – 1909 MHz CDMA EV-DO BC 10: 817 MHz – 824 MHz WLAN IEEE 802.11 b, g, n: 2400 MHz - 2483.5 MHz (20MHz) Bluetooth Low Energy: 2400 MHz – 2483.5 MHz Bluetooth: 2400 MHz - 2483.5 MHz Bluetooth LR: 2400 MHz - 2483.5 MHz Number of antennas 3 Antenna (WLAN/Bluetooth/Bluetooth Low Energy) Type integrated Model W3008C Manufacturer Pulse Gain 2.2dBi Antenna (GSM/UMTS/CDMA) Type integrated Model P522303 Manufacturer Ethertronics Gain 2.8dBi Antenna (Bluetooth LR) Type integrated Model 805684 Manufacturer Leica Geosystems Gain 1dBi Page 6 of 112 Test Report No.: G0M-1406-3915-TFC093SR-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Power supply V NOM 11.1 V DC AC/DC-Adaptor Model AEL40US15 Vendor XP Power Input 100 ...240 V AC Output 15 V DC Accessories None Manufacturer Leica Geosystems AG Heinrich Wild Strasse 9435Heerbrugg SWITZERLAND Page 7 of 112 Test Report No.: G0M-1406-3915-TFC093SR-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.3 Reference Documents Document KDB Publication 447498 : Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Polices KDB Publication 648474 : SAR Evaluation Considerations for Handsets with Multiple Transmitters and Antennas KDB Publication 648474 : Review and Approval Policies for SAR Evaluation of Handsets with Multiple Transmitters and Antennas KDB Publication 865664 : SAR measurement procedures for devices operating between 100 MHz to 6 GHz KDB Publication 941225: SAR Measurement Procedures for 3G Devices KDB Publication 941225: 3GPP R6 HSPA and R7 HSPA+ SAR Guidance KDB Publi…

Text truncated - open the document above for the full version.

Test Report No.: G0M-1406-3915-TFC247WF-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 148 FCC TEST REPORT FCC 47 CFR Part 15C Industry Canada RSS-210 Digital transmission systems operating within the 2400 – 2483.5 MHz band Report Reference No. ..................... : G0M-1406-3915-TFC247WF-V01 Testing Laboratory ......................... : Eurofins Product Service GmbH Address............................................. : Storkower Str. 38c 15526 Reichenwalde Germany Accreditation ..................................... : A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Filed Test Laboratory, Reg.-No.: 96970 IC OATS Filing assigned code: 3470A Applicant’s name ............................ : Leica Geosystems AG Address............................................. : Heinrich Wild Strasse 9435 Heerbrugg SWITZERLAND Test specification: Standard ........................................... : 47 CFR Part 15C KDB Publication No. 558074 D01 v03r02 RSS-210, Issue 8, 2010-12 RSS-Gen, Issue 4, 2014-11 ANSI C63.4:2009 Test scope.............. ........................ : complete Radio compliance test Equipment under test (EUT): Product description Field Controller Win EC7 Model No. CS20 CDMA Disto Additional Model(s) None Brand Name(s) Leica Geosystems Hardware version V5.0 Firmware / Software version 1.0 FCC-ID: RFD-CSNGC IC: 3177A-CSNGC Test result Passed Test Report No.: G0M-1406-3915-TFC247WF-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 148 Version History Version Issue Date Remarks Revised by 01 2015-04-21 Initial Release Test Report No.: G0M-1406-3915-TFC247WF-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 148 REPORT INDEX 1 EQUIPMENT (TEST ITEM) DESCRIPTION 5 1.1 Photos – Equipment External 6 1.2 Photos – Equipment internal 7 1.3 Photos – Test setup 9 1.4 Supporting Equipment Used During Testing 10 1.5 Test Modes 11 1.6 Test Equipment Used During Testing 12 1.7 Sample emission level calculation 14 2 RESULT SUMMARY 15 3 TEST CONDITIONS AND RESULTS 16 3.1 Test Conditions and Results – Occupied Bandwidth 16 3.2 Test Conditions and Results – 6 dB Bandwidth 26 3.3 Test Conditions and Results – Maximum peak conducted power 36 3.4 Test Conditions and Results – Power spectral density 38 3.5 Test Conditions and Results – AC power line conducted emissions 39 3.6 Test Conditions and Results – Band edge compliance 42 3.7 Test Conditions and Results – Conducted spurious emissions 49 3.8 Test Conditions and Results – Transmitter radiated emissions 60 3.9 Test Conditions and Results – Receiver radiated emissions 65 ANNEX A Transmitter radiated spurious emissions 67 ANNEX B Receiver radiated spurious emissions 139 Test Report No.: G0M-1406-3915-TFC247WF-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 148 1 Equipment (Test item) Description Description Field Controller Win EC7 Model CS20 CDMA Disto Additional Model(s) None Brand Name(s) Leica Geosystems Serial number None Hardware version V5.0 Software / Firmware version 1.0 FCC-ID RFD-CSNGC IC 3177A-CSNGC Equipment type End product Radio type Transceiver Radio technology IEEE 802.11 b/g/n Operating frequency range 2412 - 2462 MHz Assigned frequency band 2400 - 2483.5 MHz Main test frequencies F LOW 2412 MHz F MID 2437 MHz F HIGH 2462 MHz Spreading CCK, DSSS, OFDM Modulations BPSK, QPSK, 16-QAM, 64-QAM Number of channels 11 Channel spacing 5MHz Number of antennas 1 Antenna Type integrated Model W3008C Manufacturer Pulse Gain +2.2 dBi (manufacturer declaration) Manufacturer Leica Geosystems AG Heinrich Wild Strasse 9435 Heerbrugg SWITZERLAND Power supply V NOM 11.1 VDC AC/DC-Adaptor Model AEL40US15 Vendor XP Power Input 100 - 240 V AC Output 15 V DC Test Report No.: G0M-1406-3915-TFC247WF-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 10 of 148 1.4 Supporting Equipment Used During Testing Product Type* Device Manufacturer Model No. Comments None *Note: Use the following abbreviations: AE : Auxiliary/Associated Equipment, or SIM : Simulator (Not Subjected to Test) CABL : Connecting cables Test Report No.: G0M-1406-3915-TFC247WF-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 11 of 148 1.5 Test Modes Mode # Description DSSS General conditions: EUT powered by USB power supply. Radio conditions: Mode = standalone transmit Spreading = DSSS Modulation = BPSK Data rate = 1 Mbps Bandwidth = 20 MHz Duty cycle = 99 % Power level = 17dBm OFDM General conditions: EUT powered by USB power supply. Radio conditions: Mode = standalone transmit Spreading = OFDM Modulation = BPSK Data rate = 6 Mbps Bandwidth = 20 MHz Duty cycle = 99 % Power level = 17dBm HT20 General conditions: EUT powered by USB power supply. Radio conditions: Mode = standalone transmit Spreading = OFDM Modulation = BPSK Data rate = 7.2 Mbps Bandwidth = 20 MHz Duty cycle = 99 % Power level = 17dBm Receive General conditions: EUT powered by USB power supply. Radio conditions: Mode = standalone receive Spreading = DSSS / OFDM AC-Powerline General conditions: EUT powered by dedicated AC/DC-Adaptor Radio conditions: Mode = standalone transmit Spreading = DSSS Power level = Maximum Test Report No.: G0M-1406-3915-TFC247WF-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 12 of 148 1.6 Test Equipment Used During Testing Measurement Software Description Manufacturer Name Version EMC Test Software Dare Instruments Radimation 2014.1.15 Occupied Bandwidth Description Manufacturer Model Identifier Cal. Date Cal. Due Spectrum Analyzer R&S FSP 30 EF00312 2014-02 2015-02 6dB Bandwidth Description Manufacturer Model Identifier Cal. Date Cal. Due Spectrum Analyzer R&S FSP 30 EF00312 2014-02 2015-02 Maximum peak conducted power Description Manufacturer Model Identifier Cal. Date Cal. Due Spectrum Analyzer R&…

Text truncated - open the document above for the full version.

Test Report No.: G0M-1406-3915-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 88 FCC TEST REPORT FCC 47 CFR Part 15C Industry Canada RSS-210 Digital transmission systems operating within the 2400 – 2483.5 MHz band Report Reference No. ..................... : G0M-1406-3915-TFC247BL-V01 Testing Laboratory ......................... : Eurofins Product Service GmbH Address............................................. : Storkower Str. 38c 15526 Reichenwalde Germany Accreditation ..................................... : A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Filed Test Laboratory, Reg.-No.: 96970 IC OATS Filing assigned code: 3470A Applicant’s name ............................ : Leica Geosystems AG Address............................................. : Heinrich Wild Strasse 9435 Heerbrugg SWITZERLAND Test specification: Standard ........................................... : 47 CFR Part 15C KDB Publication No. 558074 RSS-210, Issue 8, 2010-12 RSS-Gen, Issue 4, 2014-11 ANSI C63.4:2009 Test scope.............. ........................ : complete Radio compliance test Equipment under test (EUT): Product description Field Controller Win EC7 Model No. CS20 CDMA Disto Additional Model(s) None Brand Name(s) Leica Geosystems Hardware version V5.0 Firmware / Software version 1.0 FCC-ID: RFD-CSNGC IC: 3177A-CSNGC Test result Passed Test Report No.: G0M-1406-3915-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 88 Version History Version Issue Date Remarks Revised by 01 2015-04-21 Initial Release Test Report No.: G0M-1406-3915-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 88 REPORT INDEX 1 EQUIPMENT (TEST ITEM) DESCRIPTION 5 1.1 Photos – Equipment External 6 1.2 Photos – Equipment internal 7 1.3 Photos – Test setup 9 1.4 Supporting Equipment Used During Testing 10 1.5 Test Modes 11 1.6 Test Equipment Used During Testing 12 1.7 Sample emission level calculation 14 2 RESULT SUMMARY 15 3 TEST CONDITIONS AND RESULTS 16 3.1 Test Conditions and Results – Occupied Bandwidth 16 3.2 Test Conditions and Results – 6 dB Bandwidth 20 3.3 Test Conditions and Results – Maximum peak conducted power 24 3.4 Test Conditions and Results – Power spectral density 25 3.5 Test Conditions and Results – AC power line conducted emissions 26 3.6 Test Conditions and Results – Band edge compliance 29 3.7 Test Conditions and Results – Conducted spurious emissions 32 3.8 Test Conditions and Results – Transmitter radiated emissions 36 3.9 Test Conditions and Results – Receiver radiated emissions 39 ANNEX A Transmitter radiated spurious emissions 41 ANNEX B Receiver radiated spurious emissions 81 Test Report No.: G0M-1406-3915-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 88 1 Equipment (Test item) Description Description Field Controller Win EC7 Model CS20 CDMA Disto Additional Model(s) None Brand Name(s) Leica Geosystems Serial number None Hardware version V5.0 Software / Firmware version 1.0 FCC-ID RFD-CSNGC IC 3177A-CSNGC Equipment type End product Radio type Transceiver Radio technology Bluetooth 4.0 Low Energy Operating frequency range 2402 - 2480 MHz Assigned frequency band 2400 - 2483.5 MHz Main test frequencies F LOW 2402 MHz F MID 2442 MHz F HIGH 2480 MHz Spreading Frequency Hopping Modulations GFSK Number of channels 40 Channel spacing 2MHz Number of antennas 1 Antenna Type integrated Model W3008C Manufacturer Pulse Gain 2.2 dBi (customer declaration) Manufacturer Leica Geosystems AG Heinrich Wild Strasse 9435 Heerbrugg SWITZERLAND Power supply V NOM 11.1 VDC AC/DC-Adaptor Model AEL40US15 Vendor XP Power Input 100 - 240 V AC Output 15 V DC Test Report No.: G0M-1406-3915-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 10 of 88 1.4 Supporting Equipment Used During Testing Product Type* Device Manufacturer Model No. Comments AE Laptop Lenovo T540p Test mode software *Note: Use the following abbreviations: AE : Auxiliary/Associated Equipment, or SIM : Simulator (Not Subjected to Test) CABL : Connecting cables Test Report No.: G0M-1406-3915-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 11 of 88 1.5 Test Modes Mode # Description Transmit General conditions: EUT powered by laboratory power supply. Radio conditions: Mode = standalone transmit Spreading = Hopping stopped (single hopping channel) Modulation = GFSK Data rate = 1 Mbps Bandwidth = 2 MHz Duty cycle = 100 % Power level = 15 (Test mode setting) Receive General conditions: EUT powered by laboratory power supply Radio conditions: Mode = standalone receive (scan mode) Spreading = On Modulation = GFSK AC-Powerline General conditions: EUT powered by dedicated AC/DC adaptor Radio conditions: Mode = Transmit Spreading = On Test Report No.: G0M-1406-3915-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 12 of 88 1.6 Test Equipment Used During Testing Measurement Software Description Manufacturer Name Version EMC Test Software Dare Instruments Radimation 2014.1.15 Occupied Bandwidth Description Manufacturer Model Identifier Cal. Date Cal. Due Spectrum Analyzer R&S FSP 30 EF00312 2014-02 2015-02 6dB Bandwidth Description Manufacturer Model Identifier Cal. Date Cal. Due Spectrum Analyzer R&S FSP 30 EF00312 2014-02 2015-02 Maximum peak conducted power Description Manufacturer Model Identifier Cal. Date Cal. Due Spectrum Analyzer R&S FSP 30 EF00312 2014-02 2015-02 Power spectral density Description Manufacturer Model Identifier Cal. Date Cal. Due Spectrum Analyzer R&S FSP 30 EF00312 2014-02 2015-02 Band edge compliance Description Manufacturer Model Identifier Cal. Date Cal. Due Spectrum Analyzer R&S FSP 30 EF00312 2014-02 2015-02 Conducted spurious emissions Description Manufacturer Model Identifie…

Text truncated - open the document above for the full version.

Test Report No.: G0M-1406-3915-TFC224CD-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 135 FCC TEST REPORT FCC 47 CFR Part 22H Industry Canada RSS-132, Issue 3 Cellular Telephones Operating in the Bands 824-849MHz and 869-894MHz FCC 47 CFR Part 24E Industry Canada RSS-133, Issue 6 2GHz Personal Communication Services FCC 47 CFR Part 90S Regulations governing licensing and use of frequencies in the 806-824 band Report Reference No. ..................... : G0M-1406-3915-TFC224CD-V01 Testing Laboratory ......................... : Eurofins Product Service GmbH Address ............................................. : Storkower Str. 38c 15526 Reichenwalde Germany Accreditation ..................................... : A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Filed Test Labor…

Text truncated - open the document above for the full version.
